Diamond Multimedia Radeon X1950XTX Installation guide

X1950XTX512PCIE
9650 DeSoto Ave
Chatsworth, CA 91311
Tel: [phone]
Fax: [phone]
www.diamondmm.com
Featuring:RADEONTM X1950XTX
Memory: 512MB
Slot Type: PCIE
With:  Dual DVI (Dual Link) /
  HDTV / D-Sub /ViVo
Viper X1950XTX
The World Fastest Graphics Card
Overview
THE GAME IS ON!
With the Radeon® X1950 series, your graphics performance will never be compromised. Imagine games
with hyper realistic light blooms, lifelike skin textures, and silky smooth hair. Now imagine the non-stop
action packed gaming on a CrossFire™ platform – the only choice for hardcore gamers. That’s what it’s like
with the Radeon X1950, ATI’s fastest and most flexible 3D processor. All gaming, all the time. Radeon®
graphics. Never comprise.
AVIVOTM
•Video and Display Perfection
•True-to-Life Image Reproduction
•Sharp video and photos, smooth video playback
•Universal connectivity for TVs and display
SPECIFICATIONS
• GPU: ATI Radeon®X1950XTX
• Bus Type: PCI-Express x16
• Memory Support: 512MB GDDR4
• Memory Interface: 256 bit
• Core Clock Speed: 650 MHz
• Memory Speed: 2.0 GHz
• Shader Units: 48
• Geometry Pipelines: 16
• Peak Pixel Fill Rate: 10.4 Gpixels/sec
• Peak Vertex Throughput: 1300
• Peak Memory Bandwidth: 64.0 GB/s
• API Support: DirectX¨ 9.0, OpenGL
FEATURING
• 90 Nanometer Technology
• 48 pixel shader processors
• 384 million transistors on 90nm
• 8 vertex shader processors
• 256-bit 8-channel GDDR4 memory  
 interface
• Lightning fast memory clock speeds
• High Dynamic Range (HDR) rendering
• Support for Microsoft®DirectX®9.0 & 
 Shader Model 3.0
• AVIVO and 3D excellence
• CATALYST Software Drivers
• Simultaneously drive 2 High Resolution 
 panels
• HDTV Support
System Requirements
• Intel®Pentium®4 or AMD®Athlon®64 FX CPU's
• CPU running at 2.4 GHz or higher
• 550-Watt power supply or greater, 30 Amps on 12 volt rail  
 recommended (assumes fully loaded system)
 *1100 Watt ATX 2.0 or higher required for use with crossfire not included
• PCI Express compliant power supply required.
 Connect directly to the power supply with a 6 pin
 PCI Express power connector
• Super VGA or DVI-I compatible monitor
• Microsoft Windows®XP, XP 64, 2000, MCE
• PCI Express X16 compliant slot
• CD-ROM or DVD-ROM drive
• 512MB system RAM minimum
• 480MB available hard disk space
Package Includes:
• Quick Install Guide
• Software: ATI CATALYST, Diamond Tools, DVD Playback
• Component-out cable adapter
• 9-pin S-Video/composite VIVO
• 6-inch S-Video cable
• 6-inch composite cable
• 2 x DVI-to-VGA adapter
Diamond, Diamond Multimedia and Viper are registered trademarks of Diamond Multimedia. ©2006 Advanced Micro Devices, Inc., ATI, the ATI logo, Avivo,
Catalyst, CrossFire, HyperMemory, and Radeon are trademarks of Advanced Micro Devices, Inc.. All other trademarks are property of their respective owners.
© 2006 Diamond Multimedia. All rights reserved.
