Devine Artis Series User manual

Artis subwoofer series
Powered subwoofers (B12A, B15A, B18A)
User manual
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -

Introduction
Thank you for purchasing this Devine Artis active subwoofer. We advise that you read this user manual in its
entirety before unpacking the contents of the box, so that you are familiar with all of the functionality that this
product has to offer. Please be sure to check that all of the parts and accessories listed below under box
contents are included in the package. In the event that the product does not function properly, or if you have
any issues while operating it, please remove the plug from the power socket and contact your dealer for
assistance.
Box contents:
– Devine Artis active subwoofer (B12A, B15A or B18A)
– power cable IEC C13 to Schuko
Please ins ect the device and the included accessories.
Should you discover that either the device or any of the included parts have been damaged or rendered
defective while in transit, please contact your dealer directly.
Please note that the pictures in this user manual serve illustrative purposes only and may differ slightly from
the product you receive.
Contact:
Devine Pro Audio Products
Verrijn Stuartweg 18
4462 GE Goes
The Netherlands
Please do not send any products to this correspondence address.
Should you wish to send in a product for repair or for a refund, please contact your dealer for an RMA
Return Merchandise Authorisation).
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -

Safety instructions
Everyone involved with the installation, operation and maintenance of this device must:
- Be qualified
- Be skilled
- Have read the instructions in this user manual
- Be sure that neither the device nor the included accessories are damaged. Should the device or the
included accessories be damaged, please contact your dealer for more information.
- Ensure that the device is in good working condition and safe to operate. Please follow the advice and
instructions as they are described in this user manual.
Damage caused by misuse and/or modifications made to the device are not covered by the warranty.
This device does not contain any parts that need to be repaired or replaced by the user. Should maintenance
or repairs be necessary, they must be handled by a qualified technician.
Im ortant information regarding health and safety:
- Do not remove any labels or stickers from this device.
- Do not leave any cables lying around.
- The device should not be opened up, and any hardware or software that may be present should not be
modified.
- To achieve optimal performance, inputs on this device should not be fed with a signal higher than
necessary.
- The device should only be used indoors; contact with moisture, water and rain should always be avoided.
Do not place any objects containing liquids on top of the device.
- Remove the device from any nearby flames or heat sources; do not place it near flammable fluids, gasses
or objects.
- Disconnect this device from the power supply if it will not be used for a longer period of time, if maintenance
is necessary, or if the device needs to be cleaned.
- Do not pull on the cable to remove a connector, as this could cause damage.
- Do not use any cables other than the ones described in this manual. Do not use defective cables. Please
contact your dealer if the included or necessary cables do not function properly with this device.
- Only use this device with power from a grounded power source.
- In the event that the device is exposed to extreme temperature changes (e.g. transported through a cold
outdoor environment into a warm indoor environment), it should not be turned on until it has reached room
temperature. This is necessary to prevent moisture from forming in the device, which could lead to electric
shocks.
Guidelines and o eration of this device:
- This device is intended for indoor use by adults.
- This device is not suitable for use by children, and should always be operated by an adult.
- This device should only be used in a suitable environment where no damage to the device can occur. Do
not use the device in moist or dusty environments such as:
- indoor swimming pools where chlorine is used
- beaches where there is sand and salt
- outdoors
- indoors in spaces where intense heat sources are present, or where it reaches temperature levels
that would be considered uncomfortable for a person
- Avoid impacts and collisions during use and transport. Do not transport the device while it is in use. Avoid
using excessive force when installing and operating the device.
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -
WARNING!
Kee this device away from moisture, water and rain to avoid the chance of electric shocks.

- The user should become familiar with the functions of this device before using it.
- The user should be able to stop the devices s power supply in case of emergencies. At least one of the
following should therefore be accessible at all times:
- the power cable connector on the back of the unit
- the power socket the cable is plugged in to
- the power socket switch or extension cable switch
- Should the device not be used in the manner described in this user manual, damages or even injuries could
occur. Devine cannot be held responsible for any injuries or damages that occur as a result of improper use
of this product.
Storage and trans ort:
- This product is designed for mobile use. It can be transported separately as long as it’s well-protected
against shocks and collisions.
- This device is not designed for permanent (24/7) use. The expected lifespan of the device will not be
affected by occasionally turning the device off. Disconnect the device or turn off the power when it is not
actively in use.
- If the device will not be used for a longer period of time, it should be disconnected and stored in a dust-free
environment.
- Do not expose the device to extreme temperature differences.
Housing
- Inspect the device s housing frequently, and always just before use. Avoid operating the device if there are
large dents or cracks, or if screws are missing. Do not use the device if the housing is not in good condition.
Contact your dealer or a qualified technician if you are unsure about the state of the device.
- Check the device and the screws for corrosion. Corrosion must not be present on this device. Contact your
dealer or a qualified technician if you find any corrosion on the screws.
Every power and signal connector should be securely mounted. Do not use the device if the connectors are
not secure.
Avoid dust and dirt build-up. Clean the device once a month by disconnecting it from the power supply and
wiping it down with a dry or slightly moist cloth. If the device is used frequently, the cleaning intervals should
increase.
Symbol ex lanation:
WEEE: Ensure that this device is disposed of properly. This product falls under the WEEE
(Waste Electrical and Electronic Equipment) directive. The requirements of this directive apply
to all manufacturers and producers of electronic devices in the EU. Do not throw this product
away with regular rubbish. Please contact your local authority for more information about how
to recycle and dispose of these products in your region. By recycling this product in the proper
manner, we can work together to ensure that we can continue to enjoy these kinds of
products and still protect the environment as much as possible from pollution.
CE: The CE logo indicates that this product meets the European norms and requirements to
which it must legally conform.
Only suitable for indoor use: this product was only designed for indoor use. The maximum
environmental temperature must not exceed 40 degrees Celsius (104 degrees Fahrenheit).
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -

4 5 71
8
2 3 6 7 5
9
Guidelines and o eration of this device
Please note - the image shown is for reference only and may differ slightly from the actual layout of your
device.
1. phase switch (0 - 180 degrees)
2. high pass filter (high pass or flat)
3. LED indicators for limit, signal reception and power
4. volume control
5. 3-pin XLR line signal output (high pass or flat depending on position switch)
6. ground lift switch to disconnect ground signal from inputs and outputs
7. 3-pin XLR line signal input
8. IEC C14 power input with fuse holder
9. on/off switch
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -

O erating the device
The Artis subwoofers can be used for different purposes, but it s important to be aware of the following
information beforehand in order to achieve optimal performance.
Warning before use
Devine s Artis subwoofers are capable of producing volume levels that can cause temporary or permanent
hearing damage. Use these units with care and keep the volume at a reasonable level when possible. The
volume should ideally be set to a comfortable level when listening to music.
Devine cannot be held liable for any injuries or damage resulting from the use of this product.
General use
Housing
The Artis subwoofer has a housing made of wood with a black, textured coating designed to keep scratches
and light damage to a minimum during transport and use. In order to keep your subwoofer in optimal
condition for even longer, the use of a separately-available cover is recommended.
Handles
The Artis subwoofers are all equipped with metal handles which makes it easier to pick them up and
transport them. The handles must not be used for installation purposes.
Protection during trans ort
While the Artis subwoofers can be transported, they are not waterproof and caution is therefore advised if
they taken outside during rain or in adverse weather conditions. If they are exposed to moisture in any form,
ensure that they are completely dry again before use. Failure to do so may result in a short circuit which
could cause permanent damage or injury. Exposure to moisture can also cause visible or invisible corrosion
which may cause damage in the long term.
Grille
The Artis subwoofers are equipped with a metal grille on the front that protects the speaker components
behind. The grille should not be removed by the user. The acoustic foam behind the grille keeps the
components safe from moisture, dust and other small particles.
Pole mount
The subwoofer is equipped with a 35 mm pole mount so that a speaker can be mounted on top using a
speaker pole. Not only does this ensure optimal use of space and a tidy speaker system setup, but it also
helps the higher frequencies reach a wider audience by dispersing them over a wider area and, because the
subwoofer is on the floor, the lower frequencies are better represented too.
When placing the subwoofer, make sure that it s not in the way, that it doesn t block any routes and that it
can t be knocked over.
The pole mount has a maximum capacity of 30 kg which is more than sufficient for most (active) full-range
speakers up to and including 15 inches.
Audio technology
The Artis active subwoofers feature the very latest in audio technology. By adhering to the following tips and
instructions, you can make the most of everything this speaker has to offer for the very best audio and
performance quality possible.
Built-in crossover
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -

The Artis active subwoofers are equipped with a built-in crossover that ensures the incoming signal is filtered
so that the subwoofer only receives the low frequencies.
The line signal outputs can be switched between flat and HPF . When flat is selected, the full input signal is
sent to the line outputs and when HPF is selected, everything, apart from the low frequencies, is sent to the
line outputs. HPF should normally be selected when a satellite speaker is used together with the subwoofer
as this relieves the speaker of the low frequencies leaving more power for the mid and high tones for better
overall performance.
Ground lift function
The active Artis subwoofers have a ground lift function. When various pieces of connected audio equipment
are plugged into different power groups and/or several types of equipment work together on one power
group, ground loops can occur. These result in an audible hum that negatively influences sound quality. With
the help of the ground lift function, the link between the input and output signals is interrupted so that
separate circuits are created that no longer influence each other. This can solve many problems with hum
and noise.
How to adjust the s eaker volume
The Artis active subwoofers offer good audio amplification at an affordable price. The built-in components are
designed to work together in order to produce good audio quality through normal use.
If you notice that the speaker sounds different than normal (distortion or crackling) and/or the Clip LED on
the rear lights up, then reduce the volume level immediately. Continuously overloading the speaker can lead
to permanent damage. Make sure your sound system is set up so that the connected audio source cannot
transmit a heavily overloaded signal. DJ devices such as mixers or controllers are capable of this.
Set the audio source to transmit a signal of +3 to +6 dB (with music) and adjust the speaker volume so that
the Clip LED does not light up. If your equipment does not have an indicator for this, set it to the maximum
volume (making sure the signal is not distorted) and turn the speaker volume up gradually ensuring the
signal remains under the Clip level.
As long as the source device continues to transmit at 0 dB (the most ideal level for optimal volume), you can
not overload the speaker, not even with an accidental peak of +3 or +6 dB.
If you are not at the controls of your speaker system, it s recommended to use a limiter that penalises heavy
overloading by reducing the volume considerably. This results is a lower volume level and an inferior sound,
but this solution is much better than allowing the speaker to overload, which can cause damage to the
speaker components.
LED indicators
The blue LED on the speaker will light up whenever the speaker is connected to an active power source and
turned on.
A green LED indicates if the speaker is receiving an audio signal.
The red LED on the speaker is an indicator for the clip limiter and will light up whenever the amplifier module
is overloaded by an input signal that is too loud . In this case, appropriate adjustments should be made until
the clip LED indicator no longer lights up.
Continually overloading the amplifier module and causing the clip LED to light up is likely to cause
permanent damage to both the amplifier module and the speaker components and shorten their lifespan
considerably. Damage caused by negligent use is not covered by the warranty.
Using external equi ment
It s possible to use the Artis subwoofers with external equipment like crossovers, equalisers and speaker
management systems. Bear in mind that using external equipment may change the character of the
speaker s sound.
Also bear in mind that the subwoofer s built-in crossover is always active. It s only the line outputs that can be
switched between flat and HPF .
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -

Using in combination with satellite s eakers
The Artis subwoofers can be used in combination with Artis full-range speakers or other speakers. Normally,
the speakers chosen will be smaller in size than the subwoofer. You might use 8 or 10-inch speakers with a
12-inch subwoofer, for instance, or 12 or 15-inch speakers with an 18-inch subwoofer. Ideally, your source
signal (DJ mixer, PA mixer, smartphone, laptop etc.) should be connected to the subwoofer first and then to
other speakers. That way, the subwoofer can handle the low frequencies and, via the output, pass on only
the mid and high frequencies to the other speakers. The crossover switch should be set to HPF for this.
The signal from your speakers can be passed on to additional speakers should you wish to use more than
one in conjunction with a subwoofer.
If you intend to use multiple subwoofers and speakers, the signal will normally be split into left and right
sides. In this case, the signal should still be connected to the subwoofer first. When linking multiple
subwoofers together, make sure flat mode is selected. Only the last subwoofer in the chain should have
HPF mode selected as this sub will pass the signal on to your other speakers.
Using additional equipment like a speaker processing system gives you additional possibilities when it comes
to tweaking the sound and making adjustments that are appropriate for your situation.
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -

S eaker troubleshooting guide
If you have a problem with your subwoofer, please consult this troubleshooting section for possible solutions.
If, after consulting this section, the problem remains unresolved, please contact your dealer for more
information and/or help.
This troubleshooting section contains information on how to solve the most common subwoofer problems,
but it does not and cannot cover every eventuality. It is possible that you won t find your problem, cause and
solution in this section because product details may differ.
Problem Possible cause Solution
Speaker does not turn on with
mains power
Defective fuse Check the fuse, which is located
under the power input, to rule out
of it s blown or not. If it is blown,
replace it with a new fuse of the
same type and class.
Problem with the power cable Check that the power cable is
plugged into an active power
socket and the speaker properly.
Try using another cable of the
same type to determine if there s a
problem with the power cable and
if there is, replace the problem
cable.
Speaker doesn t turn on Check if the power switch on the
back of the speaker is set to the
on position.
Power LED doesn t light up If the speaker is connected to an
active power socket, the fuse has
been checked and the power
switch is ON but the power LED is
not lighting up, there may be a
problem with speaker itself. In this
case, the speaker should be
turned off again and you should
contact your dealer for assistance.
No sound via one of the inputs Cable not connected properly Make sure the cable between your
sound source and the speaker is
connected properly.
Switch in wrong position If present on the input channel, set
the signal switch to the correct
position for the connected device.
Microphone is not on Make sure the microphone switch,
if present, is switched on.
No sound from the master output Volume control is not turned up Turn up the master control volume
to a sufficient level.
Red Clip Limiter LED lights up
often or continually
Volume is too high Decrease the volume level on the
speaker or the connected audio
source device. Continuous
exposure to overloading can cause
permanent damage.
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -

Distorted, clipping or crackling
sound
Connected device is transferring a
distorted signal
Check if any of the connected
source devices are transferring a
distorted signal and turn down the
volume on the offending device if
necessary.
Volume control is too loud Turn the volume down
The tone controls for treble and/or
bass are too high or too low.
Turn the tone controls back to 12
o clock and listen to hear if clipping
is still audible.
Woofer or tweeter is defective If a speaker is exposed to a loud,
distorted, or clipped signal for a
longer period of time, this can
cause permanent damage to its
internal components. If you
suspect that the woofer or tweeter
is damaged, contact your local
dealer for assistance.
Sound is dull Tweeter is defective Turn the speaker to an appropriate
volume (ensure that it s not too
loud) so that you can listen directly
to the tweeter with it close to your
ear. If the tweeter is not
responding it is probably defective
and you should contact your
dealer for assistance.
Incorrect EQ settings Make sure one of the EQ controls
has not been set extremely high or
extremely low and set it to a
neutral position if possible.
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -

S ecifications
General s ecifications for all models:
- powerful 12, 15 or 18-inch subwoofers
- built-in amplifier module for amplification
- robust wooden construction, equipped with hard, textured coating
- metal handles for easy transport
- metal grille, acoustic foam on the inside
- passive cooling, no fans
- 35 mm pole mount for speaker pole and satellite speaker
- pole mount adapter max. load: 30 kg
- phase switch: 0 or 180 degrees
- HPF crossover switch - flat or HPF option for line outputs
- volume control
- ground lift switch
- IEC C14 power input with fuse holder
- equipped with on/off switch
- mains voltage: 220 - 240V, 50 Hz
- fuse: 20 mm glass, 250V, 5A
Technical s ecifications er model:
Model Artis B12A Artis B15A Artis B18A
Frequency range 20 Hz - 120 Hz
Voice coil diameter 3 in 4 in
Magnet 60 oz 100 oz
Woofer diameter 12 in 15 in 18 in
Maximum SPL (dB peak) 127 dB 129 dB 131 dB
Impedance 4 ohms 4 ohms 4 ohms
RMS power 300 W 500 W 500 W
nominal maximum power consumption 450 W 750 W 750 W
weight: 18 kg 24 kg 34 kg
dimensions: 440 x 425 x 370 mm 457 x 508 x 432 mm 500 x 950 x 600 mm
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:15-07-2019 RV Revision date and author's initials: -
