Digisol DG-GS1528HP User manual

DG-GS1528HP
24 Port Gigabit Ethernet PoE+ Smart Managed Switch with 4 SFP
Ports.
User Manual
V2.0
2018-08-07
As our products undergo continuous development the specifications are subject to change without prior notice

DG-GS1528HP User Manual
2
COPYRIGHT
Copyright 2018 by Digisol Systems Ltd. All rights reserved.
Company has an ongoing policy of upgrading its products and it may be possible that
information in this document is not up-to-date.
Please check with your local distributors for latest information. No part of this
document can be copied or reproduced in any form without written consent from the
company.
TRADEMARK
DIGISOL TM is a trademark of Digisol Systems Ltd. All other trademarks are the
property of the respective manufacturers.

DG-GS1528HP User Manual
3
Table of Contents
1. Introduction .........................................................................................................................11
1.1. Overview ................................................................................................................11
1.2. Package contents.....................................................................................................11
1.3. Features...................................................................................................................11
1.4. Product Components ..............................................................................................12
1.4.1. Ports................................................................................................................12
1.4.2. LED Indicators...............................................................................................13
2. Installation............................................................................................................................15
2.1. Mounting the Switch ..............................................................................................15
2.1.1. Placement Tips...............................................................................................15
2.1.2. Rack Mounting...............................................................................................17
3.Getting Started.....................................................................................................................20
3.1. Power......................................................................................................................20
3.1.1. Connecting to Power......................................................................................20
3.1.2. Connecting to the Network.............................................................................22
3.1.3. Power over Ethernet (PoE) Considerations....................................................23
3.1.4. Starting the Web-based Configuration Utility................................................23
3.1.5. Logging In ......................................................................................................26
4. Web-based Switch Configuration ......................................................................................28
4.1. Status ......................................................................................................................29
4.1.1. System Information........................................................................................29

DG-GS1528HP User Manual
4
4.1.2. Port .................................................................................................................31
4.1.2.1. Statistics...............................................................................................31
4.1.2.2. Error Disabled......................................................................................34
4.1.2.3. Traffic Statistics...................................................................................36
4.1.3. Link Aggregation ...........................................................................................37
4.1.4. MAC Address Table ......................................................................................38
4.2. Network..................................................................................................................39
4.2.1. IP Address ......................................................................................................39
4.2.2. System Time...................................................................................................40
4.3. Port .........................................................................................................................43
4.3.1. Port Setting.....................................................................................................43
4.3.2. Link Aggregation ...........................................................................................47
4.3.2.1. Group ...................................................................................................47
4.3.2.2. Port Setting ..........................................................................................49
4.3.2.3. LACP ...................................................................................................52
4.3.3. EEE.................................................................................................................53
4.3.4. Jumbo Frame..................................................................................................55
4.4. PoE .........................................................................................................................56
4.4.1. Global Setting.................................................................................................56
4.4.2. Priority Setting...............................................................................................58
4.4.3. Power Limit....................................................................................................58
4.5. VLAN.....................................................................................................................61
4.5.1. VLAN.............................................................................................................61

DG-GS1528HP User Manual
5
4.5.1.1. Create VLAN.......................................................................................61
4.5.1.2. VLAN Configuration...........................................................................63
4.5.1.3. Membership.........................................................................................64
4.5.1.4. Port Setting ..........................................................................................66
4.5.2. Voice VLAN..................................................................................................68
4.5.2.1. Property................................................................................................68
4.5.2.2. Voice OUI............................................................................................70
4.5.3. MAC VLAN...................................................................................................72
4.5.3.1. MAC Group.........................................................................................72
4.5.3.2. Group Binding .....................................................................................73
4.6. MAC Address Table...............................................................................................76
4.6.1. Dynamic Address...........................................................................................76
4.6.2. Static Address.................................................................................................77
4.6.3. Filtering Address............................................................................................77
4.7. Spanning Tree.........................................................................................................78
4.7.1. Property..........................................................................................................78
4.7.2. Port Setting.....................................................................................................81
4.7.3. MST Instance.................................................................................................84
4.7.4. MST Port Setting............................................................................................86
4.7.5. Statistics .........................................................................................................88
4.8. Discovery................................................................................................................90
4.8.1. LLDP..............................................................................................................90
4.8.1.1. Property................................................................................................90

DG-GS1528HP User Manual
6
4.8.1.2. Port Setting ..........................................................................................91
4.8.1.3. Packet View.........................................................................................94
4.8.1.4. Local Information................................................................................97
4.8.1.5. Neighbor ..............................................................................................99
4.8.5.6. Statistics.............................................................................................100
4.9. Multicast...............................................................................................................101
4.9.1. General.........................................................................................................101
4.9.1.1. Property..............................................................................................101
4.9.1.2. Group Address...................................................................................103
4.9.1.3. Router Port.........................................................................................105
4.9.2. IGMP Snooping ...........................................................................................108
4.9.2.1. Property..............................................................................................108
4.9.2.2. Querier...............................................................................................112
4.9.2.3. Statistics.............................................................................................113
4.9.3. MVR.............................................................................................................115
4.9.3.1. Property..............................................................................................115
4.9.3.2. Port Setting ........................................................................................116
4.9.3.3. Group Address...................................................................................117
4.10. Security...............................................................................................................120
4.10.1. RADIUS....................................................................................................120
4.10.2. Management Access .................................................................................123
4.10.2.1. Management Service .......................................................................123
4.10.2.2. Management ACL ...........................................................................124

DG-GS1528HP User Manual
7
4.10.2.3. Management ACE ...........................................................................125
4.10.3. Authentication Manager............................................................................127
4.10.3.1. Property............................................................................................127
4.10.3.2. Port Setting ......................................................................................133
4.10.3.3. Sessions............................................................................................138
4.10.4. Port Security..............................................................................................140
4.10.5. Protected Port............................................................................................143
4.10.6. Storm Control............................................................................................144
4.10.7. DoS............................................................................................................146
4.10.7.1. Property............................................................................................146
4.10.7.2. Port Setting ......................................................................................149
4.10.8. DHCP Snooping........................................................................................149
4.10.8.1. Property............................................................................................149
4.10.8.2. Statistics...........................................................................................151
4.10.8.3. Option82 Property ...........................................................................152
4.10.8.4. Option82 Circuit ID.........................................................................154
4.10.9. IP Source Guard........................................................................................156
4.10.9.1. Port Setting ......................................................................................156
4.10.9.2. IMPV Binding .................................................................................158
4.10.9.3. Save Database..................................................................................160
4.11. ACL....................................................................................................................163
4.11.1. MAC ACL.................................................................................................163
4.11.2. MAC ACE.................................................................................................164

DG-GS1528HP User Manual
8
4.11.3. IPv4 ACL..................................................................................................166
4.11.4. IPv4 ACE..................................................................................................167
4.11.5. ACL Binding.............................................................................................172
4.12. QoS.....................................................................................................................173
4.12.1. General......................................................................................................173
4.12.1.1. Property............................................................................................173
4.12.1.2. Queue Scheduling............................................................................176
4.12.1.3. CoS Mapping...................................................................................177
4.12.1.4. IP Precedence Mapping...................................................................178
4.12.2. Rate Limit..................................................................................................179
4.12.2.1. Ingress/Egress Port ..........................................................................180
4.13. Diagnostics.........................................................................................................182
4.13.1. Logging.....................................................................................................182
4.13.1.1. Property............................................................................................182
4.13.1.2. Remote Server..................................................................................184
4.13.2. Mirroring...................................................................................................185
4.13.3. Ping ...........................................................................................................187
4.13.4. Traceroute .................................................................................................187
4.14. Management.......................................................................................................188
4.14.1. User Account.............................................................................................188
4.14.2. Firmware ...................................................................................................190
4.14.2.1. Upgrade / Backup ............................................................................190
4.14.2.2. Active Image...................................................................................195

DG-GS1528HP User Manual
9
4.14.3. Configuration ............................................................................................196
4.14.3.1. Upgrade / Backup ............................................................................196
4.14.3.2. Save Configuration..........................................................................201
4.14.4. SNMP........................................................................................................202
4.14.4.1. View.................................................................................................202
4.14.4.2. Group ...............................................................................................202
4.14.4.3. Community ......................................................................................205
4.14.4.4. User..................................................................................................207
4.14.4.5. Engine ID.........................................................................................210
4.14.4.6. Trap Event........................................................................................211
4.14.4.7. Notification......................................................................................212
4.14.5. RMON.............................................................................................................215
4.14.5.1. Statistics .................................................................................................215
4.14.5.2. History....................................................................................................218
4.14.5.3. Event ......................................................................................................221
4.14.5.4. Alarm......................................................................................................224

DG-GS1528HP User Manual
10
Safety and Regulatory
Audience
This guide is for the networking professional managing the standalone GS-7000
switch series. It is recommended that only professionals with experience working
with Digisol Systems Limited networking devices who are familiar with the Ethernet
and local area networking terminology, should service the equipment.
Conventions
The following conventions are used in this manual to convey instructions and
information:
Command descriptions use these conventions:
• Commands and keywords are in boldface text.
• Arguments for which you supply values are in italic.
• Square brackets ([ ]) mean optional elements.
• Braces ({ }) group required choices, and vertical bars ( | ) separate the
alternative elements.
• Braces and vertical bars within square brackets ([{ | }]) mean a required choice
within an optional element.
Interactive examples use these conventions:
• Nonprinting characters, such as passwords or tabs, are in angle brackets (< >).
Notes and cautions use the following conventions and symbols:
Note: Means additional information. Notes contain additional useful information or
references to material available outside of this document.
Caution:Indicates that the reader must be careful. In a situation where a Caution is
listed, a user may cause equipment damage or loss of data.

DG-GS1528HP User Manual
11
1. Introduction
Thank you for choosing a Digisol (PoE) WEB Smart Ethernet Switch. This device is
designed to be operational right out-of-the-box as a standard bridge. In the default
configuration, it will forward packets between connecting devices after powered up.
Before you begin installing the switch, make sure you have all of the package contents
available, and a PC with a web browser for using web-based system management
tools.
1.1. Overview
The Digisol DG-GS1528HP is a 24 Port Gigabit Ethernet PoE+ Smart Managed Switch with
4 SFP Ports.
1.2. Package contents
Before using the product, check that the items listed below are included and in good
condition. If any item does not accord with the table, please contact your dealer
immediately.
• Digisol DG-GS1528HP WEB Smart PoE Switch
• Quick Installation Guide
• Power Cord
• Manual CD
• Rack Mount Kit
• Foot pads
1.3. Features
• Supports up to 24 10/100/1000Mbps Gigabit Ethernet ports and 4 SFP slots or 4
mini-GBIC/SFP slots

DG-GS1528HP User Manual
12
• IEEE 802.3af/at PoE compliant to simplify deployment and installation
• Supports PoE up to 30W per port with 280W total power budget
• Automatically detects powered devices (PD) and power consumption levels
• IEEE 802.1Q VLAN allows network segmentation to enhance performance and
security
• Supports Access Control List (ACL)
• Switch capacity: DG-GS1528HP: 56Gbps, Forwarding rate: 41.6Mpps
• Supports IGMP Snooping V1 / V2 / V3
• 8K MAC address table and 10K jumbo frames
• 19-inch rack-mountable metal case
1.4. Product Components
1.4.1. Ports
The following view applies to DG-GS1528HP.
1 2
Figure 1 - Front View
No.
Name
Description
1
10/100/1000Mbps
RJ-45 ports
(1~24)
Designed to connect to network devices with a
bandwidth of 10Mbps, 100Mbps or 1000Mbps. Each has
a corresponding 10/100/1000Mbps LED.

DG-GS1528HP User Manual
13
2
SFP ports (SFP1,
SFP2, SFP3, and
SFP4)
Designed to install SFP modules and connect to network
devices with a bandwidth of 100/1000Mbps. Each has a
corresponding 100Mbps & 1000Mbps LED.
The following view applies to DG-GS1528HP.
1
Figure 2 - Rear View
No.
Name
Description
1
AC power in
Supports AC 100 –240V, 50-60Hz.
1.4.2. LED Indicators
The following view applies to DG-GS1528HP.
1 2 3 4
Figure 3 - Front View LED Indicators
No.
Name
Description
1
Power
• Off: power off
• On: power on

DG-GS1528HP User Manual
14
2
System
• Off: system not ready
• On: system ready
• Blinking: system boot-up
3
Port LED
LINK/ACT bi-color LED:
• Off: port disconnected or link fail
• Green on: 1000Mbs connected, PoE power output on
• Amber on: 10/100Mbps connected
• Blinking: sending or receiving data
4
SFP LED
• Off: port disconnected or link fail
• Green on: 100/1000Mbps connected

DG-GS1528HP User Manual
15
2. Installation
This chapter describes how to install and connect your Digisol Systems Limited Switch.
Read the following topics and perform the procedures in the correct order. Incorrect
installation may cause damage to the product.
2.1. Mounting the Switch
There are two ways to physically set up the switch.
• Place the switch on a flat surface. To place the switch on a desktop, install the
four rubber feet (included) on the bottom of the switch.
• Mount the switch in a standard rack (1 rack unit high).
2.1.1. Placement Tips
• Ambient Temperature—To prevent the switch from overheating, do not operate it
in an area that exceeds an ambient temperature of 122°F (50°C).
• Air Flow—Be sure that there is adequate air flow around the switch.
• Mechanical Loading—Be sure that the switch is level and stable to avoid any
hazardous conditions.
• Circuit Overloading—Adding the switch to the power outlet must not overload
that circuit.
Follow these guidelines to install the switch securely.
1. Put the switch in a stable place such as a desktop, to avoid it falling.
2. Ensure the switch works in the proper AC input range and matches the voltage
labeled.
3. Ensure there is proper heat dissipation from and adequate ventilation around the
switch.
4. Ensure the switch’s location can support the weight of the switch and its
accessories.

DG-GS1528HP User Manual
16
Figure 4 - Desktop Installation

DG-GS1528HP User Manual
17
2.1.2. Rack Mounting
You can mount the switch in any standard size, 19-inch (about 48 cm) wide rack. The
switch requires 1 rack unit (RU) of space, which is 1.75 inches (44.45 mm) high.
For stability, load the rack from the bottom to the top, with the heaviest
devices on the bottom. A top-heavy rack is likely to be unstable and may tip
over.
When mounting smaller switch products into a standard 19-inch rack, a pair
of extension brackets (sometimes referred to as ears) are needed to adapt
the switch to the rack size.
These extension brackets are mounted on the switch using the screws
provided in the kit, and have two holes that are used to then screw the
switch into the rack.
An example of one type of these extension brackets is shown in the following
figure.
A common problem that occurs during rack mounting is the distance between
the screw holes on the rack. Some racks are made with a uniform distance
between all of the holes, and others have the holes organized into groups
(see photo on the next page for an example).
When organized into groups, the switch must be placed in the rack so that
the holes in the extension brackets line up correctly.
1. Align the mounting brackets with the mounting holes on the switch’s side panels
and secure the brackets with the screws provided.

DG-GS1528HP User Manual
18
Figure 5 - Bracket Installation

DG-GS1528HP User Manual
19
2. Secure the switch on the equipment rack with the screws provided.
Figure 6 - Rack Installation

DG-GS1528HP User Manual
20
3. Getting Started
This section provides an introduction to the web-based configuration utility, and
covers the following topics:
• Powering on the device
• Connecting to the network
• Power over Ethernet (PoE) considerations
• Starting the web-based configuration utility
3.1. Power
3.1.1. Connecting to Power
Power down and disconnect the power cord before servicing or wiring a
switch.
Do not disconnect modules or cabling unless the power is first switched off.
The device only supports the voltage outlined in the type plate. Do not use
any other power components except those specifically designated for the
switch.
Disconnect the power cord before installation or cable wiring.
The switch is powered by the AC 100-240 V 50/60Hz internal high-performance power
