Flight manual DG-500 ELAN ORION
0.1 Record of revisions
Any revision of the present manual, except actual
weighing data, must be recorded in the following
table and in case of approved sections endorsed by
the responsible airworthiness authority.
The new or amended text in the revised page will be
indicated by a black vertical line in the right hand
margin, and the Revision No. and the date will be
shown on the bottom left hand of the page.
Rev.
No.
Affected pages
/ section
Description Issue
Date
LBA
Approval
Date
Inserted
Date
Signature
1 0.3,0.4,1.4,
2.8, 4.11,
6.4, 6.8
TN 348/8
Ser.no
5E155-159
+5E164 only
Jan.
96
02.04.96
2 0.3, 4.11 ÄM 500/9/96
not for
Ser.no
5E155-159
+5E164
Mar.
96
12.06.96
30.3,0.4,
4.2, 4.18,
5.6, 6.7, 7.1,
7.9, 7.10
TN 348/9 Oct.
97
26.11.97
4 0.1,0.3,0.4,
2.3, 2.4, 2.5,
2.6, 2.7, 2.8,
4.7, 4.16,
4.18, 6.6, 7.6
Manual
revision
TN 348/14
March
2000
09.05.00
4 0.3,0.4, 4.7,
7.6, 8.2
TN 348/15 Jan.
2001
07.02.01
Issued: see last item 0.1
Flight manual DG-500 ELAN ORION
0.2 List of effective pages
Section page issued replaced replaced
0 0.0 July 95
0.1 /
0.2 /
0.3 see record of revisions
0.4 "
0.5 July 95
1 1.1 "
1.2 Nov. 95
1.3 July 95
1.4 "
1.4 Jan. 96 (only ser.no. 5E155-159)
1.5 July 95
2 App. 2.1 "
" 2.2 "
" 2.3 " March 00
" 2.4 " March 00
" 2.5 " March 00
" 2.6 " March 00
" 2.7 " March 00
" 2.8 " Jan. 96 March 00
" 2.9 "
3 " 3.1 "
" 3.2 "
" 3.3 "
" 3.4 "
4 " 4.1 "
" 4.2 " Oct. 97
" 4.3 "
" 4.4 "
" 4.5 "
" 4.6 "
" 4.7 " March 00 Jan. 01
" 4.8 "
" 4.9 "
" 4.10 "
App. 4.11 "
4.11 Jan. 96 (only ser.no. 5E155-159)
" 4.12 July 95
" 4.13 "
" 4.14 "
" 4.15 "
" 4.16 " March 00
" 4.17 "
" 4.18 " Oct. 97 March 00
" 4.19 "
" 4.20 July 95
Issued: January 2001 TN 348/15 0.3

Flight manual DG-500 ELAN ORION
0.2 List of effective pages (cont.)
Section page issued replaced replaced
5 " 5.1 July 95
" 5.2 "
" 5.3 "
App. 5.4 "
5.5 "
5.6 " Oct. 97
6 6.1 "
6.2 "
6.3 "
6.4 "
6.4 Jan. 96 (only ser.no. 5E155-159)
6.5 July 95
6.6 " March 00
6.7 " Oct. 97
6.8 "
6.8 Jan. 96 (only ser.no. 5E155-159)
6.9 July 95
7 7.1 " Oct. 97
7.2 "
7.3 "
7.4 "
7.5 "
7.6 " March 00 Jan. 01
7.7 "
7.8 "
7.9 " Oct. 97
7.10 " Oct. 97
8 8.1 "
8.2 " Jan. 01
8.3 "
8.4 "
8.5 "
9 9.1 July 95
Issued: January 2001 TN 348/15 0.4
Flight manual DG500 ELAN ORION
B Inspection after rigging
Walk around the aircraft
1. All parts of the airframe
a) check for flaws such as bubbles, holes, bumps and cracks in the surface
b) check leading and trailing edges of the wings and control surfaces for
cracks
2. Cockpit area
a) check the canopy locking mechanism
b) check the canopy emergency release see sect. 7.15 (not each day, but
min. every 3 month)
c) check the main pin securing
check the securing ropes of the headrest in the rear cockpit for wear and
function
d) check all controls for wear and function, incl. positive control check
e) check the tow release system for wear and function incl. cable release
check
f) check for foreign objects
g) check the instrumentation and radio for wear and function
h) check the radio and other electrical equipment for function. If there is no
electric power it must be assumed, that the battery is not in-stalled in the
fin. Flying is only allowed with the battery in the fin as otherwise the
forward C.G. limit may be exceeded.
i) check the brake fluid level
j) check if the fin tank is empty
3. C.G. Tow hook
a) c heck the ring muzzle of the C.G. hook for wear and function
b) check for cleanliness and corrosion
4. Main landing gear and nose wheel
a) check the struts, the gear box, the gear doors and the tyre for wear; dirt in
the struts can hinder the landing gear from locking over center the next
time!
Issued: January 2001 TN348/15 App. 4.7

Flight manual DG-500 ELAN ORION
7.4 Flight controls
Rudder control:
See diagram 2 M.M
Cable system with adjustable pedals in the front cockpit.
Elevator control:
See diagram 1 M.M.
All pushrods slide in maintenance free nylon ball guides.
Automatic control hook up system. Spring trimmer with release lever at the
control stick and control knob at the left cockpit wall. To trim, you have to
operate the release lever at the control stick and place the control knob to
the desired position.
Aileron control:
Seediagram3and4M.M
Pushrods slide in maintenance free nylon ball guides.
Automatic control hook up system..
7.5 Airbrakes
Seediagram3and4M.M.
Double storey Schempp-Hirth type airbrakes on the upper wing surface.
The wheel brake is operated by the airbrake system. Pushrods in the wings
slide in maintenance free nylon ball guides. Automatic control hook up
system.
7.6 Landing gear
See diagram 7 M.M.
a) Main wheel: retractable, assisted by a gas strut. Spring mounted
with steel compression springs, locked in retracted
position by an overcentre locking device. Fully sealed
landing gear box, hydraulic disc brake.
Tyre 380 x 150 6 PR
Diameter 380 mm (15.0 in.)
Tyre pressure 3.0 bar (44 psi)
b) Tailwheel: Tyre 200 x 50 2 PR
Diameter 200 mm (7.87 in)
Tyre pressure 4 bar (58 psi)
c) Nosewheel: Tyre 260 x 85
Diameter 260 mm (10.2 in.)
Tyre pressure 2.5 bar (36 psi)
Issued: January 2001 TN348/15 7.6
Flight manual DG-500 ELAN ORION
8.1 Introduction
This section contains manufacturer's recommended procedures for proper
ground handling and servicing of the sailplane. It also identifies certain
inspection and maintenance requirements which must be followed if the
sailplane is to retain that new-plane performance and dependability. It is
wise to follow a planned schedule of lubrication and preventive
maintenance based on climatic and flying conditions encountered.
8.2 Inspection period, maintenance
The "Instructions for continued airworthiness (maintenance manual) for the
DG-500 ELAN ORION have to be followed.
A Before each rigging all the connecting pins and bushes should be cleaned
and greased. This includes the control connectors.
B The contact surfaces of the canopies to the fuselage are to be rubbed with
colourless floor-polish (canopy and fuselage side) to reduce grating noise
in flight. Polish at the beginning of the flight season and then every month.
C Once a year all the bearings and hinges should be cleaned and greased. See
the greasing programme of the maintenance manual.
Each year the control surface displacements, adjustments and general
condition must be checked. (See the maintenance manual).
8.3 Alterations or repairs
It is essential that the responsible airworthiness authority be contacted
prior to any alterations on the airplane, to ensure that the airworthiness of
the sailplane is not impaired. It is prohibited to execute the alteration
without the approval of the airworthiness authority. The manufacturer will
not be liable for the alteration or for damages resulting from changes in the
characteristics of the aircraft due to alteration. So it is strongly
recommended to execute no alternatives which are not approved by the
aircraft manufacturer.
External loads such as external camera installations are to be regarded as
alterations! Repair instructions can be found in the DG-500 ELAN ORION
repair manual. No repairs should be carried out without referring to the
manual.
Issued: January 2001 TN348/15 8.2
