Digi DC-400 User manual

DC-400
Operation Manual
Edition Month Year
1st May 2018
Shanghai Teraoka Electronic Co., Ltd.
2C-5F Shanghai Tianhua Information Technology Park
No.299, Long Cao Road, Xu Hui District Shanghai China, 200235
Tel: [phone]
Fax: [phone]

1. General Information .......................................................................................................... 1
1.1. General Layout ................................................................................................................................ 1
1.1.1. 500g/5kg Capacity ............................................................................................................................... 1
1.1.2. 2.5kg/25kg Capacity ............................................................................................................................ 2
1.2. Features ........................................................................................................................................... 3
1.3. Operating Conditions ...................................................................................................................... 3
1.4. Dimensions...................................................................................................................................... 3
1.4.1. 500g/5kg Capacity ............................................................................................................................... 3
1.4.2. 2.5kg/25kg Capacity ............................................................................................................................ 3
1.5. Display and Indicators .................................................................................................................... 4
1.5.1. Display Specifications ......................................................................................................................... 4
1.5.2. Indicators ............................................................................................................................................. 4
1.6. Key .................................................................................................................................................. 4
1.6.1. Key Sheet Layout ................................................................................................................................ 4
1.6.2. Key Functions ..................................................................................................................................... 5
2. Setup .................................................................................................................................. 6
2.1. Mode Change .................................................................................................................................. 6
2.2. Specification Setting ....................................................................................................................... 7
2.2.1. Specification Entry (141) .................................................................................................................... 7
2.2.2. Specification List ................................................................................................................................. 8
2.3. Password Setting ........................................................................................................................... 18
2.3.1. Procedures of Password Setting ........................................................................................................ 18
2.3.2. Password Using ................................................................................................................................. 19
2.4. Clear Files ..................................................................................................................................... 19
3. Program Mode ................................................................................................................. 20
3.1. Programmable Files ...................................................................................................................... 20
3.2. Programming Mode Entry ............................................................................................................ 20
3.3. PLU FILE ...................................................................................................................................... 21
3.3.1. Program Item File .............................................................................................................................. 21
3.3.2. Delete Item Code ............................................................................................................................... 23
3.3.3. Label Format List .............................................................................................................................. 24
3.4. FACTORY NAME FILE .............................................................................................................. 25
3.4.1. Program Factory Name File .............................................................................................................. 25
3.4.2. Print Factory Name File .................................................................................................................... 25
3.4.3. Delete Factory Name File.................................................................................................................. 26
3.5. PROGRAM DATE AND TIME ................................................................................................... 26
3.6. ADDRESS FILE ........................................................................................................................... 27
3.6.1. Program Address File ........................................................................................................................ 27
3.6.2. Print Address File .............................................................................................................................. 27
3.6.3. Delete Address File ........................................................................................................................... 28
3.7. TEXT FILE ................................................................................................................................... 29
3.7.1. Program Text File .............................................................................................................................. 29
3.7.2. Print Text File .................................................................................................................................... 29
3.7.3. Delete Text File ................................................................................................................................. 30
3.8. FREE FORMAT FILE .................................................................................................................. 30
3.8.1. General Information .......................................................................................................................... 30
3.8.2 Print Area, Print Position and Print Angles ........................................................................................ 31
3.8.3 Programming Parameter of Print Items .............................................................................................. 33
3.8.4 Free Format Entry .............................................................................................................................. 35
3.8.5 Free Format Copy Function ............................................................................................................... 41
3.8.6 Free Format Delete Function .............................................................................................................. 41
3.8.7 Sample of program a format by modifying the existing format ......................................................... 42
3.9 Logo File ........................................................................................................................................ 44

3.9.1 Pre-programming Logo Data .............................................................................................................. 44
3.9.2 Program Display & Keys Function .................................................................................................... 45
3.9.3 Programming Order ............................................................................................................................ 46
3.9.4 Program Logo File ............................................................................................................................. 46
3.9.5 Delete Logo File ................................................................................................................................. 47
3.10 Memory Status ............................................................................................................................. 47
3.11 Program Multi-barcode File ......................................................................................................... 48
3.11.1. Program Multi-barcode File ............................................................................................................ 48
3.11.2. Delete Multi-barcode File ............................................................................................................... 48
3.12. 2D BARCODE TEXT FILE ....................................................................................................... 49
3.12.1. Program 2D Barcode Text File ....................................................................................................... 49
3.12.3. Delete 2D Barcode Text File ........................................................................................................... 49
4. REGISTRATION MODE ............................................................................................... 50
4.1 ON/OFF ......................................................................................................................................... 50
4.2 Reset and Weighing Check ............................................................................................................ 50
4.3 Tare Subtraction ............................................................................................................................. 50
4.3.1 One touch Tare Subtraction ................................................................................................................ 50
4.3.2 Digital tare Subtraction ...................................................................................................................... 51
4.4 Item Call Up ................................................................................................................................... 51
4.5 Set New Item Code in Registration Mode ..................................................................................... 51
4.6 Manual Print ................................................................................................................................... 52
4.6.1 Item Label Printing ............................................................................................................................. 52
4.6.2 Total Label Printing ........................................................................................................................... 52
4.7 Accumulation and Subtraction ....................................................................................................... 53
4.8 Unit Weight Operation ................................................................................................................... 54
4.8.1 Unit Weight Setting in Operation Mode ............................................................................................ 54
4.8.2 Re-computing Unit Weight in Memory ............................................................................................. 55
4.9 Inventory Operation ....................................................................................................................... 56
4.9.1 Manual Transaction ............................................................................................................................ 56
4.9.2 Total Transaction ................................................................................................................................ 57
4.10 Function key ................................................................................................................................. 58
4.10.1 Net/Gross Key .................................................................................................................................. 58
4.10.2 Switch Platform Key ........................................................................................................................ 58
4.10.3 Switch Weight Unit Key .................................................................................................................. 59
4.10.4 View Item Key ................................................................................................................................. 59
4.10.5 Address No Key ............................................................................................................................... 60
4.10.6 Lot No Key ....................................................................................................................................... 61
4.10.7 Sequence No. Key ............................................................................................................................ 61
5. Report Mode .................................................................................................................... 62
5.1. Report Type Selection ................................................................................................................... 62
5.2. Report Mode Entry........................................................................................................................ 62
5.3. Item Report ................................................................................................................................... 62
5.3.1 One Item Print .................................................................................................................................... 62
5.4. Inventory Report ........................................................................................................................... 64
5.4.1 Print Threshold Report ....................................................................................................................... 64
5.4.2 Print In / Out Count Report ................................................................................................................ 64
5.4.3 Clear In / Out Count Report ............................................................................................................... 65
5.5. SHELF LOCATION PRINT ........................................................................................................ 65

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 1 of 65
1. General Information
1.1. General Layout
1.1.1. 500g/5kg Capacity

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 2 of 65
1.1.2. 2.5kg/25kg Capacity

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 3 of 65
1.2. Features
 Digital printing scale consists of counting function and label printing function.
 High-speed, high reliability thermal head printer, the Max. printing width is 60mm, the Max. printing speed
is 110mm/sec.
 Easy paper handing achieved special designed mechanism.
 Built-in clock automatically updates date and time.
 Quick response to weight changes.
 Capacity : 500g/5kg, 2.5kg/25kg.
 High Resolution : Display Resolution 1/50,000, 4-interval.
: Internal Resolution 1/1,000,000.
 Remote platform connector support 4 x load cells 350 Ohm.
 202 x 32 pixels FSTN type LCD with back-light.
 Touch Panel Integrated.
 55 switch keys
a. ON/OFF key.
b. 10 Numeric keys, to key in numeric data.
c. 26 character keys, to key in characters.
d. 18 Operational keys, to perform various functional operations.
 Ethernet function.
 RS232C I/F for data communication and barcode scanner connection.
 PS/2 I/F for IBM keyboard
1.3. Operating Conditions
 Power Source : AC 176V ~ 264V, 47~63Hz.
 Operating Temperature : -10 C ~ +40 C.
 Operating Humidity : 15% ~ 85% RH.
 Power Consumption : 0.5A.
1.4. Dimensions
1.4.1. 500g/5kg Capacity
 Platter size : 215(W) x 162(D) mm.
 Overall size : 360(W) x 465(D) x 159(H) mm.
1.4.2. 2.5kg/25kg Capacity
 Platter size : 290(W) x 215(D) mm.
 Overall size : 360(W) x 465(D) x 162(H) mm.

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 4 of 65
1.5. Display and Indicators
DC-400
per
1000pcs
12
1.5.1. Display Specifications
 Weight display : 6 digits.
 Unit Weight display : 7 digits.
 Quantity : 8 digits.
 Second Line display : 25 characters.
1.5.2. Indicators
 ZERO : On when zero point is adjusted and weight is stable.
 NET : On when tare subtraction is performed.
 SCALE-1 : On when Scale 1(Built-in Platform) is selected.
 SCALE-2 : On when Scale 2(Remote Platform) is selected.
 RECOM : On when Unit Weight re-computing is possible.
 INSUFF : On when Net weight is below a specific percentage of the capacity weight.
 LABEL : On when label printing mode is chosen.
 ∑ : On when Quantity accumulation is done.
 IN : On when Inventory IN (For Counting Mode)
 OUT : On when Inventory OUT (For Counting Mode)
 X : On when in Report mode.
 S : On when in Programming mode.
 Z : On when in Service mode.
1.6. Key
1.6.1. Key Sheet Layout
OFF
LOT
NO
SHIFT
UP
SHIFT
DOWN SCALE
！#$%&"()
+
;
*/
-
@
′
.

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 5 of 65
1.6.2. Key Functions
 : ON/OFF key. Turn display on or off.
 : Print key. Issue label or receipt at R mode / Print out report at X mode / To enter
item programmed mode.
 PIECES : PCS key. To computing unit weight by sampling / Escape the Programming screen without
saving data in X and S mode
 UNIT WEIGHT: UNIT WEIGHT key. To set Unit Weight in Registration mode.
 : MODE SET key. To switch into control modes.
 CODE : CODE key. Call up PLU data in Registration mode / Store the programmed data in S mode.
 : Feed key. To feed paper.
 + : PLUS key.
Accumulate the Total Quantity / Select programming item such as Item Code,
Factory Name in S mode / Select Report Type in X Mode.
 - : MINUS key. Correct the sales data / Select programming item such as Item Code,
Factory Name in S mode / Select Report Type in X mode.
 CLEAR : CLEAR key. Clear Alphanumeric Data / Select "YES" in S, X and Z mode.
 : RE-ZERO key. Reset weight display to zero.
 : TARE key. Set or clear tare values / Select "NO" in S, X and Z mode / Item test print in S mode.
 0 ~ 9 : Numeric keys. Input numerical value.
 . : DOT key. To enter Decimal point.
 A to Z : Character keys. To view the Preset data such as ID CODE, PART NAME in R mode / Enter Alphabetic
data in R mode (ID CODE) and S mode.
 SCALE : SCALE key. To switch between scale1 and scale2
 LOT NO : LOT NO key. To view the Lot Number or to program new Lot Number for temporarily printing.
 SHIFT UP : SHIFT UP key. To select Top function or symbol of the desired key for entering.
 SHIFT DOWN : SHIFT DOWN key. SCALE key. To select Bottom function of desired key for entering.
 << : LEFT SHIFT key. To move cursor LEFT.
 >> : RIGHT SHIFT key. To move cursor RIGHT.
 SPACE : SPACE key. To SPACE the entering characters or numbers.
 INSERT : INSERT key. Insert Data..
 DEL : DELETE key. Delete the Data.
 CHAR TYPE : CHARACTER TYPE key. Code type entered.
 LETTER SZ : LETTER SIZE key. Switch Cap or Lower case..
 CHAR SZ : CHARACTER SIZE key. Change Font size.

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 6 of 65
2. Setup
2.1. Mode Change
OPERATION DISPLAY REMARK
WEIGHT UNIT WEIGHT QUANTITY
0.0000kg 0 0 R mode.
[MODE][MODE]
(within 3 seconds)
X1.0 ITEM REPORT Enter X mode. Lamp X turns on.
[MODE] S1 PLU FILE Enter S mode. Lamp S turns on.
[MODE] SERVICE MODE Enter Z mode. Lamp Z turns on.
[MODE] PWD X 0 SET Enter Password Set mode.
[MODE] 0.0000kg 0 0 Return to R mode.

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 7 of 65
2.2. Specification Setting
2.2.1. Specification Entry (141)
OPERATION DISPLAY REMARK
WEIGHT UNIT WEIGHT QUANTITY
SERVICE MODE
Z mode.
Lamp Z turns on.
[Rezero]+[1][4][1] SPEC 000
XXX
(setting)
XXX
(former)
Enter [1][4][1] while depressing [Rezero].
XXX:SPEC data
[+] SPEC 001 XXX XXX [+] key only increase specification count, it
does not update SPEC data.
[－] SPEC 000 XXX XXX [－] key only decrease specification count, it
does not update SPEC data.
[1][7]
[PIECES]
SPEC 000
SPEC 017
017
XXX
XXX
XXX
It goes to a designed specification count.
(000~062 is enabled)
[>>] SPEC 017 XXX XXX
[>>] key select SPEC data.
Move cursor right.
[<<] SPEC 017 XXX XXX
[<<] key select SPEC data.
Move cursor left.
[1]
[*]
SPEC 017
SPEC 018
001
XXX
XXX
XXX
[C] SPEC 018 000 XXX Clear the enter data.
[CODE]
* Note
SERVICE MODE Store the updated specification and escape to
Z mode.
Note: If press [T] key, it does not store the updated specification and escape to Z mode.

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 8 of 65
2.2.2. Specification List
Customer SPEC Setting-(141)
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
00 AUTO POWER SAVING WHEN NO WEIGHT CHANGE & NO KEY
PRESS

0 Inhibit 3 30 Minutes 1. When SPEC1 set to
0, backlight will off and
when SPEC1 set to 1, the
scale will auto power off.
1 3 Minutes 4 1 Hour
2 10 Minutes 5 3 Hours
01 POWER SAVING MODE
0 Back Light Off 1 POWER OFF .
02 NEGATIVE COUNTING 
0No 1Yes
03 EXTENT OF INSUFFICIENT SAMPLES 
00.1% 20.0%
10.2%
04 SET NEW ITEM DURING REGISTRATION MODE 
0 Yes 1 No
05 DATE ORDER 
0 Month / Day / Year 2 Year / Month / Day
1 Day / Month / Year
06 TIME FORMAT 
0 24 Hou
r
1 12 Hour (am / pm)
07 UNIT WEIGHT AUTO RECOMPUTING
0No 1Yes
08 SAMPLING TIMES FOR UNIT WEIGHT CALCULATION 
0 15 Times 1 20 Times
09 DISPLAY ACCURACY UNIT WEIGHT CALCULATION DURING
RECOMPUTING
0No 1Yes
10 SET POINT BUZZER 
0Buzzer On 1Buzzer Of
f
11 CLEAR ALL INPUT KEY IN ONE TOUCH
0Yes 1No
12 KEEP LOT NO IN REGISTRATION MODE 
0
A
llo
w
1Inhibit
13 JOB SEQUENCE
0Disable 1Enable
14 AUTO EXIT FROM ADD MODE 
0No 1Yes

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 9 of 65
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
15 SIO SELECT JOB
0 No Operation 3 PC Connection Please set SPEC29 force
balance to ENABLE when
SPEC26 is set to FORCE
BALANCE.
1
T
rack N Print (TNP) 4 Printer Connection
2 Force Balance (FB) 5 Barcode Scanner
16 RS232C BAUD RATE (SIO) 
0 1200 3 9600
1 2400 4 19200
2 4800 5 38400
17 RS-232C DATA LENGTH (SIO) 
0 7 Bits 1 8 Bits
18 RS-232C PARITY BIT (SIO) 
0 None 2 Even
1 Odd
19 RS-232C STOP BIT (SIO) 
0 1 Bit 1 2 Bits
20 RS232 OPTION CARD WITH 8 PIN DIN2 AND 8 PIN DIN1
CONNECTORS
0 Not Connected 4 PC / Printer Please set SPEC29 force
balance to ENABLE when
connected to FORCE
BALANCE.
1 Printer / Force Balance 5 PC / Force Balance
2 Force Balance / Printer 6 Force Balance / PC
3 Printer / PC
21 RS-232 BAUD RATE FOR 8 PIN DIN1 CONNECTOR (OPTIONAL
CARD)
0 4800 2 19200
1 9600 3 38400
22 RS-232 DATA LENGTH FOR 8 PIN DIN1 CONNECTOR (OPTIONAL
CARD)
0 7 Bits 1 8 Bits
23 RS-232 STOP BIT FOR 8 PIN DIN1 CONNECTOR (OPTIONAL CARD)
0 1 Bit 1 2 Bits
24 RS-232 PARITY BIT FOR 8 PIN DIN1 CONNECTOR (OPTIONAL CARD)
0 None 2 Even
1 Odd
25 RS-232 BAUD RATE FOR 8 PIN DIN2 CONNECTOR (OPTIONAL
CARD)
0 4800 2 19200
1 9600 3 38400
26 RS-232 DATA LENGTH FOR 8 PIN DIN2 CONNECTOR (OPTIONAL
CARD)
0 7 Bits 1 8 Bits
27 RS-232 STOP BIT FOR 8 PIN DIN2 CONNECTOR (OPTIONAL CARD)
0 1 Bit 1 2 Bits

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 10 of 65
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
28 RS-232 PARITY BIT FOR 8-PIN DIN2 CONNECTOR (OPTIONAL
CARD)
0 None 2 Even
1 Odd
29 RS-232 CONNECTION TO FORCE BALANCE (FB)
0 Disable 1 Enable
30 TYPE OF FORCE BALANCE
0 Export 2 SHG-200 (JAPAN)
1 HR-60 (JAPAN) 3 SHG-300 (JAPAN)
31 PC/PRN OUTPUT DATA METHOD
0 No Operation 2 By +/-/Print Key (PC/PRN)
1 Count Condition (PC only) 3 For Both Cases 1 & 2
32 SELECT EXTERNAL PRINTER TYPE
0 ELTRON LP2622/LP2722 OR
TVP1000
2 DP122 (JAPAN)
1 SE250
33 EXTERNAL ELTRON/TVP PRINTER DOWNLOAD LABEL FORMAT
0 Enable 1 Disable
34 PRINT WHEN PRESS +/- KEY
0 Disable 1 Enable
35 PC DATA WITH HEADER
0 Yes 1 No
36 PC DATA HEADER TYPE
0 Code 1 Title
37 BARCODE SCANNER (BCS) CONNECTION 
0 Disable 1 Enable
38 BARCODE SCANNER (BCS) WITH HEADER
0 Yes 1 No
39 TRACK NPRINT (TNP) TIME OUT
0 2 Seconds 2 32 Seconds
1 8 Seconds
40 SELECTION OF TRACK NPRINT (TNP) NETWORK INTERFACE
0 No Interface (RS232) 2 Ethernet - Twisted Cable
1 Ethernet - Coax
i
al Cable
41 PORT NUMBER (IP ADDRESS) 
Range (1 - 254)
42 SET SCALE NUMBER 
Range (0 - 999999)

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 11 of 65
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
43 SELECT RECEIPT OR LABEL PAPER PRINTING
0 Print Receipt Paper 1 Print Label Paper
44 PRINTING SPEED FOR RECEIPT 
0 Slow 2 High
1 Normal
45 PRINTING SPEED FOR LABEL 
0 Slo
w
2High
1 Normal
46 LABEL PRINTING DENSITY 
0 Low 2 Medium High
1 Medium 3 High
47 LABEL TYPE (DC300 only) 
0 Gap 1 No Gap
48 PEEL SENSOR FUNCTION
0 Disable 1 Enable
49 NO OF REPRINT LABELS
0 No Label 2 2 Labels
1 1 Label
50 SELECTION OF LABEL AND RECEIPT PRINTING OPERATION
0 All Operation (In/Out/Non-Add) 3 In & Out (Receiving & Shipping)
1 Out (Shipping Operations) 4 No Printing
2 In (Receiving Operations)
51 HUMAN READABLE BARCODE PRINTING FORMAT
0 No Print 1 Print
52 ITEM DATA (SUCH AS ID CODE, PART NAME, PART NO & LOT NO)
PRINTING FORMAT

0 Centering 1 Start Printing From Left
53 DATE TITLE PRINT 
0 No 1 Yes
54 WEIGHT DATA AND QUANTITY TITLE PRINT
0 No Print 1 Print
55 PRINTING OF FACTORY NAME ON LABEL 
0 No Print 1 Print
56 DEFAULT PRINTING LABEL FACTORY NO 
Range (0 - 32)
57 PRINTING OF FACTORY NAME FORMAT 
0 No Centering 1 Centering

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 12 of 65
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
58 SELECTION OF LABEL LOGO PRINTING STATUS 
0 No Print 3 Logo 3
1 Logo 1 4 Logo 4
2 Logo 2
59 SELECTION OF BARCODE TYPE 
0 Code128 2 Code39
1 Ean128
60 AUTO PRINT FUNCTION
0 Between Set Point 1 And Set Point
2
1 Disable
61 ETHERNET FUNCTIONS
0 No Operation 2 Data Transfer Mode
1 Scale Genie
62 RS232C SOFTWARE HANDSHAKING XON/XOFF
0 Disable 1 Enable
63 SAMPLE QUANTITY 
0 10 Pcs 2 50 Pcs
1 25 Pcs 3 100 Pcs
64 SCALE A B
0 Manual 1 Auto
65 UNIT OF Pcs WT
0 1000 Pcs 1 1 Pcs
66 RESERVED
67 IMS
0 Disable 1 Enable
68 EPSON II
0 Disable 1 Enable
69 4 LOT NO
0 Disable 1 Enable
70 UPD LOT & PART NM
0 Disable 1 Enable
71 TEXT 11-16 IN TTL 
0 Disable 1 Enable
72 COMMA IN QUANTITY
0 Disable 1 Enable
73 PRINT BARCODE
0 With Header 2 QTY Without Header
1 All Without Header

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 13 of 65
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
74 OVERWRITE UNIT WT
0 No 1 Yes (If Unit WT = 0)
75 RESET SEQ NO
0 No 1 Yes (When Print)
76 SELECTABLE PRINTE
0 Disable 1 Enable
77 SELECTABLE PRINTS
0 Disable 1 Enable
78 TRANSACTION ABC
0 Disable 1 Enable
79 ID MANAGER
0 Disable 1 Enable
80 DHCP 
0 Disable 1 Enable
81 2D ITEM-TTL SEQ#
0 Disable 1 Enable
82 TTL SEQ NUM INC
0 Yes 1 No
83 WIRELESS COMM
0 Disable 1 Enable
84 SELECT UW/SCALE
0 Disable 1 Enable
85 SCALE 1 PER PCS
0 Disable 1 Enable
86 SCALE 2 PER PCS
0 Disable 1 Enable
87 SCALE 3 PER PCS
0 Disable 1 Enable
88 SCALE 4 PER PCS
0 Disable 1 Enable
89 AUTO PRINT COND
0 No Condition 1 WT = Below
90 PRINT CONDITION
0 No Condition 1 Lot Numbe
r
91 SP BUZZER COND 
0 Standard 2 Outside Set Point
1 Inside Set Point

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 14 of 65
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
100 SERVER IP ADDRESS 
Range (1 - 255) For Client scale only
101 ON/OFF KEY 
0 Enable 1 Disable
102 BLACK BAR SENSING LABEL 
0 Normal 1 Black Bar Sensing
103 TRANSPARENT FILM LABEL 
0 No 1 Yes
104 PRINT CHECKING LINE 
0 Print 1 No Print
105 LABEL PRINT ORIENTATION 
0 From Bottom 1 From Top
106 DEFAULT LABEL FORMAT FOR ITEM PRINTING 
0 T1 Not Used [A] 12 S (T6) [T7] Formats in ( ) are for U1
only.
Formats in [ ] are for CA
only.
F1 to F8 are Free
Format.
1
T
2 (A)
[
B
]
13
A
(T7)
[
T
8
]
2
T
3 (B)
[
C
]
14 B (T8)
[
T
9
]
3
T
4 (C)
[
U2
]
15 C (T9)
[
T
10
]
4 T5 (U2) [U3] 16 F1 (T10) [F1]
5 T6 (U3) [U4] 17 F2 (F1) [F2]
6 T7 (U4) [U5] 18 F3 (F2) [F3]
7
T
8 (U5)
[
U6
]
19 F4 (F3)
[
F4
]
8
T
9 (U6)
[
U7
]
20 F5 (F4)
[
F5
]
9
T
10 (U7)
[
U8
]
21 F6 (F5)
[
F6
]
10 T11 (U8) [T5] 22 F7 (F6) [F7]
11 T12 (T5) [T6] 23 F8 (F7) [F8]
24 - (F8) -
107 DEFAULT LABEL FORMAT FOR TOTAL PRINTING 
0
T
1 Not Used
[
A
]
12 S (T6)
[
T
7
]
Formats in ( ) are for U1
only.
Formats in [ ] are for CA
only.
F1 to F8 are Free
Format.
1
T
2 (A)
[
B
]
13
A
(T7)
[
T
8
]
2
T
3 (B)
[
C
]
14 B (T8)
[
T
9
]
3 T4 (C) [U2] 15 C (T9) [T10]
4 T5 (U2) [U3] 16 F1 (T10) [F1]
5 T6 (U3) [U4] 17 F2 (F1) [F2]
6
T
7 (U4)
[
U5
]
18 F3 (F2)
[
F3
]
7
T
8 (U5)
[
U6
]
19 F4 (F3)
[
F4
]
8
T
9 (U6)
[
U7
]
20 F5 (F4)
[
F5
]
9 T10 (U7) [U8] 21 F6 (F5) [F6]
10 T11 (U8) [T5] 22 F7 (F6) [F7]
11 T12 (T5) [T6] 23 F8 (F7) [F8]
24 - (F8) -
108 PRINT MANUAL WEIGHT SIGNATURE ON ITEM LABEL 
0 Inhibit 1 Allow For WG
109 LEFT ALIGNMENT OF PRICE AND WEIGHT ON LABEL 
0 No 2 Weight
1 Price 3 Price & Weight

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 15 of 65
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
110 PRINT $ AND WEIGHT UNIT ON LABEL 
0 No Print 1 Print
111 PRINTING OF CHECKSUM FOR ITEM BARCODE 
0 Disable 1 Enable For Code39 only.
112 ZERO SUPPRESS FOR DATE AND TIME 
0 Disable 1 Enable
113 ENLARGE LINE SPACING FOR G3 FONT ON ITEM LABEL 
0 Inhibit 1
A
llow For CN only.
114 ALIGNMENT OF COMMODITY NAME ON LABEL 
0 Center 2 Justify
1 Left
115 CONTINUOUS LABEL 
0 Disable 1 User Programmable # For CN.
116 MULTI BARCODE TYPE 
0 EAN128 5 GS1 DataMatrix # # For multi barcode 2
only.
1 RSS 6 GS1 DataBar Composite #
2 CODE128 7 Codabar
3 PDF417 # 8 Code39
4 GS1 QR Code # 9 GM Code #
117 ENABLE PASSWORD MODE 
0 Allow 2 Allow Multi Password
1 Inhibit
118 YEAR FORMAT 
0 YY 1 YYYY
144 PRINTING POSITION OFFSET FOR RECEIPT 
0 0mm (Standard) 5 - 1mm
1 1mm 6 - 2mm
2 2mm 7 - 3mm
3 3mm 8 - 4mm
4 4mm
120 CHARACTER SIZE FOR BARCODE DATA 
0 Large 1 Small
121 PRINT FORMAT OF MONTH 
0 Number 2 3 Alphabetic
1 2 Alphabetic
122 NUMERIC KEY ENTRY RESET 
0 3 sec 2 Disable For AA.
1 5 sec

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 16 of 65
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
123 TOTAL LABEL PRINTING 
0 No Print 1 Print
124 TARE OVERRIDE 
0 Allow 1 Inhibit
125 SETTING OF CLIENT / SERVER 
0 Client 1 Server / Workstation
126 MASK BARCODE LAST HUMAN READABLE CHECK DIGIT 
0 No 1 Yes
127 WIRELESS COMMUNICATION 
0 No 1 Yes
128 PRINT CONTROL FOR IMAGE 
0 Disable 1 Enable
129 GRATUITOUS ARP 
0 Disable 1 Enable
130 RTS/CTS HANDSHAKING OF RS-232C 
0 On 1 Off
131 SYMBOL FORMAT FOR DATE PRINT 
0 Dash 2 Null
1 Period
132 WIDTH OF STACKED SYMBOL IN SEGMENTS FOR RSS BARCODE 
0 2 2 6 Effective when SPEC116
= 1.
1 4 3 8
133 THE PRINTED QUALITY OF 2D BARCODE 
0 Mid 2 High
1 High-Mid 3 Highest (For QR Code only)
134 RSS AND 2D BARCODE HUMAN READABLE INTERPRETATION
PRINT

0 All 2 No Print
1 GTIN only
135 BARCODE CHECK LINE 
0 Print 1 No Print
136 FEED FOR CONTINUOUS LABEL 
0 No 1 Yes
137 G
A
P VALUE IN-FEED OPERATION 
0 Re-adjustable 1 No Change

DC-400 Operation Manual
Service & Support Dept. ©2018 SHANGHAI TERAOKA ELECTRONIC CO., LTD. 17 of 65
SPEC
NO. SPECIFICATION DESCRIPTION DC-400
138 WEIGHT DATA SYNCHRONIZATION FUNCTION 
0
A
llo
w
2 Enforce
1 Inhibit
139 FORCED FEED PAPER AFTER OPEN THERMAL HEAD 
0 No 1 Yes
140 RECALCULATE LABEL AND GAP VALUE BY REZERO + FEED KEY 
0 Allow 1 Inhibit
141 FTP CLIENT AUTO CONNECTION INTERVAL (MINUTE) 
Enter a value between 0 to 9999 For Client scale only.
142 FTP CLIENT DATA CONNECTION MODE 
0 Port 1 PASV For Client scale only.
143 ETHERNET IC RESET INTERVAL (MINUTE) 
Enter value from 5 to 999
