DHP 4127039WE User manual

DO NOT RETURN TO THE STORE !
Visit www.dhpfurniture.com/eng/support-home
or call Toll-Free 1-800-267-1739
4127039WE
B344127039WE00 - 10125-M
Date of Purchase
Metal daybed with trundle
N.C. - 2/14/2017
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Lot Number
Thank you for purchasing from DHP!
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1
© 2014 Dorel Home Products All Rights Reserved
Twin
Black
Weight Limit:
Daybed: 400 Lb / 181 Kg
Trundle: 225 Lb / 102 Kg
TM

Contact Us!
[email protected]
DHP Consumer Services
12345 Albert Hudon, Suite 100,
Montreal, Quebec, Canada H1G 3L1
Read Before Beginning Assembly
1-800-267-1739
Monday - Friday, 9:00 am - 5:00 pm (Eastern Time)
Warranty Information
2
B344127039WE00
Caution
DHP warrants this product to be free from defects in material and workmanship and
agrees to remedy any such defect. This warranty covers one year from the date of
original purchase. This is solely limited to the repair or replacement of defective
parts and assembly labor is not included.
This warranty does not apply to any product which has been improperly assembled,
subjected to misuse or abuse or which has been altered or repaired in any way.
Liability for consequential damages is excluded to the extent exclusion is permitted
by law. This warranty gives you specific legal rights and you may also have other
rights which vary from state to state.
To obtain warranty service, purchaser must present original bill of sale. Components
repaired or replaced are warranted through the remainder of the original warranty
period only. The defective components will be repaired or replaced without charge,
subject to the terms and conditions described above.
Visit www.dhpfurniture.com to view the limited warranty valid in the U.S. and
Canada.
●Call our toll free number if you need assistance.
●Work in a spacious area and near where the unit will be used, preferably on a
carpet, or use a piece of the cardboard packaging to protect your floor and product.
●Recommended # of people needed for assembly: 2(however it is always better
to have an extra hand). Estimated assembly time is 1.5 hours.
●Make sure all parts are included. Most parts are labeled or stamped on the raw
edge.
●Read each step carefully. It is very important that each step of the instructions is
performed in the correct order. If these steps are not followed in sequence,
assembly difficulties will occur.
●This product is designed for home use and not intended for commercial use.
●This product contains small components. Please ensure that they are kept away
from small children.
●Do not use power tools to assemble your furniture. Power tools may strip or
damage the parts.
For help with assembly, identifying parts, product information or to order parts,
please contact us:

3
B344127039WE00

4
Parts For Daybed
B344127039WE00
All in 1 big box!
Before you throw the package, please use the
Check Box to identify the parts and ensure that
you have all the parts needed for the assembly.
There are inner box(es) that include components
required to complete this assembly.
Replacement Parts, Visit www.dhpfurniture.com/eng/support-home
A
Post
T944970
X 1
Post
T944980
X 2
Post
T944990
X 1
BCIT
FJ
OQ
YW
End Guard Rail
T945000
X 1
End Guard Rail
T945010
X 1
Rear Guard Rail
T945020
X 1
Side Rail
T930010
X 1
Slats
T919600
X 22
Slat Spacer
T919490
X 21
Plastic Plug
T392590
X 44
Slat Spacer
T919480
X 22
A
B
C
F
J
I
T
O
W
Y
Q

5
Parts For Trundle
B344127039WE00
All in 1 big box!
Before you throw the package, please use the
Check Box to identify the parts and ensure that
you have all the parts needed for the assembly.
There are inner box(es) that include components
required to complete this assembly.
Replacement Parts, Visit www.dhpfurniture.com/eng/support-home
Y W Q
Side Rail
T930890
X 2
End Rail
T910390
X 2
Slats
T919600
X 20
Locking Caster
T392990
X 2
Caster
T393000
X 2
Plastic Plug
T392590
X 40
Slat Spacer
T919480
X 20
Slat Spacer
T919490
X 19
E
MON1
N
E
M
M
Y
N
N
O
Q
W
EN1
N1

6
Hardware Pack For Daybed
B344127039WE00
Hardware Pack #: T5545096-00
Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of
the page.
5
4
3
2
1
5/16" X 3/4"
X 4
1/4" X 3/4"
X 4
1/4" X 2 3/16"
X 4
1/4"
X 4
4mm
X 1

7
Hardware Pack For Trundle
B344127039WE00
Hardware Pack #: T5499196-01
Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of
the page.
1
1/4" X 9/16"
X 8
2
4mm
X 1
3
Wrench
X 1

8
B344127039WE00
Step 1
The following instructions will illustrate how
to assemble the Daybed from STEP 1 to
STEP 7. Please use the Daybed Hardware
Pack: T5545096-00.
Insert Ainto Iwith BOLT .
X 1
A
I
A
I
2

9
B344127039WE00
Step 2
Insert Cinto Twith .
X 1
C
T
C
T
2

10
B344127039WE00
Step 3
Insert B X 2 to F with .
X 2
2
B
B
F
F
B

11
B344127039WE00
Step 4
4.1 Insert I and T into F;
4.2 Attach Iand T to Fwith and .
X 4
3
X 4
4
F
A
C
I
T
F
I
F
4.1
4.2
4
3
Rear view
I

12
B344127039WE00
Step 5
Attach Jto A,C, Iand Twith .
X 4
1
J
A
C
I
T
Wide side of the slot should
be facing up !
T
C
J
J

13
B344127039WE00
Step 6
Insert O into Jand Fas illustrated, then
lock O into place with Y.
2
1
2
3
3
1
Y
J
O
OO
F
Y
FF

14
B344127039WE00
Step 7
7.1 Press Wapproximately in the
middle of Oas illustrated;
7.2 Attach Qto Walternating left and
right.
O
O
O
W
Q
W
7.1
7.2

15
B344127039WE00
Step 8
The following instructions will illustrate how
to assemble the Trundle from STEP 8 to
STEP 12. Please use the Daybed Hardware
Pack: T5499196-01.
Attach N X 2 to E.
E
N
N
3

16
B344127039WE00
Step 9
E
N1
N1
3
Attach N1 X 2 to the other E.

17
B344127039WE00
Step 10
E
E
M
M
M
E
X 8
1
Attach M X 2 to E with .

18
B344127039WE00
Step 11
2
1
2
3
3
1
Y
E
O
E
O
O
Insert Ointo Eas illustrated, then lock
O into place with Y.
E
E
Y

19
B344127039WE00
Step 12
O
W
OQ
W
O
12.1
12.2
12.1 Press Wapproximately in the
middle of Oas illustrated;
12.2 Attach Qto Walternating left and
right.

20
How to use the trundle:
B344127039WE00
Pull out the trundle completely from underneath
daybed. Once positioned, make sure casters
are locked by pushing down the lever "ON" as
illustrated "How to lock the caster!".
To store the trundle:
Unlock the casters by pushing down the lever
"OFF" as illustrated "How to unlock the caster!"
and push in the Trundle underneath the
Daybed.
WARNINGS:
For safety reasons and to prevent injuries:
●This bed is not intended for use by children under 4
years old.
●Prohibit jumping and horseplay on this bed.
●To optimize use of trundle, use a standard twin
size mattress, no thicker than 8".
●Only use a mattress which is 74" - 75" long and 37
1/2" - 38 1/2" wide.
●Do not use risers under this bed.
ON
OFF
ON
OFF
How to lock the caster! How to unlock the caster!
Please keep casters in lock condition under normal use to prevent unintentional
movement which may lead to instability and tipping.
