DeWalt DW311 User manual

DW311

B
Copyright
DeWALT
English (original instructions) 3

1
Fig. A
Fig. B
Fig. A
Fig. B
5
411
7 6
12
3
2
1
13
Fig. C
7
4
8
56

2
Fig. F
Fig. D 10
9
3
10
9
3
Fig. E
13
11

ENGLISH
3
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool
is switched off or when it is running but not actually doing
the job. This may significantly reduce the exposure level
over the total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm (relevant
for vibration), organisation of workpatterns.
DW311
Voltage VAC 230
Type 2
Power input W1200
No-load speed 0–2600
Stroke length mm 28
Cutting capacity in wood/metal profiles/plastic tubes mm 300/130/160
Weight kg 4.2
Noise values and vibration values (triax vector sum) according to EN62841-2-11
LPA (emission sound pressure level) dB(A) 92
LWA (sound power level) dB(A) 103
K (uncertainty for the given sound level) dB(A) 5
Cutting Board
Vibration emission value a
h
,B
= m/s221
Uncertainty K = m/s22.1
Cutting Wooden Beam
Vibration emission value a
h
,WB
= m/s217.5
Uncertainty K = m/s25.2
English (original instructions)
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
RECIPROCATING SABRE SAW
DW311
EC-Declaration of Conformity
Machinery Directive
Reciprocating Sabre Saw
DW311
DeWALT
declares that these products described under Technical
Data are in compliance with:
2006/42/EC, EN62841-1:2015, EN62841-2-11:2016
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
DeWALT
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
DeWALT
.
Markus Rompel
Vice-President Engineering, PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
10.03.2020

4
ENGLISH
c ) Prevent unintentional starting. Ensure the switch
is in the off‑position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust‑relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE
The term “power tool” in the warnings refers to your
mains‑operated (corded) power tool or battery‑operated (cordless)
powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non‑skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.
Batteries
Chargers/Charge Times (Minutes)
Cat #
DC
Weight
*Date code 201811475B or later
**Date code 201536 or later

5
ENGLISH
Package Contents
The package contains:
1 Reciprocating sabre saw
1 General purpose saw blade
1 Kitbox (K-models only)
1 Instruction manual
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the power supply corresponds to the voltage
on the ratingplate.
Your
DeWALT
tool is double insulated in accordance
with EN62841; therefore no earth wire isrequired.
If the supply cord is damaged, it must be replaced only by
DeWALT
or an authorised serviceorganisation.
Mains Plug Replacement
(U.K.& Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 13A.
Using an Extension Cable
If an extension cable is required, use an approved 3–core
extension cable suitable for the power input of this tool (see
Technical Data).The minimum conductor size is 1.5mm2; the
maximum length is 30m.
When using a cable reel, always unwind the cablecompletely.
Residual Risks
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of personal injury due to flyingparticles.
• Risk of burns due to accessories becoming hot
duringoperation.
• Risk of personal injury due to prolongeduse.
SAVE THESE INSTRUCTIONS
Checking and Changing the Saw Blade
• Only use saw blades conforming to the specifications
contained in these operatinginstructions.
• Only sharp saw blades in perfect working condition should
be used; cracked or bent saw blades should be discarded and
replaced atonce.
• Ensure that the saw blade is securelyfixed.
Additional Safety Instructions for
Reciprocating Sabre Saws
• ALWAYS wear a dust mask. Exposure to dust particles can
cause breathing difficulty and possibleinjury.
• Never switch on the tool when the saw blade is jammed in
the workpiece or in contact with thematerial.
• Keep hands away from moving parts. Never place your
hands near the cuttingarea.
• Use extra caution when cutting overhead and pay
particular attention to overhead wires which may be
hidden from view. Anticipate the path of falling branches
and debris ahead oftime.
• Do not operate this tool for long periods of time.
Vibration caused by the operating action of this tool may
cause permanent injury to fingers, hands, and arms. Use
gloves to provide extra cushion, take frequent rest periods, and
limit daily time ofuse.
Switching On and Off
• After switching off, never attempt to stop the saw blade with
yourfingers.
• Never put the saw down on a table or work bench unless
switched off. The saw blade will keep running briefly after the
tool has been switchedoff.
When Sawing
• When using saw blades specially designed for cutting wood
remove all nails and metal objects from the workpiece before
startingwork.
• Wherever possible, use clamps and vices to fasten the
workpiecesecurely.
• Do not attempt to saw extremely smallworkpieces.
• Do not bend too far forward. Make sure that you always stand
firmly, particularly on scaffolding andladders.
• Always hold the saw with bothhands.
• For cutting curves and pockets, use an adapted sawblade.
Safety Instructions for Reciprocating Saws
• Hold the power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own cord.
Cutting accessory contacting a "live" wire may make exposed
metal parts of the power tool "live" and could give the operator
an electricshock.
• Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
workpiece by hand or against your body leaves it unstable and
may lead to loss ofcontrol.
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
5) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool ismaintained.

6
ENGLISH
Setting the Pendulum Stroke (Fig.D)
The adjustable pendulum stroke guarantees a perfect cutting
stroke for different materials. The tool can be used in the
following operating modes:
Straight reciprocating motion: for cutting metal
and tubes and for finishingwood.
Orbital motion: for fast cutting ofwood.
• Turn the selector3 into the required position aligning the
mark9 with the arrow10.
Prior to Operation
Mount the appropriate type of saw blade. Use narrow saw
blades for cutting curves. Use flexible bimetal saw blades for
hard-to-reach positions (e.g. close to walls, etc.).
Setting the Adjustable Saw Shoe (Fig.C)
The saw shoe can be adjusted to limit the depth of cut and
prolong the life of your sawblade.
1. Push the release lever6down.
2. Slide the saw shoe5 into the desiredposition.
3. Push the lever up to secure the shoe inplace.
Mounting the Saw Blade (Fig.B)
1. Open the blade clamp collar7 to release the blade
clampingmechanism.
2. Insert the saw blade8 into the holder4 until it engages.
The blade can be installed with the teeth pointing down
orup.
3. Close the blade clamp collar to lock the blade
clampingmechanism.
To remove the saw blade, proceed in reverseorder.
Saw Blades
Material Recommended Saw Blade
ferrous metal fine-toothed
non ferrous metal coarse-toothed
wood coarse-toothed
plastic fine-toothed
A wide variety of dedicated saw blades is available as anoption.
WARNING: Always select your saw blade with greatcare.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Variable speed switch
2 Speed control dial
3 Pendulum stroke selector
4 Blade holder
5 Saw shoe
6 Shoe release lever
7 Blade clamp collar
Intended Use
Your DW311 reciprocating sabre saw has been designed for
professional sawing of wood, metal and tubes. The compact
design permits cutting extremely close to the edge of
difficultareas.
DO NOT use under wet conditions or in presence of flammable
liquids orgases.
These reciprocating saws are professional powertools.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
Use appropriate blades for cutting materials as mentioned
under the Saw Bladestable.
• Young children and the infirm.This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Date Code Position (Fig.A)
The date code 12, which also includes the year of manufacture,
is printed into thehousing.
Example:
XXXX XX XX
Year of Manufacture
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.

7
ENGLISH
WARNING:Use extra caution when cutting overhead and
pay particular attention to overhead wires that may be
hidden from view. Anticipate the path of falling branches
and debris ahead oftime.
WARNING: Inspect work site for hidden gas pipes, water
pipes, or electrical wires before making blind or plunge
cuts. Failure to do so may result in explosion, property
damage, electric shock, and/or serious personalinjury.
Sawing Up to a Projecting Edge (Fig.F)
Using a conventional blade installed upside down, cut up to the
projectededge.
Cutting Plastics
Always work at reduced speed. Carry out a test cut to check
whether the material is sensitive toheat.
Cutting Metal
When cutting thin metal always stabilize the workpiece with
wood on both sides. This guarantees clean cuts and prevents
damaging of thematerial.
For long, straight cuts draw a line on theworkpiece.
Apply a thin film of lubricant along the cutting line, switch on
the tool and follow the cuttingline.
Pocket/Plunge Cutting – Wood Only (Fig.E)
The initial step in pocket cutting is to measure the surface area
to be cut and mark clearly with a pencil, chalk or scriber. Use
the appropriate blade for the application. The blade should
be longer than 90mm and should extend past the shoe and
the thickness of the workpiece during the cut. Insert blade in
bladeclamp.
Next, tip the saw backward until the back edge of the shoe
is resting on the work surface and the blade clears the work
surface (position 1, Fig. E). Now switch motor on, and allow
saw to come up to speed. Grip saw firmly with both hands and
begin a slow, deliberate upward swing with the handle of the
saw, keeping the bottom of the shoe firmly in contact with
the workpiece (position 2, Fig. E). Blade will begin to feed into
material. Always be sure blade is completely through material
before continuing with pocketcut.
NOTE: In areas where blade visibility is limited, use the edge
of the saw shoe as a guide. Lines for any given cut should be
extended beyond edge of cut to bemade.
Flush-To Cutting (Fig.F)
The compact design of the saw motor housing permits
extremely close cutting to floors, corners and other
difficultareas.
Cutting (Fig. E, F)
WARNING: Always use eye protection. All users and
bystanders must wear approved eyeprotection.
WARNING: Exercise extra caution when cutting towards
operator. Always hold saw firmly with both hands
whilecutting.
Before cutting any type of material, be sure it is firmly anchored
or clamped to prevent slipping. Place blade lightly against
work to be cut, switch on saw motor and allow it to obtain
maximum speed before applying pressure. Whenever possible,
the saw shoe must be held firmly against the material being
cut (Fig.F). This will prevent the saw from jumping or vibrating
and minimise blade breakage. Any cuts that put pressure on the
blade such as angle or scroll cuts increase potential for vibration,
kickback, and bladebreakage.
Switching On and Off (Fig.A)
To run the tool, press the variable speed switch1. The pressure
exerted on the variable speed switch determines the toolspeed.
To stop the tool, release theswitch.
Always switch off the tool when work is finished and
beforeunplugging.
Setting the Electronic Sawing Speed (Fig.A)
The speed control dial2 can be used for advance setting of the
required range ofspeed.
Turn the electronic speed control dial to the required level. The
required setting depends on the thickness and kind ofmaterial.
Use high speeds for sawing soft materials such as wood. Use
low speeds for sawingmetal.
WARNING: After using the tool for an extended period
on low speed settings, run it for approx. 3 minutes on
maximum no‑loadspeed.
Proper Hand Position (Fig. F)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the side front
grip11, with the other hand on the back
handle13.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Cutting Masonry
WARNING: When sawing asbestos cement hazardous
dust may be produced. Follow the statutory guidelines
and observe the recommendations issued by the asbestos
cementmanufacturers.

8
ENGLISH
Protecting the Environment
Separate collection. Products marked with this symbol
must not be disposed of with normal householdwaste.
Products contain materials that can be recovered or
recycled reducing the demand for raw materials. Please
recycle electrical products according to local provisions. Further
information is available at www.2helpU.com.
Optional Accessories
WARNING: Since accessories, other than those offered
by
DeWALT
, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only
DeWALT
recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and
around the air vents. Wear approved eye protection and
approved dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.

9

Belgique et
Luxembourg België en Luxemburg
DeWALT - Belgium BVBA
Egide Walschaertsstraat 16
2800 Mechelen
Tel: NL 32 15 47 37 63
Tel: FR 32 15 47 37 64
Fax: 32 15 47 37 99
www.dewalt.be
Danmark DeWALT (Stanley Black&Decker AS)
Roskildevej 22
2620 Albertslund
Tel: 70 20 15 10
Fax: 70 22 49 10
www.dewalt.dk
Deutschland DeWALT
Richard Klinger Str. 11
65510 Idstein
Tel: 06126-21-0
Fax: 06126-21-2770
www.dewalt.de
Ελλάς DeWALT (Ελλάς) Α.Ε.
EΔΡΑ-ΓΡΑΦΕΙΑ : Στράβωνος 7
& Λ. Βουλιαγμένης, Γλυφάδα 166 74, Αθήνα
SERVICE : Ημερος Τόπος 2 (Χάνι Αδάμ) – 193 00 Ασπρόπυργος
Τηλ: 00302108981616
Φαξ: 00302108983570
www.dewalt.gr
España DeWALT Ibérica, S.C.A.
Parc de Negocios “Mas Blau”
Edificio Muntadas, c/Bergadá, 1, Of. A6
08820 El Prat de Llobregat (Barcelona)
Tel: 934 797 400
Fax: 934 797 419
www.dewalt.es
France DeWALT (Stanley Black & Decker France SAS)
62 Chemin de la Bruyère
CS 60105,
69574 DARDILLY Cedex
Tel: 04 72 20 39 20
Fax: 04 72 20 39 00
www.dewalt.fr
Schweiz
Suisse
Svizzera
DeWALT
In der Luberzen 42
8902 Urdorf
Tel: 044 - 755 60 70
Fax: 044 - 730 70 67
www.dewalt.ch
Ireland DeWALT
Building 4500, Kinsale Road
Cork Airport Business Park
Cork, Ireland
Tel: 00353-2781800
Fax: 01278 1811
www.dewalt.ie
Italia DeWALT
via Energypark 6
20871 Vimercate (MB), IT
Tel: 800-014353
39 039-9590200
Fax: 39 039-9590311
www.dewalt.it
Nederlands DeWALT
Netherlands BVPostbus 83,
6120 AB BORN
Tel: 31 164 283 063
Fax: 31 164 283 200
www.dewalt.nl
Norge DeWALT
Postboks 4613
0405 Oslo, Norge
Tel: 45 25 13 00
Fax: 45 25 08 00
www.dewalt.no
Österreich DeWALT
Werkzeug Vertriebsges m.b.H
Oberlaaerstrasse 248, A-1230 Wien
Tel: 01 - 66116 - 0
Fax: 01 - 66116 - 614
www.dewalt.at
Portugal DeWALT
Ed. D Dinis, Quina da Fonte
Rua dos Malhoes 2 2A 2º Esq.
Oeiras e S. Juliao da Barra, paço de Arcos e Caxias
2770 071 Paço de Arcos
Tel: +351 214667500
Fax: +351214667580
www.dewalt.pt
Suomi DeWALT
PL47
00521 Helsinki, Suomi
Puh: 010 400 4333
Faksi: 0800 411 340
www.dewalt.fi
Sverige DeWALT
BOX 94
43122 Mölndal
Sverige
Tel: 031 68 61 60
Fax: 031 68 60 08
www.dewalt.se
Türkiye Sanayi ve Ticareet Bakanlığı tebliğince kullanim ömrü 7 yıldır.
Stanley Black & Decker Turkey Alet Üretim San. Tic. Ltd.Şti.
AND Kozyataği - İçerenköy Mah. Umut Sok. AND Ofis Sit. No: 10-12 / 82-83-84
Ataşehir/İstanbul, Türkiye
Tel: +90 216 665 2900
Faks: +90 216 665 2901
www.dewalt.com.tr
United Kingdom DeWALT, 210 Bath Road;
Slough, Berks SL1 3YD
Tel: 01753-567055
Fax: 01753-572112
www.dewalt.co.uk
Australia DeWALT
810 Whitehorse Road Box Hill
VIC 3128 Australia
Tel: Aust 1800 338 002
Tel: NZ 0800 339 258
www.dewalt.com.au
www.dewalt.co.nz
Middle East Africa DeWALT
P.O. Box - 17164,
Jebel Ali Free Zone (South), Dubai, UAE
Tel: 971 4 812 7400
Fax: 971 4 2822765
www.dewalt.ae
N803955 03/20
Other manuals for DW311
2
Table of contents
Other DeWalt Saw manuals

DeWalt
DeWalt DWS771 User manual

DeWalt
DeWalt DCS575 User manual

DeWalt
DeWalt D28730 Series User manual

DeWalt
DeWalt D23620-XE User manual

DeWalt
DeWalt DW715 User manual

DeWalt
DeWalt D27105 User manual

DeWalt
DeWalt DCS387 User manual

DeWalt
DeWalt 7749 User manual

DeWalt
DeWalt DWS778 User manual

DeWalt
DeWalt DCS577X1 User manual

DeWalt
DeWalt DWS780 User manual

DeWalt
DeWalt DCS575 User manual

DeWalt
DeWalt D23700 User manual

DeWalt
DeWalt DCS727 User manual

DeWalt
DeWalt DW712 User manual

DeWalt
DeWalt B&D 3660 User manual

DeWalt
DeWalt D27400T User manual

DeWalt
DeWalt Multi-Cutter DW872 User manual

DeWalt
DeWalt DWS716XPS User manual

DeWalt
DeWalt DC390 User manual
