DHM PRO VORON 2.4 KIT 9 User manual

VORON 2.4
KIT 9
∙PANELLING
∙HEPA FILTER

WWW.VORONDESIGN.COM
INTRODUCTION
Before you begin on your journey, a word of caution.
In the comfort of your own home you are about to assemble a robot. This
machine can maim, burn, and electrocute you if you are not careful. Please
do not become the rst VORON fatality. There is no special Reddit air for that.
Please, read the entire manual before you start assembly. As you begin wrenching,
please check our Discord channels for any tips and questions that may halt your progress.
Most of all, good luck!
THE VORON TEAM

WWW.VORONDESIGN.COM
Heat Set Insert
PREPARATION
01

WWW.VORONDESIGN.COM
M3x8 SHCS M3x8 SHCS
M3x8 SHCS
SKIRTS
OPTION: KEYSTONE INSERTS
The picture is showing blanks
for the keystone slots.
Alternatively you can add
modules for USB or ethernet
and expose ports of the
Raspberry PI on the back of the
printer.
02

WWW.VORONDESIGN.COM
M3 T-Nut
M3 T-Nut
SKIRTS
03

WWW.VORONDESIGN.COM
M3x8 SHCS
SKIRTS
04

WWW.VORONDESIGN.COM
M3x8 SHCS
M3 T-Nut
SKIRTS
05

WWW.VORONDESIGN.COM
M3x8 SHCS
SKIRTS
06

WWW.VORONDESIGN.COM
M3 T-Nut
M3 T-Nut
M5 T-Nut
SKIRTS
07

WWW.VORONDESIGN.COM
M3x8 SHCS
SKIRTS
08

WWW.VORONDESIGN.COM
M3 T-Nut
M3 T-Nut
M5 T-Nut
SKIRTS
09

WWW.VORONDESIGN.COM
M3x8 SHCS
SKIRTS
10

WWW.VORONDESIGN.COM
APPLY VHB TAPE
VHB Tape is a double sided
adhesive tape.
BOTTOM PANEL
11

WWW.VORONDESIGN.COM
M3x8 SHCS
BOTTOM PANEL
12

WWW.VORONDESIGN.COM
Z BELT COVERS
M3x6 BHCS
M3 Hammerhead Nut
13

WWW.VORONDESIGN.COM
Z BELT COVERS
PINCH BELT
Pinch the Z belt loop at
and slide the cover in place.
TURN TO FASTEN
The hammerhead nut will rotate and
lock into place when you fasten the
screw. At least that’s the theory.
14

WWW.VORONDESIGN.COM
REPEAT FOR REMAINING COVERS
Repeat the assembly steps and install the
remaining 3 covers.
Z BELT COVERS
15

WWW.VORONDESIGN.COM
PANELS
16

17
WWW.VORONDESIGN.COM
M3x8 SHCS
M3 Hammerhead Nut
Foam Tape 1mm
BACK PANEL
APPLY FOAM TAPE
Use foam tape on the contact areas
between the panels and the frame to
mitigate noise from vibrations.
HAMMERHEAD NUTS?
A drop of thread locker will turn the
hammerhead nuts into a 1/4 turn quick
release for the panels. Best done once the
assembly is nished.

18
WWW.VORONDESIGN.COM
BACK PANEL
