SFMFF1313-220 SC, 850 nm multimode

220 m (721 ft)**

SC, 850 nm multimode

220 m (721 ft)**

[email protected] -- Click the “Transition Now” link for a live Web chat.

SFMFFxxxx-2xx User’s Guide

•Stand-Alone Media Converter

• Fast Ethernet, ATM, SONET, or Gigabit

Transition Networks SFMFFxxxx-2xx series media

converters extend both multimode and single mode

interfaces to single mode fiber optic cable over Fast

Ethernet, ATM, SONET, and Gigabit networks.

1.25 Gb/s cable speed:

The models with the -22x extensions are for cable speeds of 1.25 Gb/s and can

extend gigabit Ethernet over a single mode fiber up to 125 km.

*Typical maximum cable distance. The actual distances is dependent upon the

physical characteristics of the network installation. TX = transmit, RX = receive.

**Minimum cable distance: 2 meters, typical maximum cable distance:

220 meters for 160/500MHz•Km

270 meters for 200/500MHz•Km

Part Number Port One - Fiber-Optic Port Two - Fiber-Optic

SFMFF1324-220 SC, 850 nm multimode

220 m (721 ft)**

SC, 1300 nm extended multimode

up to 2 km (1.2 miles)*

(62.5 / 125 fiber only)

SFMFF1335-220 SC, 850 nm multimode

220 m (721 ft)**

SC, 1550 nm single mode

125 km (77.5 miles)*

SFMFF1414-220 SC, 1310 nm, single mode

10km (6.2 miles)

SC, 1310 nm, single mode

10km (6.2 miles)

SFMFF1314-220 SC, 850 nm multimode

220 m (721 ft)**

SC, 1310 nm single mode

10 km (6.2 miles)*

SFMFF1315-220 SC, 850 nm multimode

220 m (721 ft)**

SC, 1310 nm single mode

25 km (15.5 miles)*

SFMFF1317-220 SC, 850 nm multimode

220 m (721 ft)**

SC, 1550 nm single mode

65 km (40.3 miles)*

Installation . . . . . . . . . . . . . . . . .6

Operation . . . . . . . . . . . . . . . . . .7

Cable Specifications . . . . . . . . . .8

Technical Specifications . . . . . .13

Troubleshooting . . . . . . . . . . . .14

Contact Us . . . . . . . . . . . . . . . .15

Compliance Information . . . . . .12

2

SFMFFxxxx-2xx

24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

The distances listed are the typical maximum cable distance. The actual maximum

cable distances are dependent upon the physical characteristics of the network

installation. SM = single mode, TX = transmit, RX = receive.

SFMFF1329-200 SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

SC, 1310 nm (TX)/1550 nm (RX)

SM single fiber, 20 km (12.4 mi)

Note: -200 and -201 are designed to be installed in the same network

where one is the local converter and the other is the remote converter.

SFMFF1329-202 SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

SC, 1310 nm (TX)/1550 nm (RX)

SM single fiber, 40 km (24.8 mi)

SFMFF1329-203 SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

SC, 1550 nm (TX)/1310 nm (RX)

SM single fiber, 40 km (24.8 mi)

SFMFF1329-204 SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

SC, 1310 nm (TX)/1550 nm (RX)

MM single fiber, 60 km (37.3 mi)

SFMFF1329-205 SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

SC, 1550 nm (TX)/1310 nm (RX)

MM single fiber, 60 km (37.3 mi)

SFMFF1329-204 SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

SC, 1310 nm (TX)/1550 nm (RX)

SM single fiber, 60 km (37.3 mi)

SFMFF1329-205 SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

SC, 1550 nm (TX)/1310 nm (RX)

SM single fiber, 60 km (37.3 mi)

155 Mb/s cable speed:

The models with the -20x extension are for cable speeds of 155 Mb/s and extend

ATM or Fast Ethernet over single mode fiber up to 40 km.

SFMFF1329-201 SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

SC, 1550 nm (TX)/1310 nm (RX)

SM single fiber, 20 km (12.4 mi)

Note: -202 thru -205 are designed to be installed in sequential pairs in

the same network where one is the local converter and the other is the

remote converter.

SFMFF1313-200 SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

SC, 1300 nm multimode

duplex, 2 km (1.2 mi)

Part Number Port One - Fiber Optic Port Two - Fiber-Optic

1.25 Gb/s cable speed -- continued

The models with the -22x extensions are for cable speeds of 1.2Gb/s and can

extend gigabit Ethernet over a single mode fiber up to 125 km.

SFMFF1329-220 SC, 850 nm, multimode

220 m (721 ft)**

SC, 1310 nm (TX) / 1550 nm (RX)

SM single fiber, 20 km (12.4 miles)*

SFMFF1329-221 SC, 850 nm, multimode

220 m (721 ft)**

SC, 1550 nm (TX) / 1310 nm (RX)

SM single fiber, 20 km (12.4 miles)*

Note: -220 and -221 are designed to be installed in the same network

where one is the local converter and the other is the remote converter.

3

[email protected] -- Click the “Transition Now” link for a live Web chat.

155 Mb/s cable speed -- continued

SFMFF1429-202 SC, 1310 nm single mode

duplex, 20 km (12.4 mi)

SC, 1310 nm (TX)/1550 nm (RX)

SM single fiber, 40 km (24.8 mi)

SFMFF1429-203 SC, 1310 nm single mode

duplex, 20 km (12.4 mi)

SC, 1550 nm (TX)/1310 nm (RX)

SM single fiber, 40 km (24.8 mi)

Note: -202 and -203 are designed to be installed in sequential pairs in

the same network where one is the local converter and the other is the

remote converter.

SFMFF1429-200 SC, 1310 nm single mode

duplex, 20 km (12.4 mi)

SC, 1310 nm (TX)/1550 nm (RX)

SM single fiber, 20 km (12.4 mi)

SFMFF1429-201 SC, 1310 nm single mode

duplex, 20 km (12.4 mi)

SC, 1550 nm (TX)/1310 nm (RX)

SM single fiber, 20 km (12.4 mi)

Part Number Port One - Fiber Optic Port Two - Fiber-Optic

SFMFF1415-200 SC, 1310 nm single mode

duplex, 20 km (12.4 mi)

SC, 1310 nm single mode

duplex, 40 km (24.8 mi)

SFMFF1414-200 SC, 1310 nm single mode

duplex, 20 km (12.4 mi)

SC, 1310 nm single mode

duplex, 20 km (12.4 mi)

Note: -200 and 201 are designed to be installed as a pair in the same

network where one is the local converter and the other is the remote

converter.

The distances listed are the typical maximum cable distance. The actual maximum

cable distances are dependent upon the physical characteristics of the network

installation. SM = single mode, TX = transmit, RX = receive.

4

SFMFFxxxx-2xx

24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

SFMFF1329-210 SC, 1300 nm multimode

duplex, 2 km (1.2 miles)

SC, 1310 nm (TX)/1550 nm (RX)

SM single fiber, 20 km (12.4 mi)

622 Mb/s cable speed:

The models with the -210 extension are for cable speeds of 622 Mb/s and extend

ATM or SONET over single mode fiber up to 60 km.

Port One - Fiber Optic Port Two - Fiber-Optic

SC, 1300 nm multimode

2 km (1.2 miles)

SC, 1310 nm single mode

40 km (24.8 miles)

SC, 1300 nm multimode

2 km (1.2 miles)

SC, 1550 nm single mode

60 km (37.2 miles)

The distances listed are the typical maximum cable distance. The actual maximum

cable distances are dependent upon the physical characteristics of the network

installation.

Part Number

SFMFF1316-210

SFMFF1317-210

SFMFF1717-210 SC, 1550 nm single mode

60 km (37.2 miles)

SC, 1550 nm single mode

60 km (37.2 miles)

SFMFF1329-211 SC, 1300 nm multimode

duplex, 2 km (1.2 miles)

SC, 1550 nm (TX)/1310 nm (RX)

SM single fiber, 20 km (12.4 mi)

[email protected] -- Select the “Transition Now” Link for a Live Web Chat 5

These optional accessories for the SFMFFxxxx-2xx media converter are sold separately

Part Number Description

SPS-1872-SA Optional External Power Supply; 18-72VDC Stand-Alone

Output: 12.6VDC, 1.0 A

SPS-1872-PS Optional External Power Supply; 18-72VDC Piggy-back;

Output: 12.6VDC, 1.0 A

E-MCR-04 12-Slot Media Converter Rack (includes universal internal power

supply) 17 x 15 x 5 in. (432 x 381 x 127 mm)

WMBL Optional Wall Mount Brackets

Length: 4.0 in. (102 mm), Fits converter length: 4.7 in. (119 mm)

WMBV Optional Vertical Mount Bracket; Length: 5.0 in. (127 mm)

WMBD Optional DIN Rail Mount Bracket; Length: 5.0 in. (127 mm)

WMBD-F Optional DIN Rail Mount Bracket (flat); Length: 3.3in. (84 mm)

Optional accessories:

6

SFMFFxxxx-2xx

24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

Installation

Install the fiber cable

CAUTION: Both connections (Port 1 and Port 2) to the SFMFFxxxx-2xx media

converter must be of the same network speed and network protocol. Failure to

observe this caution will cause data transfer to fail.

1. Locate or build IEEE 802.3™ compliant fiber cable with male, two-

stranded TX to RX connectors installed at both ends.

2. Connect the fiber cables to the SFMFFxxxx-2xx media converter as

described:

• Connect the male TX cable connector to the female TX port.

• Connect the male RX cable connector to the female RX port.

3. Connect the fiber cables to the other device (another media converter,

hub, etc.) as described:

• Connect the male TX cable connector to the female RX port.

• Connect the male RX cable connector to the female TX port.

Connectthe fibercable

to the media converter

asshown.

C

onnect the fibercable

C

C

to t

h

e ot

h

er

de

v

i

c

e

(

media co

n

v

er

ter

,

rr

h

u

b,

etc.

)

ass

ho

wn

Connectthe fibercable

to the otherdevice

(media converter,

hub, etc.) asshown

RX

TX

RX

TX

Power the Media Converter

AC:

1. Install the power adapter cord to the back of the media converter.

2. Connect the power adapter plug to AC power.

3. Verify that the media converter is powered by observing the illuminated

LED power indicator light.

DC:

Consult the user’s guide for the Transition Networks SPS1872-xx DC external

power supply for powering the media converter.

7

[email protected] -- Click the “Transition Now” link for a live Web chat.

Delay times

Network worst-case delay through the SFMFFxxxx-2xx media converter:

623 Mbps - 1 Gbps 1 nsec

156 Mbps - 622 Mbps 2 nsec

125-155 Mbps 3 nsec

<125 Mbps 7 nsec

For example in Ethernet environments, ensure that the network conforms to

the 512-bit Rule by using the above numbers to determine the bit-time delay:

semittib4.0-=:tenrehtEspbM521=

(1/125Mbps)

3 nsec 3 nsec

8 nsec

Operation

Status LEDs

Use the status LEDs to monitor media converter operation in the network.

PWR: On = Connection to external power.

LKS: On = Single mode fiber link is up.

LKM: On = Multimode fiber link is up.

Link Pass-Through

The Link Pass-Through feature allows the media converter to monitor RX

(receive) ports for loss of signal. In the event of a loss of an RX signal on one

media port, the media converter will automatically disable the TX (transmit)

signal of the other media port, thus “passing through” the link loss.

LKS LKM

PWR

Multimode

Single Mode

Port 2 Port 1

TX RX

TX RX

4

1

Media

Converter A

Media

Converter B

Near-End

Device

Far-End

Device

original fault

on the co

pp

er link media converter B

disables the co

pp

er lin

k

media converter A

disables the fiber TX link

3

2

media converter B

loses the fiber RX link

8

CFMFFxxxx-2xx

24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

Cable Specifications

The physical characteristics must meet or exceed IEEE 802.3™ specifications.

Single mode fiber (recommended): 9 µm

Multimode fiber (recommended): 62.5/125 µm

Multimode fiber (optional): 100/140, 85/140, 50/125 µm

155 Mb/s fiber specifications

Bit Error Rate: <10-9

SFMFF1313-200 ports 1 & 2 1310 nm single mode

Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm

Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm

Link Budget: 11.0 dB

Part Numbers SFMFF1329-20x:

Port 1: 1300 nm multimode

Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm

Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm

Link Budget: 11.0 dB

Port 2:

SFMFF1329-200 1310 nm (TX) / 1550 nm (RX) single mode

Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm

Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm

Link Budget: 19.0 dB

SFMFF1329-201 1550 nm (TX) / 1310 nm (RX) single mode

Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm

Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm

Link Budget: 19.0 dB

SFMFF1329-202 1310 nm (TX) / 1550 nm (RX) single mode

Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm

Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm

Link Budget: 25.0 dB

SFMFF1329-203 1550 nm (TX) / 1310 nm (RX) single mode

Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm

Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm

Link Budget: 25.0 dB

SFMFF1329-204 1310 nm (TX) / 1550 nm (RX) MM/SM

Fiber-optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm

Fiber-optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm

Link Budget: 11.0 dB

SFMFF1329-205 1550 nm (TX) / 1310 nm (RX) MM/SM

Fiber-optic Transmitter Power: min: -5.0 dBm max: 0.0 dBm

Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -3.0 dBm

Link Budget: 29.0 dB

9

[email protected] -- Click the “Transition Now” link for a live Web chat.

Cable Specifications -- continued

Part Numbers SFMFF1429-20x:

Bit it Error Rate: <10-9

Ports 1 & 2

SFMFF1414-200 1310 nm single mode

Fiber-optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm

Fiber-optic Receiver Sensitivity: min: -31.0 dBm max: -8.0 dBm

Link Budget: 16.0 dB

Port 1: 1310 nm single mode

Fiber Optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm

Fiber Optic Receiver Sensitivity: min: -31.0 dBm max: -8.0 dBm

Link Budget: 16.0 dB

Port 2:

SFMFF1415-200 1310 nm single mode

Fiber-optic Transmitter Power: min: -8.0 dBm max: -2.0 dBm

Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm

Link Budget: 26.0 dB

SFMFF1429-200 1310 nm (TX) / 1550 nm (RX) single mode

Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm

Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -6.0 dBm

Link Budget: 19.0 dB

SFMFF1429-201 1550 nm (TX) / 1310 nm (RX) single mode

Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm

Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm

Link Budget: 19.0 dB

SFMFF1429-202 1310 nm (TX) / 1550 nm (RX) single mode

SFMFF1429-203 1550 nm (TX) / 1310 nm (RX) single mode

Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm

Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm

Link Budget: 25.0 dB

10

CFMFFxxxx-2xx

24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

Cable Specifications -- continued

622 Mb/s Fiber Specifications

Bit Error Rate: <10-9

Port 1: 1300 nm multimode

Fiber-optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm

Fiber-optic Receiver Sensitivity: min: -31.0 dBm max: -8.0 dBm

Link Budget 12.0 dB

Port 2:

SFMFF1316-210 1310 nm single mode

Fiber-optic Transmitter Power: min: -3.0 dBm max: +2.0 dBm

Fiber-optic Receiver Sensitivity: min: -28.0 dBm max: -7.0 dBm

Link Budget: 25.0 dB

SFMFF1317-210 1550 nm multimode

Fiber-optic Transmitter Power: min: -3.0 dBm max: +2.0 dBm

Fiber-optic Receiver Sensitivity: min: -28.0 dBm max: -7.0 dBm

Link Budget: 25.0 dB

SFMFF1717-210 ports 1 and 2 1550 nm single mode

Fiber-optic Transmitter Power: min: -3.0 dBm max: +2.0 dBm

Fiber-optic Receiver Sensitivity: min: -28.0 dBm max: -7.0 dBm

Link Budget: 25.0 dB

11

[email protected] -- Click the “Transition Now” link for a live Web chat.

Cable Specifications - continued

622 Mb/s fber specifications -- continued

Bit Error Rate: <10-9

SFMFF1329-210 1310 nm (TX) / 1550 nm (RX) singlemode

Fiber-optic Transmitter Power: min: -14.0 dBm max: -8.0 dBm

Fiber-optic Receiver Sensitivity: min: -28.0 dBm max: -8.0 dBm

Link Budget: 14.0 dB

SFMFF1329-211 1550 nm (TX) / 1310 nm (RX) singlemode

Fiber-optic Transmitter Power: min: -14.0 dBm max: -8.0 dBm

Fiber-optic Receiver Sensitivity: min: -28.0 dBm max: -8.0 dBm

Link Budget: 14.0 dB

1.25 Gb/s fiber specifications

Bit error rate: <10-12

Port 1: 850 nm multimode

Fiber-optic Transmitter Power: min: -10.0 dBm max: -4.0 dBm

Fiber-optic Receiver Sensitivity: min: -17.0 dBm max: 0.0 dBm

Link Budget: 7.0 dB

Port 2:

SFMFF1313-220 850 nm multimode

Fiber-optic Transmitter Power: min: -10.0 dBm max: -4.0 dBm

Fiber-optic Receiver Sensitivity: min: -17.0 dBm max: 0.0 dBm

Link Budget: 7.0 dB

SFMFF1314-220 1310 nm single mode

Fiber-optic Transmitter Power: min: -13.0 dBm max: -3.0 dBm

Fiber-optic Receiver Sensitivity: min: -20.0 dBm max: -3.0 dBm

Link Budget: 7.0 dB

SFMFF1315-220 1310 nm single mode

Fiber-optic Transmitter Power: min: -5.0 dBm max: 0.0 dBm

Fiber-optic Receiver Sensitivity: min: -20.0 dBm max: -3.0 dBm

Link Budget 15.0 dB

SFMFF1317-220 1550 nm single mode

Fiber-optic Transmitter Power: min: -3.0 dBm max: +2.0 dBm

Fiber-optic Receiver Sensitivity: min: - 23.0 dBm max: -3.0 dBm

Link Budget 20.0 dB

SFMFF1324-220 1300 nm multimode

Fiber-optic Transmitter Power: min: -10.0 dBm max: -3.0 dBm

Fiber-optic Receiver Sensitivity: min: -17.0 dBm max: -3.0 dBm

Link Budget: 7.0 db

SFMFF1335-220 1550 nm single mode

Fiber-optic Transmitter Power: min: 0.0 dBm max: +5.0 dBm

Fiber-optic Receiver Sensitivity: min: -27.0 dBm max: -3.0 dBm

Link Budget: 27.0 db

12

SFMFFxxxx-2xx

24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

1.25 Gb/s fiber specifications -- continued

SFMFF1414-220 Ports 1 & 2 1310 nm single mode

Fiber-optic Transmitter Power: min: -9.5 dBm max: -3.0 dBm

Fiber-optic Receiver Sensitivity: min: - 20 dBm max: -3.0 dBm

Link Budget 10.5 dB

SFMFF1329-220 1310 nm (TX) / 1550 nm (RX) single

mode

Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm

Fiber-optic Receiver Sensitivity: min: -21.0 dBm max: -3.0 dBm

Link Budget: 13.0 db

SFMFF1329-221 1550 nm (TX) / 1310 nm (RX) single

mode

Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm

Fiber-optic Receiver Sensitivity: min: -21.0 dBm max: -3.0 dBm

Link Budget: 13.0 db

13

[email protected] -- Click the “Transition Now” link for a live Web chat.

Technical Specifications

For use with Transition Networks Model SFMFFxxxx-2xx or equivalent

Standards IEEE 802.3™ 1998 Fast Ethernet, ATM, OC-3,

STM-1, HSTR, FDDI

Dimensions 3.25" x 1.0" x 4.7" (83 mm x 25 mm x 119 mm)

Weight 10 oz. (283 g) (approximate)

MTBF 42,590 hours (MIL217F2 V5.0) (MIL-HKBK-217F)

113,749 hours (Bellcore7 V5.0)

Delay 623 Mbps - 1 Gbps: 1 nsec

156 Mbps - 622 Mbps: 2 nsec

125-155 Mbps: 3 nsec

<125 Mbps: 7 nsec

Power Consumption 3.0 watts (typical)

Power Supply 12VDC, 0.5 A (North America)

12VDC, 0.41 A (Europe, Japan, South America)

12VDC, 1.25 A (Australia, N. Z., South Africa, UK)

Environment Tmra*: 0 to 50°C (32 to 122°F )

Storage Temp: -20 to 85°C (-4 to 185°F )

Humidity: 10 to 90%, non condensing

Altitude: 0 to 10,000 feet

Warranty Lifetime

*Manufacturer’s rated ambient temperature.

The information in this user’s guide is subject to change. For the most up-to-date

information on the SFMFFxxxx-2xx media converter, view the user’s guide on-

line at: www.transition.com

NOTE: The chassis version of this media converter is CFMFFxxxx-2xx. For more

information, see the user’s guide on-line at: www.transition.com.

The fiber optic transmitters on this device meet Class I Laser safety requirements

per IEC-825/CDRH standards and complies with 21 CFR1040.10 and

21CFR1040.11.

14

SFMFFxxxx-2xx

24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

Technical Specifications -- continued

Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,

Subchapter J applicable at the date of manufacture.

CAUTION: Visible and Invisible Laser Radiation When Open. Do Not Stare

Into Beam Or View Directly With Optical Instruments.

CAUTION: Use of controls, adjustments or the performance of procedures

otherthan those specified herein may result in hazardous radiation exposure.

Troubleshooting

If the media converter fails, isolate and correct the fault by determining the

answers to the following questions and then taking the indicated action:

1. Is the PWR (power) LED on the media converter illuminated?

NO

• Is the power adapter the proper type of voltage and cycle frequency

for the AC outlet?

•Is the power adapter properly installed in the media converter and in the outlet?

• Contact Technical Support: US/Canada: 1-800-260-1312,

International: 00-1-952-941-7600.

YES

• Proceed to step 2.

2. Is the LKS (link single mode) LED illuminated?

NO

• Check the single mode fiber cables for proper connection.

• Verify that the TX and RX cables on the media converter are

connected to the RX and TX ports, respectively, on the other device.

• Contact Technical Support: US/Canada: 1-800-260-1312,

International: 00-1-952-941-7600.

YES

• Proceed to step 3.

3. Is the LKM (link multimode) LED illuminated?

NO

• Check the multimode fiber cables for proper connection.

• Verify that the TX and RX cables on the media converter are

connected to the RX and TX ports, respectively, on the other device.

• Restart the workstation to restart the initialization process.

• Contact Technical Support: US/Canada: 1-800-260-1312,

International: 00-1-952-941-7600.

YES

• Contact Technical Support: US/Canada: 1-800-260-1312,

International: 00-1-952-941-7600.

15

[email protected] -- Click the “Transition Now” link for a live Web chat.

Contact Us

Technical support

Technical support is available 24 hours a day.

US and Canada: 1-800-260-1312

International: 00-1-952-941-7600

Transition now

Chat live via the Web with Transition Networks Technical Support. Log onto

www.transition.com and click the Transition Now link.

Web-based seminars

Transition Networks provides seminars via live web-based training. Log onto

www.transition.com and click the Learning Center link.

E-Mail

Ask a question anytime by sending an e-mail to our technical support staff.

[email protected]

Address

Transition Networks

10900 Red Circle Drive

Minnetonka, MN 55343, U.S.A.

telephone: 952-941-7600

toll free: 800-526-9267

fax: 952-941-2322

Declaration of Conformity

Name of Mfg: Transition Networks

10900 Red Circle Drive, Minnetonka, MN 55343 U.S.A.

Model: SFMFFxxxx-2xx Series Media Converters

Part Number(s): SFMFF1313-200, SFMFF1329-200, SFMFF1329-201, SFMFF1329-202,

SFMFF1329-204, SFMFF1329-205, SFMFF1414-200, SFMFF1415-200,

SFMFF1429-200, SFMFF1429-201,SFMFF1429-202,SFMFF1429-203,

SFMFF1316-210, SFMFF1317-210, SFMFF1717-210, SFMFF1313-220,

SFMFF1314-220, SFMFF1315-220, SFMFF1317-220, SFMFF1324-220,

SFMFF1335-220, SFMFF1414-220, SFMFF1329-220, SFMFF1329-221

Regulation: EMC Directive 89/336/EEC

Purpose: To declare that the

SFMFFxxxx-2xx

to which this declaration

refers is in conformity with the following standards.

EN 55022:1994 + A1:1995 + A2:1997: EN 55024:1998 + A1-2000

I, the undersigned, hereby declare that the equipment specified above conforms to the above

Directive(s) and Standard(s).

May, 2008_____

Stephen Anderson, Vice-President of Engineering Date

Trademark notice

All registered trademarks and trademarks are the property of their respective owners.

Compliance Information

CE Mark

FCC regulations

This equipment has been tested and found to comply with the limits for a Class A & B digital

device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference, in which case the user will be required to correct the

interference at the user's own expense.

Canadian regulations

This digital apparatus does not exceed the Class A & B limits for radio noise for digital

apparatus set out on the radio interference regulations of the Canadian Department of

Communications.

Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites

applicables aux appareils numériques de la Class A & B prescrites dans le Règlement sur le

brouillage radioélectrique édicté par le ministère des Communications du Canada.

European regulations

Warning This is a Class A product. In a domestic environment this product may cause

radio interference in which case the user may be required to take adequate measures.

Achtung! Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können

bei Betrieb dieses Gerätes Rundfunkstörungen auftreten. In diesem Fäll ist der Benutzer für

Gegenmaßnahmen verantwortlich.

Attention! Ceci est un produit de Classe A. Dans un environment domestique, ce produit

risque de créer des interférences radioélectriques, il appartiendra alors à l'utilsateur de

prende les measures spécifiques appropriées.

Printed in the U.S.A. 33174.Q

Copyright restrictions

© 2001 - 2005 Transition Networks.

All rights reserved. No part of this work may be reproduced or used in any form or by any

means - graphic, electronic, or mechanical - without written permission from Transition

Networks.

In accordance with European Union Directive 2002/96/EC of the European

Parliament and of the Council of 27 January 2003, Transition Networks will

accept post usage returns of this product for proper disposal. The contact

information for this activity can be found in the 'Contact Us' portion of this

document.

CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE

PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in

damage to the public telephone network.

Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-

Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der

Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über

Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer

Konformität.
