R100, R110, R120 Multifunction Systems
R100, R110, R120
435
R100, R110, R120
436
R100, R110, R120
480
R100, R110, R120
485
R100, R110, R120
495
Enclosure Galvanized Steel Frame Construction
Main Board DFI-ACP
NP101-D16C
DFI-ACP
NP100-N16C
DFI-ACP
G5C100-N
DFI-ACP
SR100-N
DFI-ACP
CA100-D
Processor Type Intel Atom N270 Intel Atom N270 Intel®
Celeron® M,
Core™ Solo,
Core™ Duo,
Core™ 2 Duo
(Mobile type)
Intel® Core™® 2
Duo
(Mobile type)
Intel® Core™® 2
Duo
(Mobile type)
Processor FSB 533 533 533 / 667 533 / 800 677/800/1066
Main Chipsets Intel 945GSE +
ICH7M
+ GMA 950
Intel 945GSE +
ICH7M
+ GMA 950
Intel 945GME
+ ICH7M
+ GMA950
Intel GME 965
+ ICH8M
+ GMA X3100
Intel GM 45
+ ICH9M
+ GMA 4500
System Memory up to 2GB up to 2GB up to 4GB up to 4GB up to 8GB
PCI Slot R100: none, R110: One Full-height, Half-length PCI Card, R120: Two Full-height, Half-length PCI Cards
HDD and Optical
Drive Bays
1 Desktop-type HDD alone, or 1 Notebook-type HDD and 1 Notebook-type Optical Drive or Compact Flash
Drive Kit, or 2 Notebook-type HDDs with Optional Shockmount Bracket/Kit
PS/2 Keyboard &
Mouse Ports
1 pair
DB-9 Serial Port 2 4 3 2 2
Video Port 1x DB-15 1x DB-15
+ 1x DVI-D
1x DB-15 1x DB-15
+ 1x DVI-D
1x DB-15
+ 1x DVI-D
RJ45 LAN Port 2x (10/100/1000) 2x (10/100/1000) 2x (10/100/1000) 2x (10/100/1000) 2x (10/100/1000)
USB Ports 6 6 6 6 8
Audio Jacks 3 3 3 3 3
Internal CF Card
Slot
0 1 1 0 0
Dimension
(W x H x D)
R100 System: 8.80” x 3.50” x 8.00” (223.5 x 88.9 x 203.2 mm)
R110 System: 8.80” x 4.35” x 8.00” (223.5 x 110.4 x 203.2 mm)
R120 System: 8.80” x 5.16” x 8.00” (223.5 x 131.0 x 203.2 mm)
These are nominal sizes - Allow additional space all-around for screws, side brackets, connectors and
ventilation
Weight 7.8 lbs to 11.0 lbs depending on configuration
Standard AC
Power
DC 12V only Internal auto-110/220V 180W ATX-type power supply
with power factor correction & noise killer feature.
Optional DC Power 12V 20V / 24V 20V / 24V 20V / 24V 20V / 24V
Ventilation One 80 mm enclosure fans
Mounting Option Removable side/bolt-down bracket - shipped as standard equipment.
Operating
Temperature
0ºC - 60ºC (32ºF - 140ºF), 10% - 90% RH.
Note: The operating temperature is limited by the processor’s specs.
