Mocka Taylor User manual

Now that I’m here you are only one
flat-pack away from transforming
your home.
Hello,
I’ve arrived!

Make Time
The first step to all seamless
assembly is taking a moment
to carefully read through the
instructions—you are already
on your way to creating a
beautifully functional space!
Tool Check
Layout the instructions, screws
and panels to check you have
everything you need. A blanket
or soft floor rug will help protect
your new favourite item from
scratches and a drill will
speed up the assembly too!
Room Reveal
You did it! Take a step back and
enjoy the moment. Don’t forget
to recycle any packaging
and share a pic of your room
reveal - we love seeing how you
transform your home! Tag us
@mockaaustralia/@mockaanz
Set The Mood
Put on your favourite playlist,
order that pizza and pour
yourself a drink to get in
the mood!
Need help? Our Support Team are available via live chat, email or phone. Visit our website for details.
Here are a few assembly tips before you get started:
Happy flat-packing!
the Moa Team
Thank you for supporting us.
We believe design belongs to everyone. From materials and processes to safety testing, production and delivery,
we are passionate and committed to bringing you the best possible product so you can create beautifully
functional spaces to feel comfortably you.

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Taylor Queen Bed
Thank you for purchasing Taylor Queen Bed. Please follow the
manufacturer’s assembly instructions in detail.
* IMPORTANT NOTICE *
When moving the bed, please lift o the ground with two
people. DO NOT drag, push or pull the bed across the floor, as
this can result in damage to the supporting leg.
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Hardware Supplied
G
25mm
screw x16
35mm
bolt x1
H
25mm
bolt x4
L
left
plate x2
R
right
plate x2
double
cap x14
A B
25mm
bolt x8
C
spring
washer x8
D
washer
x8
E
20mm
bolt x 20
F
T3
large allen
key x1
small allen
key x1
T2

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Taylor Queen Bed
1
8
3
6
3
6
4
4
6
9
3
3
8
2
7
7
7
7
10
10

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Taylor Queen Bed
1 2
1b: Attach 1x left plate (L) and 1x right plate (R) to panels [1], [3] and [4] and
secure with 4x spring washers (D), 4x washers (C), 4x 25mm bolts (B), 2 x
screws (F). Tighten with Allen Key (T2). Do not completely tighten the screws
until the complete frame is built.
1a: Attach 1x left plate (L) and 1x right plate (R) to panels [3], [2] and [4] and
secure with 4x spring washers (D), 4x washers (C) , 4x 25mm bolts (B), 2 x
screws (F). Tighten with Allen Key (T2). Do not completely tighten the screws
until the complete frame is built.
R
L
L
B
DC
L
F
L
1
Step 1c
Step 1b
R
2
4
3
3
4
2b: Attach 2 x legs (10) to assembled frame and secure with 8 x bolts (F).
Tighten with Allen Key (T2).
2c: Attach 4 x legs (7) to assembled frame and secure with 16 x bolts (G).
Tighten with a screwdriver.
2
2
3
7
G
1
7
7
7
7
4
3
3
4
F
10
Step 2a
Step 2b

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Taylor Queen Bed
3 4
3a: Attach panel [9] to assembled frame and secure with 4 x screws (E). Tighten
with a screwdriver.
3b: Attach panel [4] to assembled frame and secure with 4 x screws (F). Tighten
with a screwdriver.
3c: Attach panel [9] to panel [6] and secure with 4 x screws (H). Tighten with a
screwdriver.
Join the bed planks together in the middle of the frame using 14x double caps
(A). Insert the end of the planks into the bed frame as shown and attach the
double caps (A) into panel [8]. Make sure the double caps (A) click securely into
place.
83
A
88
Step 3a
F
Step 3b
Step 3c
H
4
4
6
9
6
9
6
4
E
10
E
6
Step 3d

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Taylor Queen Bed
5
Lift the bed into the desired location, do not drag, You’re done, enjoy!
