DeWalt DCV517M1 User manual

DCV517
Cordless 20V Max* 1/2 Gallon Portable Vacuum
INSTRUCTION MANUAL
Page Size: 8.5 x 5.5"

Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
WARNING: To reduce the risk of injury, read the
instruction manual.
Important Safety Warnings
and Instructions
General Vacuum Safety Warnings
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
TO REDUCE RISK OF INJURY
• Before any use, be sure everyone using this vacuum reads and
understands all safety instructions and other information contained
in this manual.
• Save these instructions and review frequently prior to use and in
instructing others.
When using an electric vacuum, basic safety precautions should
always be followed to reduce risk of fire, electric shock, and personal
injury, including the following:
READ ALL INSTRUCTIONS BEFORE
USING VACUUM
WARNING: To reduce the risk of fire, electric shock,
or injury:
•DO NOT leave vacuum with battery installed. Remove battery
from tool when not in use and before servicing.
•DO NOT allow vacuum to be used as a toy. Close attention is
necessary when used by or near children.
•USE ONLY as described in this manual. Use only manufacturer's
recommended attachments.
• If vacuum is not working as it should, has been dropped, damaged,
left outdoors, or dropped into water, return it to a service center.
•DO NOT handle vacuum with wet hands.
•KEEP hair, loose clothing, fingers, and all parts of body away from
openings and moving parts.
•TURN OFF all controls before removing battery.
•USE EXTRA CARE when cleaning on stairs.
•DO NOT use to pick up flammable or combustible liquids such as
gasoline or use in areas where they may be present.
•DO NOT pick up anything that is burning or smoking, such as
cigarettes, matches or hot ashes.
1

•STORE IDLE TOOLS. When not in use, the vacuum should be
stored in a dry, high or locked up place – out of reach of children.
•MAINTAIN TOOL WITH CARE. Keep fan area clean for best and
safest performance. Follow instructions for proper maintenance.
•DO NOT attempt to repair the vacuum. To assure product safety
and reliability, repairs, maintenance, and adjustments should be
performed by authorized DeWALT service centers.
•DO NOT use without filter in place.
•DO NOT use in areas where explosive vapors may be present.
•DO NOT use to pick up explosive dust, or in areas where air
contains explosive dust such as coal, grain, or other combustible
material.
• Static shocks are possible in dry areas or when the relative
humidity of the air is low. This is only temporary and does not affect
the use of the vacuum. To reduce the frequency of static shocks,
add moisture to the air with a console or installed humidifier.
•TO AVOID spontaneous combustion, empty tank after each use.
•DO NOT put any objects into openings. Do not use with any
opening blocked; keep free of dust, lint, hair and everything that
may reduce air flow.
WARNING: Some dust created by this product
contains chemicals known to State of California to cause cancer,
birth defects or other reproductive harm. Some examples of these
chemicals are:
• compounds in fertilizers
• compounds in insecticides, herbicides and pesticides
• arsenic and chromium from chemically treated lumber
To reduce your exposure to these chemicals, wear approved safety
equipment such as dust masks that are specially designed to filter out
microscopic particles.
•DO NOT place outlet of vacuum near eyes or ears when operating.
• DISCONNECT BATTERY PACK FROM VACUUM BEFORE
MAKING ANY ADJUSTMENTS CHANGING ACCESSORIES,
SERVICING, MOVING, OR STORING THE VACUUM. Such
preventative safety measures reduce the risk of starting the tool
accidentally.
•USE RECOMMENDED ACCESSORIES. Consult the instruction
manual for recommended accessories. The use of improper
accessories may cause risk of injury to persons.
•NEVER STAND ON VACUUM. Serious injury could occur if the
vacuum is tipped.
•NEVER LEAVE VACUUM RUNNING UNATTENDED. TURN
POWER OFF.
•KEEP YOUR WORK AREA CLEAN AND WELL LIT. Cluttered
benches and dark areas invite accidents.
•DO NOT OVERREACH. KEEP PROPER FOOTING AND
BALANCE AT ALL TIMES. Proper footing and balance enables
better control of the vacuum in unexpected situations.
•USE SAFETY EQUIPMENT. ALWAYS WEAR EYE
PROTECTION. Dust mask, non-skid safety shoes, hard hat, or
hearing protection must be used for appropriate conditions.
•DO NOT USE TOOL IF SWITCH DOES NOT TURN IT ON
OR OFF. Any tool that cannot be controlled with the switch is
dangerous and must be repaired.
•WHEN SERVICING, USE ONLY IDENTICAL REPLACEMENT
PARTS. FOLLOW INSTRUCTIONS IN THE MAINTENANCE
SECTION OF THIS MANUAL. Use of unauthorized parts or
failure to follow maintenance instructions may create a risk of
electric shock or injury.
•DON’T EXPOSE VACUUM TO RAIN. Store indoors.
General Safety Warnings for Vacuums
a) Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to battery pack, picking
2

up or carrying the appliance. Carrying the appliance with
your finger on the switch or energizing appliance that have the
switch on invites accidents.
b) Disconnect the battery pack from the appliance before
making any adjustments, changing accessories, or
storing appliance. Such preventive safety measures reduce
the risk of starting the appliance accidentally.
c) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another battery
pack.
d) Use appliances only with specifically designated battery
packs. Use of any other battery packs may create a risk of injury
and fire.
e) When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
f) Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
g) Do not use a battery pack or appliance that is damaged
or modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk of injury.
h) Do not expose a battery pack or appliance to fire or
excessive temperature. Exposure to fire or temperature
above 265°F may cause explosion.
i) Have servicing performed by a qualified repair person
using only identical replacement parts. This will ensure that
the safety of the product is maintained.
• The label on your tool may include the following symbols. The
symbols and their definitions are as follows:
V..............................volts A.............................. amperes
Hz...........................hertz W............................ watts
min.........................minutes or AC .............. alternating current
or DC.........direct current or AC/DC...... alternating or direct
current
............................Class I Construction
(grounded)
............................ Class II Construction
(double insulated)
…/min.................per minute no........................... no load speed
BPM .......................beats per minute n.............................. rated speed
IPM.........................impacts per minute ............................ earthing terminal
RPM .......................revolutions per minute ........................... safety alert symbol
sfpm ......................surface feet per minute ........................... visible radiation
SPM........................strokes per minute
Important Safety Instructions for All
Battery Packs
When ordering replacement battery packs, be sure to include the
catalog number and voltage. Consult the chart at the end of this
manual for compatibility of chargers and battery packs.
The battery pack is not fully charged out of the carton. Before using
the battery pack and charger, read the safety instructions below and
then follow charging procedures outlined.
READ ALL INSTRUCTIONS
•Do not charge or use the battery pack in explosive
atmospheres, such as in the presence of flammable liquids,
gases or dust. Inserting or removing the battery pack from the
charger may ignite the dust or fumes.
• NEVER force the battery pack into the charger. DO NOT
modify the battery pack in any way to fit into a non-
3

compatible charger as battery pack may rupture causing
serious personal injury. Consult the chart at the end of this
manual for compatibility of batteries and chargers.
• Charge the battery packs only in designated DeWALT chargers.
•DO NOT splash or immerse in water or other liquids.
• Do not store or use the tool and battery pack in locations
where the temperature may reach or exceed 104°F (40°C)
(such as outside sheds or metal buildings in summer). For
best life store battery packs in a cool, dry location.
WARNING: Fire hazard. Never attempt to open the
battery pack for any reason. If the battery pack case is cracked
or damaged, do not insert into the charger. Do not crush, drop or
damage the battery pack. Do not use a battery pack or charger that
has received a sharp blow, been dropped, run over or damaged in
any way (e.g., pierced with a nail, hit with a hammer, stepped on).
Damaged battery packs should be returned to the service center for
recycling.
WARNING: Fire hazard. Do not store or carry
the battery pack so that metal objects can contact exposed
battery terminals. For example, do not place the battery pack in
aprons, pockets, tool boxes, product kit boxes, drawers, etc., with
loose nails, screws, keys, etc. Transporting batteries can possibly
cause fires if the battery terminals inadvertently come in
contact with conductive materials such as keys, coins, hand
tools and the like. The US Department of Transportation Hazardous
Material Regulations (HMR) actually prohibit transporting batteries in
commerce or on airplanes (e.g., packed in suitcases and carry-on
luggage) UNLESS they are properly protected from short circuits. So
when transporting individual battery packs, make sure that the battery
terminals are protected and well insulated from materials that could
contact them and cause a short circuit.
SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION (Li-Ion)
•Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium ion battery packs are burned.
•If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If battery
liquid gets into the eye, rinse water over the open eye for 15
minutes or until irritation ceases. If medical attention is needed,
the battery electrolyte is composed of a mixture of liquid organic
carbonates and lithium salts.
•Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persist, seek medical
attention.
WARNING: Burn hazard. Battery liquid may be
flammable if exposed to spark or flame.
The RBRC®Seal
The RBRC®(Rechargeable Battery Recycling
Corporation) Seal on the nickel cadmium, nickel metal
hydride or lithium-ionbatteries (or battery packs)
indicates that the costs to recycle these batteries (or
battery packs) at the end of their useful life have already
been paid by DeWALT. In some areas, it is illegal to place spent nickel
cadmium, nickel metal hydride or lithium-ion batteries in the trash
or municipal solid waste stream and the Call 2 Recycle®program
provides an environmentally conscious alternative.
Call 2 Recycle, Inc., in cooperation with DeWALT and other battery
users, has established the program in the United States and Canada
to facilitate the collection of spent nickel cadmium, nickel metal
hydride or lithium-ion batteries. Help protect our environment and
conserve natural resources by returning the spent nickel cadmium,
nickel metal hydride or lithium-ion batteries to an authorized DeWALT
service center or to your local retailer for recycling. You may also
4
