Diamondback RESPONSE PM4360 User manual

Diamondback Fitness • 6004 S. 190th Street, Suite 101 • Kent, WA 98032 • Ph: 800.776.7642
© Diamondback Fitness 2010
PM4360
DP #: 22-10-1258
Response Er6c Owner’s Manual

PURCHASER’S REFERENCE INFORMATION
Product Name: Response Er6c Elliptical by Diamondback Fitness
Serial Number: E _ _ _ _ _ _ _ _ _ _
Record the serial number here.
Serial Number Location
The serial number will be located on the rear of the unit, above the
power input jack (see figure to the right).
Record of Purchase
NOTE: Please record details associated with the purchase of your Response Er6c below. This information will be
required in the event the unit requires future service. ATTACH THE PURCHASE RECEIPT.
Dealer Name: ___________________________________________ Dealer Telephone Number: ( ) _____________________________
Dealer Address: _________________________________________________________________________________________________________
Date Purchased: ________________________________________ Dealer Contact Name: ________________________________________
To Activate Your Warranty
Please register the unit at www.diamondbackfitness.com. Failure to comply may limit or void your warranty coverage.
SERIAL NUMBER
||||||| |||| |||||| |||||||||||
E000000000
WARNING: REMOVAL OR
DESTRUCTION OF THIS
LABEL VOIDS WARRANTY
SAMPLE
2

Release v.1 (09/2010)
Response Er6c
Owner’s Manual
3

TABLE OF CONTENTS
PURCHASER’S REFERENCE INFORMATION ....................................................................2
Serial Number: .......................................................................................2
INTRODUCTION ..........................................................................................5
RESPONSE ER6c ASSEMBLY & INSTALLATION..................................................................6
Response Er6c Assembly Instructions ..................................................................... 7
SAFETY INSTRUCTIONS & WARNINGS .......................................................................10
WORKOUT GUIDELINES...................................................................................12
Good Health is an Exercise in Common Sense ............................................................. 12
Body Mass Index .................................................................................... 12
Heart Rate is an Important Key to Your Exercise ............................................................ 13
Touch Heart Rate Sensors ............................................................................. 13
Wireless Heart Rate Receiver ........................................................................... 13
Your Estimated Maximum Heart Rate & Target Training Zone ................................................... 14
WORKOUT QUALITY AND QUANTITY ........................................................................15
CONSOLE LAYOUT.......................................................................................17
LCD Display Windows ................................................................................ 17
Buttons And Keys ................................................................................... 19
MP3/iPod Input Jack and Speakers ...................................................................... 20
Default Settings ..................................................................................... 20
PROGRAMS ............................................................................................21
Quick Start ........................................................................................ 21
Manual Program .................................................................................... 22
Classic Programs .................................................................................... 23
User Program ...................................................................................... 23
Target Heart Rate ................................................................................... 24
MAINTENANCE..........................................................................................26
WARRANTY INFORMATION ................................................................................27
WARRANTY REGISTRATION CARD ..........................................................................30
4

INTRODUCTION
Congratulations on the purchase of your new Response Er6c Elliptical trainer. You have made a smart choice and are about to
enjoy one of the most effective and technically-advanced methods of cardiovascular exercise available today.
Founded in 1991 as an off-shoot of the legendary bicycle company, Diamondback Fitness was in many ways a complimentary
addition to the Diamondback brand. One might even say this extension grew as a natural evolution…an evolution from
classic outdoor bicycle usage, toward indoor-based cycling and cross training. It turns out that many fitness enthusiasts were
searching for ways to maintain conditioning during times of inclement weather or were simply looking for new and different
cross-training options.
This trend still continues today, twenty years later, as the strong Diamondback brand resonates with both the boomers who
grew up with the bicycles, as well as the younger generations riding them today.
Diamondback Fitness continues to build upon this legendary brand identity by offering the cardio enthusiast a full line of
upright exercise bicycles, recumbents, and elliptical trainers, each offering superior value and quality in an intuitive and
visually-appealing design. Let’s just say, we are already planning our next twenty years.
Thank you for choosing Diamondback Fitness.
Diamondback Fitness
6004 South 190th Street, Suite 101 Kent WA 98032 Ph. 1.800.776.7642 Fax: [phone]
For more information or questions regarding your equipment, please visit our web site at DiamondbackFitness.com.
5

Part Description
A.......Console [Quantity: 1]
A-1 .....Console Hinge Cover [1]
A-2 .....Hex Screw M5 x 0.8 x 10.0 mm [8]
A-5 .....Main Wire Harness - Console [1]
A-6 .....Heart Rate Wire Harness - Console [1]
B.......Console Mast Assembly [1]
B-3 .....Main Wire Harness - Console Mast [1]
B-11 ....Heart Rate Wire - Console Mast [1]
B-13 ....Water Bottle [1]
B-14 ....Hex Screw M8 x 1.0 x 55.0 mm [4]
B-16 ....Lower Console Mast Cover - Front [1]
B-19 ....Lower Console Mast Cover - Left [1]
B-20 ....Lower Console Mast Cover - Right [1]
B-21 ....Hex Screw M5 x 0.8 x 20.0 mm [4]
B-25 ....Flat Washer 17.0 ID x 25.0 OD x 1t mm [2]
B-26 ....Flat Washer 8.0 ID x 16.0 OD x 2.0t mm [2]
B-27 ....Upper Pivot Cover [2]
B-33 ....Hex Bolt M8 x 1.25 x 20 mm [1]
C.......Rear Assembly [1]
C-1 .....Flat Washer 8.0 ID x 19.0 OD x 2.0t mm [4]
C-2 .....Hex Screw M8 x 1.25 x 16 mm [8]
C-3 .....Lock Washer 8.1 ID x 12.1 OD x 2.4t mm [8]
C-4 .....Curve Washer 8.0 ID x 19.0 OD x 2.0t mm [4]
C-23 ....Stabilizer Foot [4]
C-24 ....Main Wire Harness - Rear Frame [1]
C-28 ....Input Jack [1]
G-1 .....Lower Pivot Cover [2]
G-14 ....Hex Bolt M8 x 1.25 x 20 mm [2]
G-15 ....Flat Washer 8.0 ID x 16.0 OD x 2.0t [2]
H-L .....Handlebar Assembly - Left [1]
H-R .....Handlebar Assembly - Right [1]
N.......120V to 9V 2A Power Adaptor [1]
RESPONSE ER6c ASSEMBLY
6
B-11
B-3
A-6
A-5
N
A-2
B-26B-27B-33
H-L
B-25
B-13
H-R
G-14G-1G-15
C-28
B-19
B-21
B-20
B-14 B-16
C-3 C-4
C-2 C-1
C-24
C
C-23
A-1
A-2
A
B-3
B

Part Description
A.......Console [Quantity: 1]
A-1 .....Console Hinge Cover [1]
A-2 .....Hex Screw M5 x 0.8 x 10.0 mm [8]
A-5 .....Main Wire Harness - Console [1]
A-6 .....Heart Rate Wire Harness - Console [1]
B.......Console Mast Assembly [1]
B-3 .....Main Wire Harness - Console Mast [1]
B-11 ....Heart Rate Wire - Console Mast [1]
B-13 ....Water Bottle [1]
B-14 ....Hex Screw M8 x 1.0 x 55.0 mm [4]
B-16 ....Lower Console Mast Cover - Front [1]
B-19 ....Lower Console Mast Cover - Left [1]
B-20 ....Lower Console Mast Cover - Right [1]
B-21 ....Hex Screw M5 x 0.8 x 20.0 mm [4]
B-25 ....Flat Washer 17.0 ID x 25.0 OD x 1t mm [2]
B-26 ....Flat Washer 8.0 ID x 16.0 OD x 2.0t mm [2]
B-27 ....Upper Pivot Cover [2]
B-33 ....Hex Bolt M8 x 1.25 x 20 mm [1]
C.......Rear Assembly [1]
C-1 .....Flat Washer 8.0 ID x 19.0 OD x 2.0t mm [4]
C-2 .....Hex Screw M8 x 1.25 x 16 mm [8]
C-3 .....Lock Washer 8.1 ID x 12.1 OD x 2.4t mm [8]
C-4 .....Curve Washer 8.0 ID x 19.0 OD x 2.0t mm [4]
C-23 ....Stabilizer Foot [4]
C-24 ....Main Wire Harness - Rear Frame [1]
C-28 ....Input Jack [1]
G-1 .....Lower Pivot Cover [2]
G-14 ....Hex Bolt M8 x 1.25 x 20 mm [2]
G-15 ....Flat Washer 8.0 ID x 16.0 OD x 2.0t [2]
H-L .....Handlebar Assembly - Left [1]
H-R .....Handlebar Assembly - Right [1]
N.......120V to 9V 2A Power Adaptor [1]
Assembly Notes
• Please read the entire Response Er6c Owner’s
Manual before beginning the assembly. Review
the package contents to ensure all listed parts are
included.
• The assembler will require 14 mm & 18 mm box
wrenches, 6 mm, 5 mm, 4 mm & 3 mm hex
wrenches, and a Phillips screwdriver for assembly.
All required tools are included.
• The estimated assembly time of the Response Er6c
by a person familiar with basic tool usage is forty-
five (45) to sixty (60) minutes.
• Always inspect the unit to ensure handlebars and
steparms are tightened prior to using the unit.
1
14mm / 19mm Box Wrench and Phillips Screwdriver Combination Tool
Outil combinant une clé polygonale 14 mm/19 mm et un tournevis cruciforme
(1)
3.0 mm, 4.0 mm, 5.0 mm & 6.0 mm Hex Key Set
Ensemble de clés hexagonales de 3,0 mm, 4,0 mm, 5,0 mm et 6,0 mm
(1)
Response Er6c
Assembly Hardware Kit / Ensemble du matériel de montage
DP # / DP nº #22-10-1254
Model: Er6c Assembly Hardware Kit Card
Year: DB Fitness 2011
Graphics Prepared by: Skip Reys; [e-mail]
Date Created:
12-Sep-10
ASSEMBLY INSTRUCTIONS
7
Install the four (4) stabilizer feet (C-23).
Remove the eight (8) hex fixing bolts (C-2) and 16 washers (C-4,
C-3 & C-1) from the console mast (B) and and set aside.
While supporting the console mast (B) and the rear frame (C),
connect the lower connector of wire (B-3) with connecter (C-24).
Ensure the connections are solid.
Carefully insert rear frame (C) into the receiver of the console mast
(B) taking care not to pinch the wire harness. Align the holes in the
console mast receiver with the bolt holes of the rear frame and re-
install bolts (C-2), curved washers (C-4), flat washers (C-1) and
lock washers (C-4).
Level the unit. If viewed from above, turn the knobs clockwise to
raise the feet and counter-clockwise to lower them.
C-3
C-1
C-4 C-2
B
C-24B-3
C-23
C

8
3 42
Parts B-14, B-16, B-19, B-19, B-20 & B-21
will arive from the factory pre-assembled in the
carton. Disassemble by removing bolts B-14
and B-21 from parts B-16, B-19 & B-20.
Gather the left (B-19) and right (B-20) lower
console mast covers and bring together as a
clamshell over the console mast/main frame
union. Align covers with the mounting holes
and loosely thread the four (4) hex bolts B-21
into place. Do not tighten yet.
Positon the lower console mast front cover
(B-16) in place and thread the four (4) hex
bolts (B-14) through the face and into parts
B-19 and B-20. Do not over-tighten.
Align and tighten all bolts. Do not over-tighten.
B-19
B-21
B-20
B-14 B-16
G-14G-1G-15
G-R
H-RH-L
G-L
B-27
B-26
B-33
H-L
H-RB-25
Parts B-33, B-27, B-26 &
B-25 will arive from the factory
pre-assembled on the console
mast. Remove all components
except B-25 and set aside.
Slide the left (H-L) and right
(H-R) handlebar assemblies
over the upper pivot. The fit is
designed to be tight so proper
alignment is necessary for
installation.
Re-install washers B-26,pivot
caps B-27 and fixing bolts
B-33. Tighten bolt B-33 firmly.
The forward pivots of steparm G-L &
G-R will arive from the factory with
parts G-15, G-1 & G-14 pre-installed.
Remove bolts G-14, pivot caps G-1 &
washers G-15 from the steparms and
set aside.
Bring the pivots of the left step arm
(G-L) and handlebar (H-L) together,
sliding the handlebar pivot over the
step arm pivot axle and press into
place.
Re-install washer G-15, pivot cap G-1
and fixing bolt G-14. Tighten firmly.
Repeat for right-hand side.

9
5 6
FINAL SETUP &
INSTALLATION
Move the unit into
final position with
the help of the front
transport rollers.
This unit is heavy.
Safe transport may
require more than
one person. Carefully
lift and support the
rear end of the unit
until both wheels
touch the ground.
Slowly roll into
position.
After moving the
unit, ensure all four
feet are touching
the floor. Review
assembly step #1
above for leveling
instructions.
Inspect the unit
for loose bolts,
hardware, knobs or
pins.
Plug the AC adaptor
in a 120 Volt power
supply. Plug the
opposite end into
the input jack found
at the rear of the unit
(CC).
A-1
B-11 B-3 B-1
B-13
N
A-6A-2 A-5
A-2
C-28
A
The console hinge cover (A-1) is installed
onto the console at the factory. Remove the
four (4) screws (A-2) from the back of the
console hinge cover (A-1) and set the parts
aside. Four (4) more A-2 Phillips screws will
now be visible on the backside of the console.
Remove these, and set aside.
While supporting the console (A), feed wire
connectors A-6 & A-5 through inside of the
console hinge cover A-1 and join connector A-6
with connector B-11. Join connectors A-5 and
B-3. Make sure all connections are solid. Slide
the console hinge cover A-1 downward on the
cable to rest on the console mast.
Tilt the console hinge (B-1) to its most upright
position and feed the four (4) screws (A-2)
through the under side of the console mounting
plate (B-1) and into the back of the console (A).
Only the upper and lower holes of the hinge
plate are used in this step. Tighten firmly.
Align console hinge cover (A-1) with the
backside of the console, taking care to
tuck the wires into the backside of the
console or into the console mast.
Feed the four (4) screws (A-2)
through the back side of the
console hinge cover and into the
console. Tighten firmly.
Connect the power supply (N) to
a 120 Volt power source. Insert
the opposite end into the power
input jack (C-28).

SAFETY INSTRUCTIONS & WARNINGS
Every piece of Diamondback Fitness equipment is built for maximum safety and meets or exceeds all
applicable domestic and international standards. However, certain precautions need to be taken when
operating any piece of fitness equipment.
NOTE: Please read the entire owner’s manual before operating the unit.
NOTE: Read all warnings posted on the unit. If the warning label to the right is missing from the
Er6c elliptical, contact Diamondback Fitness at [phone] for a replacement.
Cautions – For Safe Operation
• Keep your hands and feet away from all moving parts and pinch points.
• If you have a history of heart disease, high blood pressure, diabetes, chronic respiratory diseases,
elevated cholesterol, or if you smoke cigarettes or experience any other chronic diseases or physical
complaints, consult with a physician before beginning any exercise program.
• If overweight, pregnant or above the age of 35, consult your doctor before beginning an exercise program.
• If you experience dizziness, nausea, chest pains or other abnormal symptoms during exercise, stop the
exercise session immediately and consult your physician.
• Consume water before, during and after each exercise session.
Warnings – Reduce the Risk of Injury to Yourself or Others
• To ensure proper functioning of your unit, do not install attachments or accessories not provided or
recommended by Diamondback Fitness.
• Always wear proper clothing and shoes when exercising.
• Never operate the unit without first verifying that both the handlebar and seat post are firmly fixed.
• Never extend the seat post beyond the MAX marking. See the installation instructions above for proper seat post adjustment.
• User weight is not to exceed 300 pounds / 136.4 kilograms.
• Keep children away from the unit. Hands and feet may become tangled in the moving parts which could result in serious injury.
This Class C product is rated for
home (Class H) use only. Use
only DIAMONDBACK FITNESS
replacement parts. Failure to to
so will render the warranty void
and could result in personal
injury or even death. There is a
risk assumed by individuals who
use this type of equipment. To
minimize the risk, always follow
these simple rules:
Spining cranks and pedals
can cause injury. Only
operate unit when seated.
Operation of this unit should
only commence after the
entire Owner’s Manual has
been read.
User weight for the Response
U6c is not to exceed 136 kg.
Keep children away from unit
at all times.
Contact DIAMONDBACK
FITNESS if you do not
understand these warnings,
are missing the Owner’s
Manual, or have questions
regarding the proper use and
maintenance of this unit.
1.
2.
3.
4.
5.
ES0880 Er6c
WARNING
10

• Place the unit in an area that will meet minimum the clearance requirements: Front, Back & Sides = 2 feet.
• This unit is heavy. Use caution when moving. Tilt the unit forward until the integrated transport rollers on the front stabilizer
make contact with the ground and slowly push or pull into the desired position. Always unplug the unit from the outlet before
moving or servicing.
• Keep the unit away from walls to allow proper ventilation. Air should be able to circulate freely around the unit. Keep all air
openings free of dirt and dust.
• Never insert anything into the openings.
• The Response Er6c is intended for indoor use in a home environment. Store indoors in a dry space.
• Place your unit on a solid, level surface when in use. Never operate if the unit is unstable. Review the assembly and
installation instructions for information regarding the leveling of the unit.
• Make sure all knobs for adjustments are fastened securely before getting on the unit and after making any adjustments (i.e.
seat post, saddle, seat assembly and handlebars).
• Use the handlebars when getting on and off the Response Er6c unit.
• Never operate the unit if it is damaged or broken. Contact your local authorized Diamondback Fitness Dealer for service.
• Please unplug the unit after exercising.
• Do not remove the covers or other components. Only Diamondback Fitness Dealers or Authorized Technicians should
perform service on the unit.
Assembly
Assembly of the Response Er6c should be performed by a Diamondback Fitness Dealer or an Authorized Technician as a
significant amount of technical knowledge is required for safe and complete assembly of the unit. Many retailers will offer
delivery and assembly as part of the sales agreement. If this unit was sold unassembled (in the carton) and you do not feel
you can perform the assembly, please call the dealer for service. Service calls for improper assembly are not covered by the
Warranty Policy and any associated charges will be the responsibility of the owner.
NOTE: Save this manual for your reference.
11

WORKOUT GUIDELINES
Good Health is an Exercise in Common Sense
In the study titled, “The Surgeon General’s Call To Action To Prevent and Decrease Overweight and Obesity,” the surgeon general
indicates that 61% of American adults are either overweight or obese. The study indicates that being overweight increases the risk of
health problems, such as heart disease, certain types of cancer, as well as Type-2 diabetes among other afictions.
The Surgeon General’s healthy weight advice for consumers encourages the following actions:
• Aim For a Healthy Weight: Find your Body Mass Index (BMI) on the chart below.
• Be Active: Keep physically active to balance the calories you consume.
• Eat Well: Select sensible portion sizes.
Weight in Kilograms
Height in centimeters
Healthy Weight
Over Weight
Obese
BMI = weight x 703 / height²
NOTE: Chart applies to adults
(age 20 years and older)
Body Mass Index
54.5 59.1 63.6 68.2 72.7 77.3 81.8 86.4 90.9 95.5 100.0 104.5 109.1 113.6
137.229 31 34 36 39 41 43 46 48 51 53 56 58 60
142.227 29 31 34 36 38 40 43 45 47 49 52 54 56
147.325 27 29 31 34 36 38 40 42 44 46 48 50 52
152.423 25 27 29 31 33 35 37 39 41 43 45 47 49
157.522 24 26 27 29 31 33 35 37 38 40 42 44 46
162.621 22 24 26 28 29 31 33 34 36 38 40 41 43
167.619 21 23 24 26 27 29 31 32 34 36 37 39 40
172.718 20 21 23 24 26 27 29 30 32 34 35 37 38
177.817 19 20 22 23 24 26 27 29 30 32 33 35 36
182.916 18 19 20 22 23 24 26 27 28 30 31 33 34
188.015 17 18 19 21 22 23 24 26 27 28 30 31 32
193.015 16 17 18 20 21 22 23 24 26 27 28 29 30
198.114 15 16 17 19 20 21 22 23 24 25 27 28 29
203.213 14 15 17 18 19 20 21 22 23 24 25 26 28
12

Heart Rate is an Important Key to Your Exercise
The Surgeon General also released a report on physical activity and health. This report dictates that exercise and fitness are
beneficial for a person’s health and reiterated the need for exercise as a key component for disease prevention and healthier living.
The best way to determine exercise intensity is to monitor your pulse during exercise. Heart rate can easily be determined by
counting the pulse rate at the chest, wrist or carotid artery on your neck. It is however, difficult to count your own pulse during
exercise, mainly because one cannot count fast enough to accurately track the rate. The Response Er6c is equipped with two
systems for monitoring your heart rate.
Touch Heart Rate Sensors
While the unit is powered-on and a workout program is operating, gently grasp both touch heart rate sensors on the handlebar.
The computer will detect your pulse rate and register a two or three digit number in the PULSE window on the LCD display.
NOTE: If an inconsistent heart rate is displayed while using the hand pulse sensors:
• Ensurethepalmsofbothhandsaretouchingthecontactareasofthetouchheartratesensors.
• Maintainevenpressureonthegrips.
• Donotclutchthetouchheartratesensorstightly.
• Trytokeepyourhandsstillwhilegripingthetouchheartratesensors.
Wireless Heart Rate Receiver
A wireless telemetry heart rate receiving system is one feature found on the Response models. In order for the console to
detect and display your heart rate, three conditions must be present:
• A compatible uncoded heart rate chest strap transmitter (not included) must be functioning and worn. Your Diamondback
Fitness dealer can assist you select the appropriate model. Please refer to the manufacturer’s instructions.
• The Diamondback Response Er6c must be powered on.
• A workout program must be running.
13

In general, a wireless heart rate chest strap is a more accurate method of detecting one’s heart rate as the user is not required
to grip the touch heart rate sensors and the unit will continuously display the heart rate no matter where the hands are placed.
Your Estimated Maximum Heart Rate & Target Training Zone
Your calculated target heart rate, or the ideal intensity needed to improve cardiovascular fitness, depends primarily upon your
age rather than your current state of fitness. It is calculated as a percentage of your maximum heart rate (estimated as 220
beats-per-minute minus your age). It is most effective to train at a heart rate between 60% and 85% of your maximum heart
rate. If exercise intensity is too low or too high, only modest gains will be made in strength and cardiovascular fitness. A workout
at a very low intensity will not offer maximum benefits. Conversely, if the workout intensity is too high, injury or fatigue may set
your exercise program back as the body attempts to recover.
To calculate your maximum heart rate and find the target training zone, use the following formulas. For example, the following
estimation would be relevant for a 35 year-old user:
• 220 – Age = Maximum Heart Rate 220 – 35 = 185
60% of Maximum Heart Rate 60% x 185 = 111 heart beats-per minute (Bpm)
85% of Maximum Heart Rate 85% x 185 = 157 Bpm
• Calculated Heart Rate Training Zone: 111 Bpm – 157 Bpm
170 166 162 157 153 149 145 140 136 132 128 123
120
117 114 111 108 105 102 99 96 93 90 87
180
170
160
150
140
130
120
110
100
90
80
20 25 30 35 40 45 50 55 60 65 70 75
85%
60%
Ages in Years
Heart Rate Guidelines 60%-85% Maximum Target
Heart Rate in BPM
14

WORKOUT QUALITY AND QUANTITY
It is recommended that you accumulate at least 30 minutes of physical activity most days of the week. Physical activity should
be initiated slowly and the intensity should be increased gradually. You should select activities that you enjoy and can fit into
your daily life. Having Diamondback Fitness equipment at home offers you the opportunity to work out without going to the gym.
The American College of Sports Medicine makes the following recommendations for the quantity and quality of training for
developing and maintaining cardiovascular fitness in healthy adults:
• An activity that uses large muscle groups, maintained continuously, and is rhythmical and aerobic in nature.
• Duration: 20 to 60 minutes of continuous aerobic activity, including a warm-up and cool-down period for each exercise session.
• Frequency: 3 to 5 times per week.
• Intensity: 60% to 85% of maximum heart rate.
In addition to aerobic exercise, it is recommended that you add strength training of moderate intensity twice per week to
your program.
Get a Smart Start on Exercising
Anyone over the age of 35, as well as younger persons whom are overweight, should check with his/her physician before
beginning any type of exercise program. People who have diabetes or high blood pressure, a family history of heart disease,
high cholesterol or have led a sedentary lifestyle should protect themselves with a medical check-up and a stress test, preferably
administered during exercise by a health care professional.
• Always stretch before your workout to loosen muscles, and afterwards to cool down.
• The first few minutes of your workout should be devoted to warming up muscles before a vigorous workout, and building
your heart rate slowly.
15

• After an aerobic workout of roughly 20-30 minutes, spend 10 minutes gradually reducing your heart rate with a lower
resistance level.
NOTE: Start slow, with intensity low until you build up endurance and strength. Always consult your physician
before beginning any exercise program.
Typical Target Zone Exercise
Patterns for 35 year-old
Maximum Attainable Heart Rate
85% of Maximum
185
bpm
157
bpm
111
bpm
60% of Maximum
Resting Warm-up
5 Minutes
Cool-down Resting
5 Minutes
20-30 Minutes
of Exercise
16

CONSOLE LAYOUT
NOTE: It is advised that new users read this entire section prior to beginning their first workout session.
LCD Display Windows
Time
Tracks the time of the current workout program.
Heart Symbol
Indicates that a heart rate is detected by either the
touch heart rate sensors, or the wireless heart rate
receiver. If a pulse is not detected, the heart icon will
not be visible and the Bpm will be displayed as “P”.
Pulse
Your heart rate will be displayed in this field when
detected by the touch heart rate sensors or wireless
heart rate receiver. Unit of measurement is
Bpm/Beats-Per-Minute.
Speed
An estimate of your speed (Kilometers per hour) will be
displayed. SPEED will alternate with RPM every five
(5) seconds.
17

RPM
An acronym for Revolutions-Per-Minute, the number of complete revolutions a single
pedal makes every 60 seconds. The display for RPM will alternate with SPEED every
five (5) seconds.
Load
Displays the current resistance level applied to the workout. The maximum
resistance load is 16.
Distance
The estimated total distance (in Kilometers) traveled since the beginning of the
workout.
Calories
The estimated number of calories burned since the beginning of the workout will be
displayed in this field.
Brickyard or Workout Profile
This field will graphically display the terrain of the workout program. A higher “brick”
stack represents a higher load or resistance level. A flashing column of bricks will
indicate the user’s progress in the program at any given time. Although only eight
(8) columns show in the window, the complete profile is comprised of twenty (20)
columns and will advance as the user progresses through the program.
Alpha-Numeric Messaging Bar
Program titles and instructions will be displayed in this field.
18

RESET
The reset button will return the programming to the program selection menu.
Holding the RESET key down for two seconds restarts the system and enters the User Set-Up mode.
START / QUICK START / STOP
When powering up the unit, it is possible to bypass all data entry and enter the Quick Start
program.
Pressing START / QUICK START / STOP while in the Program Set-Up mode will immediately
launch the program displayed in the Alpha-Numeric Messaging Bar.
Pressing START / QUICK START / STOP key once while in Program mode will pause the program.
Pressing the key again will un-pause the program.
UP / DOWN
During the Program Set-Up mode, press UP or DOWN to adjust the Age, Weight and Time values.
During the Program mode, press UP or DOWN to adjust the resistance level.
ENTER
Within the Set-Up mode, the ENTER key accepts the current program details such as Age and
Weight then moves to the next value to be adjusted.
In Program Selection mode, pressing ENTER will accept the displayed program and launch
Set Up mode.
Buttons and Keys
19

FITNESS TEST
At the end of a program, pressing the FITNESS TEST button once will launch the Fitness Test program.
Based upon the rate at which the user’s heart rate decreases over a sixty (60) second period, the Fitness
Test program provides a basic analysis of the user’s fitness by displaying F1, F2, F3, F4 F5 or F6 where F1
represent the highest level of fitness.
MP3/iPod Input Jack and Speakers
The Response console offers an on-board amplifier and stereo speaker set which can be connected to an Mp3 player, iPod®
or iPhone®. Connect one end of a male-to-male 3.5 mm stereo cable (not included) to the headphone jack of the device and
the other end to the console port located just above the accessory tray. Sound levels are controlled by the device so be sure to
check the internal settings of the player if the noise level is not satisfactory.
Default Settings
• Gender Male
• Age 25 years
• Weight 50 Kg
• Time 0 minutes. If left at zero, the program time will count up and run continuously until stopped by the
user. If an entry is made, the program will count down from the entered value.
• Segment Time Equals 1/20th of the entered time. If 30 minutes is entered for the program time, each segment will
equal 90 seconds.
• Load Level 1
NOTE: The default values for Age, Weight and Time will update and be stored as the default values when changed in
the program settings.
iPod® and iPhone® are registered trademarks of Apple, Inc.
20
