DW0822; DW0822CG
CROSS LINE AND PLUMB SPOTS LASER
LASER À LIGNES CROISÉES ET À POINTS D’APLOMB
LÁSER DE PUNTOS DE LÍNEA TRANSVERSAL Y PLOMADA
Instruction Manual
Guide D’utilisation
Manual de instrucciones
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per DeWalt DW0822 DW0822-XJ o
cerca il tuo prodotto tra le migliori offerte di Elettroutensili

Components
1 Battery compartment
cover
2 Indicator lights
3 Horizontal laser line
on/off button
4 Vertical laser line
on/off button
5 Plumb laser spots
on/off button
6 Lock/Power‑Unlock
7 Magnetic pivot bracket
8 Keyhole slot
9 Laser window
10 Spot laser windows
11 Laser label location
12 Magnets
Composants
1 Couvercle du
compartiment à piles
2 Voyants lumineux
3 Ligne laser horizontale
bouton marche/arrêt
4 Ligne laser verticale
bouton marche/arrêt
5 Points laser d’aplomb
bouton marche/arrêt
6 Verrouillage/
Déverrouillage électrique
7 Support pivotant
magnétique
8 Fente pour trou de
serrure
9 Fenêtre laser
10 Fenêtre laser à faisceau
11 Emplacement de
l’étiquette du laser
12 Aimants
Componentes
1 Cubierta de
compartimiento
de batería
2 Luces indicadoras
3 Botón de encendido/
apagado de línea
láser horizontal
4 Botón de encendido/
apagado de línea
láser vertical
5 Botón de encendido/
apagado de puntos
láser de plomada
6 Bloqueo/
Encendido‑Desbloqueo
7 Soporte de pivote
magnético
8 Ranura de cerradura
9 Ventana láser
10 Ventanas láser de punto
11 Ubicación de etiqueta
de láser
12 Imanes
English (original instructions) 5
Français (traduction de la notice d’instructions originale) 18
Español (traducido de las instrucciones originales) 32

Fig. A
10
345
2
6
9
8
1
7
11
10
12

STEP 1
ab
STEP 2
STEP 3
STEP 4
STEP 2 STEP 3
Fig.B Fig.C
Fig.D
Fig.E
1
LASER
LASER
63
4
5
LASER
LASER

cd
d
c
e
m
STEP 1, 2
STEP 3
STEPS 4, 5
STEP 6
STEP 7
STEP 8
STEP 3
f
g
f
g
5’(1.5m)
STEP 1
STEP 4
STEPS 2, 3 STEP 5
STEP 7
STEP 6
Fig.G
Fig.F

FLASHING
FLASHING
8
}>4°
AVERAGE
Fig.I
Fig.J
7
12
Fig.H

ENGLISH
5
English (original instructions)
Contents
• Laser Information
• User Safety
• Batteries
• Operating Tips
• Turning the Laser ON
• Checking Laser Accuracy
• Field Calibration Check
• Using the Laser
• Maintenance
• Troubleshooting
• Accessories
• Service and Repairs
• Warranty
• Specifications
LASER INFORMATION
The DW0822 and DW0822CG Laser Levels are Class2laser products and comply with
21CFR 1040.10 and 1040.11 except for deviations pursuant to laser notice No.56, dated May
8,2019.
The DW0822 and DW0822CG lasers are self‑leveling laser tool that can be used inside and
outside for horizontal (level), vertical, and plumb alignmentprojects.
Conforms to UL STDS 61010‑1 & 2595
Certified to CSA STD C22.2 No. 61010‑1
Supplier's Declaration of Conformity
47CFR § 2.1077 Compliance Information
Unique Identifier: DW0822, DW0822CG
Responsible Party – U.S. Contact Information
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or seriousinjury.
WARNING: To reduce the risk of injury, read the instructionmanual.

ENGLISH
6
DeWALT
701East Joppa Road
Towson, Maryland 21286
www.DeWALT.com
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio and television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receivingantenna.
• Increase the separation between the equipment andreceiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver isconnected.
• Consult the dealer or an experienced radio/TV technician forhelp.
ISED Compliance Statement
This device contains license‑exempt transmitter(s)/receiver(s) that comply with Innovation,
Science, and Economic Development Canada's license‑exempt RSS(s). Operation is subject
to the following twoconditions:
1. This device may not causeinterference.
2. This device must accept any interference, including interference that may cause
undesired operation of thedevice.
USER SAFETY
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to
hazardous situations and your risk of personal injury or propertydamage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result
in death or seriousinjury.

ENGLISH
7
WARNING: Indicates a potentially hazardous situation which, if not avoided, could
result in death or seriousinjury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderateinjury.
(Used without word) Indicates a safety relatedmessage.
NOTICE: Indicates a practice not related to personal injury which, if not avoided,
may result in propertydamage.
If you have any questions or comments about
this or any DeWALT tool,
call 1‑800‑4‑DeWALT (1-800-433-9258)
or go to www.DeWALT.com.
WARNING: Never modify the tool or any part of it. Damage to the laser or personal
injury couldresult.
WARNING: Read and understand all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or seriousinjury.
SAVE THESE INSTRUCTIONS
WARNING: Laser Radiation Exposure. Do not disassemble or modify the laser level.
There are no user serviceable parts inside. Serious eye injury couldresult.
WARNING:Hazardous Radiation. Use of controls or adjustments or performance
of procedures other than those specified herein may result in hazardous radiation
exposure.
CAUTION: Keep fingers clear of the back plate and stud when mounting with magnets.
Fingers may becomepinched.
CAUTION: Do not stand underneath the laser when it is mounted with the magnet
bracket. Serious personal injury or damage to the laser may result if the laserfalls.
The label on your laser may include the followingsymbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2Laser

ENGLISH
8
Warning Labels
For your convenience and safety, the following labels are on yourlaser.
WARNING: To reduce the risk of injury, user must read instructionmanual.
WARNING: LASER RADIATION. DO NOT STARE INTO BEAM. Class 2LaserProduct.
WARNING: Keep clear of magnet. Magnet hazard can disturb pacemaker operation
and result in serious injury ordeath.
• If the equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may beimpaired.
• Do not operate the laser in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust. This tool may create sparks which may ignite the dust
orfumes.

ENGLISH
9
• Store an idle laser out of reach of children and other untrained persons. Lasers are
dangerous in the hands of untrainedusers.
• Tool service MUST be performed by qualified repair personnel. Service or
maintenance performed by unqualified personnel may result in injury. To locate your nearest
DeWALT service center go to www.DeWALT.com.
• Do not use optical tools such as atelescope or transit to view the laser beam.
Serious eye injury could result.
• Do not place the laser in aposition which may cause anyone to intentionally or
unintentionally stare into the laser beam. Serious eye injury couldresult.
• Do not position the laser near areflective surface which may reflect the laser beam
toward anyone'seyes. Serious eye injury couldresult.
• Turn the laser off when it is not in use. Leaving the laser on increases the risk of staring
into the laserbeam.
• Do not modify the laser in any way. Modifying the tool may result in hazardous laser
radiationexposure.
• Do not operate the laser around children or allow children to operate the laser.
Serious eye injury mayresult.
• Do not remove or deface warning labels. If labels are removed, the user or others may
inadvertently expose themselves toradiation.
• Position the laser securely on alevel surface. If the laser falls, damage to the laser or
serious injury couldresult.
Personal Safety
• Stay alert, watch what you are doing, and use common sense when operating the laser. Do
not use the laser when you are tired or under the influence of drugs, alcohol, or medication.
Amoment of inattention while operating the laser may result in serious personalinjury.
• Do not overreach. Keep proper footing and balance at all times. Proper footing and balance
enables better control of the tool in unexpectedsituations.
• Use personal protective equipment. Always wear eye protection. Depending on the work
conditions, wearing protective equipment such as adust mask, non‑skid safety shoes, hard
hat, and hearing protection will reduce personalinjury.
Tool Use and Care
• Do not use the laser if the Power/Transport Lock switch does not turn the laser on or off.
Any tool that cannot be controlled with the switch is dangerous and must berepaired.

ENGLISH
10
• Follow instructions in the Maintenance section of this manual. Use of unauthorized parts
or failure to follow Maintenance instructions may create arisk of electric shock orinjury.
• Use only accessories that are recommended by the manufacturer for your model. Accessories
that may be suitable for one laser, may create a risk of injury when used on anotherlaser.
Battery
This tool is powered by three 1.5V AA size alkaline (LR6)batteries.
To install batteries (Fig. B)
1. Lift up the battery compartment cover1.
2. Insert three fresh AA alkaline (LR6) batteries in the compartment, placing the batteries
according to (+) and (–) on the inside of the batterydoor.
WARNING: Batteries can explode, or leak, and can cause injury or fire. To reduce
this risk:
• Use battery operated tool only with the specifically designed batteries. Use of any other
batteries may create a risk offire.
• Carefully follow all instructions and warnings on the battery label andpackage.
• Always insert batteries correctly with regard to polarity (+ and –), marked on the battery
and theequipment.
• Do not short batteryterminals.
• Do not chargebatteries.
• Do not mix old and new batteries. Replace all of them at the same time with new batteries
of the same brand andtype.
• Remove dead batteries immediately and dispose of per localcodes.
• Do not dispose of batteries infire.
• Keep batteries out of reach ofchildren.
• Remove batteries if the device will not be used for severalmonths.
Low Battery Indication
The lasers are equipped with indicator lights2. The indicator lights are located to the right
of the on/off buttons 3,4and5.
A flashing indicator lights indicates the batteries are low and need to be replaced. The laser
may continue to operate for a short time while the batteries continue to drain, but the
beam(s) will quickly dim. After fresh batteries are installed and the laser is turned on again,
the laser beam(s) will return to full brightness and the indicator lights will stay off. (A flashing
laser beam is not caused by low batteries; see Out of Tilt Range Indicator.)

ENGLISH
11
OPERATING TIPS
• To extend battery life, turn the laser off when it is not inuse.
• To ensure the accuracy of your work, check the laser calibration often. Refer to Checking
LaserAccuracy.
• Before attempting to use the laser, make sure it is positioned securely, on a smooth, flat
stable surface that is level in bothdirections.
CAUTION: To reduce the risk of serious injury, never stare directly into the laser beam
with or without these glasses. Refer to Accessories for importantinformation.
• Always mark the center of the beam created by thelaser.
• Extreme temperature changes can cause movement or shifting of building structures,
metal tripods, equipment, etc., which can effect accuracy. Check your accuracy often
whileworking.
• If the laser has been dropped, check to make sure your laser is still calibrated. Refer to
Checking LaserAccuracy.
To Turn the Laser On and Off (Fig.C, D)
1. Unlock unit by sliding Lock/Power‑Unlock bar6 to theright.
2. With the laser off, place it on a flat surface. This model has three ON/OFF buttons, one for a
horizontal laser line3, one for a vertical laser line4, and one for the plumb laser spots5.
Checking Laser Accuracy
The laser tools are sealed and calibrated at the factory. It is recommended that you perform
an accuracy check prior to using the laser for the first time (in case the laser was exposed
to extreme temperatures) and then regularly to ensure the accuracy of your work. When
performing any of the accuracy checks listed in this manual, follow these guidelines:
• Use the largest area/distance possible, closest to the operating distance. The greater the
area/distance, the easier to measure the accuracy of thelaser.
• Place the laser on asmooth, flat, stable surface that is level in bothdirections.
• Mark the center of the laserbeam.

ENGLISH
12
Field Calibration Check
Checking Accuracy – Horizontal Beam, Scan Direction (Fig. E)
Checking the horizontal scan calibration of the laser requires two walls at least 30' (9 m)
apart. It is important to conduct a calibration check using a distance no shorter than the
distance of the applications for which the tool will beused.
1. Attach the laser to a wall using its pivot bracket. Make sure the laser is facing
straightahead.
2. Turn on the laser's horizontal beam and pivot the laser approximately 45˚ so that the
right‑most end of the laser line is striking the opposing wall at a distance of at least 30' (9
m). Mark the center of the beam (a).
3. Pivot the laser approximately 90˚ to bring the left‑most end of the laser line around to
the mark made in Step 2. Mark the center of the beam (b).
4. Measure the vertical distance between themarks.
• If the measurement is greater than the values shown below, the laser must be serviced at
an authorized servicecenter.
Distance
Between Walls
Allowable Distance
Between aand b
30' 1/8"
40' 5/32"
50' 7/32"
Distance
Between Walls
Allowable Distance
Between aand b
9.0 m 3.1 mm
12.0 m 4.2 mm
15.0 m 5.2 mm
Checking Accuracy – Horizontal Beam, Pitch Direction (Fig. F)
Checking the horizontal pitch calibration of the laser requires a single wall at least 30' (9
m) long. It is important to conduct a calibration check using a distance no shorter than the
distance of the applications for which the tool will beused.
1. Attach the laser to one end of a wall using its pivotbracket.
2. Turn on the laser's horizontal beam and pivot the laser toward the opposite end of the
wall and approximately parallel to the adjacentwall.
3. Mark the center of the beam at two locations (a, b) at least 30' (9m)apart.

ENGLISH
13
4. Reposition the laser to the opposite end of thewall.
5. Turn on the laser's horizontal beam and pivot the laser back toward the first end of the
wall and approximately parallel to the adjacentwall.
6. Adjust the height of the laser so that the center of the beam is aligned with the nearest
mark (b).
7. Mark the center of the beam (c) directly above or below the farthest mark (a).
8. Measure the distance between these two marks(a,c).
• If the measurement is greater than the values shown below, the laser must be serviced at
an authorized servicecenter.
Distance
Between Walls
Allowable Distance
Between aand b
30' 1/4"
40' 5/16"
50' 13/32"
Distance
Between Walls
Allowable Distance
Between aand b
9.0 m 6.2 mm
12.0 m 8.3 mm
15.0 m 10.4 mm
Checking Accuracy – Vertical Beam (Fig. G)
Checking the vertical (plumb) calibration of the laser can be most accurately done when
there is a substantial amount of vertical height available, ideally 20' (6m), with one person
on the floor positioning the laser and another person near a ceiling to mark the position of
the beam. It is important to conduct a calibration check using a distance no shorter than the
distance of the applications for which the tool will beused.
1. Start by marking a 5' (1.5 m) line on thefloor.
2. Turn on the laser's vertical beam and position the unit at one end of the line, facing
theline.
3. Adjust the unit so its beam is aligned and centered on the line on thefloor.
4. Mark the position of the laser beam on the ceiling (a). Mark the center of the laser beam
directly over the midpoint of the line on thefloor.
5. Reposition the laser at the other end of the line on the floor. Adjust the unit once again
so its beam is aligned and centered on the line on thefloor.

ENGLISH
14
6. Mark the position of the laser beam on the ceiling (b), directly beside the first mark (a).
7. Measure the distance between these twomarks.
• If the measurement is greater than the values shown below, the laser must be serviced at
an authorized servicecenter.
Distance
Between Walls
Allowable Distance
Between aand b
8' 1/8"
10' 3/16"
14' 1/4"
20' 3/8"
Distance
Between Walls
Allowable Distance
Between aand b
2.5 m 3.4 mm
3.0 m 4.2 mm
4.0 m 5.5 mm
6.0 m 8.2 mm
Using the Laser
Leveling the Laser
As long as the laser is properly calibrated, the laser is self‑leveling. Each laser is calibrated at
the factory to find level as long as it is positioned on a flat surface within average ± 4° of
level. No manual adjustments arerequired.
If the laser has been tilted so much that it cannot self‑level (> 4°), the laser beam will flash.
When the beams flash THE LASER IS NOT LEVEL (OR PLUMB) AND SHOULD NOT BE USED
FOR DETERMINING OR MARKING LEVEL OR PLUMB. Tryrepositioning the laser on a more
levelsurface.
Using the Pivot Bracket (Fig.H, I)
The laser has a magnetic pivot bracket7 permanently attached to theunit.
WARNING: Position the laser and/or wall mount on astable surface. Serious personal
injury or damage to the laser may result if the laserfalls.
• The bracket has a keyhole slot8 so it can be hung from a nail or screw on any kind
ofsurface.

ENGLISH
15
• The bracket has magnets12which allow the unit to be mounted to most upright surfaces
made of steel or iron. Common examples of suitable surfaces include steel framing studs, steel
door frames, and structural steelbeams.
Using the Lasers with Accessories
The lasers are equipped with a 1/4”x 20female thread on the bottom of the unit. This thread
is to accommodate current or future DeWALT accessories. Only use DeWALT accessories
specified for use with this product. Follow the directions included with theaccessory.
CAUTION: The use of any other accessory not recommended for use with this tool could
behazardous.
If you need any assistance in locating any accessory, please contact DeWALT Industrial Tool
Co., 701East Joppa Road, Towson, MD 21286or call 1–800–4‑DeWALT (1–800–433–9258).
See our catalog on the World Wide Web at www.DeWALT.com.
Maintenance
• To maintain the accuracy of your work, check the laser often to make sure it is properly
calibrated. See Field CalibrationCheck.
• Calibration checks and other maintenance repairs may be performed by DeWALT
servicecenters.
• When not in use, store the laser in the kit box provided. Do not store your laser at
temperatures below ‑5˚F (‑20˚C or above 140˚F (60˚C).
• Do not store your laser in the kit box if the laser is wet.The laser should be dried first with
a soft dry cloth prior tostorage.
Cleaning
Exterior plastic parts may be cleaned with a damp cloth. Although these parts are solvent
resistant, NEVER use solvents. Use a soft, dry cloth to remove moisture from the tool
beforestorage.
Troubleshooting
The Laser Does Not Turn On
• Remove the batteries and replace with fresh batteries. Ensure the battery contacts are
free ofcorrosion.

ENGLISH
16
• If the laser unit is heated above 120˚F (50˚C), the unit will not turn on. If the laser has been
stored in extremely hot temperatures, allow it to cool.The laser level will not be damaged by
pressing the on/off button before cooling to its proper operatingtemperature.
The Laser Beams Flash (Fig. J)
The lasers are designed to self‑level up to an average of 4° in all directions If the laser is tilted
so much that the internal mechanism cannot level itself, the laser beams will flash indicating
that the tilt range has been exceeded. THE FLASHING BEAMS CREATED BYTHE LASER ARE
NOT LEVEL OR PLUMB AND SHOULD NOT BE USED FOR DETERMINING OR MARKING LEVEL
OR PLUMB. Try repositioning the laser on a more level surface.
The Laser Beams Will Not Stop Moving
The laser is a precision instrument. Therefore, if it is not positioned on a stable (and
motionless) surface, the laser will continue to try to find level. If the beam will not stop
moving, try placing the laser on a more stable surface. Also, try to make sure that the surface
is relatively flat, so that the laser isstable.
Service and Repairs
NOTE: Disassembling the laser level(s) will void all warranties on theproduct.
To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment should be
performed by authorized service centers. Service or maintenance performed by unqualified
personnel may result in a risk of injury.To locate your nearest DeWALT service center call
1‑800‑4‑DeWALT (1-800-433-9258) or go to www.DeWALT.com.
Warranty
Go to www.DeWALT.com for the latest warrantyinformation.

ENGLISH
17
SPECIFICATIONS
DW0822 DW0822CG
Light Source Semiconductor laser diodes Semiconductor laser diodes
Laser Wavelength 630 ‑ 680 nm visible 510 ‑ 530 nm visible
Laser Power <1 mW (each beam) CLASS II
(2) LASER PRODUCT
<1 mW (each beam) CLASS II
(2) LASER PRODUCT
Working Range 100' (30m)
165' (50m) with detector
100' (30m)
230' (70m) with detector
Accuracy (Plumb) ±1/8" per 30'
(±3.1 mm per 9m)
±1/8" per 30'
(±3.1 mm per 9m)
Accuracy (Level) ±1/8" per 30'
(±3.1 mm per 9m)
±1/8" per 30'
(±3.1 mm per 9m)
Battery Low Flashing battery indicator on
product
Flashing battery indicator on
product
Indicators Flashing Laser: tilt range
exceeded
Flashing Laser: tilt range
exceeded
Power Source 3x AA alkaline (LR6) batteries 3x AA alkaline (LR6) batteries
Operating
Temperature
20°F to 115°F (‑10°C to
45°C)
20°F to 115°F (‑10°C to 45°C)
Storage Temperature ‑5°F to 140°F (‑20°C to 60°C) ‑5°F to 140°F (‑20°C to 60°C)
Environmental IP54 IP54

FRANÇAIS
18
Français (traduction de la notice d’instructions originale)
AVERTISSEMENT: lisez tous les avertissements de sécurité et toutes les
instructions. Ne pas suivre les avertissements et les instructions peut entraîner un choc
électrique, un incendie et/ou des blessuresgraves.
AVERTISSEMENT: pour réduire le risque de blessure, lisez le guided’utilisation.
TABLE DES MATIÈRES
• Renseignements sur le laser
• Sécurité de l’utilisateur
• Piles
• Conseils sur l’utilisation
• Mise en marche du laser
• Vérification de la précision du laser
• Vérification du calibrage sur place
• Utilisation du laser
• Entretien
• Dépannage
• Accessoires
• Entretien et réparations
• Garantie
• Caractéristiques
Renseignements sur le laser
Le niveau laser DW0822 et DW0822CG est un produit laser de classe 2conforme aux normes
21CFR 1040.10 et 1040.11 hormis les écarts en vertu de la notice laser N°56en date du
8mai2019.
Le laser DW0822 et DW0822CG est un outil laser à correction de niveau automatique qui
peut être utilisé à l’intérieur et à l’extérieur pour les projets d’alignement horizontal (niveau),
vertical etd’aplomb.
Conforme aux normes UL STDS 61010‑1 et 2595
Certié selon la norme CSA C22.2 No. 61010‑1
Déclaration de conformité du fournisseur
47CFR § 2,1077 informations de conformité
