Digital Watchdog DWC-V7JUNCW User manual

DWC-V7JUNCW DWC-V7JUNC
Junction box for vandal dome cameras
Quick Start Guide
Tel: [phone]
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
digital-watchdog.com
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in the ‘Search by Product’ search bar. Results
for applicable part numbers will populate automatically based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
WHAT’S IN THE BOX
Camera Mounting Screws 2Mounting Template 1
Screws and Plastic Anchors 4Quick Setup Guide 1

Quick Start Guide
Rev Date: 08/21
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
INSTALLATION
Junction box
Camera module
Camera dome cover
1Using the mounting template or the junction box itself, mark and drill the necessary holes on the mounting surface.
2Secure the junction box to the mounting surface using the screws and anchors included.
3To mount the camera to the mounting accessory, remove the dome from the camera base using the wrench included
with the camera.
NOTE: Do not touch the lens when handling the camera.
4
Pass wires through and make all necessary connections.
5
Secure the camera to the mounting bracket using the included screws. Align the camera’s mounting holes with the ones
in the junction box.
6
Adjust the camera’s lens position and angle, then place the cover dome over the camera lens and ax the cover to the
bracket with the original dome housing’s screws.
