Dexter Laundry T-900 User manual

8514-244-001 REV PR page 1
INDUSTRIAL WASHER
MODEL T-900/950 ON-PREMISE
N-SERIES CONTROL
OPERATOR’S MANUAL
INSTALLATION & OPERATION
INSTRUCTIONS
Please read this information and retain for reference.
WARNING: THIS WASHER IS EQUIPPED WITH DEVICES AND FEATURES RELATING TO ITS SAFE
OPERATION. TO AVOID INJURY OR ELECTRICAL SHOCK, DO NOT PERFORM ANY SERVICING UNLESS
QUALIFIED TO DO SO.
IT IS THE RESPONSIBILITY OF THE OWNER TO CHECK THIS EQUIPMENT ON A FREQUENT
BASIS TO ASSURE ITS SAFE OPERATION.
A machine should NOT be allowed to operate if any of the following occur:
-Excessively high water level.
-If machine is not connected to a properly grounded circuit.
-If the door does not remain securely locked during the entire cycle.
-Vibration or shaking from an inadequate mounting or foundation.
WARNING - SAFETY PRECAUTIONS
-Always shut off power and water supply before servicing.
-Do not overload the washer.
-Do not open door when cylinder is in motion or it contains water.
-Do not bypass any safety devices of this washer.
-Do not use volatile or flammable substances in or near this washer.
-Keep all panels in place. They protect against shock and injury and add rigidity to the washer.
PREVENTIVE MAINTENANCE REQUIREMENTS
DAILY
-Check that the loading door remains securely locked and cannot be opened during an entire
cycle.
-Check the water connections for leaks.
-Clean the top, front, and sides of the cabinet to remove residue.
-Clean the soap dispenser and lid and check that all dispenser mounting screws are in-place and
tight.
-Check the drain valve for leaking and that it opens properly.
-Check the loading door for leaks. Clean the door seal of all foreign matter.
-Leave the loading door open to aerate the washer when not in use.
QUARTERLY
-Make sure the washer is inoperative by switching off the main power supply.
-Check the V-belts for wear and proper tension.
-Clean lint and other foreign matter from around motor.
-Check all water connections for leaks.
-Wipe and clean the inside of the washer and check that all electrical components are free of
moisture and dust.
-Remove and clean water inlet hose filters. Replace if necessary.
-Check anchor bolts. Retighten if necessary
IMPORTANT: Replace any and all panels that were removed to perform daily and/or quarterly
maintenance.

8514-244-001 REV PR page 2
TABLE OF CONTENTS
1INSTALLATION INSTRUCTIONS ..........................................................................3
1.1 FOUNDATION REQUIREMENTS......................................................................3
1.2 MOUNTING ..................................................................................................3
1.3 PLUMBING ...................................................................................................7
1.4 DRAIN .........................................................................................................7
1.5 PROTECTIVE FILM ........................................................................................7
1.6 ELECTRICAL .................................................................................................7
1.6.1 INSTALLING THE ELECTRICAL CONNECTION...........................................8
1.6.2 FUSING REQUIREMENTS.........................................................................8
1.6.3 CONTROLS TRANSFORMER (208-240V models only) ................................8
1.6.4 MAXIMUM SPIN SPEED ADJUSTMENT......................................................9
1.7 INJECTION SOURCE CONNECTIONS ............................................................10
1.8 OPERATION CHECK ....................................................................................10
2WASHER OPERATION.......................................................................................11
2.1 CONTROL BUTTONS ...................................................................................11
2.2 STARTING THE WASHER.............................................................................12
2.3 OPTIONAL SOAK ........................................................................................13
2.4 END OF CYCLE ...........................................................................................13
2.5 SAFETY DOOR LOCK...................................................................................13
2.6 VARIABLE FREQUENCY DRIVE INDICATORS ................................................13
3MACHINE PROGRAMMING INSTRUCTIONS ........................................................15
3.1 EDITING AN EXISTING CYCLE.....................................................................15
3.2 PROGRAMMING A NEW CYCLE ....................................................................17
3.3 DEFAULT WASHER CYCLE PROGRAMS .........................................................18
3.4 RAPID ADVANCE MODE ..............................................................................30
3.5 DIAGNOSTIC TEST CYCLE...........................................................................31
4TROUBLESHOOTING ........................................................................................34
5SERVICE AND PARTS........................................................................................40
MODEL
T-900/950 60 LB. WASHER
CAPACITY
60 LBS/9 CUBIC FT. (27.2 kg/255 L)
CYLINDER SIZE
30” DIA X 22” DEEP (76 cm X 55.9 cm)
ELECTRICAL
208-240 VAC, 60 HZ, 1 OR 3 PHASE; OR
208-240 VAC, 60 HZ, 3 PHASE ONLY (ELECTRIC HEAT MODEL)
DRIVE SYSTEM
SOFT START REVERSING INVERTER DRIVE
WASH SPEED
43 RPM
INTERMEDIATE EXTRACT
375 RPM (60 G’S)
FINAL EXTRACT
T-900: 484 RPM (100 G’S)
T-950: 685 RPM (200 G’S)
MACHINE CONTROL
PROGRAMMABLE COMPUTER UP TO 30 CYCLES
WATER INLET
SOLENOID OPERATED VALVES, 30-120 PSI
T-900: 2 VALVES, 9 GAL/MIN (34 L/MIN) EACH
T-950: 2 DUAL VALVES 9 GAL/MIN (34 L/MIN) EACH.
2 SINGLE VALVES 12 GAL/MIN (45 L/MIN) EACH.
DRAIN VALVE
3” (76 mm) DIAMETER
Table 1: Washer Specifications

8514-244-001 REV PR page 3
1INSTALLATION INSTRUCTIONS
All washers must be installed in accordance with all local, state and national
building, electrical, plumbing and other codes in effect in the area.
WARNING:
THESE INSTALLATION AND SERVICING INSTRUCTIONS ARE FOR USE
BY QUALIFIED PERSONNEL ONLY. TO AVOID INJURY AND ELECTRICAL
SHOCK, DO NOT PERFORM ANY SERVICING OTHER THAN THAT
CONTAINED IN THE OPERATING INSTRUCTIONS, UNLESS QUALIFIED.
1.1 FOUNDATION REQUIREMENTS
This machine is designed for use on or over bare concrete floor - not to be
used above combustible flooring, such as carpet or wood. The washer
must be securely bolted and grouted to a substantial concrete floor, or
mounted and grouted upon a suitable base that is securely bolted and
grouted to a substantial concrete floor.
CARE MUST BE TAKEN WITH ALL FOUNDATION WORK TO ENSURE A
STABLE UNIT INSTALLATION, ELIMINATING POSSIBILITIES OF
EXCESSIVE VIBRATION.
All installations require concrete floors 8 inches (203 mm) or thicker.
Anchor bolts or expansion anchors must be of a quality grade and a
minimum of 3/4 inch (19 mm) diameter. Six bolts are required to mount
the washer to the steel base or concrete pad. Mounting hardware is not
provided with the machine.
1.2 MOUNTING
A concrete pedestal or steel-mounting base that elevates the machine
approximately 4 inches (102 mm) above the floor level is recommended to
provide easy access to the loading door. Allow a minimum 24 inches (610
mm) of clearance behind the rear of the machine to provide access for
motor service. Refer to Figures Figure 1-1 and Figure 1-2 for machine
bolt-down dimensions. Contact a Dexter laundry equipment distributor for
recommended steel mounting bases.
If an elevated concrete pedestal is desired, it should be embedded into
the existing floor. Anchor bolts should be 3/4" x 8" (19 mm x 200 mm),
grade 8 or better, headed by a 4 inch (10 cm) square fish plate and
should protrude 2 1/2” (64 mm) above the finished surface of the
pedestal.
EXPANSION ANCHORS ARE NOT RECOMMENDED FOR USE IN CONCRETE
PEDESTALS BECAUSE THE ANCHORS ARE TOO CLOSE TO AN EDGE,
CAUSING IT TO BREAK OUT.
Refer to Figures Figure 1-1 and Figure 1-3 for recommended concrete
pedestal dimensions. Refer to Figure Figure 1-4 for overall machine
mounting dimensions.

8514-244-001 REV PR page 4
Figure 1-1: Concrete Pedestal Mounting
Figure 1-2: Floor Outline

8514-244-001 REV PR page 5
Figure 1-3: Machine Mounting Detail

8514-244-001 REV PR page 6
Figure 1-4: T-900/950 Industrial Washer Mounting Diagram
**NOTE: Top water valves shown in Figure 1-4 are only on T-950 model.

8514-244-001 REV PR page 7
1.3 PLUMBING
Two (for T-900 models) or four (for T-950 models) 48 inch (1.22 m) water
supply hoses are provided with each machine. The threaded connections
on the hoses are ¾-11 ½ NHT.
Separate hot and cold water lines must be supplied to the machine,
maintaining 30 psi to 120 psi (207 kPa to 827 kPa) water flow pressure. A
140°F (60°C) hot water supply is recommended for best washing results.
Do not exceed 180°F (82°C) water temperature.
1.4 DRAIN
The drain outlet tube at the rear of the machine is 3 inches (76 mm) in
diameter. Any drain hose used must be lower than the drain valve to
assure proper draining.
1.5 PROTECTIVE FILM
The machine may have protective adhesive film on the front control panel
label area and on the front, top, and side stainless steel panels. The film
may be peeled off before putting the machine into service.
1.6 ELECTRICAL
The Dexter T-900/950 single/three-phase 208-240VAC 60 Hz and T-
900/950 three-phase 208-240VAC 60 Hz (with Electric Heater) washing
machines are intended to be permanently installed appliances. No power
cord is provided. The machine should be connected to an individual
branch circuit not shared by lighting or other equipment. The connection
should be sheathed in liquid tight flexible conduit, or equivalent, with
conductors of the proper size and insulation. A qualified technician should
make such connections in accordance with the wiring diagram with a
minimum 12 gauge wire. Select models with the electric heat option
require a minimum 6 gauge wire.
WARNING:
SHUT OFF POWER AND WATER BEFORE OPENING ANY SERVICE
PANELS.
Figure 1-5: Electrical Connections and Chemical Supply Signals

8514-244-001 REV PR page 8
1.6.1 INSTALLING THE ELECTRICAL CONNECTION
1.6.1.1 Disconnect all power to the washer.
1.6.1.2 Locate the power terminal block cover in the upper
left corner of the machine when viewed from the
back. Remove the screw and lift out the cover.
Connections are as shown in Figure 1-5.
1.6.1.3 If power is 208-240-3PH-60Hz, connect L1, L2, L3
and Ground. If there is a high leg, it must be
connected to L3.
1.6.1.4 If power is 208-240-1PH-60Hz, connect L1, L2 and
Ground.
NOTE: It is important that the grounding screw next to the power
terminal block TB-1 be connected to a good external ground.
1.6.2 FUSING REQUIREMENTS
Single- and Three -phase 208-240VAC 60 Hz models:
20 AMP TIME-DELAY (DUAL ELEMENT) FUSE (or equivalent circuit
breaker)
Three -phase 208-240VAC 60 Hz models with electric heat source:
60 AMP TIME-DELAY (DUAL ELEMENT) FUSE (or equivalent circuit
breaker)
1.6.3 CONTROLS TRANSFORMER (208-240V models only)
The controls transformer is located inside the control trough and
steps a range of 208 to 240 volts down to 115 volts. There are two
terminals on the controls transformer for the primary (incoming)
power. Use the terminal marked “208V” for power supplies
between 208 and 219 volts. Use the terminal marked “240V” for
power supplies between 220 and 240 volts. Refer to Figure 1-6 for
control transformer connections.
Figure 1-6: Control Transformer Connections

8514-244-001 REV PR page 9
1.6.4 MAXIMUM SPIN SPEED ADJUSTMENT
If desired, the washer can be adjusted to limit the maximum
extract spin speed for all wash cycles.
To make this adjustment, a jumper wire must either be installed or
removed on the Variable Frequency Drive (VFD), depending on the
washer model and desired speed. This Dexter jumper part number
8220-057-036 (qty 1) is factory supplied on terminal points “10V”
and “RC”. Remove this jumper to make new jumper connections if
necessary. Refer to Figure 1-7 for the approximate location of the
control terminations on the Variable Frequency Drive (VFD) and
Table 2 for appropriate jumper connection points indicated with an
“X” for the desired maximum spin speed setting. If no adjustment
to default spin speed is desired, do not remove or add any wires on
VFD.
Figure 1-7: Control Terminations on Variable Frequency Drive
MI1 MI2 MI3 MI4 MI5 MI6
DCM
(Left)
DCM
(Right)
24V ACM AVI ACI 10V M01
60 G X X
80 G X X
100 G
100 G X X
140 G
200 G
T-600, T-900,
T-1200
Default Setting (No Jumper Required)
T-950, T-1450
REMOVE Brown Jumper between MI6/M01
Default Setting (With Factory Installed Brown Jumper)
N Series Washer
Model
Max Spin
Speed
Jumper Terminal Locations on Variable Frequency Drive (VFD)
Table 2: Spin Speed Adjustment Jumper Locations

8514-244-001 REV PR page 10
1.7 INJECTION SOURCE CONNECTIONS
The washer control may be programmed to send six 120V output signals
for a chemical injection system of up to four chemical sources. There are
convenient electrical connection points for the injection pumps in the rear
of the machine, as shown in Figure 1-5. The four independent pumps can
be controlled through the signals A, B, C and D. The COM shown in Figure
1-5 is the common or return for these injection signals. For the injection
sources, program codes 0 through 6 and their respective terminal block
connections and combinations are as shown in Table 3.
Dexter
Recommended
Connections
Controller
Programmed
Signals
Injection
Terminal Block
Circuits
Detergent
1
A
Bleach
2
B
Starch
3
C
Sour/Softener
4
D
5
A and B
6
C and D
0
None
Table 3: Injection Signal and Circuit Identification
Chemical Injection hoses are to be inserted into the injection inlet at the
upper right rear of the washer. These hoses should be inserted into the
round PVC pipe a minimum of 14" (35.5 cm) and a maximum of 18" (45.7
cm) to eliminate chemical buildup in the pipe and/or restrict water flow to
the tub. Secure the hoses as required.
1.8 OPERATION CHECK
After all mounting, plumbing and electrical work is completed, run through
each step of the diagnostic cycle (cycle #31), detailed in section 3.5, and
a complete wash cycle. Check for water leaks and verify proper operation.
During intermediate spin and final spin, the cylinder should turn in a
counterclockwise direction when viewed from the front of the machine.
If spin is clockwise, the T1 and T2 motor wires connecting to terminal T1
and T2 on the variable frequency drive should be swapped. Remove
power to the machine before opening service panels and swapping wires.

8514-244-001 REV PR page 11
2WASHER OPERATION
2.1 CONTROL BUTTONS
There are four (4) push buttons that control the washer operation. Each
button is shown in Figure 2-1, followed by an explanation of each button.
Figure 2-1: Washer Control Keypad Layout
SCROLL DOWN ARROW: Press momentarily / press and hold.
Scroll Down decreases the cycle number displayed by one each
time the switch is pressed. When the “DOWN” is held, the display
cycle numbers will continue to decrease until cycle #1 is reached at
which time the cycle number displayed will rollover to cycle #30
(cycle #31 while in Programming Mode).
SCROLL UP ARROW: Press momentarily / press and hold.
Scroll Up increases the cycle number displayed by one each time
the switch is pressed. When the “UP” is held, the display cycle
numbers will continue to increase until cycle #30 (cycle #31 while
in Programming Mode) is reached at which time the cycle number
displayed will rollover to cycle #1.
START/ENTER (green diamond): Press momentarily.
Starts the cycle shown on the display. If a wash cycle is
interrupted, pressing the “START” button will resume the cycle
from the point at which the cycle was interrupted.
STOP/EXIT (red octagon):
When pressed momentarily, it pauses the washer during the cycle.
All washer cycle information is retained, the door remains locked,
and the water remains in the tub.
When pressed and held for 3 seconds or longer, it stops the
washer, clears the cycle, drains the water, and unlocks the door
(up to 3 minutes after the washer is stopped). All washer cycle
information is cleared, and it is ready for the next wash cycle.
WARNING:
PRESSING AND HOLDING THE STOP IS AN EMERGENCY STOP
BUTTON. HOWEVER, THIS DOES NOT DISCONNECT THE
MACHINE FROM THE INPUT POWER.

8514-244-001 REV PR page 12
2.2 STARTING THE WASHER
2.2.1 Turn on power to the washer.
2.2.2 Ensure washer is in “RUN” mode.
Locate the “ADVANCE/RUN/PROGRAM” key switch and key. The
current mode is indicated by the alignment of the key slot. If
washer is not in “RUN” mode, insert and turn the key to the “RUN”
position.
2.2.3 Load the laundry.
Place laundry loosely into the cylinder and latch the door securely.
Be sure laundry does not get caught between the door gasket and
tub front when closing the door. Maximum load is 60 pounds
clothes, dry weight. Do not load the washer with more than 60
pounds.
NOTE: To begin closing the door, the handle must be in the
horizontal position. After moving the door to the closed position,
the handle must be turned down to the vertical position in order to
latch the door for machine operation.
2.2.4 Select wash cycle.
Select the appropriate cycle number (1 through 30) for the type of
load being washed. See the default cycle descriptions in section
3.3. Use the “UP”and “DOWN”buttons to change the two digit
cycle number on the display to the desired cycle.
2.2.5 Add washing chemicals.
If not using a chemical injection system, add low sudsing powdered
detergent into the “DETERGENT” compartment of the automatic
dispenser on the top of the washer.
If liquid wash products are used in the “DETERGENT”
compartment, they must be added at the beginning of the wash
cycle.
If desired, add fabric softener to the “FABRIC SOFTENER”
compartment. Use the amount of fabric softener as recommended
by the manufacturer. This compartment will be flushed during the
“FINAL RINSE”segment of the cycle.
If the machine is set for pre-wash, washing products can be added
to the round opening of the dispenser or put in with the clothes
when loading the washing machine.
If bleach is desired, DO NOT place into dispenser until step 2.2.7.
2.2.6 Press “START”.
The door will lock and remain locked until the end of the cycle.
The cycle time remaining is displayed throughout the cycle. The
cycle number in operation can be displayed by pressing and holding
“START”, then press “UP”.The cycle number will be displayed as

8514-244-001 REV PR page 13
long as these two buttons are pressed.
2.2.7 Add bleach if desired.
If you wish to manually add bleach during the cycle, add bleach in
the “BLEACH” compartment 3 minutes after the start of the
“WASH” cycle.
NOTE: Any additional washing chemicals may be added at the
appropriate time by pouring into the round opening on the top of
the washer.
2.3 OPTIONAL SOAK
At any time during the cycle, the red “STOP”button can be momentarily
pressed to pause the washer. All washer cycle information is retained and
the door remains locked. The washer will soak the load for 15 minutes
then agitate for 30 seconds. This will repeat until the cycle is started
again. This feature allows for an extended soak if required. The washer
cycle will continue when the “START”button is pressed.
NOTE: The selected cycle can be cleared at any time by pressing and
holding the “STOP”button for a minimum of 3 seconds.
2.4 END OF CYCLE
At the end of the cycle, the machine stops, the “END CYCLE”LED
illuminates, the alarm sounds, and the loading door unlocks. The door
can now be opened. Immediately remove contents of washer. Leave the
door open when the machine is not in use.
2.5 SAFETY DOOR LOCK
This machine is equipped with a safety door lock that locks the door when
the cycle is started until the cycle is complete. The door lock prevents
opening the door for up to 3 minutes if the power is interrupted during
the cycle.
2.6 VARIABLE FREQUENCY DRIVE INDICATORS
There are three small red LEDs located on the upper Variable Frequency
Drive (VFD) cover. They are labeled as “READY”, “RUN”, and “FAULT”
and can be used for troubleshooting. The definitions of the LEDs are
listed in Table 4 below.

8514-244-001 REV PR page 14
Table 4: Variable Frequency Drive Indicators
Washer Condition
“READY”
LED
Status
“RUN”
LED Status
“FAULT”
LED
Status
Idle Mode
(No Cylinder Movement)
ON
OFF
OFF
Tumbling
ON
ON
OFF
Stop from Tumble
ON
FLASHING
OFF
Ramp to Intermediate or
Final Extract Spin
ON
ON
OFF
Spinning
(Intermediate or Final)
ON
ON
OFF
Stop from Spin
(Intermediate or Final)
ON
FLASHING
OFF
Faulted
ON
OFF
ON

8514-244-001 REV PR page 15
3MACHINE PROGRAMMING INSTRUCTIONS
This Dexter T-900/950 computer control OPL machine has 30 different selectable
cycles; 29 of the 30 cycles are preset with the most common industry
applications. See section 3.3 for complete cycle information. If these cycle
settings do not meet the required application, each cycle is reprogrammable by
the user simply and reliably.
Each cycle can have up to 9 baths including Flush, Prewash, Wash, Rinse 1, 2, 3,
4, 5 and Final Rinse/Extract. Each of those baths can be customized with various
defined settings including Cycle Time, Water Temperature, Water Level, Spin
Time, and Injection Source. Programming can be accomplished manually using
the machine controls. Please read below for manual programming instructions.
NOTE: It is recommended when changes are made to one or more of the preset
programs that the cycle number and the changes be documented for later
reference. Blank cycle tables have been provided at the end of section 3.3.
3.1 EDITING AN EXISTING CYCLE
3.1.1 Turn on the power to the washer.
Washer must be in idle mode to program.
3.1.2 Ensure washer is in “PROGRAM” mode.
Locate the “ADVANCE/RUN/PROGRAM” key switch and key. The
current mode is indicated by the alignment of the key slot. If
washer is not in “PROGRAM” mode, insert and turn the key to the
“PROGRAM” position.
The display will show a two digit cycle number. The “PROGRAM
MODE” LED and “SELECT CYCLE” LED illuminate.
3.1.3 Select cycle to alter.
Press the “DOWN” or “UP” buttons on the keypad until the desired
cycle number, 1 through 30, is displayed. Do not select cycle 31.
3.1.4 Press “ENTER” to enter the cycle.
Once pressed, the first of the nine bath LEDs will illuminate. The
“SELECT CYCLE” LED is turned off.
3.1.5 Select a bath to alter.
Press the “UP” and “DOWN” buttons to select a bath. The bath
indicator lights, shown in Figure 3-1, illuminate to indicate which
bath is being selected.
Figure 3-1: Bath Indicator Lights
There are 9 available baths to program: FLUSH, PRE WASH, WASH,
RINSE1, RINSE 2, RINSE 3, RINSE 4, RINSE 5 and FINAL RINSE.

8514-244-001 REV PR page 16
3.1.6 Press “ENTER”to display the settings.
Available settings to alter in each bath are Cycle Time, Water
Temperature, Water Level, Injection Source, and Spin Time.
3.1.7 Input settings.
The first setting to alter is the Cycle Time as indicated by the
“CYCLE TIME” LED. Use the “DOWN” and “UP” keys to set the
desired time in minutes and press “ENTER” to advance to the next
setting. If no change is desired, press “ENTER” to advance to the
next setting.
Repeat process for each setting. Each bath setting can be
programmed with the options shown in Table 5.
SETTING
OPTIONS
Cycle Time1
Two-digit amount of time for bath tumble in minutes.
-00 to 30 minutes for Flush, Prewash, Wash,
Rinse 1, 2, 3, 4 and 5. If the time is set to 00,
then the bath will be eliminated from the
cycle.
-01 to 30 minutes for Final Rinse.
Water
Temperature2
HH for hot water
CH for warm water
CC for cold water
EE for no water3
Water Level
LO for low level
HI for high level
Injection
Source3
Two-digit code indicating injector signal(s), 00 to 06.
Spin Time
Two-digit amount of time for spin in minutes.
-00 to 10 minutes for Flush, Prewash, Wash,
Rinse 1, 2, 3, 4, and 5
-01 to 10 minutes for Final Rinse
Table 5: Bath Program Settings
1 Cycle times are approximate and do not include fill time from empty to low
water level. However, fill time from low to high water level is included as
computer operates during this period.
2For models with electric heat, entering a temperature value of 20°-90°C will
result in a heated bath if temperature of fill water is less than programmed
temperature.
3Codes for injections sources are defined in Table 3. When “EE” is selected in
the Water Temperature setting, the electronic controller prohibits injection
signals. The programmed injection source value is ignored.
When the final desired Spin Time setting is selected, press
“ENTER”. The Spin Time is entered, The “SPIN TIME” LED turns
off, and the editing of the selected bath is complete. The next
sequential bath light is immediately illuminated.

8514-244-001 REV PR page 17
3.1.8 Program another bath.
If desired, repeat steps 3.1.5 through 3.1.7 to program another
bath. Otherwise, continue to the next step.
3.1.9 Program another cycle.
To program a different cycle when any of the nine bath LEDs are
illuminated, press the “EXIT” button. The “SELECT CYCLE” LED will
immediately illuminate. The programming changes made prior to
the program exit are retained and the cycle is updated.
NOTE: When the “FINAL RINSE” bath programming is complete,
the cycle programming is also complete and the “SELECT CYCLE”
LED will immediately illuminate. Another cycle can be programmed.
If desired, repeat steps 3.1.3 through 3.1.8 to program another
cycle. Otherwise, continue to the next step to end programming.
3.1.10 End programming mode.
When the “SELECT CYCLE” LED is illuminated, turn the key to the
“RUN” position. The “PROGRAM MODE” LED will turn off.
NOTE: The Wash Cycle programming mode will automatically exit and
return to the Idle mode if no buttons are pressed for one minute.
3.2 PROGRAMMING A NEW CYCLE
The instructions for entering a new cycle are the same as the instructions
in section 3.1. To program a new cycle, an existing cycle number
between 1 and 30 must be overridden with a custom program. Cycle 31
cannot be reprogrammed. Only the cycle baths required need to be
programmed. Any baths, except FINAL RINSE, can be skipped by
entering a “00” time value in the Cycle Time for each unused bath.

8514-244-001 REV PR page 18
3.3 DEFAULT WASHER CYCLE PROGRAMS
The factory default cycles pre-programmed into the washer are listed with
each bath and setting option in this section. All wash cycles can be
reprogrammed, refer to section 3.1 for instructions.
To reset all customized programs back to original factory default settings,
refer to section 3.5 and complete step 14 of the Test Diagnostic Cycle.
Application
Cycle #
Recommendation Description
Shirt/Laundry
1
Shirts –No Starch
2
Shirts –Starch
Hotel/Motel
3
White Sheets
4
White Pillowcases
5
White Towels, Bath Mats, Wash Cloths
6
Colored Sheets and Towels
7
Delicate Wash
8
Housekeeping Rags and Mops
9
Housekeeping Uniforms
10
Stain Treatment
11
Reclaim Part 1
12
Reclaim Part 2
Health Care
13
Sheets and Pillowcases
14
Towels
15
Diapers and Pads
16
Personals
17
Delicate
Food & Beverage
18
White (Cotton/Blend) Table Linen
19
Colored (Cotton/Blend) Table Linen
20
White 100% Polyester Table Linen
21
Colored 100% Polyester Table Linen
22
White Chef Coats
23
Kitchen and Maintenance Rags
24
White/Colored (Cotton/Blend) Table Linen
25
White/Colored 100% Polyester Table Linen
26
White Chef Coats
27
Kitchen and Maintenance Rags
Other
28
Oxygen Bleach –Terry
29
Oxygen Bleach –Terry (No iron)
Test
30
Test Injection Signals and Pressure Switch
31
Test Diagnostic (not customizable)
Table 6: Default Washer Cycle Programs

8514-244-001 REV PR page 19
Cycle 1 Shirts - No Starch (Shirt/Laundry)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Injection Source
Spin Time
(min.)
Flush
Prewash
Wash
12
HH
LO
5 (Detergent/Bleach)
Rinse 1
2
CH
HI
Rinse 2
2
CH
HI
Rinse 3
2
CH
HI
Rinse 4
Rinse 5
Final Rinse
4
CH
LO
3
Cycle 2 Shirts - Starch (Shirt/Laundry)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Injection Source
Spin Time
(min.)
Flush
Prewash
Wash
12
HH
LO
5 (Detergent/Bleach)
Rinse 1
2
CH
HI
Rinse 2
2
CH
HI
Rinse 3
2
CH
HI
Rinse 4
Rinse 5
Final Rinse
7
CH
LO
3 (Starch)
3
Cycle 3 White Sheets (Hotel/Motel)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Injection Source
Spin Time
(min.)
Flush
Prewash
7
HH
LO
1 (Detergent)
Wash
7
HH
LO
2 (Bleach)
Rinse 1
2
CH
HI
1
Rinse 2
2
CH
HI
Rinse 3
Rinse 4
Rinse 5
Final Rinse
4
CH
LO
4 (Sour/Softener)
4

8514-244-001 REV PR page 20
Cycle 4 White Pillowcases (Hotel/Motel)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Injection Source
Spin Time
(min.)
Flush
7
HH
LO
1 (Detergent)
Prewash
1
HH
HI
Wash
7
HH
LO
2 (Bleach)
Rinse 1
2
CH
HI
1
Rinse 2
2
CH
HI
Rinse 3
Rinse 4
Rinse 5
Final Rinse
4
CH
LO
4 (Sour/Softener)
4
Cycle 5 White Towels (Hotel/Motel)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Injection Source
Spin Time
(min.)
Flush
7
HH
LO
1 (Detergent)
Prewash
1
HH
HI
Wash
7
HH
LO
2 (Bleach)
Rinse 1
2
CH
HI
1
Rinse 2
2
CH
HI
Rinse 3
Rinse 4
Rinse 5
Final Rinse
4
CH
LO
4 (Sour/Softener)
5
Cycle 6 Color Sheets (Hotel/Motel)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Injection Source
Spin Time
(min.)
Flush
Prewash
Wash
7
HH
LO
5 (Detergent/Bleach)
Rinse 1
2
HH
HI
Rinse 2
2
CH
HI
1
Rinse 3
2
CH
HI
Rinse 4
Rinse 5
Final Rinse
4
CH
LO
4 (Sour/Softener)
4
