Digital Watchdog DWC-MCAM User manual

DWC-MCAM
Angle mount for micro dome cameras
Quick Start Guide
Tel: [phone]
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
digital-watchdog.com
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in the ‘Search by Product’ search bar. Results
for applicable part numbers will populate automatically based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
WHAT’S IN THE BOX
Mounting Screws 3Quick Setup Guide 1
2. Installation
Quick Manual
Ver. 1.0 / 2021.05
Before installing and using the Camera, please read this manual carefully.
Be sure to keep it handy for future reference.
Indoor Micro Dome Camera
Angle Mount Bracket Manual
1. Dimension & Accessories
31.8
105°
17
80
57
2
3
4
1Mount the angle mount on the wall.
Connect the cable.
Aach the camera boom to the mount
hole.
Aer adjusng the camera, aach the
upper case to complete the mounng.
66
4-Ø 4.0
4-TAP
M4.0xP0.7 DP9
46
Please check if all the camera and accessories are included in the package.
Mount
Screw 3ea Manual
2. Installation
Quick Manual
Ver. 1.0 / 2021.05
Before installing and using the Camera, please read this manual carefully.
Be sure to keep it handy for future reference.
Indoor Micro Dome Camera
Angle Mount Bracket Manual
1. Dimension & Accessories
31.8
105°
17
80
57
2
3
4
1Mount the angle mount on the wall.
Connect the cable.
Aach the camera boom to the mount
hole.
Aer adjusng the camera, aach the
upper case to complete the mounng.
66
4-Ø 4.0
4-TAP
M4.0xP0.7 DP9
46
Please check if all the camera and accessories are included in the package.
Mount
Screw 3ea Manual

Quick Start Guide
Rev: 08/21
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
INSTALLATION
1Use the angle mount to mark and drill the necessary holes on the mounting surface.
2Secure the angle mount to the mounting surface using screws and wall anchors. These are not included with the accessory.
3Pass wires through and make all necessary connections to the camera. See the camera’s QSG for more information.
4For the installation, remove the camera’s top cover by rotating it counterclockwise.
5Attach the camera’s bottom to the mounting bracket with the screws included with the camera.
6Adjust the camera’s angle and attach the upper case by rotating it back into place.
NOTE: Do not touch the lens when handling the camera module.
