Digital Watchdog DWC-EXTIR100 User manual

DWC-EXTIR100
100ft IR Illuminator for MEGApix®PANO™and STAR-LIGHT™
HD over Coax™Panoramic Bullet Camera
Quick Start Guide
WHAT’S IN THE BOX
QSG Manual 1 Set Screw 1 Set
Attention: This document is intended to serve as a quick reference for initial set-up.
It is recommended that the user read the entire instruction manual for complete and proper installation and usage.
NOTE Download All Your Support Materials and Tools in One Place
1. Go to: http://www.digital-watchdog.com/support-download/
2. Search your product by entering the part number in the ‘Search by Product’ search bar. Results for applicable part numbers will
populate automatically based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals, Quick Start Guides (QSG), software and rmware will appear in the results.
Tel: [phone]
Technical Support Hours: 9:00AM – 8:00PM EST, Monday thru Friday
digital-watchdog.com
NOTE To check if your camera supports the new Infra Red Extrernal Illuminator, check to see if it has an additional cables lebeled EX-LED in
the bullet’s cables.

LED
EX-LED
EX-LED
DC12V
Power
INSTALLING THE MOUNTING ACCESSORY
Rev Date: 07/17
Copyright © Digital Watchdog. All rights reserved.
Specications and pricing are subject to change without notice.
INSTALLATION ON AN IP CAMERA INSTALLATION ON AN ANALOG CAMERA
Quick Start Guide
1. Connect the EXT-LED cable from the illuminator to the camera’s cable labeled “EX-LED”
2. Connect the power cable to an adequate power supply.
• Power requirements: DC12V/AC24V Dual Voltage
• Power consumption: DC12V : Max 11.0W, AC24V : Max 11.0W
PARTS & DIMENSIONS
5.06”
(128.6mm)
6.28”
(159.6mm)
1.09”
(27.9mm)
1.45”
(37mm)
NOTE: Please check your
hardware to see if it supports the IR
illuminator connection.
NOTE: The illuminator’s cables can
be placed in any of the four holes in
the camera’s mounting bracket.
IR LEDs
Screw
DC12V / AC24V Cable
EX-LED Cable
12VDC / 24V AC 12VDC / 24V AC
LED
EX-LED
DC12V
Power
