Desisti SUPER LED F10 VW User manual

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
This Manual is applicable to the De Sisti F10 Vari-White !Revised on July 2018
ILT ITALY srl
Via Cancelliera, 10/a
00041 Albano Laziale (Rome) Italy
tel. [phone] fax [phone]
www.desisti.it
SUPER LED F10 VW Vari-White
120W Vari-White from 2.750 to 6.900 °K - Enhanced CRI > 94
White light, with Adjustable Correlated Colour Temperature
INSTRUCTION MANUAL
Manual Operated
Pole Operated
1.
INTRODUCTION
Congratulations on your purchase of a SUPER LED F10 Vari White lighting fixture.
The SUPER LED F10 VW is a compact, highly efficient Fresnel lens spotlight using a LED ARRAY combined
with the DE SISTI Patented optical system to optimize the photometric performances of LED ARRAYS when
utilized in combination with either Fresnels or Plano Convex lenses. The Lighting Fixture is DMX Controlled
and includes a number of parameters that can be set locally, it is equipped with power supply for AC universal
feed 90/240V 50/60Hz and feature variable CCT from Tungsten to Daylight with high power and high CRI. It
utilizes Standard accessories from the DE SISTI range of equivalent Fresnel Lens size, such as Barndoor, Colour
Frame, Cones, scrims.
MANUFACTURER!
REPRESENTATIVE!
ILT Italy S.r.l.
Via Cancelliera # 10a, 00041 Albano Laziale (Rome- Italy).
Tel. [phone] Fax. [phone]
www.desisti.itE-mail: [e-mail]
!

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
This Manual is applicable to the De Sisti F10 Vari-White !Revised on July 2018
ILT ITALY srl
Via Cancelliera, 10/a
00041 Albano Laziale (Rome) Italy
tel. [phone] fax [phone]
www.desisti.it
2.
YOKE AND ACCESSORIES ASSEMBLY
3.
POWER AND DMX DAISY CHAIN
The SUPER LED F10 VW permits both POWER and DMX DAISY CHAIN.
In fact each Fixture is respectively equipped with:
For DMX:
1 XLR5 pin Panel Mount Male (DMX IN)
1 XLR5 pin Panel Mount Female (DMX OUT)
For Mains Supply
1 20A Powercon NAC3MPA BLUE (POWER IN)1
1 20A Powercon NAC3MPB WHITE (POWER OUT)
It is recommended to Daisy Chain a Max of 10 fixtures, even if the limitations imposed by
DMX Standards are for an higher q.ty of units and even if the Powercon Connections are
rated for 20A max.
SUPER LED F10 (MANUAL OPERATED)
SUPER LED F10 (POLE OPERATED)

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
This Manual is applicable to the De Sisti F10 Vari-White !Revised on July 2018
ILT ITALY srl
Via Cancelliera, 10/a
00041 Albano Laziale (Rome) Italy
tel. [phone] fax [phone]
www.desisti.it
4.
CHARACTERISTICS AND PERFORMANCE DATA
DESCRIPTION
VALUE
DESCRIPTION
VALUE
LED Power
200 W
Protection Type
IP22
Power Consumption
220 W @ 230V (50-60 Hz)
Max Housing temperature
70° C
230 W @120V (50-60 Hz)
DMX Data Link
USITT DMX512-A
This product uses a 5-pin XLR for DMX
input and output. Use a shielded data
cables. Do not overload the daisy chain.
Up to a maximum of 32 devices can be
used on a single DMX chain.
Weight of Fixture
M.O.
P.O.
13,5 kg.
14,8 kg.
DMX Channels
Total 4 DMX Channels:
Dimmer / Light Intensity 16 BITù
Base : Dimmer Gross
Base +1: Dimmer Fine
Base +2: CCT Control
Base +3: CCT Control Mode
Weight of barndoor
4 leaf
8 leaf
1,4 kg.
1,65 kg
Protection class
Class 1– ground connection required
Size of scrims & color frame
Seat Diameter
Acc.ies Diameter
306 mm.
305 mm ( 12’’ )
Lens diameter
250 mm.
Size of barndoor ring
Seat Diameter
Ring Diameter
314 mm.
313 mm.
Specifications subject to change without notice.
5. SAFETY INSTRUCTIONS
Professional use: This luminaire has been designed for professional use and must be operated by qualified personnel only. Not for residential use.
Grounding: WARNING: THIS LUMINAIRE MUST BE GROUNDED
Electrical connections: IMPORTANT The cores in this mains lead are colored in accordance with the following code:
Europe
America
Ground
Green & yellow
Green or green & yellow
Neutral
Blue
White
Live
Brown
Black
In case the colors of the cores do not correspond to the colors of the connection points on your plug, please proceed as follows:
- the green or green and yellow core must be connected to the connection point marked with the letter E or with the symbol or colored in
green or in green - yellow;
- the blue (or white) core must be connected to the connection point marked with the letter N or colored in black;
- the brown (or black) core must be connected to the connection point marked with the letter L or colored in red.
!
!
!
!
!
!
!
WARNING:
Disconnect Power CORDS before
any maintenance work or opening the FUSE HOLDER.
RISK OF SERIOUS INJURY.

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
This Manual is applicable to the De Sisti F10 Vari-White !Revised on July 2018
ILT ITALY srl
Via Cancelliera, 10/a
00041 Albano Laziale (Rome) Italy
tel. [phone] fax [phone]
www.desisti.it
Working conditions
Working Position
Lighting fixture: max. tilting ±90° from horizontal
Ambient temperature, ta at the place of installation and storage
Minimum 10°C, maximum +40°C
Humidity at the place of installation and storage
25-80% (not condensing)
Minimum distances from inflammable surfaces
Top
Back
Sides
Front
0,2 m.
0,1 m.
0,1 m.
0,75 m.
The luminaire should never be OPERATED close to inflammable materials. The ones indicated in the above table are the minimum distances
recommended. Other requirements for safe use are:
A. Do not cover the apertures of the luminaire housing. They are essential for correct ventilation
B. Use only original accessories and spares from De Sisti Lighting.
C. Before hanging the luminaire ensure that the suspension point (or the stand) is properly rated to accept the luminaire weight.
D. In case of pole operated use, fit only a P.O. stirrup from De Sisti Lighting.
E. A suitable secondary safety suspension device (safety cable, chain or equivalent) must be fitted between the suspension point and the eyelet
at the front of the body
WARNING : DO NOT MOUNT THE LUMINAIRE ON A NORMALLY FLAMMABLE SURFACE.
6. INSTALLATION INSTRUCTIONS
The following procedure should be adopted:
Before connecting the luminaire to the electrical mains ensure that:
A. Earth line is present on the power socket.
B. The mains voltage is within the rated range of the luminaire (see technical data on the rating label)
C. The front safety shield is present and in good condition. It consists of a Fresnel lens made by borosilicate un-toughened glass, with a
Diameter = 150 mm , thickness = 5 mm type ( 3 min )
WARNINGS :
• Do not operate the product if the ambient temperature exceeds 40° C
• Provide a minimum clearance of 0,1m (4 in.) around fans and air vents.
• Shields, lenses safety or dichroic glasses shall be changed if they have become visibly damaged to such an extent that their effectiveness
is impaired, for example by cracks or deep scratches.
• The luminaire shall only be used complete with its protective shield
D. Applying power: never connect to dimmer power. Install a power plug on the power cable using the following pin assigment:
1 : Neutral
2 : Live Green/Yellow : Ground - This fixture must be connected to ground.
Make sure the local power voltage is within the range specified. If so; connect the power cable and turn the power on.
E. Stand Alone operation:
Using the navigation buttons and display readout ( refer to the “Local Menu” chapter )navigate to Manual and set the desired intensity (for
additional operations see “Local Menu” chapter)
F. DMX operation:
Connect DMX cable.
Navigate to Address mode (Addr) and set the desired address, (refer to the “Local Menu” chapter). Connect to DMX controller (refer to the “Channel
Setting” in the “Local Menu” chapter) and Use it.

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
This Manual is applicable to the De Sisti F10 Vari-White !Revised on July 2018
ILT ITALY srl
Via Cancelliera, 10/a
00041 Albano Laziale (Rome) Italy
tel. [phone] fax [phone]
www.desisti.it
7.
LOCAL MENU
The SUPER LED F10 VW has a GRAPHIC DISPLAY backlit, with two local knobs, each one having a push/click function in addition to the rotation:
KNOB 1
It is as a DEFAULT the CCT Variation Knob, By rotating it clockwise the CCT
Changes from 2.750°K up to 6.900 °K. If such a knob is kept pushed, it provides
a FAST ACTION on the KNOB 2 which is normally the DIMMING
Display It is a Graphic, backlit LCD Display. It contains all the relevant information for the product
setup and performances, such as CCT, DMX Address, DMX Level, LED Temperature and
local dimming. When the local knobs are not used for more than 5 seconds the display
back illumination will go OFF and the display itself will go in STAND BY Mode. It will go
ON again anytime a KNOB is activated.
KNOB 2 It is as a DEFAULT the DIMMING Variation Knob, By rotating it clockwise the Dimming of
the Light Changes from 0up to Full Light Output. If such a knob is pushed, it has the
selection or enter function to, for instance, enter into a Menu
DEFAULT SETTINGS ARE INDICATED IN BOLD LETTERS ON THE FOLLOWING TABLE:
The following are the BASIC FUNCTIONS and COMMANDS that are provided on the LOCAL MENU of the LED FRESNEL. The unit is provided with a USER
MENU accessible instantly on the product.
DMX ADDRESS
This Function is to SET the DMX address from 1 to 512
The Product is delivered with a default setting of the DMX address at 1.
As indicated next to each picture, it is required to reach the DMX
addr Menu, select the preferred base DMX Address and Select
it.
Once the DMX Address is SET, in order to return to the MAIN
MENU, it is necessary to rotate KNOB 2 counter-clock-wise to
return to the EXIT item and then select it by pressing KNOB 2
itself.
1st menu displayed
2nd menu displayed
Explanation of each menu function

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
This Manual is applicable to the De Sisti F10 Vari-White !Revised on July 2018
ILT ITALY srl
Via Cancelliera, 10/a
00041 Albano Laziale (Rome) Italy
tel. [phone] fax [phone]
www.desisti.it
LOCAL DIMMING CONTROL
This function is to LOCALLY DIM THE LED INTENSITY from 0 to 100% (Product is
delivered with default setting of the Dimmer at 0)
he right knob is doing the dimming action and it goes with a fine tuning in normal
condition, or a fast dimming when rotating KNOB 2 while keeping KNOB 1 pressed
in.
When the DISPLAY is in STAND BY Mode, please rotate KNOB 2
to act on the LIGHT INTENSITY Dimming…Clock Wise to
increase the level and Counter Clock Wise to decrease it. Fine
control:
For faster Dimming Control keep KNOB 1 pressed
and rotate KNOB 2:
1 full TURN of the KNOB 2 = 40% Dimming
Variation
LOCAL CORRELATED COLOR TEMPERATURE CONTROL
This function is to LOCALLY ADJUST the CORRELATED COLOR
TEMPERATURE from 2.750°K to 6.900°K (Product is delivered
with default setting of the CCT at 2750°K)
The rotation of KNOB 1 will determine CCT increments according
to the following table (STEP MODE)
If a continuous CCT Adjustment is required (LINEAR MODE) it is
necessary to operate through a DMX Console: please see DMX
parameters above
LOCAL OR REMOTE CONTROL SETTINGS
The LED Fresnel has the facility to block the LOCAL DIMMING and CCT SETTINGS and
maintain it when the POWER is turned off and than on again.
This allows for the LIGHT to be TUNED and FOCUSED locally and its dimming plus CCT
level can be blocked, so that for instance a system lighting a SET can be operated by a
remote switch or simple brakers by TURNING POWER ON.
The machine is set to Auto save OFF as default: in this condition the Fixture can be
controlled locally until a DMX device is connected to it. Once the Console will be acting it
will take priority over any local control.
To turn the Auto sve ON please follow these instructions:
- rotate KNOB 2 and select Auto save OFF
- press KNOB 2 to highlight the status of Auto save, in this case OFF
- rotate KNOB 2 to turn the status of Auto save to ON and press it
- leave the settings in this condition; the light will ignore any DMX Control. In this mode
any local dimming setting will be maintained and will be automatically recalled after power
off, when turnig the power on again.
CHANNEL SETTING (RESOLUTION & FUNCTION)
This function is to SET THE DIMMING RESOLUTION either at 8 bits or at 16 bits.
Select DMX resol by rotating and pushing KNOB2, the following choices are available:
- 8 bits resolution (the display will show 8 bit). The fixture utilizes 1 DMX Circuit for the
Light Dimming, which is the BASE CIRCUIT set in the ADDRESS.
- 16 bits: 16 bits resolution (the disply will show 16 bit and this is the default setting).
The fixture utilizes 2 DMX Circuits:
The Base Circuit set in the address is the Coarse Dimming, the second Circuit (Base +1)
is the Fine Dimming.
Of course the benefit of the 16 bits function the corresponding circuits on the DMX
Lighting Board shall also beset at 16 bits.
The DMX channels Base +2 and Base +3 are dedicated to the CCT Variation Control as
described previously.

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
This Manual is applicable to the De Sisti F10 Vari-White !Revised on July 2018
ILT ITALY srl
Via Cancelliera, 10/a
00041 Albano Laziale (Rome) Italy
tel. [phone] fax [phone]
www.desisti.it
INFORMATION PROVIDED ON THE DISPLAY
8.
DIMENSIONS
Dimensions: Black=mm. Red=inches
Dimensions: Black=mm. Red=inches
- Display of Correlated Colour Temperature
- Display of LED Case TEMPERATURE
- Display of DMX LEVEL
- DMX Address
- Display of local Potenciometer Level (when in local control or turned off DMX
controller)
- Graphic Scale of Dimming

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
This Manual is applicable to the De Sisti F10 Vari-White !Revised on July 2018
ILT ITALY srl
Via Cancelliera, 10/a
00041 Albano Laziale (Rome) Italy
tel. [phone] fax [phone]
www.desisti.it
9. PERIODIC INSPECTION & MAINTENANCE
This product requires very little routine maintenance, if any, but has special cleaning instructions:
Disconnect fixture from power and allow it to cool for 10 min.
1. Vacuum or gently blow away any dust from fan blades and grills
2. Very gently clean the LED with Isopropyl alcohol.
3. Clean the lenses with a soft damp cloth.
4. Check the condition of the safety shield (see chapter: Installation Instructions) before every use.
5. Check Power supply cable and DMX control cable proper conditions
10. SAFETY STANDARDS
Europe: The product conforms the Applicable European Directives & Standards
Low Voltage Directive: 73/23/EEC (as amended by 93/68/EEC)
EMC Directive: 89/336/EEC (as amended by 92/31/EEC & by 93/68/EEC)
Europen Standards:: EN 60598-2-17, EN 60598-1 , EN 55015 , EN 61547
Disposing of this product:
Help preserve the environment! Ensure that this product is recycled at the end of its life.
This product is in compliance with the RoHS and WEEE directives.
