English
3
CORDLESS INSPECTION CAMERA
DCT410, DCT411, DCT412
Congratulations!
You have chosen a DeWALT tool. Years of
experience, thorough product development and
innovation make DeWALT one of the most reliable
partners for professional power tool users.
Technical Data
DCT410 DCT411 DCT412
Voltage VDC 10.8 10.8 10.8
Type 1 1 1
Battery Type Li-ION Li-ION Li-ION
Camera cable
diameter mm 17 9 5.8
Cable length m 0.9 0.9 0.9
Resolution dpi 320 x 480 320 x 480 320 x 480
Screen size mm 69 x 50 69 x 50 69 x 50
Weight
(without battery pack) kg 0.77 0.69 0.60
Battery pack DCB125 DCB127
Battery type Li-ION Li-ION
Voltage VDC 10.8 10.8
Capacity A
h
1.3 2.0
Weight kg 0.2 0.2
Charger DCB112
Mains voltage VAC 220-240 V
Battery type Li-ION
Approximate min 40 60
charging time (1.3 Ah) (2.0 Ah)
of battery packs
Weight kg 0.36
Charger DCB107
Mains voltage VAC 220 -240V
Battery type Li-ION
Approximate min 60 90
charging time (1.3 Ah) (2.0 Ah)
of battery packs
Weight kg 0.29
Charger DCB105
Mains voltage VAC 220-240 V
Battery type Li-ION
Approximate min 25 40
charging time (1.3 Ah) (2.0 Ah)
of battery packs
Weight kg 0.49
WARNING: This is a Class A product.
In a domestic environment this product
may cause radio interference in which
case the user may be required to take
adequate measures.
WARNING: Increased electrostatic
voltage may cause display to fail and
all unsaved data will be lost. Before
reusing, ensure that the electrostatic
voltage has stopped occuring and
actuate the reset button using the
appropriate pin. Afterwards the camera
display will function.
Definitions: Safety Guidelines
The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
NOTICE: Indicates a practice not
related to personal injury which, if
not avoided, may result in property
damage.
Denotes risk of electric shock.
Denotes risk of fire.
WARNING: To reduce the risk of injury,
read the instruction manual.

English
4
Important Safety Instructions
 • Readtheseinstructions.
 • Keeptheseinstructions.
 • Heedallwarnings.
 • Followallinstructions.
 • Onlyuseattachments/accessoriesspecifiedby
the manufacturer.
 • Referallservicingtoqualifiedservicepersonnel.
Servicing is required when the apparatus has
been damaged in any way, the apparatus has
been exposed to rain or moisture, does not
operate normally, or has been dropped.
Save all warningS and inStructionS for
future reference
Work Area Safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Keep children and bystanders away
while operating an inspection camera.
Distractions can cause you to lose control.
Personal Safety
a) Stay alert, watch what you are doing
and use common sense when operating
an inspection camera. Do not use an
inspection camera while you are tired or
under the influence of drugs, alcohol or
medication. A moment of inattention while
operating the inspection camera may result in
serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce
personal injuries.
c) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the inspection camera in
unexpected situations.
d) Dress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
Use and Care
a) Store an idle inspection camera out of
the reach of children and do not allow
persons unfamiliar with the inspection
camera or these instructions to operate
the inspection camera. Inspection cameras
are dangerous in the hands of untrained
users.
b) Use the inspection camera, accessories,
etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the inspection camera
for operations different from those intended
could result in a hazardous situation.
Battery Tool Use and Care
a) Recharge only with the charger
specified by DeWALT. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.
b) When battery pack is not in use, keep it
away from other metal objects like paper
clips, coins, keys, nails, screws, or other
small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
c) Under abusive conditions, liquid may
be ejected from the battery; avoid
contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid
ejected from the battery may cause irritation
or burns.
Safety Information for Inspection
Cameras
WARNING: Do not disassemble
or modify the inspection camera.
There are no serviceable parts
inside. If you need assistance contact
your local dealer.
 • Do not operate the inspection camera in
explosive atmospheres, such as in the
presence of flammable liquids, gases, or
dust. Inspection cameras create sparks which
may ignite the dust or fumes.
 • The inspection camera should only be
used with specifically designated DeWALT
batteries. Use of any other batteries may
create a risk of fire.
 • Store the inspection camera out of reach
of children and other untrained persons.
Tools are dangerous in the hands of untrained
users.

English
5
 • Do not disassemble the inspection camera.
There are no user serviceable parts inside.
 • Do not use anywhere the unit may
come into exposure with moving parts,
hazardous chemicals, or electrical charges.
Such situations may result in serious injury or
death; such as walls, pipes, automobiles, and
machinery.
 • Do not operate inspection camera near
moving machinery. Can result in injury if the
camera cable gets caught into moving parts
and pulls the user in.
 • Ensure the work area is free of current-carrying
parts during the work process.
 • Do not use the inspection camera around
corrosive chemicals.Exposure to corrosive,
oily environments can ruin the plastic covering
on the camera head and ruin the picture quality.
 • Do not use the camera if condensation
forms inside the lens. Let the water evaporate
before using again.
 • Do not remove or deface warning labels.
 • Toavoiddamagingtheinspectioncameraor
the equipment under test, protect them from
the following:
  – EMF(electromagneticfields)likefromarc
welders, induction heaters, etc.
  – ESD(electrostaticdischarge).
  – Thermalshock(causedbyabruptambient
temperature changes for highest accuracy;
allow 30 minutes for thermometer to stabilize
beforeuse).
WARNING: Do not expose camera,
monitor or battery to excessive heat
such as sunshine, fire or the like.
WARNING: Shock hazard. Do not
allow the inspection camera cable
to come into contact with live wires.
Shut off circuit breakers to the entire
area to avoid injury.
WARNING: Do not use on humans
or animals. This is not for human or
animal use and can cause injury if used.
WARNING: ALWAYS use safety
glasses. Everyday eyeglasses are
NOTsafetyglasses.Alsousefaceor
dust mask if cutting operation is dusty.
ALWAYSWEARCERTIFIEDSAFETY
EQUIPMENT.
CAUTION: When not in use, place
inspection camera on its side on
a stable surface where it will not
cause a tripping or falling hazard.
Some tools with large battery packs will
stand upright on the battery pack but
may be easily knocked over.
WARNING: Modifications not
authorised by the manufacturer may
void user’s authority to operate this
device.
Residual Risks
In spite of the application of the relevant safety
regulations and the implementation of safety
devices, certain residual risks cannot be avoided.
These are:
 – Riskofpersonalinjuryduetoprolongeduse.
 – Riskofpersonalinjurydue to unintentional
contact with current-carrying parts during the
work process.
Markings on Inspection Camera
The following pictograms are shown on the
inspection camera:
Read instruction manual before use.
DATE CODE POSITION
The date code, which also includes the year of
manufacture, is printed into the housing surface that
forms the mounting joint between tool and battery.
Example:
2014 XX XX
Year of Manufacture
Important Safety Instructions for All
Battery Chargers
SAVE THESE INSTRUCTIONS: This manual
contains important safety and operating instructions
for the DCB105, DCB107 and DCB112 battery
chargers.
 • Beforeusingcharger,readallinstructionsand
cautionary markings on charger, battery pack,
and product using battery pack.
WARNING: Shock hazard. Do not allow
any liquid to get inside charger. Electric
shock may result.
CAUTION: Burn hazard. To reduce
the risk of injury, charge only DeWALT
rechargeablebatteries.Othertypesof
batteries may burst causing personal
injury and damage.

English
6
CAUTION: Children should be
supervised to ensure that they do not
play with the appliance.
NOTICE: Under certain conditions, with
the charger plugged in to the power
supply, the charger can be shorted by
foreignmaterial.Foreignmaterialsof
a conductive nature such as, but not
limited to, grinding dust, metal chips,
steel wool, aluminum foil, or any buildup
of metallic particles should be kept away
from charger cavities. Always unplug the
charger from the power supply when
there is no battery pack in the cavity.
Unplug charger before attempting to
clean.
 • DONOTattempttochargethebatterypack
withanychargersotherthantheonesin
thismanual. The charger and battery pack are
specifically designed to work together.
 • Thesechargersarenotintendedfor
anyusesotherthanchargingDeWALT
rechargeablebatteries. Any other uses
may result in risk of fire, electric shock or
electrocution.
 • Donotexposechargertorainorsnow.
 • Pullbyplugratherthancordwhen
disconnectingcharger.This will reduce risk
of damage to electric plug and cord.
 • Makesurethatcordislocatedsothatit
willnotbesteppedon,trippedover,or
otherwisesubjectedtodamageorstress.
 • Donotuseanextensioncordunlessit
isabsolutelynecessary.Use of improper
extension cord could result in risk of fire,
electric shock, or electrocution.
 • Donotplaceanyobjectontopofcharger
orplacethechargeronasoftsurfacethat
mightblocktheventilationslotsandresult
inexcessiveinternalheat. Place the charger
in a position away from any heat source. The
charger is ventilated through slots in the top and
the bottom of the housing.
 • Donotoperatechargerwithdamagedcord
orplug— have them replaced immediately.
 • Donotoperatechargerifithasreceived
asharpblow,beendropped,orotherwise
damagedinanyway. Take it to an authorised
service centre.
 • Donotdisassemblecharger;takeittoan
authorisedservicecentrewhenserviceor
repairisrequired. Incorrect reassembly may
result in a risk of electric shock, electrocution or
fire.
 • Incaseofdamagedpowersupplycordthe
supply cord must be replaced immediately by
the manufacturer, its service agent or similar
qualified person to prevent any hazard.
 • Disconnectthechargerfromtheoutlet
beforeattemptinganycleaning.Thiswill
reducetheriskofelectricshock.Removing
the battery pack will not reduce this risk.
• NEVERattempt to connect 2 chargers together.
 • Thechargerisdesignedtooperateon
standard230Vhouseholdelectricalpower.
Donotattempttouseitonanyother
voltage.This does not apply to the vehicular
charger.
Save tHeSe inStructionS
Chargers
The DCB105, DCB107 and DCB112 chargers
accept 10.8 V Li-ION batteries.
These chargers require no adjustment and are
designed to be as easy as possible to operate.
Charging Procedure (fig. 1)
1. Plug the charger into an appropriate outlet
before inserting battery pack.
2. Insert the battery pack (a) into the charger.
The red (charging) light will blink continuously
indicating that the charging process has started.
3. The completion of charge will be indicated by
the red light remaining ON continuously. The
pack is fully charged and may be used at this
time or left in the charger.
NOTE: To ensure maximum performance and life of
Li-ION batteries, charge the battery pack fully before
first use.
Charging Process
Refer to the table below for the state of charge of
the battery pack.
State of charge - DCB105
charging – – – –
fully charged –––––––––––
hot/cold pack delay –– – –– –
 replacebatterypack •••••••••••

English
7
State of charge - DCB107 and DCB112
charging –– –– –– –– ––
fully charged ––––––––––––––––––––
hot/cold pack delay –– –– –– –––––––
Hot/Cold Pack Delay
DCB105
When the charger detects a battery that is too hot
or too cold, it automatically starts a Hot/Cold Pack
Delay, suspending charging until the battery has
reached an appropriate temperature. The charger
then automatically switches to the pack charging
mode. This feature ensures maximum battery life.
DCB107 AND DCB112
When the charger detects a battery that is hot, it
automatically delays charging until the battery has
cooled.
When the charger detects a battery that is cold, it
automatically delays charging until the battery has
warmed.
The red light will continue to blink, but a yellow
indicator light will be illuminated during this
operation. Once the battery has cooled, the yellow
light will turn off and the charger will resume the
charging procedure.
XR Li-ION tools are designed with an Electronic
Protection System that will protect the battery
against overloading, overheating or deep discharge.
The tool will automatically turn off if the Electronic
Protection System engages. If this occurs, place the
Li-ION battery on the charger until it is fully charged.
LI-ION BATTERY PACKS ONLY
Li-ION batteries are designed with an Electronic
Protection System that will protect the battery
against overloading, overheating or deep discharge.
The tool will automatically turn off if the Electronic
Protection System engages. If this occurs, place the
Li-ION battery on the charger until it is fully charged.
Important Safety Instructions for All
Battery Packs
When ordering replacement battery packs, be sure
to include catalog number and voltage.
The battery pack is not fully charged out of the
carton. Before using the battery pack and charger,
read the safety instructions below. Then follow
charging procedures outlined.
read all inStructionS
 • Donotchargeorusebatteryinexplosive
atmospheres,suchasinthepresenceof
flammableliquids,gasesordust.Inserting
or removing the battery from the charger may
ignite the dust or fumes.
• Neverforcebatterypackintocharger.Do
notmodifybatterypackinanywaytofitinto
anon-compatiblechargerasbatterypack
mayrupturecausingseriouspersonalinjury.
 • ChargethebatterypacksonlyinDeWALT
chargers.
• DONOTsplash or immerse in water or other
liquids.
 • Donotstoreorusethetoolandbattery
packinlocationswherethetemperature
mayreachorexceed40˚C(105˚F)(suchas
outsideshedsormetalbuildingsinsummer).
WARNING: Never attempt to open the
battery pack for any reason. If battery
pack case is cracked or damaged,
do not insert into charger. Do not
crush, drop or damage battery pack.
Do not use a battery pack or charger
that has received a sharp blow, been
dropped, run over or damaged in any
way(i.e.,piercedwithanail,hitwitha
hammer,steppedon).Electricshock
or electrocution may result. Damaged
battery packs should be returned to
service centre for recycling.
CAUTION: When not in use, place
tool on its side on a stable surface
where it will not cause a tripping or
falling hazard. Some tools with large
battery packs will stand upright on the
battery pack but may be easily knocked
over.
SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION
(Li-ION)
 • Donotincineratethebatterypackevenifit
isseverelydamagedoriscompletelyworn
out. The battery pack can explode in a fire.
Toxic fumes and materials are created when
lithium ion battery packs are burned.
 • Ifbatterycontentscomeintocontactwith
theskin,immediatelywashareawithmild
soapandwater.If battery liquid gets into the
eye, rinse water over the open eye for
15 minutes or until irritation ceases. If medical
attention is needed, the battery electrolyte
is composed of a mixture of liquid organic
carbonates and lithium salts.
 • Contentsofopenedbatterycellsmaycause
respiratoryirritation. Provide fresh air. If
symptoms persist, seek medical attention.

English
8
WARNING: Burn hazard. Battery liquid
may be flammable if exposed to spark
or flame.
Battery Pack
BATTERY TYPE
The DCT410, DCT411 and DCT412 operate on
10.8 volt battery packs.
Storage Recommendations
1. The best storage place is one that is cool and
dry, away from direct sunlight and excess heat
or cold. For optimum battery performance and
life, store battery packs at room temperature
when not in use.
2. For long storage, it is recommended to store a
fully charged battery pack in a cool, dry place
out of the charger for optimal results.
NOTE: Battery packs should not be stored
completely depleted of charge. The battery pack will
need to be recharged before use.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual,
the labels on the charger and the battery pack show
the following pictographs:
Read instruction manual
before use.
100%
Battery charging.
100%
Battery charged.
Battery defective.
Hot/cold pack delay.
Do not probe with conductive objects.
Do not charge damaged battery packs.
Use only with DeWALT battery packs,
others may burst, causing personal injury
and damage.
Do not expose to water.
Have defective cords replaced
immediately.
Charge only between 4 ˚C and 40 ˚C.
Discard the battery pack with due care for
the environment.
Do not incinerate the battery pack.
See Technical data for charging time.
Only for indoor use.
Package Contents
The package contains:
1 Inspection camera
1 Camera Cable 17mm (DCT410)
1 Camera Cable 9mm (DCT411)
1 Camera Cable 5.8mm (DCT412)
1 Hook (DCT410, DCT411)
1 Magnet (DCT410, DCT411)
1 Mirror (DCT411)
1 Battery pack
1 Charger
1 Kit box
1 Instruction manual
1 Exploded drawing
NOTE: Battery packs and chargers are not included
with N-models.
 • Checkfordamagetothetool,partsor
accessories which may have occurred during
transport.
 • Takethetimetothoroughlyreadand
understand this manual prior to operation.
Description (fig. 2, 3)
WARNING: Never modify the inspection
camera or any part of it. Damage or
personal injury could result.
a. 10.8 V lithium ion battery
b. Camera with LED’s
c. 0.9 m Camera cable
d. Camera connector

English
9
e. Screen
f. Camera cable on/off switch / LED brightness
control switch
g. Handle set
h. Micro SD slot for micro SD memory cards
16 GB or less
i. Power button for the screen: Both
the screen and the camera cable (f)
need to be turned on.
j. Zoom/Delete button:
The button has 2 functions:
Zoom: This is to be used
when you need a
closer look at the
object (3x zoom).
Delete: When in the folder
menu, pictures can
be deleted by using
this button.
k. Play: Press the button to go to the
folder where photos and videos are
saved.
OR
Press the button to play videos.
l. Camera: Press this button for taking a
photo.
m. Record: Press this button to start and
stop recording a video.
n. Main Menu: Press this button to
show a list of options for operating the
inspection camera or to exit a screen.
o. Back Arrow: Press this button to
navigate backward.
p. OK: Press this button to save
changes.
q. Forward Arrow: Press this button to
navigate forward.
r. Power indicator for the handle set:
When the green light is on it indicates
that the handle set is on.
s. Reset button
INTENDED USE
The inspection camera is designed to play real-time
video while looking into walls and/or tight spaces.
With a micro SD card (sold separately), the tool can
then take photos or record videos for documentation
purposes.
Photos are saved in JPG format and videos are
saved as AVI. This DeWALT inspection camera is
compatible with micro SD memory cards up to
16 gigabytes.
Applications consist of automotive inspection,
plumbing inspection, HVAC inspection or cable
routing. Read the entire manual before using this
inspection camera.
DO NOT use in presence of flammable liquids or
gases. The camera cable extension is waterproof up
to the camera connector. DO NOT USE the handle
set under wet conditions or submerge in liquid.
The inspection camera is a professional tool.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use this tool.
 • Thisproductisnotintendedforusebypersons
(including children) suffering from diminished
physical, sensory or mental abilities, or for lack
of experience and/or for want of knowledge or
skills unless they are supervised by a person
responsible for their safety. Children should
never be left alone to play with this product.
Electrical Safety
The charger has been designed for one voltage
only. Always check that the battery pack voltage
corresponds to the voltage on the rating plate.
Also make sure that the voltage of your charger
corresponds to that of your mains.
Your DeWALT charger is double insulated
in accordance with IEC 60335; therefore
no earth wire is required.
If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
DeWALT service organisation.
Using an Extension Cable
An extension cord should not be used unless
absolutely necessary. Use an approved extension
cable suitable for the power input of your charger
(see Technical data). The minimum conductor size
is 1 mm2; the maximum length is 30 m.

English
10
When using a cable reel, always unwind the cable
completely.
ASSEMBLY AND ADJUSTMENTS
WARNING: Prior to assembly and
adjustment, always remove the battery
pack. Always turn the inspection camera
off before inserting or removing the
battery pack.
WARNING: Use only DeWALT battery
packs and chargers.
Screen (fig. 4)
When the screen is attached to the handle set with
a battery, it will receive a charge from the battery.
Ensure the screen is fully charged before use.
When the screen is disengaged from the handle set,
a battery icon appears in the upper left corner. This
icon also displays the current charge of the screen.
To install the screen (e) into the handle set (g), align
the screen with the rails on the handle set and slide
it firmly into the handle until you hear the lock snap
into place.
To remove the screen from the handle set, firmly
slide the screen up from the tool handle.
The screen can be turned on and viewed when it
is not attached to the handle set, allowing easier
maneuverability of the camera.
Camera Cable (fig. 5)
Align the camera cable (c) with the camera
connector (d). Push in and turn the connector
counterclockwise (camera screen facing you) to
firmly attach.
To remove the camera cable, turn the connector
clockwise (direction of arrow).
Additional camera cable and extensions are available
at additional cost. Consult your dealer for further
information.
Hook and Magnet (fig. 6)
DCT410
The hook is beneficial for retrieving cable or wire
located in tight spaces. The magnet is beneficial for
retrieving metal objects in tight spaces.
To attach the hook or magnet, turn the knurled part
of the camera counterclockwise until it stops.
Align the hook or magnet with the gray groove (t)
then slide it down until the tabs (u) at the top of the
hook/magnet are securely in the notches (v) located
in the camera lens.
Turn the knurled part clockwise to lock the base of
the hook and magnet.
Hook, Magnet and Mirror (fig.7,8)
DCT411
Follow the process below to assemble the hook,
magnet or mirror onto the DCT411 9mm camera.
1. With the sleeve (w) on the accessory, insert the
bottom of accessory (bent wire) into the hole (x)
in the 9mm camera cable.
2. Make sure the accessory is in the groove (y) on
the sleeve and slide the sleeve onto the camera
until the sleeve covers the hole(x).
CAUTION:CutHazard.Usecarewhen
handling hook.
Belt Hook (fig. 9)
(Optional Accessory)
WARNING: To reduce the risk of
serious personal injury, DO NOT
suspend camera overhead or suspend
objects from the belt hook. ONLY hang
camera’s belt hook from a work belt.
WARNING: To reduce the risk of
serious personal injury, ensure the
screw (z) holding the belt hook is
secure.
IMPORTANT: When attaching or removing the belt
hook, use only the screw (z) that is provided.
The belt hook (aa) can be attached to either side
of the tool using only the screw (z) provided, to
accommodate left- or right-handed users. If the
hook is not desired at all, it can be removed from
the tool.
To move belt hook, remove the screw (z) that holds
the belt hook in place then reassemble on the
opposite side.
OPERATION
Instructions for Use
WARNING: Always observe the safety
instructions and applicable regulations.
Inserting and Removing the
Battery Pack from the Inspection
Camera (fig. 10)

English
11
NOTE: Make sure your battery pack (a) is fully
charged.
TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE
1. Align the battery pack with the rails inside the
handle.
2. Slide it firmly into place until you hear the lock
snap into place.
TO REMOVE THE BATTERY PACK FROM THE TOOL
1. Press the release button (bb) and firmly pull the
battery pack out of the camera handle.
2. Insert battery pack into the charger as
described in the charger section of this manual.
Getting Started
INITIAL SETUP
Language Setup
1. Press the forward or back arrow to select
English, German, Spanish, French, Italian or
Dutch.
2. Press the OK button to confirm and exit.
Date and Time Setup
1. Press the forward or back arrow to highlight the
field to change.
2. Press the OK button to activate the field (field
turns green).
3. Press the forward or back arrow to change the
activated field.
4. Press the OK button to save changes (field
turns yellow).
5. Repeat above steps to change remaining fields.
6. Press the main menu button to exit.
BASIC OPERATION
NOTE: At any time during the camera operation,
pressing the main menu button will return to the
previous menu.
To Record Photos or Videos (fig. 2, 3)
Be sure a micro SD card (sold separately) is loaded
in the card slot (h).
1. Turn both the camera (b) and the handle set (g)
on.
2. Aim camera at destination.
A. Press the camera button (l) to take a photo.
A confirmation icon will appear in the top
right side of screen.
OR
B. Press the record button (m) to start
recording.
A red dot will appear in the top right side
of the screen. To stop recording, press the
record button again.
The camera will create a folder on the micro SD card
for that day. All photos or videos taken that day will
be stored in this folder.
To View Photos or Videos
1. Press the main menu button to show the Main
Menu.
2. Press the forward or back arrow to select the
Folder option.
3. Press the OK button to navigate to the next
screen.
4. Press the forward or back arrow to select a
dated folder.

English
12
5. Press the OK button to select the dated folder.
6. Press the forward or back arrow to select the
photo or video.
7. Press the OK button to view the photo or video.
8. Press the forward or back arrow to advance to
the next photo or video.
9. When finished, press the main menu button to
exit.
To Delete Individual Photos or Videos
1. Press the main menu button to show the Main
Menu.
2. Press the forward or back arrow to select the
Folder option.
3. Press the OK button to navigate to the next
screen.
4. Press the forward or back arrow to select a
dated folder.
5. Press the OK button to navigate to the next
screen.
6. Press the forward or back arrow to select a
photo or video.
7. Press the delete button. Select YES to delete
the individual photo or video.
8. Press the main menu button to exit.
To Delete a Photo or Video While Viewing
1. Press the main menu button to show the Main
Menu.
2. Press the forward or back arrow to select the
Folder option.

English
13
3. Press the OK button to navigate to the next
screen.
4. Press the forward or back arrow to select a
dated folder.
5. Press the OK button to navigate to the next
screen.
6. Press the forward or back arrow to select a
photo or video.
7. Press the OK button to view.
8. Press the delete button. Select YES to delete
the individual photo or video.
To Change Languages
1. Press the main menu button to show the Main
Menu.
2. Press the forward or back arrow to select the
Language option.
3. Press the OK button to select.
4. Press the forward or back arrow to select
English, German, Spanish, French, Italian or
Dutch.
5. Press the OK button to save changes.
6. Press the main menu button to exit.
To Change Date/Time
1. Press the main menu button to show the Main
Menu.
2. Press the forward or back arrow to select Date/
Time option.
3. Press the OK button to navigate to the next
screen.
4. Press the forward or back arrow to highlight a
field to change.
5. Press the OK button to activate the field (field
turns green).
6. Press the forward or back arrow to change the
activated field.
7. Press the OK button to save changes.

English
14
8. Repeat above steps to change remaining fields.
9. Press the main menu button to exit.
To Activate the Time Stamp
1. Press the main menu button to show the Main
Menu.
2. Press the forward or back arrow to select the
Time Stamp option.
3. Press the OK button to navigate to the next
screen.
4. Press the forward or back arrow to select OFF
or ON.
5. Press the OK button to save changes.
6. Press the main menu button to exit.
To Format Micro SD Card
NOTICE: Formatting the micro SD
card will erase all data.
1. Press the main menu button to show the Main
Menu.
2. Press the forward or back arrow to select the
Format Disk option.
3. Press the OK button to navigate to the next
screen.
4. Press the forward or back arrow to select NO or
YES.
5. Press the OK button to save changes and exit.
To Change Default Setup
NOTICE: Changing to default setup
will erase current settings and
restore factory settings.
1. Press the main menu button to show the Main
Menu.
2. Press the forward or back arrow to select the
Default Setup option.
3. Press the OK button to navigate to the next
screen.

English
15
4. Press the forward or back arrow to select NO or
YES.
5. Press the OK button to save changes and exit.
Operating Tips
 • UseonlyDeWALT 10.8 V lithium ion battery.
 • EnsuretheDeWALT battery is in good working
condition. If the low battery indicator light on
the screen is flashing, the battery needs to be
recharged.
 • Toextendbatterylife,makesuretoturnboth
the screen and the handle set off when not in
use.
 • Makesurethescreenisfullychargedbefore
operation.
MAINTENANCE
Your DeWALT inspection camera has been designed
to operate over a long period of time with a
minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and
regular cleaning.
The charger and battery pack are not serviceable.
There are no serviceable parts inside.
Cleaning
WARNING: Blow dirt and dust off with
clean, dry air at least once a week. To
minimize the risk of eye injury, always
wear proper eye protection when
performing this.
WARNING: Never use solvents or
other harsh chemicals for cleaning the
non-metallic parts of the tool. These
chemicals may weaken the materials
used in these parts. Use a cloth
dampened only with water and mild
soap. Never let any liquid get inside the
tool; never immerse any part of the tool
into a liquid.
CHARGER CLEANING INSTRUCTIONS
WARNING: Shock hazard. Disconnect
the charger from the AC outlet before
cleaning. Dirt and grease may be
removed from the exterior of the charger
using a cloth or soft non-metallic brush.
Do not use water or any cleaning
solutions.
Optional Accessories
WARNING: Since accessories, other
than those offered by DeWALT,have
not been tested with this product, use
of such accessories with this tool could
be hazardous. To reduce the risk of
injury, only DeWALT recommended
accessories should be used with this
product.
RECOMMENDED ACCESSORIES
• DCT4101–17mmdiametercameracable
 • DCT4102–9mmdiametercameracable
 • DCT4105–5.8mmdiametercameracable
 • DCT4103–17mmdiameter,0.9mlongcable
extension
 • HookandmagnetDCT410(availableonlyas
spare parts)
 • Hook,magnetandmirrorDCT411(available
only as spare parts)
Consult your dealer for further information on the
appropriate accessories.
Troubleshooting
 • Makesurethe10.8Vbatteryischarged.
 • Makesurethescreenisfullycharged.
 • Makesurethescreenisalwaysattachedto
the handle set. The picture may freeze if you
attempt to remove the screen from the handle
set while taking a photo or video.
 •Makesurethebatteryisinstalledonthehandle
set when in use.

English
16
 •Makesurethecameracableisattachedtothe
handle set properly.
 •Makesurethehandlesetisturnedonaswell
as the screen.
 •Make sure the back of the handle set is not
covered with debris so the screen slides on
easily and no damage to the screen occurs.
 • Ifthescreenfreezesorwon’tturnon,inserta
small object (i.e., paper clip end) into the reset
button (s) located on the back of the screen.
 •Ifthepictureisdim,rollthebrightnesscontrol
switch to brighten the LED light.
Protecting the Environment
Separate collection. This product must
not be disposed of with normal
household waste.
Should you find one day that your DeWALT product
needs replacement, or if it is of no further use to you,
do not dispose of it with household waste. Make this
product available for separate collection.
Separate collection of used products
and packaging allows materials to be
recycled and used again. Re-use of
recycled materials helps prevent
environmental pollution and reduces
the demand for raw materials.
Local regulations may provide for separate collection
of electrical products from the household, at
municipal waste sites or by the retailer when you
purchase a new product.
DeWALT provides a facility for the collection and
recycling of DeWALT products once they have
reached the end of their working life. To take
advantage of this service please return your product
to any authorised repair agent who will collect them
on our behalf.
You can check the location of your nearest
authorised repair agent by contacting your local
DeWALT office at the address indicated in this
manual. Alternatively, a list of authorised DeWALT
repair agents and full details of our after-sales
service and contacts are available on the Internet at:
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when
it fails to produce sufficient power on jobs which
were easily done before. At the end of its technical
life, discard it with due care for our environment:
 • Runthebatterypackdowncompletely,then
remove it from the tool.
 • Li-IONcellsarerecyclable.Takethemtoyour
dealer or a local recycling station. The collected
battery packs will be recycled or disposed of
properly.

简体中文
17
10.8 V 锂电充电式检修摄像机
DCT410、DCT411、DCT412
恭喜！
恭喜您选择了得伟工具。凭借多年的产品开发和
创新经验，得伟已经成为专业电动工具用户最可
靠的合作伙伴之一。
技术参数
DCT410 DCT411 DCT412
电压 VDC 10.8 10.8 10.8
型号 1 1 1
电池类型 锂离子 锂离子 锂离子
摄像机电缆
直径 mm 17 9 5.8
电缆长度 m 0.9 0.9 0.9
分辨率 dpi 320 x 480 320 x 480 320 x 480
屏幕尺寸 mm 69 x 50 69 x 50 69 x 50
重量
（不含电池组） kg 0.77 0.69 0.60
电池组 DCB125 DCB127
电池类型 锂离子 锂离子
电压 VDC 10.8 10.8
电池容量 A
h
1.3 2.0
重量 kg 0.2 0.2
充电器 DCB112
电源电压 VAC 220 V
电池类型 锂离子
大约 分钟 40 60
充电 (1.3 Ah 电池组) (2.0 Ah电池组)
时间
重量 kg 0.36
充电器 DCB107
电源电压 VAC 220V
电池类型 锂离子
大约 分钟 60 90
充电 (1.3 Ah 电池组) (2.0 Ah电池组)
时间
重量 kg 0.29
充电器 DCB105
电源电压 VAC 220 V
电池类型 锂离子
大约 分钟 25 40
充电 (1.3 Ah 电池组) (2.0 Ah电池组)
时间
重量 kg 0.49
警告：本产品属于 A 类产品。在家用环
境下，此产品可能会造成无线电干扰，
用户可能需要采取适当的措施。
警告：较高的静电电压可能会导致显
示屏故障，所有未保存的数据将丢失。
重新使用前，确保静电电压已消失，
并使用适当的针状物启动复位按钮。
随后摄像机显示屏将开始运行。
定义：安全指引
下列定义解释了各警示词的严重程度。请仔细阅
读本手册，并注意这些警示符号。
危险：表示存在紧急危险情况，如果不
加以避免，将导致死亡或严重伤害。
警告：表示存在潜在危险情况，如果不
加以避免，可能导致死亡或严重伤害。
警示：表示存在潜在危险情况，如果不
加以避免，可能导致轻度或中度伤害。
注意：表示不涉及人身伤害的情况，如
果不加以避免，可能导致财产损失。
表示存在触电危险。
表示存在火灾危险。
警告：为降低伤害风险，请阅读使用
手册。

简体中文
18
重要安全指示
• 请阅读这些指示。
• 请遵守这些指示。
• 注意所有警告。
• 遵守所有指示。
• 仅使用由制造商指定的配件 /附件。
• 所有维修应由合格的服务人员执行。当仪器发
生任何形式的损坏，暴露于雨水或湿气中，未
正常运行或发生掉落时，需要进行维修。
请保存好所有警告和守则，
以备将来查阅
工作场所安全
a) 保持工作场所清洁和明亮。杂乱或阴暗的地
方容易引发事故。
b) 让儿童和旁观者离开后才操作检修摄像机。
干扰可能会导致您控制不当。
人身安全
a) 保持警觉。操作检修摄像机时注意操作，
保持清醒。切勿在疲倦或治疗时或在药物
或酒精的影响下使用检修摄像机。操作检修
摄像机时注意力不集中可能会导致严重的人
身伤害。
b) 使用个人防护装备。始终佩戴护目镜。防
护装备，例如适当条件下使用的防尘罩、防
滑安全鞋、安全帽或听力保护设备等将减少
人身伤害。
c) 禁止手伸得太长。时刻注意脚下和身体平
衡。这样在意外情况下才能更好地控制检修
摄像机。
d) 穿着得当。切勿穿宽松的衣服或佩戴首饰。
让您的头发、衣服和手套远离运动部件。
宽松衣服、配饰或长发可能会卷入运动部
件中。
使用及注意事项
a) 将闲置的检修摄像机贮存在儿童所及范围
之外，并且不要让不熟悉检修摄像机或对
这些说明不了解的人员操作检修摄像机。
检修摄像机在未经培训的用户手中会发生危
险。
b) 按照使用说明以及作业条件和具体进行的
工作使用检修摄像机、附件等。将检修摄
像机用于非预期操作用途可能会导致危险情
况。
电池工具的使用及注意事项
a) 仅使用由得伟指定的充电器为电池充电。
使用适用于其他类型电池组的充电器充电可
能会引发火灾。
b) 不使用电池组时，要将电池组存储在远离
回形针、硬币、钥匙、钉子、螺钉或其他
可能使电池短路的小型金属物体。电池短路
可能会导致灼伤或火灾。
c) 在恶劣环境条件下，电池可能会喷出电解
液，请避免接触该液体。如果不小心接触
到电解液，请立即用清水冲洗。如果眼睛
接触到电解液，请寻求医疗救护。从电池喷
出的电解液可能会刺激皮肤或造成灼伤。
检修摄像机安全信息
警告：切勿拆卸或改装检修摄像机。
这些组件内没有可以维修的部件。若
您需要协助，请联系您当地的经销商。
• 不要在易爆环境，如有易燃液体、气体或粉尘
的环境下操作检修摄像机。检修摄像机产生的
火花会点燃粉尘或气体。
• 本检修摄像机仅可使用专门指定的得伟电池。
使用其他类型的电池会造成火灾危险。
• 本检修摄像机应存放于儿童和其他未经培训人
员的所及范围以外。工具在未经培训的用户手
中会发生危险。
• 切勿拆卸检修摄像机。这些组件内没有可供用
户维修的部件。
• 切勿在可能暴露于活动部件、危险化学品或电
荷的地方使用本装置。此类情况（如墙壁、管
道、汽车和机械）可能导致严重的人身伤害或
死亡。
