Dexter Laundry DN20X2 Guide

USE THE BLUE TABS LOCATED ON THE
RIGHT AND LEFT SIDES OF THE FOLLOWING
DOCUMENT TO ADVANCE TO EACH SECTION.
8533-108-001 10/22

8533-108-001 10/22
Service and Parts Data
OPL Stack Dryer
DN20X2
Indicates an imminently hazardous situation, which if
not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation, which if not
avoided could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may
also be used to alert against unsafe practices. Minor
burns, pinch points that result in bruises and minor
chemical irritation.
Indicates information or a company policy that relates
directly or indirectly to the safety of personnel or protec-
tion of property.
This is the user caution symbol. It indicates a condition
where damage to the equipment resulting in injury to
the operator could occur if operational procedures are
not followed. TO REDUCE THE RISK OF DAMAGE OR
INJURY, refer to accompanying documents; follow all
steps or procedures as instructed.
This is the electrical hazard symbol. It indicates that
there are DANGEROUS HIGH VOLTAGES PRESENT inside
the enclosure of this product. TO REDUCE THE RISK OF
FIRE OR ELECTRIC SHOCK, do not attempt to open the
enclosure or gain access to areas where you are not
instructed to do so. REFER SERVICING TO QUALIFIED
SERVICE PERSONEL ONLY
Caution! There are sharp edges on various sheet metal
parts internal to the enclosure. Use safety consciousness
when placing or moving your hands while working in the
interior of this equipment.
Caution! To reduce the risk of damage to the Water Inlet
Valve, do not supply inlet water with a temperature that
exceeds 70˚ C.
Caution! To reduce the risk of re or explosion, do not
operate this equipment in any hazardous classied
(ATEX) environment.
Equipment Safety Warnings
Symbols and Terminology Used in this Equipment
3
Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

Warning! Do not operate equipment if door glass is
damaged in any way.
Warning! Keep clear of rotating parts.
Prohibited! Do not enter this equipment or space.
Prohibited! Do not step or stand on this equipment.
Prohibited! Do not operate without all guards and covers in
place.
Prohibited! Do not operate without all guards and covers in
place.
Prohibited! Do not wash or Dry clothing impregnated with
ammable liquids (petrochemical).
Prohibited! Do not allow children to play in or around
equipment.
Equipment Safety Warnings
Symbols and Terminology Used in this Equipment
Indicates an imminently hazardous situation,
which if not avoided, will result in death or seri-
ous injury.
Indicates a potentially hazardous situation,
which if not avoided could result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury. It may also be used to alert
against unsafe practices. Minor burns, pinch
points that result in bruises and minor chemical
irritation.
Indicates information or a company policy that
relates directly or indirectly to the safety of per-
sonnel or protection of property.
This is the user caution symbol. It indicates a
condition where damage to the equipment re-
sulting in injury to the operator could occur if
operational procedures are not followed.
TO REDUCE THE RISK OF DAMAGE OR INJURY,
refer to accompanying documents; follow all
steps or procedures as instructed.
This is the electrical hazard symbol. It indicates
that there are DANGEROUS HIGH VOLTAGES
PRESENT inside the enclosure of this product.
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, do not attempt to open the enclosure or
gain access to areas where you are not instruct-
ed to do so. REFER SERVICING TO QUALIFIED
SERVICE PERSONEL ONLY
Caution! To reduce the risk of re or explosion,
do not operate this equipment in any hazardous
classied (ATEX) environment.
4 5
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

• All Dryers must be installed in accordance to
all applicable electrical, plumbing and all other local
codes.
• These installation and operation instructions are
for use by qualied personnel only. To avoid injury
and electrical shock, do not perform any servicing
other than that contained in the installation and op-
eration instructions, unless qualied.
Do not install Equipment in an explosive atmosphere.
•Care must be stressed with all foundation work to
ensure a stable unit installation, eliminating pos-
sibilities of excessive vibration.
•Foundation must be level within 13 mm to ensure
proper washer operation.
Do not operate washer or Dryer if door glass is dam-
aged in any way.
Do not wash or Dry clothing impregnated with am-
mable liquids (petrochemical).
WARNING
Children should be supervised to
ensure they do not operate or play
in or around equipment.
Keep all panels in place to protect against electrical
shock and injury and add rigidity to washer.
WARNING
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
A washer should not be allowed to operate if any of the following occur:
• Excessive high water level.
• Machine is not connected to a properly earthed circuit.
• Door does not remain securely locked during the entire cycle.
• Vibration or shaking from an inadequate mounting or foundation
6 7
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

Warning! Do not operate equipment if door glass is
damaged in any way.
Warning! Keep clear of rotating parts.
Prohibited! Do not enter this equipment or space.
Prohibited! Do not step or stand on this equip-
ment.
Prohibited! Do not operate without all guards and
covers in place.
Prohibited! Do not operate without all guards and
covers in place.
Prohibited! Do not wash or Dry clothing impreg-
nated with ammable liquids (petrochemical).
Prohibited! Do not allow children to play in or
around equipment.
Prohibited! Do not attempt to open, touch, or pro-
ceed before referring to the manual or unless quali-
ed.
Mandatory! Read all supporting documentation be-
fore operating or maintaining equipment.
Mandatory! Disconnect power before servicing
equipment.
Mandatory! Lock out and tag out before servicing
this equipment.
Mandatory! Children should be supervised to ensure
they do not operate equipment.
8 9
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

Dry only fabrics washed in water
to avoid the risk of fire, including
spontaneous combustions, do not dry:
• Items containing foam rubber, or any
similarly textured rubber-like materials.
• Any items on which you have used a
cleaning solvent or which contain amm.
able liquids or solids, such as naptha,
gasoline, or other oils or waxes.
Table of Contents
Section 1:
Specications .............................. 14-15
Installation Dimensions .....................16
Section 2:
Installation and Operation
Installation Clearances ......................20
Make Up Air .....................................21
Electrical Requirements .....................21
Gas Requirements ............................21
Burner Set Up ..................................21
Exhaust Installation ..................... 22-23
Description of Control .................. 24-25
Operating Instructions ................. 27-28
Programming .............................. 28-33
Section 3:
Wiring Schematics
Dryer Idle ........................................36
Motor Starting and Running...............36
Heat Circuit......................................36
Over Temperature Thermostat...........37
Cool Down .......................................37
End of Cycle.....................................37
Wiring Diagram for DN20X2 Dryer......40
Wiring Schematic for DN20X2 Dryer ...41
Section 4:
Service Procedures
Clothes Door Removal.......................44
Clothes Door Latch Adjustment..........44
Door Switch Removal and Installation.44
Installation of Clothes Door Window and
Gasket.......................................... 44
Dexter Safety Guidelines
WARNING
For your safety, the information in this manual
must be followed to minimize the risk of re
or explosion or to prevent property damage,
personal injury or loss of life.
IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any
telephone in your building.
• Clear the room, building or area of all occupants.
• Imm.ediately call your gas supplier from a
neighbor’s telephone.
• Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the
re department. Installation and service must be
performed by a qualied installer, service agency or
the gas supplier.
To activate your warranty, be sure to return
your red warranty form to the factory. Please
have serial number and model ready when
calling for assistance.
10 11
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
10
Notes
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

High Limit Thermostat Locations and
Functions...............................44-45
Pressure Regulator Adjustment ..........45
Heat Sensor .....................................45
Electronic Control Removal ................45
Membrane Switch Replacement .........45
Temperature Sensor Testing ..............45
Temperature Testing .........................46
Temperature Sensor Removal ............46
Upper Front Panel Removal ...............46
Lower Front Panel Removal ...............46
Final Drive Belt Replacement .............46
Motor Drive Belt Replacement............46
Tumbler Pulley Removal/ Installation ..46
Intermediate Pulley and Tension Arm
Removal .....................................47
Tension Arm Support Assembly
Adjustment .................................47
Motor and Blower Assemly Removal
and Installation ...........................47
Air Flow Switch Operation and
Adjustment .................................47
Ignition Transformer Fuse..................47
Ignition Control Transformer ..............47
Electronic Ignition Module ............ 47-48
Spark Ignition Module Removal..........48
Ignition System Function/Sequence....48
Ignition System Checkout ..................49
Spark Electrode Assembly Removal ....49
Gas Valve & Manifold Removal ...........49
Main Burner Orice Removal..............49
Main Burner Removal ........................49
Recirculation Chamber Inspection ......49
Cylinder Removal..............................49
Adjustment of Cylinder Assembly
with Front Panel Removed............50
Tumbler Through Bolt Access Cover ...50
Bearing Housing Removal..................50
Section 5:
Troubleshooting
Trouble Shooting Fault Codes ............55
Troubleshooting Tips.................... 55-58
Section 6:
Parts Data
Cabinet Group ............................. 62-65
Rear Panel & Cover Group.................66
Burner Housing Group .................68-69
Bearing Housing/Tumbler Group ... 70-71
Rear View ................................... 72-75
Control Assembly Group............... 76-77
Door Switch Group ...........................78
OPL Control .....................................79
Section 7:
60 Hz Electric Heated Models
-84..................................................82
-85..................................................86
-86..................................................90
-87..................................................94
Section 8:
50Hz Models
Section 9:
50Hz Electric Heated Models
Section 10:
Maintenance
Regular Required Maintenance......... 104
12 13
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Notes
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

Express Stack Dryer Specications
Model DN20X2ND-15
Capacity:
Dry Weight Capacity - lb (kg) 2 x 20 (2 x 9.1)
Cylinder Volume (per tumbler) - cu ft (L) 7 (198.2)
Speed:
Tumbler Speed - RPM 51
Motor Size (per tumbler) - hp (kW) 0.3 (0.25)
Airow (per tumbler):
60 Hz Model - cfm (M3/min) 370 (10.5)
50 Hz Model - cfm (M3/min) 300 (8.5)
Dimensions:
Cabinet Height - in (cm) 68 1/2 (174)
Cabinet Width - in (cm) 27 (68.6)
Cabinet Depth - in (cm) 44 5/8 (113.3)
Door Opening - in (cm) 18 1/8 (46)
Floor to Lower Door Bottom - in (cm) 8 1/2 (21.6)
Floor to Upper Door Bottom - in (cm) 42 (106.7)
Cylinder Diameter - in (cm) 25 1/2 (64.8)
Cylinder Depth - in (cm) 24 (61)
Lint Screen Area (per tumbler) - sq in (sq cm) 285 (1839)
Weight:
Net Weight - lb (kg) 615 (279)
Shipping Information:
Shipping Weight - lb (kg) 650 (295)
Shipping Height - in (cm) 74 (188)
Shipping Width - in (cm) 31.5 (80)
Shipping Depth - in (cm) 49 (124.5)
Gas Requirements (Gas Models Only):
Gas Supply Connection - in (mm) 1/2 (12.7)
Natural Gas Supply (Water Column) - in (cm) 5-8 (12.7 - 20.3)
LP Gas Supply (Water Column) - in (cm) 11 1/2-14 (29.2-35.6)
Gas Usage (Gas Models Only):
60Hz Model (per tumbler) - BTU/hr (kW) 56,000 (16.4)
50Hz Model (per tumbler) - BTU/hr (kW) 47,000 (13.8)
15
Part # 8533-108-001 10/22
14
Part # 8533-108-001 10/22
Section 1:
Specications
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

Electrical Requirements:
Gas Models (per stack dryer):
Model Volts / Hz / Phase / Wiring Circuit Breaker Amps / Running Amps / Wire Size
-15 208-240 / 60 / 1 / 2 wire + ground 15 / 3.8 / #12
-15 120 / 60 / 1 / 2 wire + ground 15 / 7.8 / #12
-39 230 / 50 / 1 / 2 wire + ground 15 / 3.8 / 3.5 mm2
-59 230 / 50 / 1 / 2 wire + ground 15 / 3.8 / 3.5 mm2
Electric Models (per tumbler):
Model kW / Volts / Hz / Phase / Wiring Circuit Breaker Amps / Running Amps / Wire Size
-82 15 / 400 / 50 / 3 / 4 wire + ground 30 / 30 / 8.4 mm2
-84 15 / 208 / 60 / 3 / 4 wire + ground 60 / 55 / #4
-85 15 / 240 / 60 / 3 / 4 wire + ground 50 / 50 / #4
Installation Recommendations:
Minimum Clearance Between Machines - in (cm) 0 (0)
Minimum Clearance Behind Machines - in (cm) 18 (45.7)
Make-Up Air Required (per stack dryer) - sq ft (sq cm) 1 (929)
Exhaust Size - in (cm) 8 (20.3)
Max. Exhaust Back Pressure (Water Column) - in (mm) 0.3 (7.6)
Recommended Exhaust Length - ft (m) & 2 elbows 14 (4.3)
16 17
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

18 19
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Notes Notes
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

1.
DRYER INSTALLATION
1. CODE CONFORMITY: All commercial dryer installations must conform with local codes, or in
the absence of local codes, with the latest edition of the National Fuel Gas Code ANSI
Z223.1. Canadian installations must comply with the current Standard CAN/CGA-B149
(.1 or .2) Installation Code for Gas Burning Appliances or Equipment, and local codes if
applicable. Australian installations must meet installation requirements and pipe sizing requirments
of AS/NZA 5601. The appliance, when installed, must be electrically grounded in
accordance with the latest edition of the National Electric Code, ANSI/NFPA70, or, when installed
in Canada, with Standard CSA C22.1 Canadian Electrical Code Part 1.
2. INSTALLATION CLEARANCES: This unit may be installed at the following alcove clearances:
I. Left Side 0”
II. Right Side 0”
III. Back 18” (457 mm) (Certied for 6” (150 mm) clearance; however, 18” (457 mm) clearance
is necessary behind the motors to allow servicing and maintenance.)
IV. Front 48” (1220 mm) (to allow use of dryer)
V. Top Refer to gure labeled “Vertical Clearance Dimensions”.
AB. Certication allows 0” clearance at the top 4” (100 mm) back from the front.
However, a 1/4” (6 mm) clearance should be allowed in case the dryer needs moving.
C. A 10” (250 mm) clearance is required from top at all other points.
VI. Floor This unit may be installed upon a combustible oor.
Do not obstruct the ow of combustion and ventilation air.
Maintain minimum of 1” (25 mm) clearance between duct and combustible material.
Refer to the label attached to the Belt Guard on the rear of the dryer for other installation information and
start-up instructions.
The sources of all make-up air and room ventilation air movement to all dryers must be located away
21
Part # 8533-108-001 10/22
20
Section 2:
Installation
& Operation
Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

3. MAKE-UP AIR: Adequate make-up air must be supplied to replace air exhausted by dryers on
all types of installations. Refer to specications for the minimum amount of make-up air opening
to outside for each dryer. This is a net requirement of eective area. Screens, grills or lou
vers, which will restrict the ow of air, must be considered. Consult the supplier to determine the
free area equivalent for the grill being used. The source of make-up air should be located
suciently away from the dryers to allow an even airow to the air intakes of all dryers. Multiple
openings should be provided.
The sources of all make-up air and room ventilation air movement to all dryers must be located
away from any dry cleaners. This is necessary so that solvent vapors will not be drawn into
the dryer inlet ducts. Dry cleaner solvent vapors will decompose in contact with open ame
such as the gas ame present
in clothes dryers. The decomposition products are highly corrosive and will cause damage to the
dryer(s) ducts and clothes loads.
4. ELECTRICAL REQUIREMENTS. The electrical power requirements necessary to operate the
unit satisfactorily are listed on the serial plate located on the back panel of each dryer and
in the specications section of this manual. The electrical connection should be made to the ter
minal board, on the rear of the unit. It is absolutely necessary that the dryer be grounded
to a known ground. Individual circuit breakers for each stacked dryer are required. Dryer
-15 models are adjusted for 120V as shipped. They can be converted to 208-240V
as required. Instructions for this conversion are located in the schematic section of this manual.
5. GAS REQUIREMENTS. The complete gas requirements necessary to operate the dryer
satisfactorily are listed on the serial plate located on the back panel of the dryer and in the
specications section of this manual. The inlet gas connection to the unit is 1/2-inch pipe thread.
However, the size of the piping to supply the dryer should be determined by reference to the
National Fuel Gas Code ANSI Z223.1A and consultation with the local gas supplier.
An individual gas shuto valve is recommended for each dryer and may be required by local code
(not supplied). A joint compound resistant to the action of liqueed petroleum gases should be
employed in making pipe connections. A 1/8-inch NPT plugged tapping, accessible for test gage
connection, must be installed immediately upstream of the gas supply connection to the dryer.
A drip tee is provided in the unit gas piping to catch dirt and other foreign articles. All pipe
connections should be checked for leakage with soap solution. Never check with an open ame.
For altitudes above 2,000 feet (610m), it is necessary to derate the BTU input.
Contact your local distributor for instructions. L.P. gas conversion kits are available for this dryer.
Contact your local distributor.
CAUTION: The dryer must be disconnected from the gas supply piping system during any pres
sure testing of that system. Do not expose the dryer’s gas control valve to testing pressure.
Burner Set-Up
All gas burner manifolds should be checked for proper gas pressure while burning. Stack dryer
burners should be set at 3.5 W.C. while burner operating.
6. EXHAUST INSTALLATION. (Refer to Figure 3) Exhausting of the dryer(s) should be planned
and constructed so that no air restrictions occur. Any restriction due to pipe size or type of
installation can cause slow drying time, excessive heat, and lint in the room.
From an operational standpoint, incorrect or inadequate exhausting can cause a cycling of the
high limit thermostat, which shuts o the main burners and results in inecient drying.
The exhaust duct connection near the top of the dryer will accept an 8” (200 mm) round duct.
Individual exhausting of the dryers is recommended. All heat, moisture, and lint should
be exhausted outside by attaching a pipe of the proper diameter to the dryer adapter collars and
extending it out through an outside wall. This pipe must be very smooth on the inside, as
rough surfaces tend to collect lint, which will eventually clog the duct and prevent
the dryer from exhausting properly. All elbows must be smooth on the inside. All joints must be
made so the exhaust end of one pipe is inside the next one downstream. The addition of
an exhaust pipe tends to reduce the amount of air the blower can exhaust. This does not
aect the dryer operation if held within practical limits. For the most ecient operation, it
is recommended that no more than 14 ft. (4.25 m) of straight 8 in. diameter pipe with two right
angle elbows be used for each cylinder.
Maintain a minimum of 1” (25mm) clearance between duct and combustible material.
If the exhaust pipe passes through a wall, a metal sleeve of slightly larger diameter should be set
in the wall and the exhaust pipe passed through this sleeve. This practice is required by some lo
cal codes and is recommended in all cases to protect the wall.
This type of installation should have a means provided to prevent rain and high winds from enter
ing the exhaust when the dryer is not in use. A hood with a hinged damper can be used for
this purpose. Another method would be to point the outlet end of the pipe downward to prevent
entrance of wind and rain. In either case, the outlet should be kept clear, by at least 24 in.
(610 mm) of any objects, which would cause air restriction.
Never install a protective screen over the exhaust outlet.
When exhausting a dryer straight up through a roof, the overall length of the duct has the same
limits as exhausting through a wall. A rain cap must be placed on top of the exhaust and must be
of such a type as to be free from clogging. The type using a cone shaped “roof” over the pipe is
suitable for this application.
Exhausting the dryer into a chimney or under a building is not permitted. In either case there is a
danger of lint buildup, which can be highly combustible.
Installation of several dryers, where a main discharge duct is necessary, will need the follow
ing considerations for installation (see Figure 3). Individual 8” (200 mm) exhaust ducts from each
dryer should enter main discharge duct at a 45-degree angle in the direction of discharge airow.
NOTE: Never install the individual ducts at a right angle into the main discharge duct. The indi
vidual ducts from the dryers can enter at the sides or bottom of the main discharge duct. Figure 3
indicates the various round main duct diameters to use with the individual dryer ducts. The
main duct can be rectangular or round, provided adequate airow is maintained. The to
tal exhausting (main discharge duct plus duct outlet from the dryer) should not exceed the equiva
lent of 14 ft. (4.25 m) and two elbows. The diameter of the main discharge duct at the last
dryer must be maintained to exhaust end.
NOTE: STATIC BACK PRESSURE should be a maximum of 0.3 in. w.c (7.6 mm w.c) at the rear
exhaust outlet of the dryer. If multiple dryers are connected to the common duct, ensure the back
draft damper is installed properly.
22 23
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

periodic clean out of the main duct.
7. DRYER IGNITION (SOLID STATE IGNITION): The solid-state ignition system lights the main burner gas by spark.
The gas is ignited and burns only when the gas-relay (in the electronic controller) calls for heat. The procedure for
first-time starting of a dryer is as follows.
i. First review and comply with the "Warnings About Use and Operation" found on the inside front cover
of this manual. Be sure electrical power is connected correctly. The dryer must be properly grounded.
NOTE: A small diameter duct will restrict airow; a large diameter duct will reduce air
velocity - both contributing to lint build up. An inspection door should be provided for
periodic clean out of the main duct.
7. DRYER IGNITION (SOLID STATE IGNITION): The solid-state ignition system lights
the main burner gas by spark. The gas is ignited and burns only when the gas-relay (in the elec
tronic controller) calls for heat. The procedure for rst-time starting of a dryer is as follows.
I. First review and comply with the “Warnings About Use and Operation” found on the
inside front cover of this manual. Be sure electrical power is connected correctly. The
dryer must be properly grounded.
II. Make sure all gas supply lines are purged of air. Close the main gas shut-o valve and
wait for ve minutes before turning it back on.
III. Turn on the main electrical power switch. The dryer may be started by following the
“Operating Instructions” found later in this manual.
IV. Natural gas and LPG red dryers operate in the same manner. When the gas valve relay
contacts are closed (indicating a demand for heat), the solid-state ignition control will
automatically supply energy to the redundant gas valve. Sparking will continue until a
ame is detected by the sensing probe, but not longer than ten seconds. If the gas fails
to ignite in 10 seconds, the gas valve closes and the gas system pauses to allow gas to
purge from the inside of the dryer. After the pause, the ignition control repeats the igni
tion trial cycle twice more. If the gas system fails to detect ignition after the three at
tempts, the system will “lock out”. No further attempts will be performed automatically.
To reset the ignition control electrical power to the ignition control must be interrupted.
This can be done by opening the dryer door (stopping the dryer) for 15 seconds. Clos
ing the door and pushing the “Start” button will repeat the ignition trial cycle.
8. MAIN BURNER ADJUSTMENT. The primary air shutter of each main burner must be prop
erly adjusted for the correct air-gas ratio. Loosen the shutter locking screw. Adjust the shutter
by closing it suciently to give a blue ame with a yellow tip. Next open the shutter until the
yellow tips are at a minimum. After adjustment securely lock each shutter in position by tighten
ing the shutter locking screws.
9. DRYER SHUTDOWN. To render the dryer inoperative, turn o the main gas shut o valve and
disconnect the electrical supply to the dryer.



24 25
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

Touch Pad Description
Description
These L.E.D.s are on solid when a particular cycle is chosen for operation or programming.
This L.E.D. is part of the 4-digit numeric display and will be on solid during the drying part of a
cycle when the gas valve does not need to be on. The L.E.D. will be blinking when the gas valve
needs to be on. The L.E.D. will not be on solid or blinking (o) if the cycle is stopped, complete,
in cool down, or terminated.
These L.E.D.s are on solid as they are selected during the programming of the dryer controller.
This L.E.D. is on solid when either the stop button is pressed once or the door is opened during
an operating cycle.
Description
This touch pad switch will increment (increase) dry time, cool down time, and drying temperature.
It will also scroll upwards when selecting a dry cycle.
This touch pad switch will decrement (decrease) dry time, cool down time and drying
temperature. It will also scroll downwards when selecting a dry cycle.
This touch pad switch allows the dryer controller to enter the permanent prdgramming mode.
This touch pad switch will select one of the three variable parts of the dry cycle (dry time,
temperature, or cool down) by sequencing through them. Once one ofthe variable parts of the
dry cycle is chosen and changed, this touch pad switch will enter the new (changed) value into
the dry cycle program.
This touch pad switch allows the dryer controller to enter the temporary programming mode.
This touch pad switch will stop the dryer during a dry cycle without clearing the present drying
cycle if pressed once. If pressed and released twice, consecutively, the present dry cycle will be
cleared.
This touch pad switch will start the operation of a dry cycle if pressed and
released once. Pressing and holding this touch pad switch will display the current
temperature of the dryer heat sensor as long as it is held in the depressed
position.
Description
This message is displayed after a dry cycle is complete and the dryer loading door
has been opened or the STOP touch pad key on the dryer controller has been
pressed and released twice.
This message blinks immediately after completion of the dry cycle and continues
to blink until the stop key on the dryer controller touch pad is pressed or the dryer
loading door is opened.
This message is displayed when entering the permanent programming mode.
This message appears while the dryer is in the heating time of a dry cycle.
The decimal point will blink if the output for the gas valve is on, or remain on
constantly if the output for the gas valve is not on. The number represents the
total time left in the dry cycle (includes cool down time).
This message appears when the cool down time of the dry cycle is reached.
The letter “C” represents the cool down (non-heating) part of the dry cycle. The
number(s) after the letter “C” represent(s) the total time remaining in the dry
cycle.
This message appears if there is a dryer fault. The letter “F” indicates a fault and
the number after the “F” represents the specic fault that has occurred. There are
ve dierent faults that can appear (Fl through F5).
Start
Message
LOAd
donE
Prog
.15
C02
F5
26 27
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

Operating Instructions
To dry a load of items, you must choose one of the ve-programmed dry cycles. Each of these ve dry
cycles may be modied in two dierent ways to match your load. Please refer to the “Permanent Dryer
Controller Programming” or “Temporary Dryer Controller Programming” section of this manual.
There are two parts to each dry cycle. The rst part is the heating time, which is when the gas valve is
cycled on and o according to the temperature setting in the dry cycle program. The second part is the
cool down time, which is after the heating part of the dry cycle, and is when the cylinder continues to tum,
but no heat is applied.
There will always be at least two minutes of cool down time for each dry cycle. The maximum amount of
cool down time is 60 minutes.
The default value of the ve dry cycles is shown in the “Dryer Controller Factory Default Program Settings”
table in this manual.
To improve the drying capabilities of this dryer, you should always separate (untangle) the individual aticles
in your load before using the dryer.
In the following instruction steps, things that are displayed on the 4-digit numerical display will be in “quo-
tation marks” and any keys on the dryer controller touch pad that physically need to be pressed will be in
CAPITAL AND BOLD LETTERS.
1. Place your untangled load into the dryer cylinder and close the dryer loading door. Notice that the
dryer controller 4-digit numerical display should show the word “LOAd”. It does not show this word,
then press and release the STOP touch pad key on the dryer controller twice.
2. Press and release the UP or DOWN arrow touch pad key on the dryer controller to select a dry cycle.
3. Once the desired dry cycle is selected, press and release the START touch pad key.
4.
After the dryer controller START touch pad key is pressed, the dryer cylinder will start rotating and the
two-digit total dry cycle time, along with a decimal point, will appear on the dryer controller display.
The time shown on the dryer controller display will count down to the programmed cool down time. At
that time, the display will change from the decimal point and two-digit number to a letter “C” and two
digits.
The letter “C” represents the cool down portion of the dry cycle. The two digits represent the amount of
time remaining in the dry cycle. The two-digit time, shown on the dryer controller display, will count down
to zero.
When the time decrements to zero, the dryer controller display will ash the word “donE” and the end of
cycle tone will sound.
At that point, the wrinkle free cycle will automatically begin. This cycle will wait two minutes, if the door is
not opened or the STOP touch pad key on the dryer controller is not pressed, and then rotate the cylinder
for 10 seconds and stop. This idle time of two minutes and tumble time of 10 seconds will repeat a total of
10 times, at which time the wrinkle free cycle stops. The cylinder will not rotate again until a new dry cycle
is started.
During the wrinkle free cycle the gas valve will not be operated and there will be no heat applied to the
load. The word “donE” will also continue to ash and do so even after the wrinkle free cycle is nished.
When the dryer loading door is opened, or the STOP touch pad key is pressed, the word “donE” will
change to the word “LOAd” on the dryer controller display. The dryer will then be ready for another dry
cycle.
During the dry cycle, either pressing the STOP touch pad key on the dryer controller or opening the dryer
loading door, will stop the dry cycle and not clear it. If you press the STOP touch pad key on the controller
and then open the dryer loading door the dry cycle will not be cleared. However, if you open (or open and
close) the dryer loading door and then press the STOP touch pad key on the dryer controller, the present
dry cycle will be cleared and the word “LOAd” will appear on the dryer controller display.
There are two jumpers and one push button on the component side of the dryer controller printed circuit
board.
The jumper located at the back right side of the each circuit board controls whether the controller display
shows and operates in the Fahrenheit or Celsius mode. This jumper is labeled as TEMP SELECT and has
three pins. The back and middle pins are for Celsius and the front and middle pins are for Fahrenheit,
which is indicated by the letter C for Celsius and the letter F for Fahrenheit.
The other jumper, located at the back middle side of each circuit board controls, is used for choosing ei-
ther a reversing or non-reversing type of dryer. This jumper is labeled as REV and NON-REV. This jumper
must be in the non-reversing position, which are the front and middle pins. If the jumper is in the revers-
ing position, the heating part of the dry cycle will not operate properly. The dryer will not reverse direction
either.
The push button, which is located at the middle center of each circuit board controls, is used to reset all
ve of the dry cycles to the factory default settings. It is labeled as DEFAULT SETTINGS. Even the dry
cycles that have been modied using the permanent programming procedure will be changed back to the
factory default settings when using this push button. This push button must be pressed and held for at
least three seconds with power applied to the dryer controller circuit board.
If changing a jumper, remove power before moving jumper and then move jumper. Before restoring
power, press and hold the DEFAULT SETTINGS pushbutton. Then, restore power and release the DEFAULT
SETTINGS pushbutton after three seconds of restoring power.
Temporary Dryer Controller Programming
The temporary programming mode will allow the change of the stored dry cycle settings in the dryer con-
troller for one complete dry cycle. After the dry cycle is complete, the default settings that existed before
the temporary change are restored. The temporary dry cycle can be stopped and cleared at any time dur-
ing the dry cycle operation.
To temporarily change a dryer controller cycle, follow the procedures below. Things that are displayed on
the 4-digit numeric display will be in “quotation marks”. Keys on the dryer controller touch pad that physi-
cally need to be pressed will be in CAPITAL AND BOLD LETTERS.
If, at any time, you want to escape the temporary programming mode while changing the program set-
tings, you can press the STOP key on the dryer controller touch pad if the 4-digit numeric display is not
ashing. The SELECT/ENTER key on the dryer controller touch pad can be pressed and released to enter
the ashing value shown on the 4-digit numeric display and allow you to escape.
If you press and release the STOP key on the dryer controller touch pad, when the 4-digit numeric display
is not ashing, the temporary changes to the dry cycle program will be cancelled. The stored dry cycle
settings that existed before the temporary change will then be restored.
If, at any time, you want to start the temporary dry cycle during the temporary programming mode, press
and release the START key on the dryer controller touch pad if the 4-digit numeric display is not ash-
ing. The SELECT/ENTER key on the dryer controller touch pad can be pressed and released to enter the
ashing value shown on the 4-digit numeric display and allow you to start the temporary dry cycle. If you
start the temporary dry cycle, the 4-digit numerical display will change to the total dry time and count
down to 0 as the dry cycle progresses.
28 29
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

Procedure
1. Make sure the dryer is not in a dry cycle. The 4-digit numeric display on the dryer controller will show
“LOAd” when the dryer is not in a dry cycle.
2. Press and release the UP or DOWN arrow keys on the dryer controller touch pad to chose the dry
cycle that you want to change (dry cycle 1 through 5). The dry cycle L.E.D. will illuminate to indicate
which dry cycle you are choosing. If you press either arrow key and hold it down, the controller will
sequence through the ve dry cycles.
3. Press and release the CYCLE key on the dryer controller touch pad once you have chosen the dry
cycle you want to change. After you press this key, the programming L.E.D. and the dry time L.E.D.
will illuminate. The dry cycle L.E.D. will remain illuminated. The total dry time will also be displayed on
the 4-digit numeric display.
4. Press and release the UP or DOWN arrow keys to change the total cycle time. Once either of the ar-
row keys is pressed, the dry time L.E.D. and the total dry time on the 4-digit numeric display will ash.
If you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN ar-
row) through the total dry times available (1 through 60 minutes). This displayed dry time includes the
cool down time along with the heated time. To not change the total dry time, do not press the arrow
keys to change the total dry time.
5. Press and release the SELECT/ENTER key. Once this key is pressed and released, the dry time L.E.D.
will switch o, the dry cycle L.E.D. and programming L.E.D. will remain on, and the temperature L.E.D.
will illuminate. The drying temperature will also be shown on the 4-digit numeric display.
6. Press and release the UP or DOWN arrow keys to change the drying temperature. Each press and re-
lease of the arrow keys will either increase or decrease the temperature by ve degrees Fahrenheit or
three degrees Celsius, depending on how your dryer controller is set up. Once either of the arrow keys
is pressed, the temperature L.E.D. and the drying temperature on the 4-digit numeric display will ash.
If you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN
arrow) your way through the available drying temperatures (10So Fahrenheit or 40° Celsius, up to
19So Fahrenheit or 9( Celsius). If you do not want to change the drying temperature, do not press the
arrow keys. Go to the next step.
7. Press and release the SELECT/ENTER key. Once this key is pressed and released, the temperature
L.E.D. will switch o, the dry cycle L.E.D. and programming L.E.D. will remain on, and the cool down
L.E.D. will illuminate. The cool down time will also be shown on the 4-digit numeric display. 8) Press
and release the UP or DOWN arrow keys to change the cool down time. Once either of the arrow keys
is pressed, the cool down L.E.D. and the cool down time on the 4-digit numeric display will ash. If
you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN arrow)
through the cool down times available (2 through 60 minutes). To not change the cool down time, do
not press the arrow keys. Go to the next step.
8. Press and release the SELECT/ENTER key. Once this key is pressed and released, the cool down L.E.D.
and the programming L.E.D. will switch o, and the dry cycle L.E.D. will remain on. The ashing cool
down time on the 4-digit display will stop ashing and remain.
9. At this point, you have two choices. 1) You can perform the modied dry cycle by pressing and re-
leasing the START key on the dryer controller touch pad, or 2) You can clear the modied dry cycle
program by pressing and releasing the STOP key once. If you start the modied cycle, the total dry
time will appear on the 4-digit numeric display and it will count down to 0 as the dry cycle progresses.
If you choose to clear the modied dry cycle, the 4-digit numeric display will change to “LOAd”.
Temporary Dryer Controller Programming Example
Requirements: Dry a load with 40 minutes of actual heat at 18SoF and ve minutes of cool down.
The following procedure will show you how to temporarily modifY the existing dry cycle 1 program for
one cycle of drying. It is based on the assumption that the factory defaults have not been permanently
changed. If they have been changed, the steps of this procedure will be the same, but the values that
are displayed will be dierent. The amount of times that the dryer controller touch pad UP or DOWN keys
must be pressed and released may also be dierent.
If you want the change to be permanent, go to the “Permanent Dryer Controller Programming” section of
this manual.
Procedure
1. After the load has been placed in the dryer, press and release the UP or DOWN touch pad key on the
dryer controller until the L.E.D. for dry cycle 1 is illuminated.
2. Press and release the CYCLE key on the dryer controller touch pad. You will see the number “35” on
the dryer controller display. The programming L.E.D. and dry time L.E.D. will be illuminated.
3. Press and release the UP arrow key on the dryer controller touch pad 10 times so the display will
show a ashing “45”. When the UP arrow touch pad key is pressed the rst time, the number “36” will
be ashing on the dryer controller display. Each number after that will also ash.
4. Now, press and release the SELECT/ENTER touch pad key on the dryer controller. The number “45”
will stop ashing and the dry time L.E.D. will switch o. The dryer controller display will now show
“180”, the temperature L.E.D. will illuminate, and the programming L.E.D. and dry cycle 1 L.E.D. will
remain on.
5. Press and release the UP arrow key on the dryer controller touch pad one time so the controller dis-
play will show a ashing” 185”. Each press of the UP arrow key will increment the temperature by ve
degrees.
6. Now, press and release the SELECT/ENTER touch pad key on the dryer controller. The number “185”
will stop ashing and the temperature L.E.D. will switch o. The dryer control display will now show
a number “5”, the cool down L.E.D. will illuminate, and the programming L.E.D. and dry cycle 1 L.E.D.
will remain on.
7. Press and release the SELECT/ENTER key on the dryer controller touch pad, since the desired cool
down time is ve minutes. After you press the SELECT/ENTER touch pad key on the controller, the
cool down L.E.D. and programming L.E.D. will switch o. The controller display will remain at “5” and
the cycle 1 L.E.D. will remain on.
You are now ready to start the new dry cycle. This new dry cycle will be in eect for one dry cycle only.
After the dry cycle is done, or if the STOP touch pad key on the dryer controller is pressed and released
twice, consecutively, the cycle 1 program will revert to the factory default settings.
If you press the START touch pad key on the dryer controller, the controller display will change from the
number “5” to the number “45” and dry cycle 1 will begin.
30 31
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

Permanent Dryer Controller Programming
The permanent programming mode will allow the change of the stored dry cycle settings in the dryer
controller until the operator physically changes them again. The factory default settings can be restored in
the dryer controller by pressing the default settings pushbutton on the back (component) side of the dryer
controller circuit board. It is labeled and located at the lower middle side of the printed circuit board, as
you face the component side of the board. It must be pressed and held down for at least three seconds.
To permanently change a dryer controller cycle, follow the procedure below. Things that are displayed on
the 4-digit numeric display will be in “quotation marks”. Keys on the touch pad that physically need to be
pressed will be in CAPITAL AND BOLD LETTERS.
If, at any time, you want to escape the permanent programming mode while changing the settings, you
can press the STOP key on the dryer controller touch pad if the 4-digit numeric display is not ashing. The
SELECT/ENTER key on the dryer controller touch pad can be pressed and released to enter the ashing
value shown on the 4-digit numeric display and allow you to escape.
Procedure
1. Make sure the dryer is not in a dry cycle. The 4-digit numeric display on the dryer controller will show
“LOAd” when the dryer is not in a dry cycle.
2. Press and release the PROG key on the dryer controller touch pad.
3. Press and release the UP arrow key on the dryer controller touch pad. The programming L.E.D. will
illuminate and the 4-digit numeric display on the dryer controller will change to “Prog”.
4. Press and release the UP or DOWN arrow keys to choose the dry cycle you want to change (dry cycle
1 through 5). The dry cycle L.E.D. will illuminate to indicate which dry cycle you are choosing. If you
press either arrow key and hold it down, the controller will sequence through the ve dry cycles.
5. Press and release the SELECT/ENTER key once you have chosen the dry cycle you want to change.
After you press this key, the dry time L.E.D. will illuminate. The dry cycle L.E.D. and the programming
L.E.D. will remain illuminated. The total dry time will also be displayed on the 4-digit numeric display.
6. Press and release the UP or DOWN arrow keys to change the total dry time. Once either of the arrow
keys is pressed, the dry time L.E.D. and the total dry time on the 4-digit numeric display will ash. If
you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN arrow)
through the total dry times available (1 through 60 minutes). This displayed dry time includes the cool
down time along with the heated time. To not change the total dry time, do not press the arrow keys.
Go to the next step.
7. Press and release the SELECT/ENTER key. Once this key is pressed and released, the dry time L.E.D.
will switch o, the dry cycle L.E.D. and programming L.E.D. will remain on, and the temperature L.E.D.
will illuminate. The drying temperature will also be shown on the 4-digit numeric display.
Press and release the UP or DOWN arrow keys to change the drying temperature. Each press and release
of the arrow keys will either increase or decrease the temperature by ve degrees Fahrenheit or three de-
grees Celsius, depending on how your dryer controller is set up. Once either of the arrow keys is pressed,
the temperature L.E.D. and the drying temperature on the 4-digit numeric display will ash. If you press
and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN arrow) your way
through the available drying temperatures (1050 Fahrenheit or 400 Celsius, up to 1950 Fahrenheit or 9(
Celsius). If you do not want to change the drying temperature, do not press the arrow keys. Go to the
next step.
Press and release the SELECT/ENTER key. Once this key is pressed and released, the temperature L.E.D.
will switch o, the dry cycle L.E.D. and programming L.E.D. will remain on, and the cool down L.E.D. will
illuminate. The cool down time will also be shown on the 4-digit numeric display.
Press and release the UP or DOWN arrow keys to change the cool down time. Once either of the arrow
keys is pressed, the cool down L.E.D. and the cool down time on the 4-digit numeric display will ash. If
you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN arrow)
through the cool down times available (2 through 60 minutes). To not change the cool down time, do not
press the arrow keys. Go to the next step.
Press and release the SELECT/ENTER key. Once this key is pressed and released, the cool down L.E.D. will
switch o, the dry cycle L.E.D. and programming L.E.D. will remain on, and the 4-digit numeric display will
change to “Prog”.
Press and release the STOP key to save the cycle program and escape the programming mode. If you
want to change the same dry cycle program again, press the SELECT/ENTER key and continue at step 6
of this procedure. If you want to modify another dry cycle program, go to step 4 of this procedure and
continue.
Ifyou pressed the STOP key to escape the programming mode, you may now start the dry cycle by press-
ing the START key.
Permanent Dryer Controller Programming Example
Requirements: Dry a load with 50 minutes of actual heat at 1950 F and three minutes of cool down.
The following procedure will show you how to permanently modify the existing dry cycle 1 program for
one cycle of drying. It is based on the assumption that the factory defaults have not been permanently
changed. If they have been changed, the steps of this procedure will be the same, but the values that
are displayed will be dierent. The amount of times that the dryer controller touch pad UP or DOWN keys
must be pressed and released may also be dierent.
If you want the change to be temporary (for only one dry cycle), go to the “Temporary Dryer Controller
Programming” section of this manual.
Procedure
1. After the load has been placed in the dryer, press and release the UP or DOWN touch pad key on the
dryer controller until the L.E.D. for dry cycle 1 is illuminated.
2. Press and release the PROG touch pad key on the dryer controller. The dryer controller display will not
change.
3. Immediately, press and release the UP arrow key on the dryer controller touch pad. The controller
display will change from “LOAd” to “Prog”. You have now entered the permanent programming mode.
The dry time L.E.D. will remain on and the programming L.E.D. will illuminate.
4. Press and release the SELECT/ENTER touch pad key once. The dry time L.E.D. and programming
L.E.D. will remain on and the dry time L.E.D. will illuminate. The dryer controller will also show the
number “35”.
5. Press the UP arrow touch pad key 18 times until the dryer controller display shows the number “53”.
6. Press and release the SELECT/ENTER touch pad key once. The dry time L.E.D. and programming
L.E.D. will remain on and the dry time L.E.D. will switch o. The temperature L.E.D. will illuminate and
the dryer controller display will show the number”180”.
32 33
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

7. Press and release the UP arrow touch pad key three times until the dryer controller display shows the
number “195”.
8. Press and release the SELECT/ENTER touch pad key. The dry time L.E.D. and the programming L.E.D.
will remain on and the temperature L.E.D. will switch o. The cool down L.E.D. will illuminate and the
dryer controller display will show the number “5”.
9. Press and release the DOWN arrow touch pad key twice until the dryer controller display shows the
number “3”.
10. Press and release the SELECT/ENTER touch pad key. The dry time L.E.D. and the programming L.E.D.
will remain on and the cool down L.E.D. will switch o. The dryer controller display will change to
“Prog”.
11. Press and release the STOP touch pad key. The dry time L.E.D. will remain on and the programming
L.E.D. will switch o. The dryer controller display will change to the word “LOAd”.
The dryer is now ready for the new modied dry cycle to start. This modied dry cycle 1 program will re-
main in the dryer controller memory until the default settings push button is pressed. This default settings
push button is located on the component side of the dryer controller printed circuit board at the middle
center side of each circuit board controls.
TRANSIENT VOLTAGE SURGE SUPPRESSORS
Like most electrical equipment your new machine can be damaged or have its life shortened by voltage
surges due to lightning strikes which are not covered by factory warranty. Local power distribution
problems also can be detrimental to the life of electrical components. We recommend the installation of
transient voltage surge suppressors for your new equipment. These devices may be placed at the power
supply panel for the complete installation and don’t require and individual device for each machine.
These surge protectors help to protect equipment from large spikes and also from small ongoing spikes
in the power that occur on a day to day basis. These smaller surges can shorten overall life of electrical
components of all types and cause their failure at a later date. Although they can’t protect against all
events, these protective devices have a good reputation for signicantly lengthening the useful life of
electronic components.
Electronic Components are helped to have a longer useful life when they are supplied with the clean
stable electrical power they like.
We are including the following names and links to a few suppliers of these devices for those who don’t
currenty have a source.
MANUFACTURER LINK
MCG Surge Protection mcgsurge.com
Eaton Corporation eaton.com/us/en-us
Schneider Electric se.com/us/en
Asco Power Technolgies ascopower.com/us/en
Emerson Electric Co. emerson.com/en-us
34 35
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

36 37
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
Notes Notes
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring

60HZ Wiring Schematic Dryer Idle - No Coins Added
Top Dryer Used For This Example
110 VAC 60Hz is supplied to the main power terminal block, L1 power, N=neutral, plus ground. BLK/Red
coming o of L1 and BLK/BLU coming from N power the R1, and R2 motor relays. Red wire from L1 and
the blue wire from N supply power and neutral to the step down transformer. After the stepdown trans-
former the control is protected by a 2.5 Amp fuse in the black wire. When there is power to the dryer the
Computer Board will be powered and the display lighted from the 24 VAC secondary side of Control Step
Down Transformer. 24 VAC from here is also on one side of the door switch on a black wire. Closing the
loading door allows 24 VAC to pass on to the Computer Board on two blue wires. One blue wire makes 24
VAC available to one side of the Motor Run Relay on Computer Board. The other blue wire provides a 24
VAC signal to the Computer Board telling it that the door is closed and door light on the computer board
should be illuminated.
Coins Added - Motor Starting and Running
Top Dryer Used For This Example
As each coin is added the Coin Switch closes and completes a circuit to the Computer Board. The Com-
puter Board counts these signals and registers them against time. The time will display once the Start But-
ton for Upper or Lower is pushed. When the Start Button is pushed again the Computer Board Motor Run
Relay closes on the computer. With this Relay closed, 24 VAC is supplied to the Motor Control Relay (R1)
on the red wire and also a violet wire going down to motor. The motor LED on the computer board should
be illuminated anytime the computer calls for the motor to operate. With (R1) engaged and 110 VAC at
motor the Motor Start Switch in motor is drawn in to the start position. In this position the incoming power
110 VAC is supplied directly to the main run winding and through the Start Capacitor to the Auxiliary Wind-
ing (start winding). As the Motor comes up to speed, the centrical switch inside motor opens the circuit to
the Start Winding and closes the circuit to allow 24 VAC to pass to the Gas Relay on the Computer Board
on the other violet wire.The heat circuit in the dryer can not operate if the motor is not running. The gas
LED on the computer board will be illuminated when Computer Board calls for the heat after Motor Cen-
trical Switch has closed.
Heat Circuit
Top Dryer Used For This Example
With the Drive Motor running and 24 VAC provided to the Computer Board Gas Relay, it will close if Com-
puter Board senses programmed temperature is needed. The violet wire changes to an orange wire out
of the Computer Board Gas Relay. When this relay closes it provides 24 VAC to the High Limit Thermostat.
The High Limit Thermostat is normally closed. (It will open, turning o the heat circuit, if the dryer can’t
move enough air from problems such as an exhaust restriction or other problems.) 24 VAC now goes
through to the normally open Air Switch (Sail Switch) on the brown wire. This switch is closed only if the
dryer is running and has the correct air ow. With the dryer running and the Air Switch closed, 24 VAC is
supplied to the normally closed upper manual reset Overtemp Thermostat on the gray wire and changes
to the black wire out of switch and then changes to red wire and goes to the 1.5 amp in-line fuse that pro-
tects the Upper Ignition Controller(GREY BOX). With 24 VAC now supplied to the Upper Ignition Controller
(GREY BOX) it will then send high voltage to the Spark Ignition Electrode via the High Voltage Lead Wire
(this lead looks like an automotive spark plug wire). The Ignition Control Module (GREY BOX)simultane-
ously sends 24VAC to the Gas Valve Coil which open the Gas Valve and allows gas to pass through to the
main burner. When ignition occurs the high voltage sparking stops and if Ignition Control Module (GREY
BOX) gets a ame sense signal it will allow gas valve coil to remain energized and continue burner opera-
tion. If ignition does not occur, the Ignition Control Module (GREY BOX) will spark for 10 seconds before
locking out.
39
Part # 8533-108-001 10/22
38
Part # 8533-108-001 10/22
