ENGLISH
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
EC-Declaration of Conformity
Machinery Directive
Table Saw
DWE7485
DeWALT
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841-1:2015+AC:2015,
EN62841-3-1:2014+AC:2015 + A11:2017.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
DeWALT
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
DeWALT
.
Markus Rompel
Vice-President Engineering, PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
09.08.2019
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
English (original instructions)
DWE7485
(QS, GB)
DWE7485
(XE)
DWE7485
(LX)
Voltage VDC 230 220–240 115
Type 1 1 1
Rated input power W1850 1850 1700
No load speed min-1 5800 5800 5800
Blade diameter mm 210 210 210
Blade bore mm 30 30 30
Blade kerf mm 1.8 1.8 1.8
Blade body thickness mm 1.3 1.3 1.3
Riving knife thickness mm 1.6 1.6 1.6
Depth of cut at 90° mm 65 65 65
Depth of bevel cut at 45° mm 45 45 45
Ripping capacity
(Right of blade)
mm 622.3 622.3 622.3
Ripping capacity (Left of blade) mm 318 318 318
Work surface dimensions mm 485 x 485 485 x 485 485 x 485
Overall dimensions mm 605 x 605
x 330
605 x 605
x 330
605 x 605
x 330
Weight kg 22 22 22
Noise values and/or vibration values (triax vector sum) according to
EN62841-1-2015:
LPA (emission sound pressure
level)
dB(A) 90 90 91
LWA (sound power level) dB(A) 107 107 108
K (uncertainty for the given
sound level)
dB(A) 3 3 3
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
TABLE SAW
DWE7485

7
ENGLISH
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
Batteries
Chargers/Charge Times (Minutes)
Cat #
DC
Weight
*Date code 201811475B or later
**Date code 201536 or later
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.

8
ENGLISH
Safety Instructions for Table Saws
1) Guarding Related Warnings
a ) Keep guards in place. Guards must be in working
order and be properly mounted. A guard that is loose,
damaged, or is not functioning correctly must be repaired
orreplaced.
b ) Always use saw blade guard, riving knife for every
through–cutting operation. For through-cutting
operations where the saw blade cuts completely through
the thickness of the workpiece, the guard and other safety
devices help reduce the risk ofinjury.
c ) Immediately reattach the guarding system after
completing an operation (such as rabbeting or
resawing cuts) which requires removal of the guard
or riving knife. The guard and riving knife help to reduce
the risk ofinjury.
d ) Make sure the saw blade is not contacting the guard,
riving knife or the workpiece before the switch is
turned on. Inadvertent contact of these items with the
saw blade could cause a hazardouscondition.
e ) Adjust the riving knife as described in this instruction
manual. Incorrect spacing, positioning and alignment
can make the riving knife ineffective in reducing the
likelihood ofkickback.
f ) For the riving knife to work, they must be engaged in
the workpiece. The riving knife is ineffective when cutting
workpieces that are too short to be engaged with the
riving knife. Under these conditions a kickback cannot be
prevented by the riving knife .
g ) Use the appropriate saw blade for the riving knife.
For the riving knife to function properly, the saw blade
diameter must match the appropriate riving knife and the
body of the saw blade must be thinner than the thickness
of the riving knife and the cutting width of the saw blade
must be wider than the thickness of the rivingknife.
2) Cutting Procedures Warnings
a ) DANGER: Never place your fingers or hands in
the vicinity or in line with the saw blade.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
5) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
Amoment of inattention or a slip could direct your hand
towards the saw blade and result in serious
personalinjury.
b ) Feed the workpiece into the saw blade only against
the direction of rotation. Feeding the workpiece in the
same direction that the saw blade is rotating above the
table may result in the workpiece, and your hand, being
pulled into the sawblade.
c ) Never use the mitre gauge to feed the workpiece
when ripping and do not use the rip fence as a
length stop when cross cutting with the mitre gauge.
Guiding the workpiece with the rip fence and the mitre
gauge at the same time increases the likelihood of saw
blade binding andkickback.
d ) When ripping, always apply the workpiece feeding
force between the fence and the saw blade. Use a
push stick when the distance between the fence and
the saw blade is less than 150 mm, and use a push
block when this distance is less than 50 mm. “Work
helping” devices will keep your hand at a safe distance
from the sawblade.
e ) Use only the push stick provided by the
manufacturer or constructed in accordance with the
instructions. This push stick provides sufficient distance
of the hand from the sawblade.
f ) Never use a damaged or cut push stick. A damaged
push stick may break causing your hand to slip into the
sawblade.
g ) Do not perform any operation “freehand”. Always
use either the rip fence or the mitre gauge to
position and guide the workpiece. “Freehand” means
using your hands to support or guide the workpiece, in lieu
of a rip fence or mitre gauge. Freehand sawing leads to
misalignment, binding andkickback.
h ) Never reach around or over a rotating saw blade.
Reaching for a workpiece may lead to accidental contact
with the moving sawblade.
i ) Provide auxiliary workpiece support to the rear
and/or sides of the saw table for long and/or wide
workpieces to keep them level. A long and/or wide
workpiece has a tendency to pivot on the table’s edge,
causing loss of control, saw blade binding andkickback.
j ) Feed workpiece at an even pace. Do not bend or
twist the workpiece. If jamming occurs, turn the
tool off immediately, unplug the tool then clear the
jam. Jamming the saw blade by the workpiece can cause
kickback or stall themotor.
k ) Do not remove pieces of cut-off material while the
saw is running. The material may become trapped
between the fence or inside the saw blade guard and the
saw blade pulling your fingers into the saw blade. Turn
the saw off and wait until the saw blade stops before
removingmaterial.
l ) Use an auxiliary fence in contact with the table top
when ripping workpieces less than 2 mm thick. A

9
ENGLISH
thin workpiece may wedge under the rip fence and create
akickback.
3) Kickback Causes and Related Warnings
Kickback is a sudden reaction of the workpiece due to a pinched,
jammed saw blade or misaligned line of cut in the workpiece with
respect to the saw blade or when a part of the workpiece binds
between the saw blade and the rip fence or other fixedobject.
Most frequently during kickback, the workpiece is lifted from the
table by the rear portion of the saw blade and is propelled towards
the operator. Kickback is the result of saw misuse and/or incorrect
operating procedures or conditions and can be avoided by taking
proper precautions as givenbelow.
a ) Never stand directly in line with the saw blade.
Always position your body on the same side of
the saw blade as the fence. Kickback may propel the
workpiece at high velocity towards anyone standing in
front and in line with the sawblade.
b ) Never reach over or in back of the saw blade to pull
or to support the workpiece. Accidental contact with
the saw blade may occur or kickback may drag your
fingers into the sawblade.
c ) Never hold and press the workpiece that is being
cut off against the rotating saw blade. Pressing the
workpiece being cut off against the saw blade will create a
binding condition andkickback.
d ) Align the fence to be parallel with the saw blade. A
misaligned fence will pinch the workpiece against the saw
blade and createkickback.
e ) Use a featherboard to guide the workpiece against
the table and fence when making non-through cuts
such as rabbeting or resawing cuts. A featherboard
helps to control the workpiece in the event of akickback.
f ) Use extra caution when making a cut into blind
areas of assembled workpieces. The protruding saw
blade may cut objects that can causekickback.
g ) Support large panels to minimise the risk of saw
blade pinching and kickback. Large panels tend to sag
under their own weight. Support(s) must be placed under
all portions of the panel overhanging the tabletop.
h ) Use extra caution when cutting a workpiece that is
twisted, knotted, warped or does not have a straight
edge to guide it with a mitre gauge or along the
fence. A warped, knotted, or twisted workpiece is unstable
and causes misalignment of the kerf with the saw blade,
binding andkickback.
i ) Never cut more than one workpiece, stacked
vertically or horizontally. The saw blade could pick up
one or more pieces and causekickback.
j ) When restarting the saw with the saw blade in the
workpiece, centre the saw blade in the kerf so that
the saw teeth are not engaged in the material. If the
saw blade binds, it may lift up the workpiece and cause
kickback when the saw isrestarted.
k ) Keep saw blades clean, sharp, and with sufficient
set. Never use warped saw blades or saw blades with
cracked or broken teeth. Sharp and properly set saw
blades minimise binding, stalling andkickback.
4) Table Saw Operating Procedure Warnings
a ) Turn off the table saw and disconnect the power
cord when removing the table insert, changing
the saw blade or making adjustments to the riving
knife, or saw blade guard, and when the machine
is left unattended. Precautionary measures will
avoidaccidents.
b ) Never leave the table saw running unattended.
Turn it off and don’t leave the tool until it comes
to a complete stop. An unattended running saw is an
uncontrolledhazard.
c ) Locate the table saw in a well-lit and level area
where you can maintain good footing and balance.
It should be installed in an area that provides
enough room to easily handle the size of your
workpiece. Cramped, dark areas, and uneven slippery
floors inviteaccidents.
d ) Frequently clean and remove sawdust from under
the saw table and/or the dust collection device.
Accumulated sawdust is combustible and may self-ignite.
e ) The table saw must be secured. A table saw that is not
properly secured may move or tipover.
f ) Remove tools, wood scraps, etc. from the table
before the table saw is turned on. Distraction or a
potential jam can bedangerous.
g ) Always use saw blades with correct size and shape
(diamond versus round) of arbour holes. Saw blades
that do not match the mounting hardware of the saw will
run off-centre, causing loss ofcontrol.
h ) Never use damaged or incorrect saw blade mounting
means such as flanges, saw blade washers, bolts or
nuts. These mounting means were specially designed for
your saw, for safe operation and optimumperformance.
i ) Never stand on the table saw, do not use it as a
stepping stool. Serious injury could occur if the tool is
tipped or if the cutting tool is accidentallycontacted.
j ) Make sure that the saw blade is installed to rotate
in the proper direction. Do not use grinding wheels,
wire brushes, or abrasive wheels on a table saw.
Improper saw blade installation or use of accessories not
recommended may cause seriousinjury.
Additional Safety Rules for Saw Benches
WARNING: Cutting plastics, sap coated wood, and other
materials may cause melted material to accumulate on
the blade tips and the body of the saw blade, increasing
the risk of blade overheating and binding whilecutting.
• Make sure that the blade rotates in the correct direction and
that the teeth are pointing to the front of the sawbench.
• Be sure all clamp handles are tight before starting
anyoperation.

10
ENGLISH
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the power supply corresponds to the voltage
on the ratingplate.
Your
DeWALT
tool is double insulated in accordance
with EN62841; therefore no earth wire isrequired.
If the supply cord is damaged, it must be replaced only by
DeWALT
or an authorised serviceorganisation.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA or less.
NOTE: This device is intended for the connection to a power
supply system with maximum permissible system impedance
Zmax of 0.25 Ω at the interface point (power service box)
of user’s supply. The user has to ensure that this device is
connected only to a power system which fulfills the requirement
above. If necessary, the user can ask the public power supply
company for the system impedance at the interfacepoint.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 13A.
Using an Extension Cable
If an extension cable is required, use an approved 3–core
extension cable suitable for the power input of this tool (see
Technical Data).The minimum conductor size is 1.5 mm2; the
maximum length is 30m.
When using a cable reel, always unwind the cablecompletely.
Residual risks
The following risks are inherent to the use of saws:
• injuries caused by touching the rotating parts
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Be sure all blade and flanges are clean and the larger face
of the clamp washer is against the blade. Tighten the arbor
nutsecurely.
• Make sure that the riving knife is adjusted to the correct
distance from the blade - maximum 8mm.
• Never operate the saw without the upper and lower guards
inplace.
• Do not apply lubricants to the blade when it isrunning.
• Always keep the push stick in its store place when not inuse.
• Do not use the guard for handling ortransportation.
• Do not exert side pressure on the sawblade.
• Never cut light alloy. The machine is not designed for
thisapplication.
• Do not use abrasive disc or diamond cuttingwheels.
• Rabbeting, slotting or grooving is notallowed.
• In case of machine failure, immediately switch the machine
off and remove from the power source. Report the failure and
mark the machine in suitable form which prevents that other
persons use the defectivemachine.
• When the saw blade is blocked due to abnormal feed force
during cutting, ALWAYS switch the machine off and remove
from the power source. Remove the workpiece and ensure that
the saw blade runs free. Turn the machine on and start a new
cutting operation with reduced feedforce.
• NEVER attempt to cut a stack of loose pieces of material
which could cause loss of control or kickback. Support all
materialssecurely.
• Take care that the blade guard is properly positioned. When
sawing, it must always face against theworkpiece.
Saw Blades
• Do not use saw blades that do not conform to the dimensions
stated in the Technical Data. Do not use any spacers to make
a blade fit onto the spindle. Use only the blades specified in this
manual, complying with EN847-1, if intended for wood and
similarmaterials.
• The maximunm speed of the saw blade shall always be
greater than or at least equal to the speed marked on the
rating plate of thetool.
• The saw blade diameter must be in accordance with the
markings on rating plate of thetool.
• Consider applying specially designed noise-reductionblades.
• Do not use high steel (HS) sawblades.
• Do not use cracked or damaged sawblades.
• Ensure that the chosen saw blade is suitable for the material
to becut.
• Always wear gloves for handling saw blades and rough
material. Saw blades should be carried in a holder
whereverpracticable.
• Impairment ofhearing.
• Risk of accidents caused by the uncovered parts of the rotating
sawblade.
• Risk of injury when changing the saw blade with
unprotectedhands.
• Risk of squeezing fingers when opening theguards.
• Health hazards caused by breathing dust developed when
sawing wood, especially oak, beech andMDF.
The following factors are of influence to noise production:
• the material to be cut
• the type of saw blade
• the feed force
• machine maintenance
The following factors are of influence to dust exposure:
• worn saw blade
• dust extractor with air velocity less than 20 m/s
• workpiece not exactly guided

11
ENGLISH
Unpacking
• Remove the saw from the packaging materialcarefully.
• The machine is fully assembled except for the rip fence,
mitre gauge, dust adapter and blade guardassembly.
• Finalise the assembly following the instructions as
describedbelow.
Mounting the Saw Blade (Fig. A, B)
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
WARNING: To reduce the risk of injury, wear gloves when
handling the sawblade.
WARNING: The teeth of a new blade are very sharp and
can bedangerous.
WARNING: The saw blade MUST be replaced as described
in this section. ONLY use saw blades as specified under
Technical Data. We suggest DT99565. NEVER fit other
sawblades.
NOTE: This tool has blade installed fromfactory.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Description (Fig. A, C)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Table
2 Blade
3 Rip scale indicator
4 Fine adjust knob
5 Rail lock lever
6 Blade height adjustment
wheel
7 Bevel lock lever
8 ON/OFF assembly
9 Mounting holes
10 Mitre gauge
11 Blade guard assembly
12 Carry handle
13 Dust collection port
14 Guard dust collection port
15 Throat plate
Date Code Position (Fig. A)
The date code 25, which also includes the year of manufacture,
is printed into thehousing.
Example:
2019 XX XX
Year of Manufacture
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Wear facemask.
Keep hands away from cutting area and theblade.
Carryingpoint.
Package Contents
The package contains:
1 Partly assembled machine
1 Rip fence assembly
1 Mitre fence
1 Saw blade
1 Upper blade guard assembly
1 Throat plate
2 Blade wrenches
1 Dust extraction adapter
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
16 Rip fence
17 Rip fence latch
18 Narrow ripping fence/
support extension
19 Blade wrenches (stored
position)
20 Push stick (stored position)
21 Riving knife (non-through
sawing) (Fig.C)
22 Mitre gauge storage
23 Cable holder
24 DE7400 brackets mounting
holes
Intended Use
Your table saw has been designed for professional ripping,
cross-cutting, mitreing and bevelling with various materials as
wood analogous materials andplastic.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This table saw is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.

12
ENGLISH
1. Raise the saw blade arbour to its maximum height by
turning the blade height adjustment wheel6clockwise.
2. Remove the throat plate15. Refer to Mounting the
ThroatPlate.
3. Using wrenches19, loosen and remove the arbour nut26
and clamp washer27 from the saw arbour by turning anti-
clockwise.
4. Place the saw blade on to the arbour28 making sure the
teeth of the blade2 point down at the front of the table.
Assemble the washers and arbour nut to the spindle and
tighten arbour nut26 as far as possible by hand, making
sure that the saw blade is against the inner washer and the
outer clamp washer27 is against the blade. Ensure the
largest diameter of the flange is against the blade. Ensure
the spindle and washers are free from dust anddebris.
5. To keep the spindle from rotating when tightening the
arbour nut, use the open end of the blade wrench19 to
secure thespindle.
6. Using the closed end of the blade wrench, tighten the
arbour nut 26 firmly by turning itclockwise.
7. Replace the throatplate.
WARNING: Always check the rip fence pointer and the
blade guard assembly after having changed theblade.
Mounting/Removing the Blade Guard
Assembly/Riving Knife (Fig. A, C)
WARNING: Use the guard assembly for all
throughcutting.
1. Raise the saw blade arbour to its maximumheight.
2. Loosen the riving knife lock knob29 (minimum of
threeturns).
3. To disengage riving knife lock pin, pull lock knob as
indicated by the black arrows on theknob.
4. While pulling the lock knob, lift the riving knife out of the
clamp. Then slide the blade guard assembly 11 into the
clamp until it bottomsout.
NOTE: Do not install both blade guard assembly and riving
knife into the clamp at the sametime.
5. Release the lock knob to engage the lock pin. Give the blade
guard a slight pull upwards to ensure pin isengaged.
6. Tighten the riving knife lockknob.
NOTE: Follow the same procedure for the rivingknife.
WARNING: Before connecting the table saw to the power
source or operating the saw, always inspect the blade
guard assembly for proper alignment and clearance
with saw blade. Check alignment after each change of
bevelangle.
WARNING: To reduce the risk of serious personal injury,
DO NOT operate saw if blade assembly is not securely
clamped inplace.
When properly aligned, the riving knife21 will be in line with
the blade at both table top level, and at the top of the blade.
Using a straight edge, ensure that the blade2 is aligned with
the riving knife21. With power disconnected, operate the
blade tilt and height adjustments through the extremes of
travel and insure the blade guard assembly clears the blade in
alloperations.
WARNING: Correct mounting and alignment of the blade
guard assembly is essential to safeoperation!
Mounting the Throat Plate (Fig. D)
1. Align the throat plate15 as shown in FigureD, and insert
the tabs on the back of the throat plate into the holes on the
back of the tableopening.
2. Turn the locking screw30 with a screw driver clockwise 90°
to lock the table insert inplace.
3. The throat plate includes four adjustment screws which
raise or lower the throat plate. When properly adjusted, the
front of the throat plate should be flush or slightly below the
surface of the table top and secured in place. The rear of the
throat plate should be flush or slightly above the tabletop.
WARNING: Never use the machine without the throat
plate. Immediately replace the throatplate when worn
ordamaged.
Removing the Throat Plate
1. Remove the throat plate15 by turning the locking
screw30 with a screw driver 90˚ anti-clockwise
2. Pull throat plate up and forward to expose the inside of the
saw. DO NOT operate the saw without the throatplate.
Fitting the Rip Fence (Fig. E)
The rip fence can be installed in two positions on the right
(Position 1 47 for 0mm to 510mm ripping, and Position2 47
for 100mm to 610mm ripping.) and one position on the left of
your tablesaw.
1. Unlock the rip fence latches17.
2. Holding the fence at an angle, align the locator pins 47
(front and back) on the fence rails with the fence head
slots31.
3. Slide the head slots onto the pins and rotate the fence down
until it rests on therails.
4. Lock the fence in place by closing the front and back
latches17 onto therails.
Fixing to Workbench (Fig. A)
• The machine frame between the feet on each side is
provided with two holes9 which allow fixing on a
workbench. Use the holesdiagonally.
• To improve the handling, fix the machine onto a piece of
plywood a minimum of 15 mmthick.
When in use, the plywood sheet can be clamped to the
workbench. This allows easier transportation of the machine, by
releasing theclamps.
Holes 24 are also provided under under the saw feet for
mounting to DE7400brackets.

13
ENGLISH
ADJUSTMENTS
Blade Adjustment
Blade Alignment (Parallel to Mitre Slot) (Fig.F)
WARNING: Cut Hazard. Check the blade at 0˚ and 45˚
to make sure blade does not hit the throat plate, causing
personalinjury.
If the blade appears to be out of alignment with the mitre slot
on the table top, it will require calibration for alignment. To
realign the blade and mitre slot, use the following procedure:
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
1. Using a 5mm hex wrench, loosen rear pivot bracket
fasteners32, located on the underside of the table, just
enough to allow the bracket to move side-to-side.
2. Adjust the bracket until the blade is parallel to the mitre
gaugeslot.
3. Tighten the rear pivot bracket fasteners to 12.5–13.6 Nm.
Blade Height Adjustment(Fig.A)
The blade can be raised and lowered by turning the blade
height adjustment wheel6.
Make sure the top three teeth of the blade are just breaking
through the upper surface of the workpiece when sawing. This
will ensure that the maximum number of teeth are removing
material at any given time, thus giving optimumperformance.
Aligning Guard Assembly to Blade (Fig. G)
1. Remove the throat plate. Refer to Removing Throat Plate
underAssembly andAdjustments.
2. Raise the blade to full depth of cut and 0° bevelangle.
3. Locate the three small set screws33. These screws will be
used to adjust the riving knifeposition.
4. Lay a straight edge on the table against two blade tips. The
riving knife should not touch the straightedge.
5. If adjustment is needed, loosen the two larger lock
screws34.
6. Use the small set screws33 to adjust the riving knife
position. Lay the straight edge on the opposite side of the
blade and repeat adjustments asneeded.
7. Lightly tighten the two larger lock screws34.
8. Place a square flat against the riving knife to verify the riving
knife is vertical and in-line with theblade.
9. If needed, use the set screws to bring the riving knife vertical
with thesquare.
10. Repeat step 4 to verify position of rivingknife. Repeat 5
through9 ifnecessary.
11. Fully tighten the two larger lock screws34.
Parallel Adjustment (Fig. A, H, I)
For optimum performance, the blade must be parallel to the
rip fence. This adjustment has been made at the factory. To
re-adjust:
Position 1 Fence Alignment
1. Install the fence in position 1 and unlock the rail lock
lever5. Locate both locator pins 47 that support the fence
on the front and rearrails.
2. Loosen the rear locator pin screw and adjust the allignment
of the fence in the groove until the fence face is parallel to
the blade. Make sure you measure from the fence face to
the front and back of the blade to ensurealignment.
3. Tighten the locator screw and repeat on the left side of
theblade.
4. Check rip scale pointer adjustment(Fig.I).
Position 2 Fence Alignment (Fig. H)
1. To align position 2 fence locator pins 47, ensure
position 1 pins have been aligned, refer to Position 1
FenceAlignment.
2. Loosen the position 2 pins, then using the holes on the
blade wrench19 as a guide for positioning, align the
pins(Fig.H).
3. Tighten the locator pins(front andrear).
Adjusting the Rip Scale (Fig. H, I)
1. Unlock the rail lock lever5.
2. Set the blade at 0° bevel and move the fence in until it
touches theblade.
3. Lock the rail locklever.
4. Loosen the rip scale indicator screws35 and set the rip
scale indicator to read zero(O). Retighten the rip scale
indicator screws. The yellow rip scale(top) reads correctly
only when the fence is mounted on the right side of the
blade and is in position 1 47 (for 0mm to 510mm ripping)
not the 610mm rip position. The white scale(bottom)
reads correctly only when the fence is mounted on the
right side of the blade and in position 2 47 (for 100mm to
610mmripping).
The rip scale reads correctly only when the fence is mounted to
the right of theblade.
Rail Lock Adjustment (Fig. I, J)
The rail lock has been factory-set. If you need to re-adjust,
proceed as follows:
1. Lock the rail lock lever5.
2. On the underside of the saw, loosen the jam nut36.
3. Tighten the hex rod37 until the spring on the locking
system is compressed creating the desired tension on the
rail lock lever. Retighten the jam nut against the hexrod.
4. Flip the saw over and check that the fence does not move
when the lock lever is engaged. If the fence is still loose,
tighten the springfurther.

14
ENGLISH
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
Bevel Stop And Pointer Adjustment (Fig. K)
1. Raise the blade fully by rotating the blade height
adjustment wheel6 clockwise until itstops.
2. Unlock the bevel lock lever7 by pushing it up and to the
right. Loosen the bevel stop screw38.
3. Place a square flat against the table top and against the
blade between teeth. Ensure the bevel lock lever is in its
unlocked, or up,position.
4. Using the bevel lock lever, adjust the bevel angle until it is
flat against thesquare.
5. Tighten the bevel lock lever by pushing itdown.
6. Turn the bevel stop screw38 to rotate the cam until
it firmly contacts the bearing block. Tighten the bevel
stopscrew.
7. Check the bevel angle scale. If the pointer does not read 0°,
loosen pointer screw39 and move the pointer so it reads
correctly. Retighten the pointerscrew.
8. Repeat at 45°, but do not adjustpointer.
Mitre Gauge Adjustment (Fig. A)
To adjust mitre gauge10 loosen knob, set to desired angle and
tightenknob.
Body and Hand Position
Proper positioning of your body and hands when operating the
table saw will make cutting easier, more accurate andsafer.
WARNING:
• Never place your hands near the cuttingarea.
• Place your hands no closer than 150mm from
theblade.
• Do not cross yourhands.
• Keep both feet firmly on the floor and maintain
properbalance.
Prior to Operation
WARNING:
• Install the appropriate saw blade. Do not use
excessively worn blades.The maximum rotation speed
of the tool must not exceed that of the sawblade.
• Do not attempt to cut excessively smallpieces.
• Allow the blade to cut freely. Do notforce.
• Allow the motor to reach full speed beforecutting.
To reduce effects of increased vibration, make sure the
environment is not too cold, the machine and accessory are well
maintained and the workpiece size is suitable for thismachine.
WARNING:
• Always observe the safety instructions and
applicableregulations.
• Ensure the machine is placed to satisfy ergonomic
conditions in terms of table height and stability. The
machine site shall be chosen so that the operator
has a good overview and enough free surrounding
space around the machine that allow handling of the
workpiece without anyrestrictions.
• Install the appropriate saw blade. Do not use
excessively worn blades. The maximum rotation speed
of the tool must not exceed that of the sawblade.
• Do not attempt to cut excessively smallpieces.
• Allow the blade to cut freely. Do notforce.
• Allow the motor to reach full speed beforecutting.
• Make sure all locking knobs and clamp handles
aretight.
• Never place either hand in the blade area when the
saw is connected to the electrical powersource.
• Never use your saw for freehandcuts!
• Do not saw warped, bowed or cupped workpieces.
There must be at least one straight, smooth side to go
against the rip fence or mitrefence.
• Always support long workpieces to preventkickback.
• Do not remove any cut-offs from the blade area while
the blade isrunning.
Switching On and Off (Fig. A, L)
The on/off assembly8 of your saw bench offers
multipleadvantages:
• No-volt release function: should the power be shut off for
any reason, the switch has to be deliberatelyreactivated.
• To switch the machine on, press the green startbutton 40.
• To switch the machine off, press the red stopbutton 41 .
Lock Off Feature Instructions
A cover above the switch folds down for insertion of a padlock
to lock the saw off. A padlock with a maximum diameter of
6.35mm and minimum clearance of 76.2 mm isrecommended.
Rip Fence Operation (Fig. A, M)
Rail Lock Lever
The rail lock lever5 locks the fence in place preventing
movement during cutting. To lock the rail lever, push it down
and toward the rear of the saw. To unlock, pull it up and toward
the front of thesaw.
NOTE: When ripping, always lock the rail locklever.
Work Support Extension /Narrow Ripping Fence
Your table saw is equipped with a work support extension to
support work that extends beyond the sawtable.

15
ENGLISH
To use the narrow ripping fence in the work support position,
rotate it from its stored position as shown in FigureM, and
slide the pins into the lower sets of slots42 on both ends of
thefence.
To use the narrow ripping fence in the narrow ripping position,
snap the pins into the upper sets of slots43 on both ends of
the fence. This feature will allow 51mm of extra clearance to the
blade. Refer to FigureM.
NOTE: Retract the work support extension or adjust to narrow
rip fence position whenever working over thetable.
Fine Adjustment Knob
The fine adjustment knob4 allows smaller adjustments when
setting the fence. Before adjusting, be sure the rail lock lever is in
its up or unlocked,position.
Rip Scale Pointer
The rip scale pointer will need to be adjusted for proper
performance of the rip fence if the user switches between thick
and thin kerf blades. The rip scale pointer only reads correctly
for position 1(0mm to 510mm), however for position 1 with
narrow rip fence in use add 52mm. See Adjusting the Rip Scale
underAssembly andAdjustments.
Basic Saw Cuts
Ripping(Fig.A,N)
WARNING: Sharpedges.
1. Set the blade to 0°.
2. Lock the rip fence latch17(Fig.A).
3. Raise the blade until it is about 3 mm higher than the top of
theworkpiece.
4. Adjust the position of the fence, refer to Rip
FenceOperation.
5. Hold the workpiece flat on the table and against the fence.
Keep the workpiece away from theblade.
6. Keep both hands away from the path of theblade.
7. Switch the machine on and allow the blade to reach
fullspeed.
8. Slowly feed the workpiece underneath the guard, keeping
it firmly pressed against the rip fence. Allow the teeth to
cut, and do not force the workpiece through the blade. The
blade speed should be keptconstant.
9. Always use a push stick20 when working close to the
blade(Fig.N).
10. After completing the cut, switch the machine off, allow the
blade to stop and remove theworkpiece.
WARNING:
• Never push or hold the "free" or cut-off-side of
theworkpiece.
• Do not cut excessively smallworkpieces.
• Always use a push stick when ripping
smallworkpieces.
Bevel Cuts(Fig.A)
WARNING: Avoid bevel ripping on the beveling (left) side
of theblade.
1. Set the required bevel angle, by rotating lever7 by pushing
it up and to theright.
2. Set to desired angle, rotate lever by pushing down and to
the left to lock inplace.
3. Proceed as forripping.
Cross-Cutting and Bevel Crosscutting
1. Remove the rip fence and install the mitre gauge in theslot.
2. Lock the mitre gauge at 0°.
3. Proceed as forripping.
Mitre Cuts(Fig.A)
1. Set the mitre gauge10 to the requiredangle.
NOTE: Always hold the workpiece tightly against the face of the
mitregauge.
2. Proceed as forripping.
Compound Mitre
This cut is a combination of a mitre and a bevel cut. Set the
bevel to the angle required and proceed as for a cross-cutmitre.
Support for Long Pieces
• Always support longpieces.
• Support long workpieces using any convenient means
such as saw-horses or similar devices to keep the ends
fromdropping.
Dust Extraction (Fig. A)
Dust from materials such as lead-containing coatings and some
wood types, can be harmful to one’s health. Breathing-in the
dust can cause allergic reactions and/or lead to respiratory
infections of the user or bystanders. Certain dust, such as oak or
beech dust, is considered carcinogenic, especially in connection
with woodtreatmentadditives.
Observe the relevant regulations in your country for the
materials to beworked.
The vacuum cleaner must be suitable for the material
beingworked.
When vacuuming dry dust that is especially detrimental to
health or carcinogenic, use dust class M vacuumcleaner.
The machine is provided with a dust collection port13 at
the rear of the machine suitable for use with dust extraction
equipment featuring 57/65 mm nozzles. Supplied with the
machine is a reducer port for use of dust extraction nozzles of
34–40mmdiameter.
The blade guard assembly also features a dust collection
port14 for 35mmnozzles and AirLocksystem.
• During all operations, connect a dust extraction device
designed in accordance with the relevant regulations
regarding dustemission.

16
ENGLISH
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING:To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
Cleaning (Fig. A, Q)
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
WARNING: To reduce the risk of injury, regularly clean
the tabletop and ventilationslots.
WARNING: To reduce the risk of injury, regularly clean
the dust collectionsystem.
WARNING: To reduce the risk of serious personal
injury, do not use the saw without reattaching the
dust accessdoor.
The blade guard assembly11 and throat plate must be placed
in position before operating thesaw.
Before use, carefully inspect upper and lower blade guards as
well as the dust extraction tube to determine that it will operate
properly. Ensure that chips, dust or work piece particles cannot
lead to blockage of one of thefunctions.
In case workpiece fragments are jammed between saw blade
and guards, disconnect the machine from the power supply
and follow the instructions given in section Mounting the
Saw Blade.Remove the jammed parts and reassemble the
sawblade.
Keep the ventilation slots clear and regularly clean the housing
with a softcloth.
Regularly clean the dust collection system:
1. Turn the saw on its side, so the bottom, open part of the
unit isaccessible.
2. Open the dust access door45 shown in FigureQ loosening
the two screws46 and detaching the door. Clean out
the excess dust, then reattach the door securing it with
thescrews.
Lubrication (Fig. P)
The motor and bearings require no additional lubrication. If
raising and lowering the blade becomes difficult, clean and
grease the height adjustment screws:
1. Unplug the saw from powersource.
2. Turn the saw on itsside.
3. Clean and lubricate the height adjustment screw
threads44 on the underside of this saw as shown in
FigureP. Use general purposegrease.
• Ensure that the dust extraction hose in use is suitable for
the application and material being cut. Ensure proper
hosemanagement.
• A splitter accessory is available to connect both ports to a
single dustextractor.
• Be aware that man-made materials such as chipboard
or MDF produce more dust particles during cutting than
naturaltimber.
Storage (Fig. A, O)
1. Attach push stick20 tofence.
2. Remove the blade guard assembly11. Refer to Mounting/
Removing the Blade Guard Assembly/Riving Knife. Place
blade guard assembly into holder as shown, then turn lock
1/4 turn to lock inplace.
3. Slide closed end of blade wrenches19 into catch then
secure in place with wingnut.
4. Insert guide bar of mitre guage10 into pocket until it
bottomsout.
5. Remove the non-through sawing riving knife 21. Refer to
Mounting/Removing the Blade Guard Assembly/Riving
Knife. Place the non-through sawing riving knife into the
holder as shown, then turn lock 1/4 turn to lock in place. The
non-through sawing riving knife can also be installed and
stored in its regular usageposition.
6. To store fence16, snap work support in stored position.
Remove fence from rails. Reattach fence upside down on
left side of saw. Pivot fence lock latches tosecure.
7. Turn the handwheel 6 in anticlockwise direction until
the teeth of the saw blade are positioned below the saw
table1.
8. Wind the mains cable around the cable holder 23.
Transporting (Fig. A)
• Turn the tool off and disconnect from powersupply.
• Wind the mains cable around the cable holder 23.
• Remove all accessories that cannot be mounted firmly to
the powertool.
• Retract the work supportextension.
• Always carry the machine using the carry handles12.
WARNING: Always transport the machine with the upper
blade guardfitted.

17
ENGLISH
Protecting the Environment
Separate collection. Products marked with this symbol
must not be disposed of with normal householdwaste.
Products contain materials that can be recovered
or recycled reducing the demand for raw materials.
Please recycle electrical products according to local provisions.
Further information is available at www.2helpU.com.
Replace blade guard when worn. Contact your local
DeWALT
service centre for details on a blade guardreplacment.
SAW BLADES: ALWAYS USE 210 mm noise reduced saw blades
with 30 mm arbour holes. Blade speed rating must be at least
6000 RPM. Never use a smaller diameter blade. It will not be
guardedproperly.
BLADE DESCRIPTIONS
Application Diameter Teeth
Construction Saw Blades(fast rip)
General Purpose 210 mm 24
Fine Crosscuts 210 mm 40
Woodworking Saw Blades (provide smooth, clean cuts)
Fine crosscuts 210 mm 60
Optional Accessories
WARNING: Since accessories, other than those offered
by
DeWALT
, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only
DeWALT
recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.

Belgique et
Luxembourg België en Luxemburg
DeWALT - Belgium BVBA
Egide Walschaertsstraat 16
2800 Mechelen
Tel: NL 32 15 47 37 63
Tel: FR 32 15 47 37 64
Fax: [phone]
www.dewalt.be
[email protected]
Danmark DeWALT (Stanley Black&Decker AS)
Roskildevej 22
2620 Albertslund
Tel: [phone]
Fax: [phone]
www.dewalt.dk
[email protected]
Deutschland DeWALT
Richard Klinger Str. 11
65510 Idstein
Tel: [phone]
Fax: [phone]
www.dewalt.de
[email protected]
Ελλάς DeWALT (Ελλάς) Α.Ε.
EΔΡΑ-ΓΡΑΦΕΙΑ : Στράβωνος 7
& Λ. Βουλιαγμένης, Γλυφάδα 166 74, Αθήνα
SERVICE : Ημερος Τόπος 2 (Χάνι Αδάμ) – 193 00 Ασπρόπυργος
Τηλ: 00302108981616
Φαξ: 00302108983570
www.dewalt.gr
[email protected]
España DeWALT Ibérica, S.C.A.
Parc de Negocios “Mas Blau”
Edificio Muntadas, c/Bergadá, 1, Of. A6
08820 El Prat de Llobregat (Barcelona)
Tel: [phone]
Fax: [phone]
www.dewalt.es
[email protected]
France DeWALT (Stanley Black & Decker France SAS)
62 Chemin de la Bruyère
CS 60105,
69574 DARDILLY Cedex
Tel: [phone]
Fax: [phone]
www.dewalt.fr
[email protected]
Schweiz
Suisse
Svizzera
DeWALT
In der Luberzen 42
8902 Urdorf
Tel: 044 - 755 60 70
Fax: 044 - 730 70 67
www.dewalt.ch
[email protected]
Ireland DeWALT
Building 4500, Kinsale Road
Cork Airport Business Park
Cork, Ireland
Tel: [phone]
Fax: [phone]
www.dewalt.ie
[email protected]
Italia DeWALT
via Energypark 6
20871 Vimercate (MB), IT
Tel: [phone]
39 039-9590200
Fax: [phone]
www.dewalt.it
Nederlands DeWALT
Netherlands BVPostbus 83,
6120 AB BORN
Tel: [phone]
Fax: [phone]
www.dewalt.nl
Norge DeWALT
Postboks 4613
0405 Oslo, Norge
Tel: [phone]
Fax: [phone]
www.dewalt.no
[email protected]
Österreich DeWALT
Werkzeug Vertriebsges m.b.H
Oberlaaerstrasse 248, A-1230 Wien
Tel: 01 - 66116 - 0
Fax: 01 - 66116 - 614
www.dewalt.at
[email protected]
Portugal DeWALT
Ed. D Dinis, Quina da Fonte
Rua dos Malhoes 2 2A 2º Esq.
Oeiras e S. Juliao da Barra, paço de Arcos e Caxias
2770 071 Paço de Arcos
Tel: [phone]
Fax: [phone]
www.dewalt.pt
[email protected]
Suomi DeWALT
PL47
00521 Helsinki, Suomi
Puh: 010 400 4333
Faksi: 0800 411 340
www.dewalt.fi
[email protected]
Sverige DeWALT
BOX 94
43122 Mölndal
Sverige
Tel: [phone]
Fax: [phone]
www.dewalt.se
[email protected]
Türkiye Sanayi ve Ticareet Bakanlığı tebliğince kullanim ömrü 7 yıldır.
Stanley Black & Decker Turkey Alet Üretim San. Tic. Ltd.Şti.
AND Kozyataği - İçerenköy Mah. Umut Sok. AND Ofis Sit. No: 10-12 / 82-83-84
Ataşehir/İstanbul, Türkiye
Tel: [phone]
Faks: [phone]
www.dewalt.com.tr
[email protected]
United Kingdom DeWALT, 210 Bath Road;
Slough, Berks SL1 3YD
Tel: [phone]
Fax: [phone]
www.dewalt.co.uk
[email protected]
Australia DeWALT
810 Whitehorse Road Box Hill
VIC 3128 Australia
Tel: Aust 1800 338 002
Tel: NZ 0800 339 258
www.dewalt.com.au
www.dewalt.co.nz
Middle East Africa DeWALT
P.O. Box - 17164,
Jebel Ali Free Zone (South), Dubai, UAE
Tel: [phone]
Fax: [phone]
www.dewalt.ae
[email protected]
N778418 08/19
