INSTRUCTION MANUAL
2797/20
PORTABLE PROPANE (G31) AND BUTANE/PROPANE MIXTURE (G30 + G31) HEATER FOR
RECREATIONAL, COMMERCIAL AND EMERGENCY INDOOR USE DXRH012E
LANGUAGES INCLUDED: ENGLISH, GERMAN, FRENCH, ITALIAN
WARNING: READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe place for future reference. Do not
allow anyone who has not read these instructions to assemble, adjust or operate the heater.
EN 449:2002+A1:2007
EN 521:2006
TP 6.39
EN 60335-1:2012+A13:2017
EN 60335-2-102:2006+A2:2016

English
2
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
CONTENTS
WARNINGS 2
HEATER SPECIFICATIONS 3
Odour FADE WARNINGS 4
SAFETY PRECAUTIONS 5
LIGHTING AND OPERATION 6
MAINTENANCE AND STORAGE 7
BATTERY CHARGER PRECAUTIONS 9
BATTERY CHARGER INSTRUCTIONS 11
EXPLODED VIEW 15
PARTS LIST 16
WARNING:
Early signs of carbon monoxide poisoning resemble the u, with headache,
dizziness and/or nausea. If you have these signs, heater may not be working
properly. Get fresh air at once! Have heater serviced.
Caution:
• Some carpets or linoleum surfaces may discolor if heater is placed directly
on these oor coverings.
• When operating the heater at altitudes over 2.13 km above sea level the
heater may shut off. (Please read the GENERAL INFORMATION)
WARNING:
- Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
- A Propane (G31) or Butane/Propane mixture (G30+G31)
cartridge not connected for use shall not be stored in the
vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light appliance.
• Extinguish any open flame.
• Shut off gas to appliance.
- Service must be performed by a qualified service agency.
This is an unvented gas-red portable heater. It uses air (oxygen) from the
area in which it is used. Adequate combustion and ventilation air must be
provided. Refer to page 5.
WARNING:
Every time a cartridge is connected to unit, connection must be checked
for leaks in one or more ways: Apply soapy water to connection, look for
bubbles, listen for hiss of escaping gas, feel for extreme cold, smell for rotten
egg odour. If there is a leak on your appliance (smell of gas), take it outside
immediately into a well ventilated ame free location where the leak may be
detected and stopped. If you wish to check for leaks on your appliance, do
it outside. Do not try to detect leaks using a ame, use soapy water. Any
changes to this heater or its controls can be dangerous. DO NOT modify
appliance.
WARNING:If the recreational or commercial enclosure
does not have a window or roof vent, DO NOT USE THIS HEATER
INSIDE. Use only in a well ventilated area.
WARNING: This appliance shall only be used with Vapor Pressure
Propane 100%(G31) and Propane Butane Mixture 70/30 (G30+G31) fuels It
may be hazardous to attempt to t other types of gas cartridges.

3
English
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Specications
MODEL NO.: .................................................................................... DXRH012E
GAS TYPE:.......................................Propane (G31) Gas shall only be used with
Coleman and Primus Power Gas 70/30 Butane/ Propane (G30+G31)
INPUT (kW):.............................................................................2.2 kW (158 G/H)
2.8kW (200 G/H)
INJECTION SIZE...................................................................................1.01 mm
WARNING: CERTIFIED FOR USE WITH PROPANE ONLY
WARNING: CERTIFIED FOR USE WITH DEWALT RECHARGEABLE BATTERY
PACKS. REFER TO LIST BELOW A LIST OF APPROVED BATTERIES.
DEWALT 18V MAX batteries
•1.3 Ah
•1.5 Ah
•2.0Ah
BATTERIES AND CHARGER ARE NOT INCLUDED.
Electronic Features (requires battery)
•400 Lumens Light embedded in adjustable handle
•135 CFM Fan
•3 USB Power Outlets (5 Volts DC current, 2 Amps)
From outlet..........................................................................................60.96 cm
From top ...............................................................................................76.2 cm
From Sides..........................................................................................15.24 cm
From Rear ..................................................................................................0 cm
Minimum Clearances from normal combustible material
General Information
The DXRH012E is safe for indoor use in small recreational enclosures having means
for providing combustion air and ventilation, such as enclosed porches, cabins, shing
huts, trailers, tent trailers, tents, truck caps and vans. It may be used for emergency
indoor heating when connected disposable 465g propane (G31) OR 450g Butane/
Propane mixture (G30+G31) cartridge and for indoor use in commercial enclosures,
provided that there is sufcient air for combustion and ventilation (specied in OPERATING
PRECAUTIONS page 5).
NOTE: This heater can be used outdoors, but may experience nuisance shutoffs in certain
wind conditions.
• A DEWALT battery is necessary only for Fan, USB Power Outlets, and Light operation.
• A Propane gas supply is necessary only for Heating operation.
• When the heater is cold or at room temperature, it will take a few minutes for the burner
tile to turn bright orange. This is normal and the heater is working properly. If burner tile
is visibly aming, turn heater off and call a qualied service technician.
• When the unit is lit, there should be about a quarter inch (.635 cm) border around the
tile that will not turn bright orange. This is normal.
• When operating the heater for the rst time, the top area of the reector may discolor.
This is also normal and is no reason for concern.
• The protective grill on the front of this heater is coated with a special high-temperature
resistant paint. When the heater is used for the rst time, the grill may give off noticeable
smoke or fumes. This is normal and will not occur during subsequent uses. The fumes
are not harmful.
• When operating the heater at altitudes over 2.13km above sea level, the unit may not
burn as bright as in lower altitudes. This is normal. At higher altitudes the heater may
shut off. If this happens provide fresh air, wait 5 minutes, and then re-light. Due to local
atmospheric conditions heater may not re-light.
• When moving heater when lit or bumping heater setting it down, the tip over switch may
shut off heater. If this happens, relight.
• Due to natural operation of small cartridges, condensation may build up on cartridge
and drip on surface under heater. Sometimes this condensation may freeze due to the
extreme cold caused when propane (G31) vaporizes. This is normal and no reason for
alarm.
• Operating time will vary depending on the heater setting and the supply cartridge size.
Up to 1.5 to 3.5 hours on a 450G 70/30 Butane/Propane mixture (G30+G31) cartridge.
Due to the properties of Propane gas (G31), run times can be signicantly reduced
when operating continuously at temperatures below -6.6 C.
WARNING: If the information in this manual is not followed
exactly, a re or explosion may result causing injury or loss of life.

English
4
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
WARNING
Asphyxiation Hazard
•Do not use in unventilated areas
•The ow of combustion and ventilation air must not be obstructed
•Proper ventilation air must be provided to support the combustion air
requirements of the heater being used.
•Refer to the specication section of the heater’s manual, heater
dataplate, or contact the factory to determine combustion air ventilation
requirements of the heater.
•Lack of proper ventilation air will lead to improper combustion
•Improper combustion can lead to carbon monoxide poisoning leading
to serious injury or death. Symptoms of carbon monoxide poisoning can
include headaches, dizziness and difculty in breathing.
Fuel Gas Odour
Propane gas(G31) and butane/propane mixture (G30+G31) gases have man-made
odourants added specically for detection of fuel gas leaks. If a gas leak occurs
you should be able to smell the fuel gas. Since Propane (G31) is heavier than air
you should smell for the gas odour low to the oor. ANY GAS Odour IS YOUR
SIGNAL TO GO INTO IMMEDIATE ACTION!
• Do not take any action that could ignite the fuel gas.
• Do not operate any electrical switches.
• Do not pull any power supply or extension cords.
• Do not light matches or any other source of ame.
• Do not use your telephone.
• Get everyone out of the building and away from the area immediately. Close all propane
gas (G31) tank or cylinder fuel supply valves, or the main fuel supply valve located at the
meter if you use natural gas.
• Propane gas (G31) is heavier than air and may settle in low areas. When you have
reason to suspect a propane leak, keep out of all low areas.
• Use a telephone remote from the area of the leak and call your fuel gas supplier and
your re department. Do not re-enter the building or area.
• Stay out of the building and away from the area until declared safe by the reghters
and your fuel gas supplier.
• FINALLY, let the fuel gas service person and the reghters check for escaped gas.
Have them air out the building and area before you return. Properly trained service
people must repair any leaks, check for further leakages, and then relight the appliance
for you.
Odour Fading - No Odour Detected
• Some people cannot smell well. Some people cannot smell the odour of the man-
made chemical added to propane gas (G31). You must determine if you can smell the
odourant in these fuel gases.
• Learn to recognize the odour of propane gas (G31).
• Smoking can decrease your ability to smell. Being around an odour for a period of time
can affect your sensitivity to that particular odour. Odours present in animal connement
buildings can mask fuel gas odour.
• The odourant in propane gas (G31) is colorless and the intensity of its odour
can fade under some circumstances. If there is an underground leak, the movement
of gas through the soil can lter the odourant.
• Propane gas (G31) odour may differ in intensity at different levels. Since Propane gas
(G31) is heavier than air, there may be more odour at lower levels.
• Always be sensitive to the slightest gas odour. If you continue to detect any gas
odour, no matter how small, treat it as a serious leak. Immediately go into action as
discussed previously.
ATTENTION - Critical Points to Remember!
• Propane gas (G31) or Butane/Propane mixture (G30+G31) has a distinctive odour.
Learn to recognize these odours. (Reference Fuel Gas Odour and Odour Fading
sections on this same page)
• Even if you are not properly trained in the service and repair of the heater, ALWAYS be
consciously aware of the odours of propane gas(G31) and natural gas.
• If you have not been properly trained in repair and service of propane gas(G31) or
Butane/Propane mixture(G30+G31) then do not attempt to light heater, perform service
or repairs, or make any adjustments to the heater on the propane (G31) or Butane/
Propane mixture(G30+G31) gas fuel system.
• A periodic sniff test around the heater or at the heater’s joints; i.e. hose, connections,
etc., is a good safety practice under any conditions. If you smell even a small amount of
gas, CONTACT YOUR FUEL GAS SUPPLIER IMMEDIATELY. DO NOT WAIT!

5
English
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
THIS IS A HEATING APPLIANCE. DO NOT OPERATE THIS APPLIANCE WITHOUT
THE FRONT WIRE GUARD INSTALLED. DO NOT ATTEMPT TO WARM OR COOK
FOOD ON THIS HEATER.
1. REGULATOR IN HEATER MUST ALWAYS BE IN PLACE DURING OPERATION.
2. Due to high temperatures, the appliance should be located out of trafc and away
from combustible materials. (See Specications on page 3.)
3. CAUTION: Accessible parts may become very hot. Keep young children away from
the appliance Children and adults should be alerted to the hazard of high surface
temperatures and should stay away to avoid burns or clothing ignition.
4. Young children should be carefully supervised when they are near the appliance.
5. Do not place clothing or other ammable material on or near the appliance.
6. If the wire guard is removed for servicing, it must be replaced prior to operating the
heater.
7. Do not use non-approved attachments on this heater. Do not modify appliance.
8. The appliance should be inspected before each use. Frequent cleaning may be
required. The control compartments, burner and circulating air passageways of the
appliance must be kept clean. (See MAINTENANCE on page 7.)
9. Do not use this heater is any part has been under water. Immediately call a qualied
service technician to inspect the heater and to replace any part of the control system
and any gas control which has been under water.
10. This heater can only be used in a recreational or commercial enclosure with a window
or roof vent. It may also be used outdoors.
11. This heater requires a well ventilated location of 77 cm2 (example 7.62 cm x 10.16 cm
opening) minimum for adequate ventilation during operation which is in accordance
with national requirements for the supply of combustion air. Do not use other fuel
burning appliances inside.
12. GAS PRESSURE AT HEATER IS REGULATED AND FIXED AT 2.74 kPa. IN ANY
CASE DO NOT REGULATE OR REDUCE PROPANE(G31) OR BUTANE/PROPANE
MIXTURE(G30+G31) CARTRIDGE SUPPLY PRESSURE TO HEATER!
13. When used without adequate combustion and ventilation air, this heater may give off
excessive CARBON MONOXIDE, an odourless, poisonous gas.
14. Some people - pregnant women, persons with heart or lung disease, anemia, those
under the inuence of alcohol, those at high altitudes - are more affected by carbon
monoxide than others.
15. Do not operate heater in any moving vehicle such as leisure vehicles like caravans and
auto caravans. Do not use in high rise ats, basements, bathrooms or bedrooms.
General Safety Instructions 16. When heater is placed on the ground, make sure the ground is level and keep
any objects at least 60.96 cm from the front of the heater. DO NOT MOVE THE
APPLIANCE WHEN OPERATING, SHOCKS AND BUMPS MAY ACTIVATE THE
SAFETY TIP OVER DEVICE. DO NOT LEAVE HEATER UNATTENDED OR WHERE
CHILDREN MAY CAUSE THE HEATER TO TIP OVER. NEVER OPERATE THE HEATER
WHILE SLEEPING!
Preparation for Operation
WARNING: Always inspect propane cylinder and heater propane connections for
damage, dirt, and debris before attaching propane cylinder. Do not use if head of cylinder
is damaged, punctured or deteriorated.
ALWAYS ATTACH OR DETACH CYLINDER OUTDOORS AWAY FROM FLAMES, OTHER
IGNITION SOURCES, AND ONLY WHEN HEATER IS COOL TO TOUCH. NEVER SMOKE
WHEN ATTACHING OR REMOVING PROPANE CYLINDER OR MAKING REMOTE
CONNECTIONS!
• Propane cylinder(s) must be disconnected from heater when not in use.
Pulse Ignition
The Pulse Ignition Button is located at the bottom of the USB Compartment (Figure 4,
page 6). Unscrew the button cap to install the “AAA” battery (included), with positive
end toward the button.

English
6
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Lighting/Operating Instructions
USE WITH DISPOSABLE 465G PROPANE OR 450G 70/30 BUTANE
PROPANE MIXTURE(G30+G31) CARTRIDGES: START
•Use only 465g disposable propane (G31) cartridges that mate with No.
600 valve connection or butane/propane (70/30) (G30+G31) mixtures with
thread type 7/16-28 EN417.
•Heater and attached cylinder must be in an upright position during
operation.
•Check that seals (between the appliance and the gas cartridge ) are in
place and in good condition before connecting to the gas cartridge. Refer
to Figure 3. Do not use an appliance which has damaged or worn seals. Do
not use an appliance which is leaking, damaged or which does not operate
properly.
•Make sure the four-position Control Knob is in “OFF” position. See Figure 1.
•To use with propane: Swivel regulator outward for easy cartridge
installation. Screw 465g disposable Propane-gas (G31) supply cartridge
clockwise (from bottom) into portable heater until hand-tight. See Figure 2.
DO NOT use thread sealant on this connection.
•To use with Butane/Propane mixture (G30+G31): Screw brass adapter
clockwise into portable heater regulator (from bottom) until tight. See Figure
3. Do not use thread sealant on this connection. Screw 450g butane
propane mixture cartridge into the adapter (clockwise), once the shaft on
the adapter starts to turn, the cartridge is connected.
•Check adapter and cartridge connection for leaks with soapy water at the
threaded connection under the domed plastic cover where the cylinder
screws into the regulator. SEE WARNING! ON DOMED PLASTIC COVER.
•Turn control knob counterclockwise to “PILOT” position and depress.
While holding knob down, depress the pulse ignition button located in the
USB Compartment, see Figure 4 and 5. The pilot should remain lit.
•After pilot lights, hold down for 30-60 seconds and then release knob. Knob
should return to fully extended position, see Figure 6. To operate heater,
slightly depress knob and gently turn to lock in the “HI” position to light
burner tile. Leave on “HI” position until burner tile turns bright orange.
•If heater does not light, hold knob down for approximately 30 seconds;
release and depress again. Repeat until pilot lights.
•After burner tile has turned bright orange, adjust heat output by turning
control knob to desired position (“LO” or “HI” setting).
HI
LO
PILOT
OFF
Figure 1: Control Knob
Figure 2: Attach Fuel
Cartridge
WARNING: DO NOT OPERATE HEATER
UNLESS CONTROL KNOB IS LOCKED IN A
POSITION MARKED “HI”, “LO” OR “PILOT”.
NEVER SET CONTROL KNOB BETWEEN LOCKED
POSITIONS. POOR COMBUSTION AND HIGHER
LEVELS OF CARBON MONOXIDE MAY RESULT.
USE WITH DISPOSABLE 465g PROPANE
CYLINDER(S): STOP
• To shut off heater, slightly push down and turn
control knob clockwise to “OFF” position
• CAUTION: After turning heater off, wire guard
will remain hot. Allow to thoroughly cool before
storing.
• Check that burners are extinguished before
disconnecting the gas cartridge.
• TO REMOVE PROPANE (G31) CARTRIDGE:
Remove cartridge from stand and turn cartridge
counterclockwise until it is fully unscrewed off of
heater.
• TO REMOVE BUTANE/PROPANE MIXTURE
(G30+G31) CARTRIDGE: Remove cartridge from
stand and turn cartridge counterclockwise until it
is fully unscrewed off of adapter.
• Once Cartridge is removed then the
Butane adapter can be unscrewed turning
counterclockwise until it is fully unscrewed off of
the heater.
• Do not operate, store or remove cartridge near
ammable items or ignition sources. Only change
cartridges in a well ventilated location, preferably
outside, away from any sources of ignition such
as naked ames, pilots, electric res and away
from other people.
• Propane-GAS (G31) or Butane/Propane
mixture (G30+G31) cartridges MUST BE
DISCONNECTED FROM HEATER WHEN NOT
IN USE! Make sure to check the seals before
connecting a new gas cartridge to the appliance.
Figure 5: Depressed
Control Knob
Figure 6: Released
Control Knob
USB Power Outlets
Pulse Igniter
Figure 4: USB Compartment
Adapter
shaft
Seals
Figure 3: Butane Adapter

7
English
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Status Light Diagnostics: Steady On/Off Blinking
If the Status Light is blinking on and off steadily this is an indication that the DEWALT battery
is low on charge. See Battery Charging Precautions and Instructions, starting on page 9.
The battery must be removed from the heater in order to charge.
Status Light Diagnostics: Double Flash
(2 Blinks, 1 Pause)
If the Status Light is “Double Flashing” (repetition of 2 rapid blinks followed by a pause) this
is an indication that the battery is outside of its operating temperature range.
Maintenance
Always keep the heater area clear and free from combustible materials, gasoline and other
ammable vapors and liquids.
Keep the vent areas (slots in the bottoms and the top at the front and rear of heater) clear
at all times.
Visually inspect the pilot ame and burner periodically during use. The pilot ame should be
blue in color (not yellow) and will extend beyond the thermocouple. The ame will surround
the thermocouple just below the tip, see Figure 8.
A slight yellow ame may occur where the pilot ame and main burner ame meet. The
burner should be bright orange (with a slight blue color around the border, a red-orange
haze that is visible on the ceramic tile is acceptable) and without a noticeable ame. A blue
ame that rolls out at the top of the ceramic tile indicates an accumulation of dust, lint or
spider webs inside the casing assembly and main burner assembly. If the pilot is yellow or
the burner has a noticeable ame, cleaning may be required. Use the following procedure
to inspect the casing assembly and main burner assembly. It is necessary to periodically
check the burner orice and burner venturi tube to make sure they are clear of insects/
nests or spider webs that may accumulate over time. A clogged tube can lead to a re.
Electronic Operation
When a charged DEWALT battery is inserted into the battery
dock, Figure 7, the heater may activate the following electronic
features. The battery inserts into the battery dock upright, with
contacts facing the roof of the dock. These Electronic features
may be used individually or simultaneously. When any of them are
in use the status light, Figure 8, will illuminate with a steady green
glow to visually signal that an electronic feature is active. If the
status light is blinking see the diagnostics section below.
Lights
Toggling the Light control button on the back of the heater
activates/deactivates the lights in the handle bar. The Lights
operate with any orientation of the heater and handle.
Fan
Toggling the Fan control button on the back of the heater
activates/deactivates the fan. Using the fan while the heater is
active enhances the heaters convective heating ability. Using the
fan while the heater is inactive will make the heater into a fan,
meaning that you may enjoy the DXRH012E no matter the season!
USB Power Outlets
Inside the USB Compartment which houses the pulse igniter are
also 3 USB Power Outlets, a power button, and a status light.
Toggling the power button will activate/deactivate the USB Power
Outlets with 5 Volts of DC current at 2 amps rating, signaled by
illumination of the status light. The USB Power Outlets facilitate
the charging or powering of up to three USB devices. NOTICE:
The USB power should be shut off when not in use. Failure to do
so may cause battery to drain.
Figure 8:
Electronic Status LED,
USB Power Button,
USB Power Outlets
STATUS LIGHT
USB
Power
Outlets
USB
Power
Button
Figure 7:
Back Controls
LIGHTS
BATTERY DOCK
FAN

English
8
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
MAINTENANCE CLEANING AND INSPECTION PROCEDURE
1. Allow heater to thoroughly cool before performing any maintenance.
2. Remove disposable 465g cylinder from heater or turn OFF gas supply at remote cylinder
valve, and disconnect hose from heater.
3. Remove (4) four screws that secure the rear cover to the Heater.
4. Pivot cover outward from bottom. Release from 2 top clips. Set aside.
5. Remove (4) four burner retaining screws and fuel line from burner assembly.
6. Remove burner assembly from back of housing.
7. Inspect interior of housing for accumulation of dust, insect or spider webs. If necessary,
clean interior housing with a vacuum cleaner or apply air pressure. Do not damage any
components within the housing assembly
when you are cleaning.
8. Inspect and clean main burner orice
(threaded into orice holder). Orice holder is
attached to the burner assembly venturi with
(2) two screws.
9. Inspect and clean pilot (mounted to bracket)
by using a vacuum or apply air pressure
through the holes in the pilot indicated by the
arrows in Figure 9.
WARNING: Never use needles, wires, or
similar cylindrical objects to clean the pilot to
avoid damaging the calibrated orice that controls the gas ow assembly.
10. Apply air pressure (max. 30 psi) into ceramic tile of burner assembly and the venture
tube to remove dust, lint or spider webs.
11. Reassemble main burner orice holder onto the burner.
12. Reinstall burner assembly into the heater housing.
13. Reinstall fuel line and check for leaks.
14. Install heater back cover.
TROUBLESHOOTING
IF SPARK ELECTRODE DOES NOT PRODUCE SPARK
CHECK
• Spark electrode broken - replace ODS (Oxygen Depletion Sensor)
• Igniter wire may not be attached to spark electrode
• Igniter wire damaged - replace
• Pulse Igniter Battery dead - replace AA battery
IF SPARK ELECTRODE PRODUCES SPARK BUT PILOT DOES NOT LIGHT.
CHECK
• No gas to heater - install disposable cylinder or connect hose and lter where
required and turn on valve at remote cylinder.
• “PILOT” position not properly aligned - turn gas control knob to “PILOT” position and
depress.
• Pilot is blocked from spider web or dirt - clean pilot (See MAINTENANCE beginning
on page 7.)
IF PILOT FLAME DOES NOT STAY LIT WHEN KNOB IS RELEASED
CHECK
• Control knob in “PILOT” position not completely depressed or held in long enough to
purge air from lines.
• Pilot ame not surrounding thermocouple - clean pilot (See MAINTENANCE
beginning on page 7.)
• Pilot Assembly defective - replace
• Tip switch wires disconnected - connect
IF MAIN BURNER DOES NOT IGNITE
CHECK
• Main burner orice is blocked - clean burner (See MAINTENANCE beginning on page
7.)
IF HEATER KEEPS SHUTTING “OFF” DURING NORMAL OPERATION
CHECK
• Pilot is blocked - clean pilot (See MAINTENANCE beginning on page 7.)
• Provide minimum fresh air opening of 77 cm2 (example 7.62 cm x 10.16 cm
opening)
• Tip over switch activated from bumping heater. Re-light.
• Regulator defective - Replace regulator.
• Internal contamination - Replace control valve and regulator
• Call Technical Services for additional information.
Figure 9
Pilot Flame Oxygen Depletion
Sensor

9
English
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Important Safety Instructions for all Battery Chargers
SAVE THESE INSTRUCTIONS: This manual contains important safety and
operating instructions for battery chargers.
• Before using the charger, read all instructions and cautionary markings on
the charger, battery pack and product using the battery pack.
WARNING: Shock hazard. Do not allow any liquid to get inside the char-
ger. Electric shock may result.
WARNING: We recommend the use of a residual current device with a
residual current rating of 30mA or less.
CAUTION: Burn hazard. To reduce the risk of injury, charge only DEWALT
rechargeable batteries. Other types of batteries may burst causing personal
injury and damage.
CAUTION: Children should be supervised to ensure that they do not
play with the appliance.
NOTICE: Under certain conditions, with the charger plugged into the power
supply, the charger can be shorted by foreign material. Foreign materials of
a conductive nature, such as, but not limited to, grinding dust, metal chips,
steel wool, aluminum foil or any buildup of metallic particles should be kept
away from the charger cavities. Always un-plug the charger from the power
supply when there is no battery pack in the cavity. Unplug the charger before
attempting to clean.
WARNING: DO NOT let children come into contact with the charger.
Supervision is required when inexperienced operators use this charger.
• Young children and the inrm. This appliance is not intended for use by
young children or inrm persons without supervision.
• This product is not intended for use by persons (including children) suffering
from diminished physical, sensory or mental abilities, or for lack of experi-
ence and/or for want of knowledge or skills unless they are supervised by
a person responsible for their safety. Children should never be left alone to
play with this product.
• Only use rechargeable batteries with this charger.
• These battery chargers and battery packs are professional tools.
WARNING:
• DO NOT attempt to charge the battery pack with any chargers other
than the ones in this manual. The charger and battery pack are speci-
cally designed to work together.
• These chargers are not intended for any uses other than charging
DEWALT rechargeable batteries. Any other uses may result in risk of re,
electric shock or electrocution.
• Do not expose the charger to rain or snow.
• DO NOT use under wet conditions or in presence of ammable liquids or
gases.
• Pull by the plug rather than the cord when disconnecting the char-
ger. This will reduce the risk of damage to the electric plug and cord.
• Make sure that the cord is located so that it will not be stepped on,
tripped over or otherwise subjected to damage or stress.
• Do not use an extension cord unless it is absolutely necessary.
Use of improper extension cord could result in risk of re, electric shock or
electrocution.
• When operating a charger outdoors, always provide a dry location
and use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
• Do not place any object on top of the charger or place the charger
on a soft surface that might block the ventilation slots and result
in excessive internal heat. Place the charger in a position away from
any heat source. The charger is ventilated through slots in the top and the
bottom of the housing.
• Do not operate the charger with a damaged cord or plug - have them
replaced immediately.
• Do not operate the charger if it has received a sharp blow, been
dropped or otherwise damaged in any way. Take it to an authorized
service center.
• Do not disassemble the charger; take it to an authorized service
center when service or repair is required. Incorrect reassembly may
result in a risk of electric shock, electrocution or re.
• In case of damaged power supply cord the supply cord must be replaced
immediately by the manufacturer, its service agent or similar qualied person
to prevent any hazard.

English
10
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
• Disconnect the charger from the outlet before attempting any
cleaning. This will reduce the risk of electric shock. Removing the
battery pack will not reduce this risk.
• NEVER attempt to connect 2 chargers together.
• The charger is designed to operate on standard 230V household
electrical power. Do not attempt to use it on any other voltage. This
does not apply to the vehicular charger.
• Take care to ensure that the charger is standing in a steady, secure
position. A falling battery or charger may present a risk of injury to yourself
and/or others.
IMPORTANT SAFETY INSTRUCTIONS FOR ALL BATTERY
PACKS
When ordering replacement battery packs, be sure to include the catalog
number and voltage. Consult the chart at the end of this manual for compati-
bility of chargers and battery packs.
The battery pack is not fully charged out of the carton. Before using the
battery pack and charger, read the safety instructions below and then follow
charging procedures outlined.
READ ALL INSTRUCTIONS
WARNING:
• Do not charge or use the battery pack in explosive atmospheres,
such as in the presence of ammable liquids, gases or dust. Inserting
or removing the battery pack from the charger may ignite the dust or fumes.
• NEVER force the battery pack into the charger. DO NOT modify
the battery pack in any way to t into a non-compatible charger as
battery pack may rupture causing serious personal injury.
• Charge the battery packs only in designated DEWALT chargers.
• DO NOT splash or immerse in water or other liquids.
• Do not store or use the tool and battery pack in locations where the
temperature may reach or exceed 40 °C (such as outside sheds or
metal buildings in summer). For best life store battery packs in a cool,
dry location. NOTE: Do not store the battery pack in a tool with the
trigger switch locked on. Never tape the trigger switch in the ON
position.
WARNING: Never attempt to open the battery pack for any reason. If the
battery pack case is cracked or damaged, do not insert into the charger. Do
not crush, drop or damage the battery pack. Do not use a battery pack or
charger that has received a sharp blow, been dropped, run over or damaged
in any way (e.g., pierced with a nail, hit with a hammer, stepped on). Damaged
battery packs should be returned to the service center for recycling.
WARNING: Fire hazard. Do not store or carry the battery pack so
that metal objects can contact exposed battery terminals. For exam-
ple, do not place the battery pack in aprons, pockets, tool boxes, product kit
boxes, drawers, etc., with loose nails, screws, keys, etc.
CAUTION: When not in use, place tool on its side on a stable sur-
face where it will not cause a tripping or falling hazard. Some tools with
large battery packs will stand upright on the battery pack but may be easily
knocked over.
SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION (Li-Ion)
• Do not incinerate the battery pack even if it is severely damaged
or is completely worn out. The battery pack can explode in a re. Toxic
fumes and materials are created when lithium ion battery packs are burned.
• If battery contents come into contact with the skin, immediately
wash area with mild soap and water. If battery liquid gets into the eye,
rinse water over the open eye for 15 minutes or until irritation ceases. If
medical attention is needed, the battery electrolyte is composed of a mix-
ture of liquid organic carbonates and lithium salts.
• Contents of opened battery cells may cause respiratory irritation.
Provide fresh air. If symptoms persist, seek medical attention.
WARNING: Burn hazard. Battery liquid may be ammable if exposed to
spark or ame.
