USERMANUAL
InstallationGuide
AUGUST2015|v1.0
Decoder
TVID1000

Decoder(TVID1000)|UserManual  InstallationGuide

  Page2
DECODER INSTALLATION GUIDE
ThankyouforpurchasingaTVIdecoder(TVID1000)unit.TheD1000isasinglechannelvideodecoderforthe
TVIvideosystem.EachdecoderwillconnecttoaTVIServeranddecodeavideostreamtoitscorrespondingTV
output.Additionallyeachunitofferstheabilityto:
•Specifyupto99streamsanduseaUSBkeyboardtoswitchbetweenthem.
•TakecontrolofanyPTZattachedcameraandsteerthecamerausingaUSBkeyboard.
Thisdocumentcoverstheoperationsandconfigurationofthedecoderunit.Itshouldbereadinconjunction
withtheTVIUserGuideandTVIAdministratorGuide,whichcoverthesoftwareaspectsofTVIoperation.The
decoderisdesignedtoworkincombinationwithaTVIServertodelivervideotoendusersanditwillnot
operatewithoutaTVIServerinplaceandtheappropriateencoderaccountandpermissionsdefined.Referto
theTVISystemAdministratorGuidefordetailsofhowtocreateandadministeraccounts.
Beforeproceedingwiththeinstallationandsetupofyourdecoderunit,pleaseensurethatyoucheckthe
packagecontentslistedbelow.





 
WHATISINTHEBOX?
DecoderUnitDecoder(TVID1000)
AccessoriesHMDItocompositevideoconvertor
USBtoMiniBcable
miniDisplayPorttoHDMIcable
Mainspowercable
Rackmountingbracket(andscrews)
USBpendriveContainingTVIDecoderInstallationGuide


CONNECTIVITY
ToconnecttoaTVIserverthisdecoderunitwillneedoutgoingaccesstoUDPport2048
WHEREDOIGOFORFURTHERSUPPORT?
TheTVIsupportsitehasuptodateinformation,troubleshootingtipsandfirmwareforallTVIproducts.
Accessthesite(orregister)athttp://tvisupport.digitalbarriers.com.Foradditionalsupport,contact:
DigitalBarriers|TVIProducts
39StVincentPlace,GlasgowG12ER,UK|t:+44(0)2035535888|www.digitalbarriers.com/tvi


Decoder(TVID1000)|UserManual  InstallationGuide

  Page3
Installation


1. PluganetworkcablethatisconnectedtoyourLANintothedecoderunit(labelled‘A’indiagram).
2. Ifcompositevideooutputisrequired,attachtheHDMItocompositeconverter.UsetheUSBtoMiniB
cabletopowertheconvert(installintooneofthesocketslabelled‘B’andattachtotheconvertor
portlabelled‘B*’below)theninsertthemicroDisplayPorttoHDMIcable(intoportlabelled‘C’on
thedecodertoportlabelled‘C*’ontheconvertor).Alternatively,forHDoutput,connectthemicro
DisplayPorttoHDMIcabledirectlytoyourHDMIdevice.
3. Ifkeyboardcontrolisrequired,plugaUSBkeyboardintotheunit(useoneofthesocketsonUSB
connectorlabelled‘B’).
4. Onceyouhaveconnectedtheotherendsofyourcablesintotheappropriatedevicesyoushould
insertthekettlepowerleadintothedecoder.Nowpressthepowerswitchonthefrontpanelto
powerupthedecoder.



5. Ifrequiredthedecodercanbeconvertedforusewithinarackusingthesuppliedrackmountbracket.
UptothreeD1000decoderunitscanbemountedtothebracket.Eachunithastwoscrewholeson
thefrontpanelthatalignwiththebracket.




A
B
C
C*
B*

Decoder(TVID1000)|UserManual  InstallationGuide

  Page4
Configuring the Decoder Unit
ThedecoderisconfiguredusingtheConfigureDecoder.exeprogramonthesuppliedUSBFlashDrive.Insert
theUSBFlashDriveintoaWindowsPCandruntheConfigureDecoder.exeprogram.

SelecttheDecoderModel
ThisguideshowsthestepsrequiredtoconfigureaD1000.
SelecttheD1000fromtheavailabledecodermodels.

NetworkConfiguration
InmostcircumstancesthedefaultDHCPoptionissufficienthoweverifyouhavea
specialrequirementitispossibletoenteraStaticIPconfiguration.Onceyouhave
selectedtheappropriateoptionforyourrequirementhitthe‘Next’button.


ConfigureStreamstoView
Onthisnextpageyoucanenterthelistofstreamsyouwanttobeabletoselect
fromonthedecoderbox.

Eachentryisassignedanumberthatcorrespondstothesamenumberkeyonthe
USBkeyboard.Ifyouwanttoordertheentriesdifferentlyselecttheentryanduse
thetwomovebuttonsontherighttomovetheentriesupordowninthelist.

VideoOutputConfiguration
Nextyouwillbeaskedtoselectthevideooutputtypethattheencoderwilluse.
ThismodifiestheoutputtogivebetterresultswhenusingeithertheSD/Composite
orHD/DigitalVideooutput.
Onceyouhaveenteredthedesiredoutputtypeyoushouldhit‘Finish’.Thiswill
closethewizardandyoushouldfollowtheonscreeninstructionsonhowtoeject
theUSBFlashDrive.


Poweronthedecoderunitandallowittoboot(waituntilyouseethesplashscreen).InserttheUSBFlash
DriveintooneoftheUSBsocketsonthefrontoftheunit.Theunitwillreconfigureitselfand,ifsuccessful,
shouldnowbeshowingthefirststreamontheoutput.


Decoder(TVID1000)|UserManual  InstallationGuide

  Page5
Factory Reset
Thedecodercanberesettofactorydefaultsifrequired.ThesuppliedUSBflashdrivecontainsafoldercalled
‘FactoryReset’.Inthisfolderthereisafilecalled‘.FACTORY_RESET’whichshouldbecopiedtoablankUSB
FlashDriveandappliedtothedecoderinthesamewayasaconfiguration.Thedecoderwilldisplay
‘Reconfiguring’onscreenandwillthenremoveallconfigurationsettings.

TheUSBFlashDrivecannowberemoved.

Software Updates
Whensoftwareupdatesarereleasedforthedecoderthesewillcomeintheformof‘Decoder1.x.x.update’
files.ThesefilesshouldbecopiedtoablankUSBFlashDriveandappliedtothedecoderinthesamewayasa
configuration.Thedecoderwilldisplay‘Updating’onscreenandwilldisplayablackscreenforafewseconds
beforeshowingthesplashscreenloadingimageagain.Thedecoderwillnowbeusingtheupdatedsoftware
andwillstillhavethepreviousconfiguration.

TheUSBFlashDrivecannowberemoved.





ECDECLARATIONOFCONFORMITY
ThisistocertifythattheproductslistedhereinandsuppliedbyDigitalBarriersaremanufacturedin
accordancewiththefollowingCouncilDirectives:
2004/108/EC:
ElectromagneticCompatibility

2006/95/EC:
LowVoltageDirective

1995/5/EC:
RadioandTelecommunicationsTerminalEquipment(R&TTE)

Issuedunderthesoleresponsibilityofthemanufacturer,declarethat:
Equipment:
D1000VideoDecoder

Isinconformitywiththeapplicablerequirementofthefollowingdocuments:
EN55022:
Limits&methodsofmeasurementofradiodisturbancecharacteristicsof
informationtechnologyequipment

EN55024:
Limits&methodsofmeasurementofImmunitycharacteristicsof
informationtechnologyequipment

EN609501:
SafetyforInformationtechnologyequipment.(Part1:General
Requirements)

Incaseoffurtherquestionsregardingtheconformityofthisproduct,pleasedonothesitateto
contactus.
Signed:


CraigYoung
Position:


ManufacturingManager
Date:


28thSeptember2015

