Digital Watchdog DWC-DSWM User manual

Wall mount bracket for DWC-PDS10Wi28A
dual-sensor vandal dome cameras
Quick Start Guide
Tel: [phone]
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
digital-watchdog.com
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in the ‘Search by Product’ search bar. Results
for applicable part numbers will populate automatically based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
DWC-DSWM
WHAT’S IN THE BOX
Camera Mounting Screws
(12.7mm) 4Mounting Pad 1
Quick Setup Guide 1Mounting Template 1
Screws and Plastic Anchors 4 1

Quick Start Guide
Rev: 11/22
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
INSTALLATION
1
Mark and drill the necessary holes on the mounting surface.
2
Secure the mounting bracket to the mounting surface using the screws and anchors included with the mount. Use the
mounting pad between the bracket’s arm and mounting surface as needed.
3
To mount the camera to the mounting accessory, remove the dome from the camera base using the wrench included
with the camera.
NOTE: Do not touch the lens when handling the camera.
4
Pass wires through and make
all necessary connections.
5
Secure the camera to the
mounting bracket using the
included screws.
6
Adjust the camera’s lens
modules’ position and angle
and place the cover dome on
the camera base to complete
the installation.
Wall mount
Camera
base
Camera dome cover
