Digital Watchdog Megapix DWC-MV72I4V User manual

DWC-MV72i4V / DWC-MV72i28V
Step 1 – PREPARING TO MOUNT THE CAMERA
Step 3 – INSTALLING THE CAMERA
Step 2 – CABLING THE CAMERA TO EXTERNAL DEVICES
1. The mounting surface must bear ve times the weight of your camera.
2. Do not let the cables get caught in improper places or the electric line cover to
be damaged. This may cause a breakdown or re.
3. For the installation process, remove the dome cover from the camera module
by loosening the three (3) screws on the dome. Use the wrench provided with
the camera.
4. Using the mounting template sheet or the camera itself, mark and drill the
necessary holes in the wall or ceiling.
6. To use the camera’s water proof wiring:
(1).Install the LAN cable into (a).
(2).(b) will be assembled to (a)
with a 1/4 turn.
(3).Thread (c) tightly to (b).
7. Use the camera’s 3-Axis gimbal to adjust the camera’s tilt and angle. The
camera’s maximum tilting angle is 70.
8. Assemble the dome cover over the camera body and detach the protecting lm
from the dome bubble.
5. Pass the wires through the mount bracket and make all necessary connections.
a. NETWORK CONNECTIONS – If you are using a PoE Switch, connect the
camera using an Ethernet cable for both data and power.
b. NETWORK CONNECTIONS – If you are using a non-PoE switch, connect
the camera to the switch using an Ethernet cable for data transmission and
use a power adapter to power the camera.
Power Requirements
DC 12V
PoE IEEE 802.3atPoE+ / PoE Class 2
Power Consumption
LED Off: 1.92W, 160mA
LED On: 2.7W, 230mA (IR models only)
NETWORK
CONNECTION
POWER
1
2
3
5
4
Template
Sheet
Reset
Button
Quick Start Guide Quick Start Guide
Username: admin Password: admin
Attention: This document is intended to serve as a quick reference page for initial set-up.
It is recommended that the user read the entire instruction manual for complete and proper
camera usage.
Tel: [phone]
Technical Support Hours:
9:00AM – 8:00PM EST, Monday thru Friday
digital-watchdog.com
WHAT’S IN THE BOX
QSG Manual 1 Set Mount Bolt &
Nut – 2pcs 1 Set
Manual CD 1 Set Screw & Plastic
Anchor – 2pcs 1 Set
Template Sheet
for installing by
Bolt & Nut
1 Set Torx Wren c h 1 Set
Note: To ensure moisture seal, make sure the o-ring is in place between
(a) and (b). In extreme environments use of an outdoor rated sealer
is recommended.
Resetting the camera: To reset the camera, use the tip of a paper clip or
a pencil and press the reset button. Pressing the button for ve (5) seconds
will initiate a camera-wide reset of all the settings, including network settings.
a
b
c

Step 5 – WEB VIEWER
Once the camera’s network settings have been setup properly, you can access the
camera’s web viewer using the DW IP Finder™. To open the camera’s web viewer:
1. Find the camera using the DW IP Finder™.
2. Double-click on the camera’s view in the results table.
3. Press the ‘View Camera Website’. The camera’s web viewer will open up in
your default web browser.
4. Enter the camera’s username and password (default are admin / admin).
5. If you are accessing the camera for the rst time, install the VLC les in
order to view video from the camera.
Step 3 – INSTALLING THE CAMERA (CONT.)
Installation using Mount Bolt and Screws:
1. Using the template sheet, make and drill the cabling holes on the wall/ceiling.
2. Secure the two long mounting screws to the camera’s base.
3. Pass the wires through the mount bracket and make all necessary connections.
4. Mount the camera to the mounting surface by using the 2 mounting nuts.
Rotate the locking discs over the screws until the camera is held tightly from
the mounting surface.
Quick Start Guide
Note: The camera’s maximum tilting angle is 70°
4. The camera’s default network information is:
Network Setup
1. Run the CD included with the camera and click on the DW IP Finder™le.
2. The software will scan your network for all supported cameras and display the
results in the table. Allow up to 5 seconds for the IP Finder to nd the camera on
the network.
3. Select a camera from the list by double-clicking on the camera’s image or
clicking on the ‘Click’ button under the IP Conf. column. The camera’s network
information will appear. If necessary, you can adjust the camera’s network type.
Select DHCP if the internet service is dynamic IP. This will allow the camera to
receive its IP address from the DHCP server.
Select STATIC to manually enter the camera’s IP address, subnet mask,
Gateway and DNS information.
Contact your network administrator for more information.
Default TCP/IP information
• IP: 192.168.1.80
• Subnet Mask: 255.255.255.0
• Ga t eway : 19 2 .16 8.1.1
• DN S : 16 8.126.6 3.1
6. To save the changes made to the camera’s settings, input the ID and PW of the
camera for authentication and click ‘Save’.
7. If the camera needs to be rebooted after the settings were changed, press the
‘Reboot’ button. The camera will cycle power and will appear back in the search
results once the reboot is complete.
5. To view the camera’s web viewer, click on ‘View Camera Website’.
‘Port Forwarding’ has to be set in your network’s router for external access
to the camera.
Default ID / PW : admin / admin
Rev Date: 3/16
Copyright © Digital Watchdog. All rights reserved. Specifications
and pricing are subject to change without notice.
Note: Please see the full product manual for web viewer setup, functions
and camera settings options.
Step 4 – DW IP FINDER™
Use the DW IP Finder™included in the camera’s accessory CD to scan the network
and detect all MEGApix®cameras, set the camera’s network settings, perform
rmware upgrade or access the camera’s web client.
DWCMF10M28T
DWCMF21M4TIR
DWCMF10M28T
DWCMF21M4TIR
