Tyco TY7158 User manual

Model TY7158 — 16.8 K-factor
Standard Coverage Upright
Storage Sprinkler — Specific Use
Page 1 of 2 JUNE 2019 TFP336
IMPORTANT
Refer to Technical Data Sheet
TFP2300 for warnings pertaining to
regulatory and health information.
Always refer to Technical Data
Sheet TFP700 for the “INSTALLER
WARNING” that provides cautions
with respect to handling and instal-
lation of sprinkler systems and com-
ponents. Improper handling and
installation can permanently damage
a sprinkler system or its compo-
nents and cause the sprinkler to fail
to operate in a fire situation or cause
it to operate prematurely.
Worldwide
Contacts
www.tyco-fire.com
General
Description
The TYCO 16.8 K-factor Model TY7158
Standard Coverage Upright Storage
Sprinkler is an automatic, standard
response, standard coverage sprin-
kler intended for a specific end use
application.
The TYCO Model TY7158 Sprinkler
has been subjected to full-scale fire
testing at UL LLC using test parame-
ters specified by TYCO that are con-
sidered representative of the specific
end use. The fire test performance
results of the large scale testing have
been verified by UL. Details of the tests
performed and results obtained may be
found in UL Test Report ‘Report of a
Special Services Investigation Involving
K16.8 gpm/(psi)½Upright and Pendent
Sprinkler Protection of a Shelf Display
and Rack Storage Arrangement of Car-
toned Group A Plastic’ (Report Number
NC27954).
The specific parameters for commodity
classification limits, allowable storage
arrangement, maximum ceiling and
storage height are based on limits
established by UL tested configura-
tions. The minimum operating pres-
sures are to match those utilized during
UL testing with the number of operating
sprinklers, including a 50% increase in
the number operated during UL testing
but not less than 12 sprinklers for the
standard coverage spacing. The hose
stream allowance with the design for
12 sprinklers is 250 GPM (946,4 LPM).
Sprinkler installation shall otherwise
comply with NFPA 13.
For further details, contact the Techni-
cal Services Department.
NOTICE
The Model TY7158 Standard Coverage
Upright Storage Sprinkler described
herein must be installed and main-
tained in compliance with this docu-
ment, as well as with the applicable
standards of the National Fire Protec-
tion Association, in addition to the stan-
dards of any other authorities having
jurisdiction. Failure to do so may impair
the performance of these devices.
The owner is responsible for main-
taining their fire protection system
and devices in proper operating
condition. Contact the installing con-
tractor or product manufacturer with
any questions.
Sprinkler
Identification
Number (SIN)
TY7158
Technical
Data
Approvals
Maximum Working Pressure
175 psi (12,1 bar)
Pipe Thread Connection
3/4 in. NPT
Minimum Spacing
6 ft (1,83 m)
Discharge Coefficient
K=16.8 GPM/psi½(241,9 LPM/bar½)
Temperature Ratings
155°F (68°C)
200°F (93°C)*
286°F (141°C)*
* Fire testing of the TYCO Model TY7158 Sprinkler was
completed only in the 155°F (68°C) temperature rating.
The results of such re testing is outlined in UL test re-
port number NC27954.
Finish
Natural Brass
Physical Characteristics
Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Brass
Deflector ............... Commercial Bronze
Compression Screw . . . . . . . . . . . . . . . . . .Brass
Bulb (5 mm). . . . . . . . . . . . . . . . . . . . . . . . . Glass
Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Brass
Sealing Assembly ..Beryllium Nickel w/TEFLON
Operation
When the glass bulb reaches its rated
temperature of 155°F (68°C), 200°F
(93°C), or 286°F (141°C) the glass bulb
bursts allowing the sprinkler to activate
and flow water.
Installation
Install the TYCO Model TY7158 Stan-
dard Coverage Upright Sprinkler in
accordance with this section.
General Instructions
Do not install any bulb type sprinkler
if the bulb is cracked or there is a loss
of liquid from the bulb. With the sprin-
kler held horizontal, a small air bubble
should be present. For the Model
TFP336
Page 2 of 2
NATIONAL FIRE PROTECTION ASSOCIATION is a registered trademark of National Fire Protection Association;
TEFLON is a registered trademark of DuPont
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone +1-215-362-0700
© 2018 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
TY7158 Sprinkler, the diameter of the
air bubble is approximately 1/16 in.
(1,6 mm).
A leak tight 3/4 in. NPT sprinkler joint
should be obtained by applying a min-
imum-to-maximum torque or 10 to 20
lb-ft (13,4 to 26,8 N·m). Higher levels
of torque may distort the sprinkler inlet
with consequent leakage or impair-
ment of the sprinkler. Only the W-Type
8 Sprinkler Wrench (Ref. Figure 2) shall
be used during installation.
Sprinkler Installation
Install the Model TY7158 Upright Sprin-
kler only in the upright position as
follows:
Step 1. Apply pipe-thread sealant to
sprinkler threads.
Step 2. Hand-tighten sprinkler into
sprinkler fitting. Do not apply force to
glass bulb, grasp only by wrench flats
while hand-tightening.
Step 3. Wrench tighten the Model
TY7158 sprinkler 1-1/4 to 1-1/2 turns
beyond hand-tightening or by applying
a minimum-to-maximum torque of 10
to 20 lb-ft (13,4 to 26,8 N·m) by fully
engaging (seating) the wrench on the
sprinkler flats (Ref. Figure 1) using only
the W-Type 8 Sprinkler Wrench (Ref.
Figure 2).
NOTICE
Higher levels of torque may distort
sprinkler inlet with consequent leakage
or impairment of sprinkler.
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
When placing an order, indicate the full
product description and Part Number
(P/N).
Sprinkler Assembly
Specify: Model TY7158 Standard Cov-
erage Upright Sprinkler, SIN TY7158,
temperature rating (specify), P/N
(specify):
155°F (68°C) ................ 51-901-1-155
200°F (93°C)* . . . . . . . . . . . . . . . 51-901-1-200
286°F (141°C)* . . . . . . . . . . . . . . . 51-901-1-286
* Fire testing of the TYCO Model TY7158 Sprinkler was
completed only in the 155°F (68°C) temperature rating.
The results of such re testing is outlined in UL Test Re-
port Number NC27954.
Sprinkler Wrench
Specify: W-Type 8 Sprinkler Wrench,
P/N 56-892-1-001
Care and
Maintenance
The TYCO Model TY7158 Standard
Coverage Upright Sprinkler must be
maintained and serviced in accordance
with this section.
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system
that it controls, obtain permission to
shut down the affected fire protection
system from the proper authorities
and notify all personnel who may be
affected by this decision.
Inspection, testing, and maintenance
must be performed as indicated below
and in accordance with the local
requirements and/or national codes.
Any impairment must be immediately
corrected.
The owner is responsible for the
inspection, testing, and maintenance of
their fire protection system and devices
in compliance with this document, as
well as with the applicable standards
of any authorities having jurisdiction.
Contact the installing contractor or
product manufacturer regarding any
questions.
Automatic sprinkler systems are rec-
ommended to be inspected, tested,
and maintained by a qualified Inspec-
tion Service in accordance with local
requirements and/or national codes.
2-3/8"
(60,3 mm)
WRENCH
FLAT
1/2"
(12,7 mm)
NOMINAL
MAKE-IN
3/4"
NPT
Compression
1
3
2
6
5
4
Button
Frame
2-
-
1 3
Deector
Bulb
Assembly
-Sealing
-
5
-
4
Screw
-
6
WRENCH
RECESS
FIGURE 1
MODEL TY7158 STANDARD COVERAGE,
UPRIGHT STORAGE SPRINKLER, 16.8 K-FACTOR
FIGURE 2
W-T YPE 8
SPRINKLER WRENCH
