OWNER’S MANUAL
SVX3-M
INDUSTRIAL VACUUM
USER & MAINTENANCE BOOK
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

1. INTRODUCTION
This user and maintenance manual will set out the guidelines and proce-
dures that must be followed by those operating this equipment in order to
guarantee:
• Operators’ safety
• Correct use of the machine
• Optimum performance
IT IS NECESSARY THAT THE AUTHORIZED PERSON-
NEL AND MACHINE OPERATOR HAVE READ AND
UNDERSTOOD THE MANUAL BEFORE USING THE
MACHINE.
Due to the importance of this information, we recommend that the
operator:
• Always keeps this manual close at hand for easy consultation
• Keeps the manual in a safe place in order to prevent loss or damage
• Asks the manufacturer/supplier for a replacement copy in case of loss or
damage
• Supplies this manual and the manufacturer’s details together with the
machine if it is sold to a third party
The manufacturer reserves the right to update its products and manuals
and is not required to provide updated versions of the them.
2. WARRANTY
DiamaPro SVX model vacuums are warranted to be free from manufactur-
ing defects in normal service for a period of one or two years from the date
of purchase by the original consumer purchaser. Component manufac-
turers o󰀨er separate warranty periods. Call 800-622-2048 for complete
information.
DiamaPro System’s obligation under this warranty is expressly limited to
the replacement of such part or parts as inspection shall disclose to have
been defective.
This warranty does not apply to defects caused by damage, unreasonable
use, faulty repairs made by others or defects caused by failure to provide
reasonable maintenance.
Further, the warranty is void if the product, or any of its components, is
altered or modied by the consumer or if the product is used in an inappro-
priate manner or with equipment not recommended by the manufacturer.
Wear items are not covered under warranty: examples include: belts,
wheels, casters, bearings, cart wheels, lters, wear pads, spark plugs,
hoses, wands and squeegees, motors, etc.
To qualify for warranty coverage, DiamaPro SVX vacuums must be regis-
tered within 30 days of purchase. Registration can be completed online at
www.DiamaProSystems.com
To request your warranty service you MUST send a written request to:
DiamaPro Systems
P.O. Box 19946
Charlotte, NC, 28219
including the manufacturing details that can be found on a plate tted
inside your machine together with a copy of the invoice.
The warranty is invalid under the following conditions:
• Improper use of the machine or total or partial failure to comply with the
contents of this manual
• Any part of the vacuum cleaner is altered or modied in any way
• Incorrect electrical installation
• If the laws in the country of use are not respected
• Inadequate maintenance
• The machine has not undergone routine maintenance as specied in this
manual
• Use of spare parts that are not produced by DiamaPro or not specically
indicated for the model in use
• Partial or total failure to comply with the instructions given in this manual
3. UNINTENDED USE
• Do not use the machine for sucking up liquid material
• Do not use the machine or expose the machine to water, rain, or rain like
environments
• Do not use the machine with improper extension cords or extension cords
of improper length
4. MACHINE DATA
4.1 TECHNICAL DATA PLATE
Every DiamaPro machine carries a registration plate showing essential
details that are necessary when contacting the supplier/manufacturer for
advice, suggestions or information on spare parts. The following details are
included on the plate:
• Manufacturer
• Model
• Supply voltage
• Installed rated power
• CE symbol (built in compliance with Machinery Directive 2006/42/EEC)
4.2 SAFETY DEVICE
The vacuum cleaner has been manufactured in compliance with all legal
standards for the operator’s safety.
• All metal components are grounded to eliminate shock or electrostatic
discharge, including the exible suction hose that is properly grounded.
Also in this regard the choice of a suitable exible suction hose allows to
eliminate this risk on the hose length that goes from the use area to the
vacuum cleaner.
• The brakes tted onto the anterior pivoting casters safely x the ma-
chine in its place of use where there may be a risk of movement due to
uneven oor surfaces or other particular working conditions.
BEFORE USING THE MACHINE CHECK THAT THE
MACHINE HAS NOT SUFFERED ANY SHOCKS OR
DAMAGES DURING THE TRANSPORT THAT CAN
AFFECT THE OPERATION OF THE ABOVE DEVICES
5. PERFORMANCE TOLERANCES
The performance of the machine may vary based upon environmental
factors such as temperature, air pressure, humidity, etc.
6. SAFETY PROVISIONS
• Carefully read the instructions in this manual before starting, using,
servicing or operating the vacuum cleaner
• Check that the vacuum cleaner hasn’t been damaged in any way
• Never turn on the machine if it is faulty or if you suspect it is faulty
• Check that the switch isn’t worn or damaged
• Do not approach the suction intake of the machine with unfastened or
broken garments that could easily be sucked into the machine
• Check that the lters are present and e󰀩cient
• Make sure that the lters are installed correctly and in full working order,
always observing the regulations in force in the workplace
• Do not carry out repairs without the manufacturer’s authorization
• Never use gasoline, solvents or other ammable liquids for cleaning;
only proper detergents should be used for cleaning
• Never move the machine by pulling the power cable or exible hose
• Never direct the opening of the machine or the exible tube towards
people or animals
• Protect the machine from the rain
• Check that the machine is connected to a power source with the correct
voltage indicated on the registration plate
• Make sure that the power cable has no wear or damage. If replacing
the cable, always replace it with another of the same specications as
the original one: cables that are not approved or of inferior quality may
overheat and cause serious injury to the user
• Make sure that the machine is connected to an appropriate power
source in full working order (check the presence of a fully functional
grounding socket)
• Repairs must only be carried out by authorized personnel and only
when the machine is turned o󰀨 and disconnected from the power source
• Never allow unauthorized personnel to use the machine
• Make sure that all safety devices are in full working order before turning
on the machine
• Never cover the vacuum cleaner during use

7. INSTALLATION
7.1 DELIVERY AND HANDLING
All machines are carefully tested and checked by DiamaPro before
delivery. The machine is transported inside a protective box or wrapped
in a protective lm that allows the courier to see the item during transport
and is securely xed to a pallet. If any part of the machine is not intact or
has been damaged during transport, le an immediate complaint with the
courier. Parts that have been damaged or broken due to incorrect transport
or handling of the machine will not be recognized by the manufacturer’s
warranty. The machine must be lifted and moved using a forklift truck in
accordance with the relevant safety regulations in force in the workplace
7.2 CHECK THE PROPER ELECTRICAL
CONNECTION
Connect the industrial plug to the power cable and connect the plug to a
socket that has the same amp rating and is protected by a line-isolating
switch.
8. PERIODICAL MAINTENANCE
Maintenance and cleaning operations must ALWAYS be carried out when
the vacuum is turned o󰀨 and disconnected from the power source. No
particular measures must be taken for the maintenance, cleaning or lubri-
cation of the suction unit. However, it is important to remember that correct
use and servicing are essential if the safety and e󰀩ciency of the vacuum
are to be guaranteed.
To ensure regular and constant operation and to prevent the warranty from
becoming void, always use genuine DiamaPro spare parts when repairs
are needed.
8.1 BEFORE TURNING ON AND TURNING OFF
EVERY DAY
• Visually check that the suction hose has not been damaged in any way (it
must not be damaged, torn, crushed)
• Check that the electrical switches are in full working order and are not
damaged in any way
• Check that the suction hose has not been damaged in any way
• Check that the motor head is correctly positioned on the lter chamber
and that the latter is correctly placed on the main barrel
• If the vacuum cleaner is moved, ensure that the power voltage of the play
in this new location corresponds to the one on the technical data plate
8.2 AT EVERY 50 HOURS OF OPERATION
• Check the condition of the primary lter: it must not have tears, holes or
other damage: in this case replace it (see 14.)
• Check that the technical data plate is legible and not damaged in any
way: contact the manufacturer for a replacement if necessary
9. PRODUCT DISPOSAL
Dispose of the machine and any accessories according to the legislation
of the state/country. To avoid a󰀨ecting the environment or your health or
the health of others it is recommended to separate the machine from other
waste, and if necessary properly recycle it.
10. DESCRIPTION
11. MOUNTING OF PARTS
Depending on the specic needs of the client, the vacuum cleaner may
include accessories that are not normally supplied in the standard version.
It is necessary to select the suction hose and accessories that are appro-
priate for the type of material that must be sucked into the cleaner.
The machine is now ready for use.
Connect one end of the exible hose to the desired accessory and the
other with the camlock mounted on the lter chamber.
(See the accessories sheet)
1
3
4
5
8
6
9
2
7
10
1. SUCTION UNIT
2. ON-OFF SWITCH
3. ACCESSORIES CONNECTION
4. WHEELS WITH BRAKE
5. FILTER CLEANING LEVER
6. BAG HOLDER
7. COLLECTION BAG
8. STRAP LOCKS BAG
9. ACCESS TO THE PRIMARY FILTER
10. ACCESS TO THE SECONDARY FILTER

I
0
1
I
0
I
0
12. USING THE VACUUM CLEANER
I - Motor switch ON
O - Switch OFF
13. FILTER REPLACEMENT
Before switching ON the vacuum be sure the
container is empty
1
PRIMARY FILTER REPLACEMENT
1. Disconnect and lift the head. (A)
2. Remove the lter (B)
3. Replace the lter with a proper one for
the vacuum cleaner in use
4. Insert the new lter
5. Hang up the head (A)
A
B
SECONDARY FILTER REPLACEMENT
1. Remove the rubber sleeve (C)
2. If necessary, close the lter with a cap (D)
3. Remove the three screws (E)
4. Remove the lter (F)
5. Replace the lter with a proper one for the
vacuum cleaner in use
6. Insert the new lter (F)
7. Fix the lter on the chamber with the 3 screws
8. Connect the sleeve
C
E
D
F
14. FILTER CLEANING DEVICE
AND SUCTION MODE
MANUAL FILTER CLEANING
Close the suction nozzle (A) and act on the lever (B) to clean the lter, with
a fast movement. If necessary, repeat the operation.
A
B
To make cleaning e󰀨ective the vacuum cleaner must
be in operation
15. TROUBLESHOOTING
You can thus solve any problem that may occur.
Motors do not start.
uNo electrical voltage.
uCheck cables, plugs and socket.
Suction capacity decreases slowly.
uFilter, nozzle, suction hose or suction pipe may be blocked.
uCheck, clean accessories. Clean lter.
Dust comes out during the vacuuming.
uFilter has not been fastened correctly or is defective.
uCheck to see if lter is sitting properly; replace if required.

17. BAG REPLACEMENT
1- Remove the belt. 2- Remove the Innity
Bag container and any
waste.
3- Insert the new Innity Bag
with the inner part facing
upwards.
4- Cut and remove the Innity
Bag closing bands.
5- Keep the inner part of the
bag outside the container and
pull it slightly.
6- Pull the outer part of the bag to create
the new one.
7- Insert the container with the Innity
Bag, using the pins as reference.
8- Bring the inside of the
bag up to the height of the
belt positioning. Close the
bag around the chamber
with the belt.
9- Pull the bag and place at
the edge the band to create
a new one. If necessary use
two bands.
1 - Close the bag with two
distanced bands.
2 - Cut the strip between the
two bands.
3 - Pull the Innity Bag end to
make a new bag.
16. COLLECTION BAG USE
The dust and the particles are collected in a bag placed in the container under the hopper.
The Innity Bag system consists in a plastic tubular from which are obtained 20/30 bags of di󰀨erent weights and dimensions. Once nished or damaged,
the tubular must be replaced by a new rell.
The operations below described must be carried out when machine is turned o󰀨.

18. ELECTRIC DIAGRAM

19. PARTS BREAKDOWN

19. PARTS BREAKDOWN
MOTOR

20. ACCESSORIES

DiamaPro Systems®
3343 Peachtree Road NE
Suite 145 #24
Atlanta, GA 30326
470-977-2323
