FLIGHTMANUAL
FOR THE
MOTORGLIDER
DG-808C
Type : DG-800A
Model : DG-808C
Data Sheet No.: EASA.A.067
Factory Serial No.: __________________________
Registration No.: __________________________
Date of Issue: June 2005
Pages as indicated by "EASA App." are approved by:
(Signature)
(Authority)
(Stamp)
Date of approval January 10. 2006
This motorglider is to be operated in compliance with information and
limitations contained herein.

Flight manual DG-808C
Issued: July 2017 TN 800/45 0.0
Warnings
All sailplanes, especially those with retractable powerplants, are very complex
technical devices. If you don’t use yours as it is intended and within the certified
operating limitations or if you fail to carry out proper maintenance work, it may
harm your health or place your life in danger.
Prior to flying the aircraft read all manuals carefully and regard especially all
warnings, caution remarks and notes given in the manuals.
 Never take-off without executing a serious pre-flight inspection according to the
flight manual!
 Never take-off with a motorglider without checking the max. engine RPM and
the ignition circuits!
 Always respect the relevant safety altitudes!
 With a motorglider never rely completely on the engine extending and starting.
Plan your flight path so that you are always able to carry out a safe outlanding if
necessary. Be aware that with the engine extended but not running the rate of
sink increases remarkably. This means that with a motorglider you have to
decide earlier for an outlanding than with a pure sailplane.
 Selflaunch only if you are sure that with an engine failure during the initial
climb there is the possibility to execute a safe outlanding or to return to the
airfield.
 Respect the stall speeds and always fly with a safety margin above the stall
speed according to the flight conditions, especially at low altitudes and in the
mountains.
 Use only the types of fuel and oil for your motorglider as specified in the flight
manual.
 Use only the battery chargers as specified in the flight manual.
 Don’t execute yourself any work on the control system except for greasing.
 Repairs and maintenance work should only be accomplished by the
manufacturer or at certified repair stations rated for this type of work. A list of
stations which have experience with DG aircraft may be obtained from DG
Flugzeugbau..
 Even if no annual inspections are required in your country, have your aircraft
checked annually (see maintenance manual section 2).
 Please pay attention to our web-site www.dg-flugzeugbau.de. There you will
find the latest technical notes and service information for your glider:
http://www.dg-flugzeugbau.de/en/maintenance-service-aircraft/technical-notes
The „DG Pilot Info“ informs you immediately by e-mail about the publication
of new technical notes and service information.
If you don’t receive this info service, please click on the DG website on “News,
Newsletter” Subscription to receive this service free of charge.

Flight manual DG-808C
Issued: July 2017 TN 800/45 0.1
0 Revisions
0.1 Record of revisions
Any revision of the present manual, except actual weighing data, must be
recorded in the following table and in case of approved sections endorsed by the
responsible airworthiness authority.
The new or amended text in the revised page will be indicated by a black
vertical line in the right hand margin, and the under lying document for the
Revision and the date will be shown on the bottom of the page.
Rev.
No.
Affected
Pages/
section
Description Issue
Date
EASA
Approval
Date
Inserted
Date
Signature
1 0.3-0.5, 1.5, 1.6,
2.5, 2.9-2.11, 4.22,
5.3, 5.6, 5.7, 5.9,
5.10, 5.13, 6.6,
6.10, 7.10, 7.13-
7.15
Manual revision
TN 800/34
September
2007
9. October
2007
2 0.1, 0.3 ÷ 0.5, 1.2,
1.5, 2.6, 2.8, 2.9,
3.4, 4.4 ÷ 4.6, 4.8,
4.9, 4.11, 4.15,
4.20, 4.24, 4.26,
4.27, 4.29, 5.14,
6.2, 6.4, 6.7, 6.10,
7.1, 7.2, 7.4, 7.9 ÷
7.11, 7.15, 7.18,
7.20, 7.22, 7.23
Manual revision,
Coolant pump
Pierburg
TN 800/41
May 2012 14. Sept.
2012
3 0.1, 0.6, 9.4 TN DG-G-11
NOAH
Improvements
May2015 7.07.2015
4 0.0, 0.1, 0.3 – 0.5,
2.11, 4.9, 4.10,
4.12, 4.25, 4.29,
7.2, 7.23
Manual revision
TN800/45
July 2017 10.08.2017

Flight manual DG-808C
Issued: June 2005 0.2
This page is intentionally left blank.

Flight manual DG-808C
Issued: July 2017 TN 800/45 0.3
0.2 List of effective pages
Section page issued replaced/ replaced/
0 0.0 June 2005 July 2017
0.1 see manual amendments
0.2 "
0.3 "
0.4 "
0.5 "
0.6 June 2005
1 1.1 June 2005
1.2 " May 2012
1.3 "
1.4 "
1.5 " Sept 2007 May 2012
1.6 " Sept 2007
2 App. 2.1 June 2005
" 2.2 "
" 2.3 "
" 2.4 "
" 2.5 " Sept 2007
" 2.6 " May 2012
" 2.7 "
" 2.8 " May 2012
" 2.9 " May 2012
" 2.10 " Sept 2007
" 2.11 " Sept 2007 July 2017
" 2.12 "
" 2.13 "
" 2.14 "
3 " 3.1 June 2005
" 3.2 "
" 3.3 "
" 3.4 " May 2012
" 3.5 "
" 3.6 "
" 3.7 "
4 " 4.1 June 2005
" 4.2 "
" 4.3 "

Flight manual DG-808C
Issued: July 2017 TN 800/45 0.4
0.2 List of effective pages (cont.)
Section Page issued replaced/ replaced/
4 App. 4.4 June 2005 May 2012
4.5 " May 2012
4.6 " May 2012
" 4.7 "
" 4.8 " May 2012
" 4.9 " May 2012 July 2017
" 4.10 " July 2017
" 4.11 " May 2012
" 4.12 " July 2017
" 4.13 "
" 4.14 "
" 4.15 " May 2012
" 4.16 "
" 4.17 "
" 4.18 "
" 4.19 "
" 4.20 " May 2012
" 4.21 "
" 4.22 " Sept 2007
" 4.23 "
" 4.24 " May 2012
" 4.25 "
July 2017
" 4.26 " May 2012
" 4.27 " May 2012
" 4.28 "
4.29 May 2012 July 2017
5 " 5.1 June 2005
" 5.2 "
" 5.3 " Sept 2007
" 5.4 "
" 5.5 "
" 5.6 " Sept 2007
App. 5.7 " Sept 2007
5.8 "
5.9 " Sept 2007
5.10 " Sept 2007
5.11 "
5.12 "
5.13 " Sept 2007
5.14 "

Flight manual DG-808C
Issued: July 2017 TN 800/45 0.5
0.2 List of effective pages (cont.)
Section Page issued replaced/ replaced/
6 6.1 June 2005
6.2 " May 2012
6.3 "
6.4 " May 2012
6.5 "
6.6 " Sept 2007
6.7 " May 2012
6.8 "
6.9 "
6.10 " Sept 2007 May 2012
7 7.1 June 2005 May 2012
7.2 " May 2012 July 2017
7.3 "
7.4 " May 2012
7.5 "
7.6 "
7.7 "
7.8 "
7.9 " May 2012
7.10 " Sept 2007 May 2012
7.11 " May 2012 July 2017
7.12 "
7.13 " Sept 2007
7.14 " Sept. 2007
7.15 " Sept 2007 May 2012
7.16 "
7.17 "
7.18 " May 2012
7.19 "
7.20 " May 2012
7.21 "
7.22 " May 2012
7.23 " May 2012 July 2017
8 8.1 June 2005
8.2 "
8.3 "
8.4 "
8.5 "
8.6 "
8.7 "

Flight manual DG-808C
Issued: May 2015 TN DG-G-11 0.6
0.2 List of effective pages (cont.)
Section page issued replaced/ replaced/
9 9.1 June 2005
9.2 "
9.3 "
9.4 " May 2015
9.5 "
0.3 Table of contents
Section
General (a non-approved section) 1
Limitations (an approved section) 2
Emergency procedures (an approved section) 3
Normal procedures (an approved section) 4
Performance (a partly approved section) 5
Mass (weight) and balance (a non-approved section) 6
Sailplane and systems description (a non-approved section) 7
Sailplane handling, care and maintenance (a non-approved section) 8
Supplements 9

Flight manual DG-808C
Issued: June 2005 1.1
1 General
Section
1.1 Introduction .............................................................................................. 1.2
1.2 Certification basis .................................................................................... 1.2
1.3 Warnings, cautions and notes .................................................................. 1.3
1.4 Descriptive data ....................................................................................... 1.4
1.5 Three view drawing ................................................................................. 1.6
Page

Flight manual DG-808C
Issued: May 2012 TN800/41 1.2
1.1 Introduction
The flight manual has been prepared to provide pilots and instructors with
information for the safe and efficient operation of the DG-808C motorglider.
This manual includes the material required to be furnished to the pilot by JAR
Part 22. It also contains supplemental data supplied by the glider manufacturer.
1.2 Certification basis
This motorglider type DG-800, variant DG-808C has been approved by the
EASA in accordance with:
Airworthiness requirements:
JAR Part 22 „Sailplanes and powered sailplanes“, change 4, issued 27th June
1989.
and
Noise requirements: ICAO Appendix 16, Volume I, Part II, Chapter 10
The Type Certificate No. EASA.A.067 for the variant DG-808C has been issued
on January 10. 2006.
Category of Airworthiness: "Utility"

Flight manual DG-808C
Issued: June 2005 1.3
1.3 Warnings, cautions and notes
The following definitions apply to warnings, cautions and notes used in the
flight manual.
"Warning" means that the non observation of the corresponding
procedure leads to an immediate or important
degradation of the flight safety.
"Caution" means that the non observation of the corresponding
procedure leads to a minor or to a more or less long
term degradation of the flight safety.
"Note" draws the attention on any special item not directly
related to safety but which is important or unusual.

Flight manual DG-808C
Issued: June 2005 1.4
1.4 Descriptive data
The DG-808C is a singleseater high performance self-launching motorglider
with retractable powerplant.
Technical details
 2-piece wing or 4 piece wing with parting at y = 7.25 m (Option).
 Wing tips with Winglets for 15 m span (Option)
 Removable Winglets for 18 m span (Option)
 Automatic hook-ups for all controls.
 Comfortable seating and modern cockpit design, safety cockpit.
 Large canopy for very good inflight vision.
 Draught free canopy demist and adjustable direct ventilation.
 Sealed airbrake- and landing gear boxes.
 Retractable main wheel, spring mounted.
 Steerable tailwheel.
 All controls including the engine are operated with the left hand, which
enables the right hand to remain on the control stick.
Powerplant and powerplant controls
 Retractable powerplant with liquid cooled Solo 2 625 01 two stroke engine
and GFRP-Composite propeller Technoflug KS-1G-152-R-122-( )-B 1
 Electrical engine extension-retraction, operated automatically with the
ignition switch or manually as back-up, electronic safety devices to avoid
misoperation.
 Engine control instruments with digital LCD indication (Microprocessor
technology) DEI-NT including stall warning, outside air thermometer, and
landing gear warning.
 BBSA slipping-centrifugal clutch to reduce drive belt loads as an option.
Further details:
 Waterballast in the wings.
 Waterballast in the fin in an integral tank (only Version DG-808C
Competition).
 Wing fuel tanks as an option.

Flight manual DG-808C
Issued: May 2012 TN800/41 1.5
Technical data
Wingspan m (feet) 15 (49.2) 18 (59.1)
Wing surface m² (ft²) 10.68 (115.0) 11.81 (127.1)
Aspect ratio / 21.07 27.42
Mean aerodynamic chord MAC m (ft) 0.734 (2.41) 0.700 (2.30)
Length m (ft) 7.055 (23.15)
Fuselage width m (ft) 0.63 (2.07)
Fuselage height m (ft) 0.81 (2.66)
Horizontal tail span m (ft) 2.52 (8.27)
Data for the version DG-808C Classic
Waterballast wings kg (U.S.gal) 100 (26.4)
Waterballast fin tank kg (U.S.gal) none
Empty weight approx. kg (lbs.) 336 (741) 340 (750)
Wing loading with payload 80 kg
(176 lbs.) approx. kg/m² (lbs./ft²) 39 (7.97) 35.4 (7.29)
Max. weight kg (lbs.) 525 (1157)
Max. wing loading kg/m² (lbs./ft²) 44.5 (9.11)
Data for the version DG-808C Competition
Waterballast wings kg (U.S.gal) 120 (31.7) or 150 (39.6)
Waterballast fin tank kg (U.S.gal) max. 6.5 (1.72)
Empty weight approx. kg (lbs.) 346 (762) 350 (772)
Wing loading with 80 kg (176 lbs.)
payload approx.
kg/m² (lbs./ft²) 39.9 (8.16) 36.4 (7.46)
Max. weight kg (lbs.) 540 (1190) 600 (1323)
Max. wing loading kg/m² (lbs./ft²) 50.6 (10.35) 50.8 (10.47)
Powerplant
engine Liquid cooled Solo 2 625 01 two stroke engine
power 39 kW (53 hp)
Reduction gear 1:3
Propeller Technoflug KS-1G-152-R-122-( )-B GFRP-Composite
Propeller diameter 1.52 m (4.99 ft).
Fuel tank capacity fuselage tank 21 Liter (5.5 U.S.gal.)
Empty masses are with common instrumentation.
*Options will increase the empty mass accordingly!

Flight manual DG-808C
Issued: September 2007 TN 800/34 1.6
1.5 Three view drawing (dimensions in mm)

Flight manual DG-808C
Issued: June 2005 2.1
EASA app.
2 Limitations
Section
2.1 Introduction .............................................................................................. 2.2
2.2 Airspeed ................................................................................................... 2.3
2.3 Airspeed Indicator Markings ................................................................... 2.4
2.4 Power plant .............................................................................................. 2.5
2.5 Power plant instrument markings ............................................................ 2.5
2.6 Fuel ........................................................................................................... 2.6
2.7 Mass (weight) ........................................................................................... 2.7
2.8 Centre of gravity ...................................................................................... 2.7
2.9 Approved manoeuvres ............................................................................. 2.8
2.10 Manoeuvring load factors ........................................................................ 2.8
2.11 Flight crew ............................................................................................... 2.8
2.12 Kinds of operation .................................................................................... 2.9
2.13 Minimum equipment ................................................................................ 2.9
2.14 Aerotow, winch and autotow launching ................................................ 2.10
2.15 Crosswinds ............................................................................................. 2.10
2.16 Tyre Pressure ......................................................................................... 2.10
2.17 Waterballast ........................................................................................... 2.11
2.18 Wing fuels tanks (Option) ...................................................................... 2.12
2.19 Limitations placards ............................................................................... 2.12
2.20 Other limitations .................................................................................... 2.14
Page

Flight manual DG-808C
Issued: June 2005 2.2
EASA app.
2.1 Introduction
Section 2 includes operating limitations, instrument markings and basic placards
necessary for safe operation of the glider, its standard systems and standard
equipment.
The limitations included in this section have been approved by the EASA.

Flight manual DG-808C
Issued: June 2005 2.3
EASA app.
2.2 Airspeed
Airspeed limitations and their operational significance are shown below
Speed IAS
km/h
(kts.)
Remarks
VNE Never exceed
speed
270 (146) Do not exceed this speed in any
operation and do not use more than 1/3
of control deflection.
VPE Max. speed with
powerplant
extended
190
(103)
Do not exceed this speed with the
powerplant extended (engine idling)
VRA Rough air speed 190 (103) Do not exceed this speed except in
smooth air and then only with caution.
Rough air is in lee-wave rotors,
thunderclouds, visible whirlwinds or
over mountain crests etc.
VA Manoeuvring
speed
190 (103) Do not make full or abrupt control
movement above this speed, because
under certain conditions the sailplane
may be overstressed by full control
movement.
VFE Maximum flap
extended speed
L
+5° up to +8°
150 (81)
190 (103)
Do not exceed these speeds with the
given flap setting
VW Maximum winch-
launching speed
150 (81) Do not exceed this speed during winch-
or auto-tow-launching
VT Maximum aero-
towing speed
190 (103) Do not exceed this speed during
aerotowing.
VLO Maximum landing
gear operating
speed
190 (103) Do not extend or retract the landing
gear above this speed.
VPO Max. speed to
extend and re-tract
the power-plant
100
( 54)
Do not extend or retract the powerplant
above this speed
Warning: At higher altitudes the true airspeed is higher than the indicated
airspeed, so VNE is reduced with altitude according to the table below (see also
section 4.5.9).
Altitude in [m] 0-3000 4000 5000 6000 7000 8000
VNE indicated km/h 270 256 243 230 217 205
Altitude in [ft] 0-10000 13000 16000 20000 23000 26000
VNE indicated kts. 146 138 131 124 117 111

Flight manual DG-808C
Issued: June 2005 2.4
EASA app.
2.3 Airspeed Indicator Markings
Airspeed indicator markings and their colour code significance are shown
below.
Marking (IAS) value or
range
km/h (kts)
Significance
White Arc
88 -190
(47.5 - 103)
Positive Flap Operating
Range
(lower limit is maximum weight
1.1 VSO in landing configuration.
Upper limit is maximum speed
permissible with flaps extended
positive + 8°, + 5°)
Green Arc
97 - 190
(52 - 103)
Normal Operating Range
(Lower limit is maximum weight
1.1 VS1 at most forward c.g. with
flaps neutral. Upper limit is rough
air speed.)
Yellow Arc 190 - 270
(103 - 146)
Manoeuvres must be conducted
with caution and only in smooth
air.
Red Line 270
(146)
Maximum speed for all
operations.
L 150
( 81)
Max. speed for landing
configuration L
Blue line 90
( 49)
Speed of best climb Vy
Yellow
Triangle
105
(57)
Approach speed at maximum
weight without water ballast

Flight manual DG-808C
Issued: September 2007 TN 800/34 2.5
EASA app.
2.4 Power plant
Engine manufacturer: Solo Kleinmotoren
Sindelfingen/Maichingen
Germany
Engine model: Solo 2 625 01
2 cylinder liquid cooled two stroke engine with dual
ignition
Maximum power: Take off: 39 kW (53 hp)
continuous: 39 kW (53 hp)
Max. engine RPM: 6600 RPM
Max. continious RPM: 6300 RPM
Max. coolant temperature: 95°C (203°F)
Note: After engine stop and retraction the coolant temperature may exceed
95°C. This is acceptable.
Propeller: Diameter 1.52 m (4.99 ft)
Manufacturer: Technoflug, Schramberg, Germany
Model: KS-1G-152-R-122-( )-B
2.5 Power plant instrument markings (on DEI-NT, DEI=digital engine
indicator)
Power plant instrument markings and their significance are shown below:
Engine speed indicator:
In the centre of the DEI-NT display, indication digital with 4 digits, limitation
data printed above display:
green 6300 max. continuous RPM
yellow 6300 – 6600 caution range
red 6600 max. RPM
Max. continuous RPM:
When exceeding this RPM a blinking “Hi” appears at the left hand side of the
RPM.
Max. RPM:
When exceeding this RPM a full screen warning “Engine Speed” appears,
when this warning has been confirmed (by pushing the selector knob at the right
hand side of the display) the engine speed display is blinking whilst the engine
speed is above max. RPM..

Flight manual DG-808C
Issued: May 2012 TN 800/41 2.6
EASA app.
Coolant temperature indicator (CHT):
On right hand upper side of the DEI-NT display, digital indication with 3 digits,
limitation data printed above display:
red 95°C
When exceeding this temperature a full screen warning “CHT overTemp”
appears. When this warning has been confirmed (by pushing the selector knob at
the right hand side of the display) the CHT display will keep blinking as long as
the CHT is above the max. CHT.
Fuel quantity indicator:
On left hand upper side of the DEI-NT display, digital indication with 2 digits.
Limitation data for the non useable amount of fuel printed above the display:
red 0.5 l
When a fuel quantity of approx. 4 Litres is reached a full screen warning “Low
Fuel” appears, when this warning has been confirmed (by pushing the turning
knob at the right hand side of the display) the fuel display is blinking.
When reaching the non usable amount of fuel “R” is displayed and blinking.
2.6 Fuel
Fuel capacity:
Fuselage tank:
total: 21 l (5.55 US gal.)
Non useable amount of fuel: 0.5 l (0.15 US gal.)
Useable amount of fuel: 20,5 l (5.42 US gal)
Wing tank left (Option): 10 l (2.64 US gal.)
Wing tank right (Option): 10 l (2.64 US gal.)
Approved fuel grades:
Car super gasoline min. 95 octane (ROZ) (RON) leaded or unleaded
or: AVGAS 100 LL (only if super gasoline is not available)
or: mix 50% AVGAS 100 LL and 50% Car super gasoline unleaded min 92
ctane (ROZ) (RON)
mixed with self mixing Super quality two stroke oil - specification TSC 3 or
API TC or JASO FC or higher quality. Mixing ratio 1:50.
Caution: Fuel with more than 5% Ethanol is not acceptable to be used for the
DG-808C fuel system.
Note: The SOLO company recommends the following oil types: CASTROL
Actevo 2T, or CASTROL Super Two Stroke.
