Digi DI-80 User manual

- 1 -
DI-80 USER MANUAL
DI - 80 / 80SS User Manual
Issue Date Software Version
01 April 2002
V1.27
TERAOKA WEIGH-SYSTEM PTE LTD
3A, Tuas Avenue 8
Singapore 639218
TEL: [phone]
FAX: [phone]
URL: www.teraoka.com.sg

- 2 -
DI-80 USER MANUAL
CONTENT
1. REGISTRATION MODE
1.1 DISPLAY UNIT INDICATORS ........................................................................................................4
1.2 KEY SHEET LAYOUT AND KEYS FUNCTION ..........................................................................5
1.2.1 DI-80 and DI-80SS Key Sheet Layout.........................................................................................5
1.2.2 Keys Functions...............................................................................................................................6
1. 3 REGISTRATION MODE DESCRIPTION.....................................................................................8
1.3.1 Weight Mode..................................................................................................................................8
1.3.2 Counting Mode Type 1..................................................................................................................8
1.3.3 Counting Mode Type 2..................................................................................................................8
1.4 SEGMENT CHECK & STAND-BY-STATUS.................................................................................9
1.5 TARE OPERATION.........................................................................................................................10
1.5.1 Tare Setting At Registration Mode............................................................................................10
1.5.2 Tare Value Exchange..................................................................................................................12
1.5.3 Tare Override..............................................................................................................................15
1.6 NET/GROSS OPERATION............................................................................................................. 16
1.7 PLU CALL UP...................................................................................................................................17
1.7.1 Call Up PLU by Digits Numeric Number..................................................................................17
1.7.2 Call Up PLU by Teraoka Code / ASCII Code..........................................................................18
1.8 SET NEW ITEM CODE IN REGISTRATION MODE................................................................ 19
1.9 MANUAL PRINT..............................................................................................................................20
1.9.1 Weighing Mode............................................................................................................................20
1.9.2 Counting Mode............................................................................................................................ 21
1.10 ACCUMULATION AND SUBTRACTION ................................................................................. 22
1.10.1 Single Item Transaction............................................................................................................ 22
1.10.2 Multiple Items Transaction......................................................................................................26
1.11 SWITCHING PLATFORM ...........................................................................................................32
1.12 UNIT WEIGHT OPERATION......................................................................................................34
1.12.1 Unit Weight Setting in Registration Mode..............................................................................34
1.12.2 Clearing Unit Weight................................................................................................................36
1.12.3 Re-computing Unit Weight in Memory...................................................................................37
1.13 GENERAL SET POINT SETTING...............................................................................................38
1.14 CHECKER OUTPUT .....................................................................................................................39
1.14.1 Weighing Mode..........................................................................................................................39
1.14.2 Counting Mode.......................................................................................................................... 40

- 3 -
DI-80 USER MANUAL
1.15 HOLDING FUNCTION..................................................................................................................41
1.15.1 Weighing Mode..........................................................................................................................41
1.15.2 Counting Mode.......................................................................................................................... 42
1.16 INVENTORY OPERATION..........................................................................................................43
1.16.1 Manual Transaction.................................................................................................................. 43
1.16.2 Total Transaction...................................................................................................................... 44
1.17 WEIGHT UNIT SWITCHING...................................................................................................... 46

- 4 -
DI-80 USER MANUAL
1. REGISTRATION MODE
1.1 DISPLAY UNIT INDICATORS
1) Zero lamp : Lights when scale is at the ZERO point.
2) Gross lamp : Light when Main Display is showing Gross Weight.
3) Tare lamp : Light when tare subtraction is performed.
4) Net lamp : Light when Main Display is showing Net Weight.
5) Weight Stable lamp : Light when weight is stable.
6) Battery Low lamp : Light when Battery Voltage runs low.
7) Pcs lamp : Light when Main Display is showing Quantity.
8) kg lamp : Light when Main Display is showing Weight in kg.
9) lb lamp : Light when Main Display is showing Weight in lb.
10) g lamp : Light when Main Display is showing Weight in g.
11) oz lamp : Light when Main Display is showing Weight in oz.
12) dwt lamp : Light when Main Display is showing Weight in dwt.
13) MAIN DISPLAY : To display Weight or Quantity. (Depending on the Mode of operation)
14) SUB-1 DISPLAY : Display Total Weight, Unit Weight, Set Point Data or PLU Name.
15) SUB-2 DISPLAY : Display Unit Weight, Quantity, Set Point Data or PLU Name.
16) CHECKER LAMPS : Light when Set Point in used.
17) L1: Total Weight lamp : Light when SUB-1 DISPLAY showing Unit Weight.
18) L2: Insufficient lamp : Light when Net weight is below a specific percentage of the capacity weight.
19) L3: Re-computing lamp : Light when Unit Weight re-computing is possible.
20) L4: IN lamp : Light when Inventory IN (For Counting Mode)
21) L5: OUT lamp : Light when Inventory OUT (For Counting Mode)
22) L6: Unit Weight lamp : Light when SUB-1 DISPLAY is showing Unit Weight.
23) L7: Hold lamp : Light when Holding function is enables.
24) L8: Unit Weight lamp : Light when SUB-2 DISPLAY is showing Unit Weight.
25) L9: Memory lamp : Light when Weight or Quantity accumulation is done.
26) L10: Programming lamp : Light when User in Programming Mode.
27) L11: Scale - 1 lamp : Light when Scale - 1 is selected.
28) L12: Scale - 2 lamp : Light when Scale - 2 is selected.
29) L13: Quantity lamp : Light when SUB-2 DISPLAY is showing Quantity.

- 5 -
DI-80 USER MANUAL
1.2 KEY SHEET LAYOUT AND KEYS FUNCTION
1.2.1 DI-80 and DI-80SS Key Sheet Layout
DI-80 Key Sheet Layout
DI - 80SS Key Sheet Layout

- 6 -
DI-80 USER MANUAL
1.2.2 Keys Functions
ON / OFF KEY (DISPLAY)
Turn display ON or OFF.
NUMERIC KEY
to
Enter numeric value.
MODE KEY
To switching between Weight Mode and Counting Mode.
TARE KEY
To setting or clearing tare weight.
CLEAR KEY
To clear numeric data or PLU Data.
Exit from Add. Mode.
Escape from General Set-Point programming mode.
RE-ZERO KEY
Reset Weight display to zero.
PCS KEY
To computing unit weight by sampling.
SCALE KEY
To switching between Scale 1 & 2.
UNIT WEIGHT KEY
To enter Unit Weight.
Up date re-computing Unit Weight or Tare weight to PLU file.
PLUS KEY
Accumulate the Total Weight or Quantity.
To issue receipt (Build-in Printer) or sending data to PC or Barcode printer.
MINUS KEY
To void the Total Weight or Quantity.
To issue receipt (Build-in Printer) or sending data to PC or Barcode printer.
PRINT KEY
To issue receipt (Build-in Printer) or sending data to PC or Barcode printer.

- 7 -
DI-80 USER MANUAL
CODE KEY
Call up PLU data.
To select Inventory IN or OUT for individual item in Counting Mode.
NET/GROSS KEY
To switching between NET and GROSS display.
To view the Inventory of the individual item.
DOT KEY
To enter Decimal point.
To entry Teraoka or ASCII code for call up PLU data.
SET POINT KEY
To program or view General Set point data.
To change or view individual PLU Set point data.
FEED KEY
Feed receipt paper (For Build-in Printer)
HOLD KEY
To enable or disable Holding function.
UNIT SWITCHING KEY
To switching Weight Unit between kg & lb or oz, g & dwt.

- 8 -
DI-80 USER MANUAL
1. 3 REGISTRATION MODE DESCRIPTION
DI-80 / DI-80SS has two modes (Weight Mode and Counting Mode) can be switched alternatively by pressing [MODE] key on
keypad and there are two type of Counting Mode will depending on SPEC 00 bit 3 setting.
1.3.1 Weight Mode
When DI-80 is powered up, it will go to Weight Mode, where the Main Display show the Weight and the Sub- Display will
showing Set point 1 & Set point 2 or PLU Name is depending on SPEC 00 bit 0 setting.
Weight Mode
1.3.2 Counting Mode Type 1
Main Display showing the Total Weight and Sub-Display will show the Unit Weight and Quantity (SPEC 00 bit set to "0").
Counting Mode - Type 1
1.3.3 Counting Mode Type 2
Main Display showing the Quantity and Sub-Display will show Weight and Unit Weight (SPEC 00 bit set to "1").
Counting Mode - Type 2

- 9 -
DI-80 USER MANUAL
1.4 SEGMENT CHECK & STAND-BY-STATUS
OPERATION KEY DISPLAY
di 80SS
V E R S I O N 1 . 2 7
1. Connect to AC plug supply
and check if anything is on
the platforms. If so, remove
the item and then press
[ON/OFF] to start segment
check.
The Model (di 80SS or di
80) and Software Version
Number will appear on the
LCD.
¼0»
NET
kg
0. 0 0 0
TT
2. After finish segment check,
scale on Stand - By - Status
of Weighing Mode.
Err
S T A R T U P E R R
Note 1: If there is anything on the Platforms and it exceeds
scale start range, following error message will
appear:

- 10 -
DI-80 USER MANUAL
1.5 TARE OPERATION
1.5.1 Tare Setting At Registration Mode
There are two ways to set Tare Weight in Weighing Mode or Counting Mode, One Touch Tare and Digital Tare setting. The
limit of Tare Weight is depending on SPEC 27 bit 1 & bit 0 setting. The following operation examples show two ways of
subtracting the Tare Weight of a 20g tray.
1.5.1.1 One Touch Tare
This function is to weight the actual weight of the tare then subtract its weight to get the tare value for all of PLU's.
OPERATION KEY DISPLAY
¼0»
NET kg
0. 0 0 0
TT
Stand-by-Status
(Weighing Mode)
NET
kg
0. 0 2 0
T
1. Place a tare weight on the
platform (Ex. 20g)
¼T»NET
kg
0. 0 0 0
TT
2. Press [T] key to subtract the
tare weight.
¼0»
¼T»NET
kg
- 0. 0 2 0
TT
3. Remove the tare weight (Ex.
20g) from platform.
¼0»
NET
kg
0. 0 0 0
TT
4. Press [T] key to clear the tare
weight.
Note 1: After One Touch Tare and called up a PLU, if tare value is set in PLU File in advance, the PLU Tare value will override
the One Touch Tare value, if not, the One Touch Tare value will remain for the PLU.

- 11 -
DI-80 USER MANUAL
1.5.1.2 Digital Tare
This function can be used when tare weight is decided in advance. The knowing tare value can be entering by numeric keys.
Note: To enable this function, SPEC 27 bit 2 must set to "1" in advance.
OPERATION KEY DISPLAY
0.020
TT
1. At Weighing Mode, enter the
tare weight by numeric key
(Ex. 20g)
¼0»
¼T»NET
kg
- 0. 0 2 0
TT
2. Press [T] key to subtract the
tare weight.
¼0»
NET
kg
0. 0 0 0
T T
3. Press [T] key to clear the tare
weight.
Note 1: After set Digital Tare and then called up a PLU, if tare value is set in PLU File in advance, the PLU Tare value will
override the Digital tare value, if not, the Digital Tare value will remain for the PLU.
Note 2: If you want Digital Tare when Weight loaded on platter, SPEC 38 bit 2 must set to "0" in advance. If not, set to "1".

- 12 -
DI-80 USER MANUAL
1.5.2 Tare Value Exchange
There are two ways to subtract tare weight exchange in Weighing Mode and Counting Mode, Tare Accumulation and Tare
Subtraction. To enable this function, SPEC 29 bit 1 and bit 0must set to "0" in advance.
1.5.2.1 One Touch Tare
OPERATION KEY DISPLAY
NET
kg
0. 0 2 0
T
1. At Weighing Mode, place a
tare weight on the platform
(Ex. 20g)
¼T»NET
kg
0. 0 0 0
TT
2. Press [T] key to subtract the
tare weight.
¼T»NET
kg
0. 0 5 0
T
3. Place another tare weight on
the platform (Ex. 50g)
¼T»NET
kg
0. 0 0 0
TT
4. Press [T] key to subtract the
tare weight again (Tare
Accumulation).
¼T»NET
kg
- 0. 0 2 0
TT
5. Remove 20g from the
platform.

- 13 -
DI-80 USER MANUAL
OPERATION KEY DISPLAY
¼T»NET
kg
0. 0 0 0
TT
6. Press [T] key to subtract the
tare weight (Tare
Subtraction).
¼0»
NET
kg
0. 0 0 0
TT
7. Remove 50g form platform
and press [T] key to clear the
Tare value.
1.5.2.2 Digital Tare
Note: To enable this function, SPEC 27 bit 2 must set to "1" in advance.
OPERATION KEY DISPLAY
0.020
T
1. At Weighing Mode, enter
tare weight by numeric key
(Ex. 20g).
¼0»
¼T»NET
kg
- 0. 0 2 0
TT
2. Press [T] key to subtract the
tare weight.
0.050
T
3. Enter the tare weight by
numeric key (Ex. 50g).

- 14 -
DI-80 USER MANUAL
OPERATION KEY DISPLAY
¼0»
¼T»NET
kg
- 0. 0 5 0
TT
4. Press [T] key to subtract the
tare weight (Tare
Accumulation).
Total tare value will change
from 20g to 50g.
0.030
T
5. Enter tare value by numeric
key (Ex. 30g).
¼0»
¼T»NET
kg
- 0. 0 3 0
TT
6. Press [T] key to subtract the
tare weight (Tare
Subtraction).
Total tare value will change
from 50g to 30g.
¼0»
NET
kg
0. 0 0 0
TT
7. Press [T] key to clear the
Tare value.

- 15 -
DI-80 USER MANUAL
1.5.3 Tare Override
This function is to change the tare value or set a new tare when PLU is called up in Weighing Mode and Counting Mode.
For example: Call up PLU in WEIGHING MODE.
OPERATION KEY DISPLAY
¼0»
NET
kg
0. 0 0 0
S T E A T I T E - C 3 H 5
T
1. At Weighing Mode, call up
PLU by enters the PLU
Number (Ex. 123) and press
[PLU] key.
If tare value is set in PLU
File in advance, the tare weight
will be displayed on Main
Display.
NET
kg
0. 0 5 0
S T E A T I T E - C 3 H 5
T
2. Place a tare weight on the
platter (Ex. 50g).
If you knowing the tare value,
enter the tare value by numeric
key and press [T] key.
¼T»NET
kg
0. 0 0 0
S T E A T I T E - C 3 H 5
T
3. Press [T] key to subtract the
tare weight.
If you want the tare value
update to the PLU File, after
tare subtracted press [UNIT
WEIGHT] key to save the new
tare value to the PLU File.
¼T»NET
kg
20.000
S T E A T I T E - C 3 H 5
TT
4. Place the product on the
platter (Ex. 20kg)
¼T»NET
kg
20.000
S T E A T I T E - C 3 H 5
TT
5. Press [¾]key to issue a
receipt or label.
Print Tare value on receipt
(Build-in Printer) can be select
at SPEC 14 bit 2.

- 16 -
DI-80 USER MANUAL
1.6 NET/GROSS OPERATION
Gross weight displays are available in both Weighing Mode and Counting Mode. In Weighing Mode, allow user use numeric key
and [PRINT] key to perform printing operation. PLU are not allowed to call up in Gross Mode, but allow call up in NET mode
and then switch to Gross Mode. In Counting Mode, This key is used to view the Gross Weight for the item only and all numeric
keys and [PRINT] key are disabled.
Note: To enable this operation, SPEC 25 bit 0 must set to "0" in advance.
OPERATION KEY DISPLAY
NET
kg
0. 5 0 0
T
1. At Weighing Mode, place
500g of weight on the platter.
¼T»NET
kg
0. 0 0 0
T
2. Press [T] key to subtract the
tare weight.
¼T»NET
kg
0. 5 0 0
T
3. Place another 500g of weight
on the platter.
B/G
¼T»NET
kg
1. 0 0 0
TT
4. Press [NET/ B/G] key to
enter GROSS Mode.
Press [¾]key if you want to
issue a receipt or press [+] / [-]
key for Accumulation /
Subtraction operation.
¼T»NET
kg
0. 5 0 0
T
5. Back to NET Mode, press
[NET/ B/G] key again.

- 17 -
DI-80 USER MANUAL
1.7 PLU CALL UP
There are two different type of PLU Code, Digits Numeric Number and Teraoka Code / ASCII Code to call up the programmed
PLUs in Weighing Mode or Counting Mode.
¾By press the [PLU] key after entering desired Digits Numeric Number of the PLU Code.
¾By press the [.] key to entry Teraoka or ASCII Code mode to enter Teraoka Code / ASCII Code of the PLU Code.
Note: The machines beeps and following error message "PLU NOT FOUND" appear on the display if enter not existing PLU
Number. Press [C] key to clear the message and then check the PLU Number and try again.
1.7.1 Call Up PLU by Digits Numeric Number
For example: Call up PLU in WEIGHING MODE.
OPERATION KEY DISPLAY
123
T
1. At Weighing Mode, enter the
existing PLU Number by
numeric key (Ex. 123).
¼0»
NET
kg
0. 0 0 0
S T E A T I T E - C 3 H 5
T
2. Press [PLU] key (The PLU
data will appear on the
display).
Insufficient indicator will
light up if Unit Weight for the
Item is set to 0.
Refer to Note 1.
¼0»
NET
kg
0. 0 0 0
TT
3. Press [C] key to clear the
PLU and display return to
Weighing Mode.
¼0»
NET
kg
0. 0 0 0
1. 000> <2. 000
T
Note 1: If the PLU with Individual PLU Set-Point setting
and SPEC 00 bit 0 is set to "1" and SPEC 07:
SET POINT TYPE (bit 1 & 0) must set to %
WEIGHT or WEIGHT, after display the
Commodity Name for a second, the Set Point data
will appear on Sub-Displays.

- 18 -
DI-80 USER MANUAL
1.7.2 Call Up PLU by Teraoka Code / ASCII Code
For example: Call up PLU in Counting Mode.
OPERATION KEY DISPLAY
¼0»
NET
kg
A00 00

T
TPcs
1. At Counting Mode, press [.]
key to enter ASCII Code
entry mode.
Using ASCII Code or
Teraoka Code is depending on
SPEC 14 bit 3 setting, 0:
Teraoka Code &1: ASCII
Code.
¼T»NET
kg
A03 00
A 1 2 
T
TPcs
2. Enter PLU Code by ASCII
Code (Ex. A12).
Manual or Auto Shift to next
position after enters ASCII
Code or Teraoka Code is
depending on SPEC 06 bit 0
setting.
Refer to Note 1.
¼0»
NET
kg
0. 0 0 0
2.0000 0
TPcs
3. Press [PLU] key (The PLU
data will appear on the
display).
The Commodity Name will
appear for a second on Sub-
Display column.
¼0»
NET
kg
0. 0 0 0
0 0
T
TPcs
4. Press [C] key to clear the
PLU and display return to
Counting Mode.
Note 1: Press [+] key to next position and [-] key back to previous position.

- 19 -
DI-80 USER MANUAL
1.8 SET NEW ITEM CODE IN REGISTRATION MODE
This function is used to program a New PLU Code in Registration Mode (Weighing Mode or Counting Mode) and update to
PLU Files. To enable this function, SPEC 04 bit 3 must set to "0" in advance.
For example: Set New PLU Code 246 in Counting Mode.
OPERATION KEY DISPLAY
246
T
1. At Counting Mode, enter
new PLU Code (Ex. 246) by
numeric key.
P L U N O T F O U N D
2. Press [PLU] key
The machine beeps and
following message will appears.
If you don't want the error
buzzer sound and error message
appear, SPEC 19 bit 3 must set
to "1" in advance.
¼0»
NET
kg
0. 0 0 0
0 0
T
TPcs
3. Press [PLU] key to store the
New PLU Code in PLU
Files.
¼0»
NET
kg
0. 0 0 0
2.0000 0
TPcs
4. Enter Unit Weight by
numeric key (Ex. 2.0000) and
press [UNIT WEIGHT] key.
Insufficient indicator OFF
after set the Unit Weight.
¼0»
NET
kg
0. 0 0 0
2.0000 0
TPcs
5. Update new Unit Weight to
the PLU 246, press [UNIT
WEIGHT] key.
The display will show -----
and back to previous display.
Note 1: If you don't want the new PLU Code update to PLU Files but for temporally printing, SPEC 04 bit 3 must set to "1" in
advance or at step 2, press [C] key to cancel.
Note 2: If you want set new Tare value and update to PLU, after set the tare value and then press [UNIT WEIGHT] key to
store.

- 20 -
DI-80 USER MANUAL
1.9 MANUAL PRINT
This section explains about the operation for single transaction and issues a receipt or label in Weighing Mode and Counting
Mode.
1.9.1 Weighing Mode
There has to ways for Single transaction to issue receipt (Build-in Printer) or label (Barcode Printer) in Weighing Mode, by place
the product on the platter or by enter the knowing weight of the product.
OPERATION KEY DISPLAY
¼0»
NET
kg
0. 0 0 0
S T E A T I T E - C 3 H 5
T
1. At Weighing Mode, enter the
existing PLU Number by
numeric key (Ex. 123) and
press [PLU] key.
NET
kg
5. 5 0 0
S T E A T I T E - C 3 H 5
TT
2. Place the product on the
platter (Ex. 5. 5kg).
NET
kg
5. 5 0 0
S T E A T I T E - C 3 H 5
TT
3. Press [¾]key to issue a
receipt.
Build-in Printer will start
printing and label also be issue
if machine connect to Barcode
Printer.
Press [¾]key again will
issue another receipt or label
without removing weight from
platter.
55.000
T
4. Enter the knowing weight of
the product by numeric key
(Ex. 55kg).
Maximum 6 digits and one
decimal point can be entering
(The decimal point position
must same as the Decimal Point
position of the Scale).
NET
kg
5. 5 0 0
S T E A T I T E - C 3 H 5
TT
5. Press [¾]key to issue a
receipt.
After complete issuing
receipt, remove the product
from the platter and press [C]
key to clear the PLU.
