Dexter Laundry T-30X2 Installation instructions

8514-211-001 REV D PAGE 1
INDUSTRIALDRYER OriginalInstructions
MODEL T-30X2 ON-PREMISE For GB & IE
B-SERIES CONTROL, ELECTRIC-HEATED
OPERATOR’S MANUAL
INSTALLATION & OPERATION INSTRUCTIONS
The dryer will operate correctly in ambient temperatures of 5°C to 45°C, in relative humidity
up to 50% at 40°C and above 50% when below 40°C, and at altitudes up to 1000m above
sea level, must be transported and stored from -40°C to 140°C, and has been packaged to
prevent damage from humidity, vibration, and shock. Take measures to avoid harmful
effects of occasional condensation.
Post the following “For Your Safety” cautions in a prominent location:
FOR YOUR SAFETY
Do not store or use petrol or other flammable vapours and liquids or dry cleaning
solvents in the vicinity of this or any other appliance.
FOR YOUR SAFETY
THIS MACHINE IS FOR DRYING ONLY FABRICS WASHED IN WATER. To avoid
possibility of fire, including spontaneous combustion, do not dry oiled floor mops, items
containing foam rubber or similarly textured rubberlike materials or any material on
which you have used a cleaning solvent or which contains flammable liquids or solids
(such as petrol, kerosene, waxes, etc.) Fabric softeners, or similar products, should be
used per the fabric softener instructions. Remove all objects from pockets such as
lighters and matches.
WARNING – Risk of Fire
Clothes dryer installation must be performed by a qualified installer.
Install the clothes dryer according to the manufacturer’s instructions and local codes.
Do not install a clothes dryer with flexible plastic venting materials. If flexible metal (foil type)
duct is installed, use duct that has been investigated and found acceptable for use with
clothes dryers. Flexible venting materials are known to collapse, be easily crushed, and trap
lint. These conditions will obstruct clothes dryer airflow and increase the risk of fire.
To reduce the risk of severe injury or death, follow all installation instructions.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Children of less than 3 years should be kept away unless continuously supervised.
It is important that you read this Manual and retain it for future reference. For service
or replacement parts, contact the distributor in your area or the manufacturer:
Dexter Laundry, Inc.
2211 West Grimes Avenue
Fairfield, Iowa 52556, USA

-2-
TABLE OF CONTENTS
Page No.
Dryer Dimensions (Figure 1)............................................................................. 4
Uncrating ..................…...................................................................................5
Dryer Installation (Figure 2)..............................................................................6
Dryer Exhaust System (Figure 3).......................................................................10
Dryer Shutdown...............................................................................................10
Touch Pad Layout (Figure 4).............................................................................11
Dryer Default Settings...................................................................................... 12
Dryer Default Codes......................................................................................... 12
Touch Pad Description......................................................................................13
Operating Instructions......................................................................................15
Programming Instructions.................................................................................17
Servicing Dryer................................................................................................ 24
Preventive Maintenance....................................................................................24
WARNINGS ABOUT USE AND OPERATION
Caution! There are sharp ed
g
es on various sheet metal parts internal
to the enclosure. Use safety consciousness when placing or moving
your hands while working in the interior of this equipment.
Meaning: Do Not Enter This
Equipment (or Space).
Meaning: Do Not Step, Stand, or Sit
on This Equipment.
Meaning: Do Not Operate with
Guards or Covers Removed.
Meaning: High Voltage. Disconnect
power before servicing.
Meanin
g
: Lock Out and Ta
g
Out
before servicing.
Meaning: Burn Hazard. Do Not Touch
Heater Housing or Heating Elements.
Allow these parts to cool before servicing.
Meaning: Do Not Dry Items
Containing Explosive Material.
Meaning: Do Not Dry Items
Containing Flammable Material.
Meaning: Read Operators
Manual.
Meaning: Center of Gravity.
Meaning: Left Point for Forklift
or Hand Pallet Truck or Jack.
Meaning: Right Point for Forklift or
Hand Pallet Truck or Jack.
It is ABSOLUTELY ESSENTIAL that the dryer be connected to a known earth
connection. This is not only for personal safety, but is necessary for proper operation.
DO NOT MODIFY THIS APPLIANCE. KEEP SHIELDS, GUARDS AND COVERS IN
PLACE. These safety devices are provided to protect everyone from injury.

-3-
WARNINGS ABOUT USE AND OPERATION continued
THIS DRYER IS EQUIPPED WITH A MANUALLY RESETTABLE OVER-
TEMPERATURE THERMOSTAT located on the top of the exhaust duct beside the
motor. Should the dryer cease to heat, reset the thermostat by rotating the lever
bracket clockwise. Should the thermostat continue to trip, the dryer must be inspected
by a qualified service person.
CHECK THE THERMOSTAT WHEN INSTALLING DRYER to assure it is not tripped.
Impacts, such as rough handling in shipment, may trip the thermostat.
WARNING: Do not stop dryer before end of cycle time unless all items are quickly
removed and spread out to dissipate heat.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE while in
operation.
THIS APPLIANCE SHALL NOT BE USED TO DRY OFF CLOTHES CONTAINING
SOLVENTS OR DRY-CLEANING FLUIDS.
Misuse of Dryer
Do not use this Equipment for any purpose not described in this Manual.
Do not operate this equipment without all guards and covers in place.
Do not operate this dryer from any power source not matching the
operational requirements on the back of the dryer.
Do not place your body inside the dryer cylinder or allow others to do so.
Death or serious injury can result from this!
Other Examples May Be Applicable
Caution – Replace Fuses With Same Type and Rating
Fuse No. Voltage Amperage SC I/R Type Size
F1 in
front
control
250V 600mA 35A@250VAC T 5.00 x 20.00 mm

-4-
FIGURE 1 Dryer Dimensions - inches (mm)
MAX
MIN

-5-
INSTALLATION AND OPERATING INSTRUCTIONS
Note: A forklift, or a hand pallet truck or jack, must lift the dryer and only from
the front or rear of the dryer with the dryer bolted to the pallet and supported
the full length of the dryer.
UNCRATING AND PLACING DRYER
Tools Required: 3/4" (19 mm) hex socket & ratchet driver, wood block 4" (100 mm) or
5" (125 mm) thick, a knife and a groove joint pliers, which will open to 1 3/8" (35 mm).
1. Remove and discard packaging.
2. The crate base is attached to the dryer by (4) cap screws driven upward from
below the crate base. Remove crate base from the dryer, by tipping the dryer
sidewise and place the block under the crate base rail in center of the dryer.
Using a ratchet and 3/4" (19 mm) hex socket, remove the (2) crating bolts from
the side, which is raised, and save for future moving of the dryer. Remove the
block from under the crate base. Repeat for the other side.
3. With a walking motion, move the dryer completely off the crate base. Save the
crate base for future moving of the dryer.
4. Slide the unit into position where it will be installed. Adjust the leveling legs,
using the groove joint pliers, to level and align the dryer with adjacent units.
Note: If the dryer is ever moved again, the dryer should be re-mounted on its pallet
and its crating bolts re-inserted and tightened, in the reverse order as above.
Dryer Model Mass
DN30X2E_-79 340 kg
DRYER INSTALLATION
1. CODE CONFORMITY: All industrial dryer installations must conform to the local and
national codes for the location of installation. Prior to installation, ensure that the local
distribution conditions (identification of the type) and the adjustment of the appliance
are compatible.
The appliance must not be installed behind a lockable door, a sliding door or a door
with a hinge on the opposite side to that of the tumble dryer, in such a way that a full
opening of the tumble dryer door is restricted.
2. INSTALLATION CLEARANCES: This unit may be installed at the following alcove
clearance.
I. Left Side 0 in.
II. Right Side 0 in.

-6-
III.Back 18 in. (457 mm) (Certified for 6 in. (150 mm) clearance; however,
18 in. (457 mm) clearance is necessary behind the motors to allow
servicing and maintenance.)
IV. Front 48 in. (1220 mm) to allow use of dryer.
V. Top Refer to figure labeled “Vertical Clearance Dimensions”.
AB. Certification allows 0 in. clearance at the top 4 in. (100 mm)
back from the front. However, a 1/4 in. (6 mm) clearance should
be allowed in case the dryer needs moving.
C. A 10 in. (250 mm) clearance is required from top at all other
points.
VI. Floor This unit may be installed upon a combustible floor.
Do not obstruct the flow of combustion and ventilation air.
Maintain minimum of 1 in. (25 mm) clearance between duct and combustible material.
Refer to the label attached to the Belt Guard on the rear of the dryer for other
installation information and start-up instructions.
3. MAKE-UP AIR. Adequate make-up air (600CFM/DRUM (17 m3/Min.),
1200CFM/DRYER) (34 m3/Min.) must be supplied to replace air exhausted by dryers on
all types of installations. Provide a minimum of 1.5 sq. ft. (0.14 m2) make-up air
opening to the outside of each dryer. This is a net requirement of effective area.
Screens, grills or louvers, which will restrict the flow of air, must be considered. Consult
the supplier to determine the free area equivalent for the grill being used.
TOP OF DRYER
SIDE OF DRYER
FRONT
OF
DRYER
FIGURE
2
- Vertical Clearance Dimensions

-7-
The source of make-up air should be located sufficiently away from the dryers to allow
an even airflow to the air intakes of all dryers. Multiple openings should be provided.
The operation of this appliance may affect the operation of gas appliances, which take
their air for safe combustion from the same room. Adequate ventilation must be
provided to avoid back flow of gasses from other appliances in the same room. All gas
appliances should be tested with the Dexter dryer in operation and all the windows and
doors closed. If in doubt, consult the appliance manufacturer(s).
4. ELECTRICAL REQUIREMENTS:
The electrical installation must be performed by a qualified electrical technician.
The electrical power requirements necessary to operate the unit satisfactorily are listed
on the serial plate located on the back panel of each dryer. The electrical connection
should be made at the terminal blocks in the two control boxes on the rear of the unit
using conductors rated at 75°C (167°F) and a wire size adequate to handle the
amperage and voltage listed on the serial plate (see table below for recommended
minimum sizes). It is absolutely necessary that the dryer be connected to a known
earth (No. 8 AWG copper conductor recommended). Knockouts are provided for the
connection of 1-inch (25 mm) conduit for the power supply conductors and 3/8-inch
(10 mm) conduit for the external earthing conductor. It is absolutely necessary that the
dryer be connected to a good earth connection. The earth connection resistance should
be checked prior to operation at the end. Introduction of supply wiring must not
increase the Ingress Protection (IP) rating.
HEATING
ELEMENT SIZE
(kW)
SUPPLY
VOLTAGE
(PHASE / V.)
MINIMUM DUAL ELEMENT TIME
DELAY FUSE SIZE AT FUSED
DISCONNECT (A.)
MINIMUM WIRE SIZE FROM FUSED
DISCONNECT TO DRYER TERMINAL
BLOCK (75OC COPPER WIRE)
24 3
/
400 50 # 6
(
13.3 mm^2
)
The installation must meet the electrical requirements of the country, state and
locality of the installation. Individual circuit breakers for each dryer are required. The
installer must provide a disconnect switch which will interrupt all lines. It may be a
local or national requirement to provide an electrical interruption switch visible and
accessible from the room in which the dryer is installed. The wiring diagram is located
in the control box on the back of the dryer.
For destination countries where CE requirements must be met, individual 400V supply
disconnecting devices for each dryer are required and must be one of the following
types:
a. switch-disconnector with fuses per IEC 60947-3 utilization category AC-23B;
b. disconnector with fuses per IEC 60947-3 having an auxiliary contact that in all cases
causes switching devices to break the load circuit before the opening of the main
contacts of the disconnector;
c. a circuit-breaker suitable for isolation per IEC 60947-2;
d. any other switching device in accordance with an IEC product standard for that
device and which meets the isolation requirements of IEC 60947-1 as well as a

-8-
utilization category defined in the product standard as appropriate for on-load switching
of motors or other inductive loads;
The supply disconnecting devices must
a. provide a means allowing the supply disconnecting devices to be locked in the OFF
position;
b. be mounted 0.7m to 1.7m above the floor, within 2 m from the dryer, and within 8 m
from the operator position;
c. have a red actuator to indicate that it serves a dual Emergency Stop function;
d. be rated for branch circuit operation;
e. be approved for use in the country where installed;
CONTROL TRANSFORMER CONNECTIONS Adjustment for different voltages of supply mains.
IMPORTANT: TRANSIENT VOLTAGE SURGE SUPPRESSORS
Like most electrical equipment your new machine can be damaged or have its life
shortened by voltage surges due to lightning strikes which are not covered by factory
warranty. Local power distribution problems also can be detrimental to the life of
electrical components. We recommend the installation of transient voltage surge
suppressors for your new equipment. These devices may be placed at the power
supply panel for the complete installation and don’t require an individual device for each
machine.
These surge protectors help to protect equipment from large spikes and also from small
ongoing spikes in the power that occur on a day to day basis. These smaller surges can
shorten overall life of electrical components of all types and cause their failure at a later
date. Although they can’t protect against all events, these protective devices have a
good reputation for significantly lengthening the useful life of electronic components.
Electronic components are helped to have a longer useful life when they are supplied
with the clean stable electrical power they like.
6. EXHAUST INSTALLATION. (Refer to Figure 3) Exhausting of the dryer(s) should
be planned and constructed so that no air restrictions occur. Any restriction due to pipe
size or type of installation can cause slow drying time, excessive heat, and lint in the
room.

-9-
From an operational standpoint, incorrect or inadequate exhausting can cause a
cycling of the high limit thermostat, which shuts off the heating elements and results in
inefficient drying.
The exhaust duct connection near the top of the dryer will accept an 8 in. (200 mm)
round duct. Individual exhausting of the dryers is recommended. A pipe of the proper
diameter should be attached to the dryer adapter collar and extended out through an
outside wall to exhaust all heat, moisture, and lint outside. This pipe must be very
smooth on the inside, as rough surfaces tend to collect lint, which will eventually clog
the duct and prevent the dryer from exhausting properly. All elbows must be smooth
on the inside. All joints must be made so the exhaust end of one pipe is inside the next
one downstream. The addition of an exhaust pipe tends to reduce the amount of air
the blower can exhaust. This does not affect the dryer operation if held within practical
limits. For the most efficient operation, it is recommended that no more than 14 ft.
(4.25 m) of straight 8 in. (200 mm) diameter pipe is used with two right angle elbows.
The design of the vent system shall be such that any condensate formed when
operating the dryer from cold shall either be retained and re-evaporated or discharged.
Maintain a minimum of 1” (25mm) clearance between duct and combustible material.
If the exhaust pipe passes through a wall, a metal sleeve of slightly larger diameter
should be set in the wall and the exhaust pipe passed through this sleeve. This practice
is required by some local codes and is recommended in all cases to protect the wall.
This type of installation should have a means provided to prevent rain and high winds
from entering the exhaust when the dryer is not in use. A hood with a hinged damper
can be used for this purpose. Another method would be to point the outlet end of the
pipe downward to prevent entrance of wind and rain. In either case, the outlet should
be kept clear, by at least 24 in. (610 mm), of any objects, which would cause air
restriction.
Never install a protective screen over the exhaust outlet.
When exhausting a dryer straight up through a roof, the overall length of the duct has
the same limits as exhausting through a wall. A rain cap must be placed on top of the
exhaust and must be of such a type as to be free from clogging. The type using a cone
shaped “roof” over the pipe is suitable for this application.
Exhausting the dryer into a chimney or under a building is not permitted. The exhaust
air should not be vented into a wall, a ceiling, or a concealed space of building. In
these cases, there is a danger of lint buildup, which can be highly combustible.
Installation of several dryers, where a main discharge duct is necessary, will need the
following considerations for installation (see Figure 3). Individual ducts from the dryers
into the main discharge duct should be at a 45-degree angle in the direction of
discharge airflow.
NOTE: Never install the individual ducts at a right angle into the main discharge duct.
The individual ducts from the dryers can enter at the sides or bottom of the main
discharge duct. Figure 3 indicates the various round main duct diameters to use with

-10-
the individual dryer ducts. The main duct can be rectangular or round, provided
adequate airflow is maintained. For each individual dryer, the total exhausting (main
discharge duct plus duct outlet from the dryer) should not exceed the equivalent of 14
ft. (4.25 m) and two elbows. The diameter of the main discharge duct, at the last
dryer, must be maintained to exhaust end.
NOTE: A small diameter duct will restrict airflow; a large diameter duct will reduce air
velocity - both contributing to lint build up. An inspection door should be provided for
periodic clean out of the main duct.
NOTE: Exhaust air must not be discharged into a flue which is used for exhausting
fumes from appliances burning gas or other fuels.
NOTE: The A-weighted emission sound pressure level does not exceed 70dB(A). The
operator does not need hearing protection.
NOTE: The dryer does not emit hazardous radiation.
WARNING: To avoid potential risks of spontaneous combustion of a load,
remove the load quickly after the completion of the cycle or in case of failure
of power supply.
DANGER: Do not dry loads which may create an explosive atmosphere in the
dryer.
DRYER SHUTDOWN
To render the dryer inoperative, disconnect electrical supply to the dryer.
Caution - A clothes dryer produces combustible lint and should be
exhausted outdoors. The area around the clothes dryer should be kept
free of lint.
DIAMETER TO INCREASE AS SHOWN
WALL
INSTALL NO
SCREEN OR
COVER
EXHAUST AIR
(SEE INSTRUCTIONS)
DRYER DUCTS
MUST ENTER AT
A 45° ANGLE
INCHES
(MM)
INSPECTION
COVER
FIGURE 3- Dryer Exhausting Using A Main Discharge Duct.

-11-
Upper Programming Touch Pad Switch
Upper Programming Indicator Li
g
hts
(
4
)
Upper Programming Enter / Select Touch Pad Switch
Upper Programming Cycle Touch Pad Switch
Lower Programming Touch Pad Switch
Lower Programming Indicator Li
g
hts
(
4
)
Lower Programming Enter / Select Touch Pad Switch
Lower Programming Cycle Touch Pad Switch
Lower Up/Increase Touch Pad Switch
Lower Down/Decrease Touch Pad Switch
Lower Cycle
Indicator Lights (5)
Lower Stop
Indicator Light
Lower Stop
Touch Pad Switch
Lower Start
Touch Pad Switch
Lower Heat Relay
Indicator Light
Lower 4-Digit
Numeric Display
Upper Heat Relay
Indicator Light
Upper 4-Digit
Numeric Display
Upper Start
Touch Pad Switch
Upper Stop
Touch Pad Switch Upper Stop
Indicator Light
Upper Cycle
Indicator Lights (5)
Upper Up/Increase Touch Pad Switch
Upper Down/Decrease Touch Pad Switch
Figure 4: Non-Reversing Dryer Controller Interface

-12-
DRYER CONTROLLER FACTORY DEFAULT PROGRAM SETTINGS
DRY
CYCLE
COOL DOWN
TIME
(MINUTES)
TOTAL CYCLE
TIME
(MINUTES)
DRYING
TEMPERATURE
(0F) (0C)
DRYER LOAD
1 5 35 180 82 Towels, pads, heavy cotton
2 2 20 170 77 Sheets, blended materials
3 5 25 180 82 Cotton
4 2 20 130 54 Synthetic materials
5 2 25 175 79 Blended materials
DRYER FAULT CODES
FAULT
# FAULT DESCRIPTION ACTION
F1
Shorted
thermostat
sensor.
Dryer stops and “F1” flashes on the 4-digit display.
When short circuit on sensor input is removed, “LOAd”
appears on the 4-digit display and the remaining dry
time is reset.
F2 Open thermostat
sensor.
Dryer stops and “F2” flashes on the 4-digit display.
When a good sensor is connected to sensor input,
“LOAd” appears on the 4-digit display and the remaining
dry time is reset.
F3 EEPROM
corrupted.
Dryer will not start and “F3” appears on the 4-digit
display. The power to the dryer must be cycled to reset
the controller. Fault should only occur when starting a
dry cycle.
F4 Heat relay on
fault.
The drying temperature did not increase 1ºF. in 15
minutes. “F4” will flash on the display and the dry cycle
will finish without calling for heat (energizing heat relay).
Opening the door or pressing the STOP key will reset the
fault and clear the remaining time in the dry cycle.
F5 Temperature
fault.
The drying temperature is at least 25ºF. above the
temperature setting. “F5” will flash on the 4-digit display
and the dry cycle will finish without calling for heat
(energizing the heat relay). The power to the dryer
must be cycled to reset the controller.

-13-
TOUCH PAD DESCRIPTION
INDICATOR LIGHTS (L.E.D.s)
Description
Cycle (1 through 5) These L.E.D.s are on solid when a particular cycle is
chosen for operation or programming.
Heat Relay This L.E.D. is part of the 4-digit numeric display and
will be on solid during the drying part of a cycle when
the heat relay does not need to be on. The L.E.D.
will be blinking when the heat relay needs to be on.
The L.E.D. will not be on solid or blinking (off) if the
cycle is stopped, complete, in cool down, or
terminated.
Programming These L.E.D.s are on solid as they are selected during
the programming of the dryer controller.
Stop This L.E.D. is on solid when either the STOP button is
pressed once or the door is opened during an
operating cycle.
SWITCHES (Pushbuttons)
Description
This touch pad switch will increment (increase) dry
time, cool down time, and drying temperature. It will
Up/Increase also scroll upwards when selecting a dry cycle.
This touch pad switch will decrement (decrease) dry
time, cool down time and drying temperature. It will
also scroll downwards when selecting a dry cycle.
Down/Decrease
This touch pad switch allows the dryer controller to
enter the permanent programming mode.
Program
This touch pad switch will select one of the three
variable parts of the dry cycle (dry time, temperature,
or cool down) by sequencing through them. Once one
of the variable parts of the dry cycle is chosen and
Select/Enter changed, this touch pad switch will enter the new
(changed) value into the dry cycle program.
This touch pad switch allows the dryer controller to
enter the temporary programming mode.
Cycle

-14-
SWITCHES (Pushbuttons) - continued
Description
This touch pad switch will stop the dryer during a dry
cycle without clearing the present drying cycle if
pressed once. If pressed and released twice,
Stop consecutively, the present dry cycle will be cleared.
This touch pad switch will start the operation of a dry
cycle if pressed and released once. Pressing and
holding this touch pad switch will display the current
Start temperature of the dryer heat sensor as long as it is
held in the depressed position.
4-DIGIT NUMERICAL DISPLAY MESSAGES
Message Description
LOAd This message is displayed after a dry cycle is
complete and the dryer loading door has been
opened or the STOP touch pad key on the dryer
controller has been pressed and released twice.
donE This message blinks immediately after completion of
the dry cycle and continues to blink until the stop key
on the dryer controller touch pad is pressed or the
dryer loading door is opened.
Prog This message is displayed when entering the
permanent programming mode.
.15 This message appears while the dryer is in the
heating time of a dry cycle. The decimal point will
blink if the output for the heat relay is on, or remain
on constantly if the output for the heat relay is not
on. The number represents the total time left in the
dry cycle (includes cool down time).
C02 This message appears when the cool down time of
the dry cycle is reached. The letter “C” represents
the cool down (non-heating) part of the dry cycle.
The number(s) after the letter “C” represent(s) the
total time remaining in the dry cycle.
F5 This message appears if there is a dryer fault. The
letter “F” indicates a fault and the number after the
“F” represents the specific fault that has occurred.
There are five different faults that can appear (F1
through F5).

-15-
OPERATING INSTRUCTIONS
Maximum Load Capacity: 13.6 kg (30 Pounds) Dry Weight per Drying Cylinder.
To dry a load of items, you must choose one of the five-programmed dry cycles.
Each of these five dry cycles may be modified in two different ways to match your load.
Please refer to the “Permanent Dryer Controller Programming” or “Temporary Dryer
Controller Programming” section of this manual.
There are two parts to each dry cycle. The first part is the heating time, which is
when the heat relay is cycled on and off according to the temperature setting in the dry
cycle program. The second part is the cool down time, which is after the heating part
of the dry cycle, and is when the cylinder continues to turn, but no heat is applied to
prevent damage from heat.
There will always be at least two minutes of cool down time for each dry cycle. The
maximum amount of cool down time is 60 minutes.
The default value of the five dry cycles is shown in the “DRYER CONTROLLER
FACTORY DEFAULT PROGRAM SETTINGS” table in this manual.
To improve the drying capabilities of this dryer, you should always separate
(untangle) the individual articles in your load before using the dryer.
In the following instruction steps, things that are displayed on the 4-digit numerical
display will be in “quotation marks” and any keys on the dryer controller touch pad that
physically need to be pressed will be in CAPITAL AND BOLD LETTERS.
1) Place your untangled load into the dryer cylinder and close the dryer loading door.
Notice that the dryer controller 4-digit numerical display should show the word
“LOAd”. If it does not show this word, then press and release the STOP touch pad
key on the dryer controller twice.
2) Press and release the UP or DOWN arrow touch pad key on the dryer controller to
select a dry cycle.
3) Once the desired dry cycle is selected, press and release the START touch pad key.
After the dryer controller START touch pad key is pressed, the dryer cylinder will
start rotating and the two-digit total dry cycle time, along with a decimal point, will
appear on the dryer controller display.
The time shown on the dryer controller display will count down to the programmed
cool down time. At that time, the display will change from the decimal point and two-
digit number to a letter “C” and two digits.
The letter “C” represents the cool down portion of the dry cycle. The two digits
represent the amount of time remaining in the dry cycle. The two-digit time, shown on
the dryer controller display, will count down to zero.

-16-
When the time decrements to zero, the dryer controller display will flash the word
“donE” and the end of cycle tone will sound.
At that point, the wrinkle free cycle will automatically begin. This cycle will wait two
minutes, if the door is not opened or the STOP touch pad key on the dryer controller is not
pressed, and then rotate the cylinder for 10 seconds and stop. This idle time of two
minutes and tumble time of 10 seconds will repeat a total of 10 times, at which time the
wrinkle free cycle stops. The cylinder will not rotate again until a new dry cycle is started.
During the wrinkle free cycle the heat relay will not be operated and there will be no
heat applied to the load. The word “donE” will also continue to flash and do so even
after the wrinkle free cycle is finished. When the dryer loading door is opened, or the
STOP touch pad key is pressed, the word “donE” will change to the word “LOAd” on
the dryer controller display. The dryer will then be ready for another dry cycle.
During the dry cycle, either pressing the STOP touch pad key on the dryer controller
or opening the dryer loading door, will stop the dry cycle and not clear it. If you press
the STOP touch pad key on the controller and then open the dryer loading door the dry
cycle will not be cleared. However, if you open (or open and close) the dryer loading
door and then press the STOP touch pad key on the dryer controller, the present dry
cycle will be cleared and the word “LOAd” will appear on the dryer controller display.
There are two jumpers and one push button on the component side of the dryer
controller printed circuit board.
The jumper located at the back right side of the each circuit board controls whether
the controller display shows and operates in the Fahrenheit or Celsius mode. This
jumper is labeled as TEMP SELECT and has three pins. The back and middle pins are
for Celsius and the front and middle pins are for Fahrenheit, which is indicated by the
letter C for Celsius and the letter F for Fahrenheit.
The other jumper, located at the back middle side of each circuit board controls, is
used for choosing either a reversing or non-reversing type of dryer. This jumper is
labeled as REV and NON-REV. This jumper must be in the non-reversing position, which
are the front and middle pins. If the jumper is in the reversing position, the heating part
of the dry cycle will not operate properly. The dryer will not reverse direction either.
The push button, which is located at the middle center of each circuit board controls,
is used to reset all five of the dry cycles to the factory default settings. It is labeled as
DEFAULT SETTINGS. Even the dry cycles that have been modified using the permanent
programming procedure will be changed back to the factory default settings when using
this push button. This push button must be pressed and held for at least three seconds
with power applied to the dryer controller circuit board.
If changing a jumper, remove power before moving jumper and then move jumper.
Before restoring power, press and hold the DEFAULT SETTINGS pushbutton. Then,
restore power and release the DEFAULT SETTINGS pushbutton after three seconds of
restoring power.

-17-
TEMPORARY DRYER CONTROLLER PROGRAMMING
The temporary programming mode will allow the change of the stored dry cycle
settings in the dryer controller for one complete dry cycle. After the dry cycle is
complete, the default settings that existed before the temporary change are restored.
The temporary dry cycle can be stopped and cleared at any time during the dry cycle
operation.
To temporarily change a dryer controller cycle, follow the procedures below. Things
that are displayed on the 4-digit numeric display will be in “quotation marks”. Keys on
the dryer controller touch pad that physically need to be pressed will be in CAPITAL
AND BOLD LETTERS.
If, at any time, you want to escape the temporary programming mode while
changing the program settings, you can press the STOP key on the dryer controller
touch pad if the 4-digit numeric display is not flashing. The SELECT/ENTER key on
the dryer controller touch pad can be pressed and released to enter the flashing value
shown on the 4-digit numeric display and allow you to escape.
If you press and release the STOP key on the dryer controller touch pad, when the
4-digit numeric display is not flashing, the temporary changes to the dry cycle program
will be cancelled. The stored dry cycle settings that existed before the temporary
change will then be restored.
If, at any time, you want to start the temporary dry cycle during the temporary
programming mode, press and release the START key on the dryer controller touch
pad if the 4-digit numeric display is not flashing. The SELECT/ENTER key on the dryer
controller touch pad can be pressed and released to enter the flashing value shown on
the 4-digit numeric display and allow you to start the temporary dry cycle. If you start
the temporary dry cycle, the 4-digit numerical display will change to the total dry time
and count down to 0 as the dry cycle progresses.
PROCEDURE
1) Make sure the dryer is not in a dry cycle. The 4-digit numeric display on the dryer
controller will show “LOAd” when the dryer is not in a dry cycle.
2) Press and release the UP or DOWN arrow keys on the dryer controller touch pad to
chose the dry cycle that you want to change (dry cycle 1 through 5). The dry cycle
L.E.D. will illuminate to indicate which dry cycle you are choosing. If you press either
arrow key and hold it down, the controller will sequence through the five dry cycles.
3) Press and release the CYCLE key on the dryer controller touch pad once you have
chosen the dry cycle you want to change. After you press this key, the programming
L.E.D. and the dry time L.E.D. will illuminate. The dry cycle L.E.D. will remain
illuminated. The total dry time will also be displayed on the 4-digit numeric display.
4) Press and release the UP or DOWN arrow keys to change the total cycle time.
Once either of the arrow keys is pressed, the dry time L.E.D. and the total dry time
on the 4-digit numeric display will flash. If you press and hold either arrow key
down, you will increment (UP arrow) or decrement (DOWN arrow) through the

-18-
total dry times available (1 through 60 minutes). This displayed dry time includes
the cool down time along with the heated time. To not change the total dry time,
do not press the arrow keys to change the total dry time.
5) Press and release the SELECT/ENTER key. Once this key is pressed and released,
the dry time L.E.D. will switch off, the dry cycle L.E.D. and programming L.E.D. will
remain on, and the temperature L.E.D. will illuminate. The drying temperature will
also be shown on the 4-digit numeric display.
6) Press and release the UP or DOWN arrow keys to change the drying temperature.
Each press and release of the arrow keys will either increase or decrease the
temperature by five degrees Fahrenheit or three degrees Celsius, depending on how
your dryer controller is set up. Once either of the arrow keys is pressed, the
temperature L.E.D. and the drying temperature on the 4-digit numeric display will
flash. If you press and hold either arrow key down, you will increment (UP arrow)
or decrement (DOWN arrow) your way through the available drying temperatures
(105ºFahrenheit or 40ºCelsius, up to 195ºFahrenheit or 91ºCelsius). If you do not
want to change the drying temperature, do not press the arrow keys. Go to the
next step.
7) Press and release the SELECT/ENTER key. Once this key is pressed and released,
the temperature L.E.D. will switch off, the dry cycle L.E.D. and programming L.E.D.
will remain on, and the cool down L.E.D. will illuminate. The cool down time will
also be shown on the 4-digit numeric display.
8) Press and release the UP or DOWN arrow keys to change the cool down time. Once
either of the arrow keys is pressed, the cool down L.E.D. and the cool down time on
the 4-digit numeric display will flash. If you press and hold either arrow key down,
you will increment (UP arrow) or decrement (DOWN arrow) through the cool down
times available (2 through 60 minutes). To not change the cool down time, do not
press the arrow keys. Go to the next step.
9) Press and release the SELECT/ENTER key. Once this key is pressed and released,
the cool down L.E.D. and the programming L.E.D. will switch off, and the dry cycle
L.E.D. will remain on. The flashing cool down time on the 4-digit display will stop
flashing and remain.
10)At this point, you have two choices. 1) You can perform the modified dry cycle by
pressing and releasing the START key on the dryer controller touch pad, or 2) You
can clear the modified dry cycle program by pressing and releasing the STOP key
once. If you start the modified cycle, the total dry time will appear on the 4-digit
numeric display and it will count down to 0 as the dry cycle progresses. If you choose
to clear the modified dry cycle, the 4-digit numeric display will change to “LOAd”.
TEMPORARY DRYER CONTROLLER PROGRAMMING
EXAMPLE
REQUIREMENTS: Dry a load with 40 minutes of actual heat at 185ºF and five minutes
of cool down.

-19-
The following procedure will show you how to temporarily modify the existing dry
cycle 1 program for one cycle of drying. It is based on the assumption that the factory
defaults have not been permanently changed. If they have been changed, the steps of
this procedure will be the same, but the values that are displayed will be different. The
amount of times that the dryer controller touch pad UP or DOWN keys must be pressed
and released may also be different.
If you want the change to be permanent, go to the “PERMANENT DRYER
CONTROLLER PROGRAMMING” section of this manual.
PROCEDURE
1) After the load has been placed in the dryer, press and release the UP or DOWN
touch pad key on the dryer controller until the L.E.D. for dry cycle 1 is illuminated.
2) Press and release the CYCLE key on the dryer controller touch pad. You will see
the number “35” on the dryer controller display. The programming L.E.D. and dry
time L.E.D. will be illuminated.
3) Press and release the UP arrow key on the dryer controller touch pad 10 times so
the display will show a flashing “45”. When the UP arrow touch pad key is pressed
the first time, the number “36” will be flashing on the dryer controller display. Each
number after that will also flash.
4) Now, press and release the SELECT/ENTER touch pad key on the dryer controller.
The number “45” will stop flashing and the dry time L.E.D. will switch off. The dryer
controller display will now show “180”, the temperature L.E.D. will illuminate, and
the programming L.E.D. and dry cycle 1 L.E.D. will remain on.
5) Press and release the UP arrow key on the dryer controller touch pad one time so
the controller display will show a flashing “185”. Each press of the UP arrow key will
increment the temperature by five degrees.
6) Now, press and release the SELECT/ENTER touch pad key on the dryer controller.
The number “185” will stop flashing and the temperature L.E.D. will switch off. The
dryer control display will now show a number “5”, the cool down L.E.D. will
illuminate, and the programming L.E.D. and dry cycle 1 L.E.D. will remain on.
7) Press and release the SELECT/ENTER key on the dryer controller touch pad, since
the desired cool down time is five minutes. After you press the SELECT/ENTER
touch pad key on the controller, the cool down L.E.D. and programming L.E.D. will
switch off. The controller display will remain at “5” and the cycle 1 L.E.D. will
remain on.
You are now ready to start the new dry cycle. This new dry cycle will be in effect for
one dry cycle only. After the dry cycle is done, or if the STOP touch pad key on the
dryer controller is pressed and released twice, consecutively, the cycle 1 program will
revert to the factory default settings.

-20-
If you press the START touch pad key on the dryer controller, the controller display will
change from the number “5” to the number “45” and dry cycle 1 will begin.
PERMANENT DRYER CONTROLLER PROGRAMMING
The permanent programming mode will allow the change of the stored dry cycle
settings in the dryer controller until the operator physically changes them again. The
factory default settings can be restored in the dryer controller by pressing the default
settings pushbutton on the back (component) side of the dryer controller circuit board.
It is labeled and located at the lower middle side of the printed circuit board, as you
face the component side of the board. It must be pressed and held down for at least
three seconds.
To permanently change a dryer controller cycle, follow the procedure below. Things
that are displayed on the 4-digit numeric display will be in “quotation marks”. Keys on
the touch pad that physically need to be pressed will be in CAPITAL AND BOLD
LETTERS.
If, at any time, you want to escape the permanent programming mode while
changing the settings, you can press the STOP key on the dryer controller touch pad if
the 4-digit numeric display is not flashing. The SELECT/ENTER key on the dryer
controller touch pad can be pressed and released to enter the flashing value shown on
the 4-digit numeric display and allow you to escape.
PROCEDURE
1) Make sure the dryer is not in a dry cycle. The 4-digit numeric display on the dryer
controller will show “LOAd” when the dryer is not in a dry cycle.
2) Press and release the PROG key on the dryer controller touch pad.
3) Press and release the UP arrow key on the dryer controller touch pad. The
programming L.E.D. will illuminate and the 4-digit numeric display on the dryer
controller will change to “Prog”.
4) Press and release the UP or DOWN arrow keys to choose the dry cycle you want to
change (dry cycle 1 through 5). The dry cycle L.E.D. will illuminate to indicate
which dry cycle you are choosing. If you press either arrow key and hold it down,
the controller will sequence through the five dry cycles.
5) Press and release the SELECT/ENTER key once you have chosen the dry cycle you
want to change. After you press this key, the dry time L.E.D. will illuminate. The
dry cycle L.E.D. and the programming L.E.D. will remain illuminated. The total dry
time will also be displayed on the 4-digit numeric display.
6) Press and release the UP or DOWN arrow keys to change the total dry time. Once
either of the arrow keys is pressed, the dry time L.E.D. and the total dry time on the
4-digit numeric display will flash. If you press and hold either arrow key down, you
will increment (UP arrow) or decrement (DOWN arrow) through the total dry times
available (1 through 60 minutes). This displayed dry time includes the cool down
