Digitus DN-30210 User manual

BLUETOOTH 4.0
TINY USB ADAPTER
User Manual
DN-30210

Content
INSTALLING THE BLUETOOTH STACK .....................................................................................1
PAIRING YOUR BLUETOOTH DEVICES ...................................................................................7
SENDING DATA FROM YOUR PHONE .....................................................................................14
SENDING FILES FROM YOUR PC .............................................................................................16
MAKING YOUR PC DISCOVERABLE........................................................................................19
PRINTING TO A BLUETOOTH PRINTER ..................................................................................20
CONNECTING TO A BLUETOOTH AUDIO................................................................................20
BLUETOOTH SHARE..................................................................................................................22
BLUETOOTH PIM INTERFACE ................................................................................................ 23
BLUETOOTH DIAL UP.............................................................................................................. 24
BLUETOOTH OPTIONS ..............................................................................................................25
BLUETOOTH HARDWARE.........................................................................................................26

1
Installing the Bluetooth Stack
Note: Before you install, please remove any Bluetooth software and
hardware.
The installation & driver CD will automatically activate the autorun installation program
after you insert the disk into your CD drive.
Setup Wizard
Screen – AutoPlay
• Click Run setup.exe to continue installation.
Screen – Preparing installation

2
Screen – Plug Bluetooth device
• Plug Bluetooth device to USB interface
Screen – Continue to installation
Screen – Welcome to install Bluetooth stack

3
Screen – Read End User License Agreement
Screen – Choose Bluetooth installation folder

4
Screen – Ready to installation
Screen – Coping files process

5
Screen – Installation Completed
Screen – Activate Bluetooth device after rebooting

6
Using the Bluetooth Stack
When you plug in your Bluetooth adaptor for the first time Windows will detect it and install
the Bluetooth stack. At this point it will ask you to give your PC a name. This is the name
that other devices will see if you make your PC visible to them. Use a name that is
memorable.
Once the USB adaptor is installed you will see a Bluetooth icon on the task bar at the
bottom right of the screen. If you click on it (both right and left click work the same way),
you will get a list of options.
If you do not have a Bluetooth icon, open up Control Panel -> Hardware & Sound ->
Setup a Bluetooth enabled device. Go to the Options Tab and check the final box on
the page – Show the Bluetooth icon in the notification area

7
Pairing your Bluetooth devices
Pairing is a feature of Bluetooth that allows devices to make secure connections. Although
you do not always need to pair devices to exchange data, if you are likely to send
information between them on a regular basis it is a good idea to do so.
To pair a device using the Bluetooth stack you need to click on the Bluetooth Icon in the
task bar and then select Add a Bluetooth Device.
Click Add. Read the instructions, and once you’ve done these, check the box My device is
set up and ready to be found and press Next.

8
Your PC will then start looking for Bluetooth devices that are discoverable and within
range.This may take up to a minute. You will then be given a list of the devices that
have been found. If your phone or PDA does not appear on the list then it is probably
because it has been set up as hidden or non-discoverable. Dig out the manual (that thing
you didn’t get around to reading) and find out how to make it visible. Then try again by
pressing Search Again.
Once your device has appeared on the list, highlight it and press Next.
To ensure a secure connection between the devices, you will need to enter a passkey on
both the other Bluetooth device and your PC. This is used to generate a secure code that
will be used to authenticate the device and your PC every time they connect to each other.
For phones and PDAs you can make this passkey up yourself. You don’t need to
remember it - it is only ever needed the first time you pair the devices.
To make things easier (and more secure) Windows can generate a random number for
you to use as the passcode. Choose that option (Choose a passkey for me) and press
Next.

9
Windows will display the number for you to enter in your Bluetooth device:
Enter this into your phone or PDA and then press OK. If the pairing is successful you
will see the final screen on your PC, confirming that the devices have been paired.

10
At this stage Windows assigns two COM ports to your Bluetooth device – one for incoming
and one for outgoing connections. You will need to use these if you run communications
programs that connect your PC to your Bluetooth devices. Typical applications include PC
Suite for Nokia and Sony Ericsson handsets and Easy Studio for Samsung handsets.

11
[Windows 7]
To pair a device using the Bluetooth stack you need to click on the Bluetooth Icon in
the task bar and then select Add a Device.
Select the device you want to connect and click Next button

12
Connecting the device you selected.
Windows generates the paring code for security verification.
Click Yes and Next to do paring
Click No and Next to reject paring
Click The device is not displaying a code and Next to paring without showing code.

13
The window shows after paring is done.
Click Close to show current connection status.

14
Sending Data from your phone
The Bluetooth stack protects your PC by making it invisible to other devices. However it still
allows you to send information and files from a Phone or PDA, but you need to initiate the
transfer from your PC.
To do this, click on the Bluetooth icon in the system tray and select Receive a File.
Bluetooth stack now makes your PC discoverable for a limited time, and also enables the
file receive software. Once this is complete it shows the ready to receive screen.

15
Now select the picture or file you want to send from your phone, and select the option to
send it via Bluetooth. You should see a list of devices on your phone.
Note: It only allows access for a limited time. If your phone cannot find your PC it
may be because you’ve taken too long. Check that the PC is still displaying the
Waiting for a connection screen.
It will prompt out “Bluetooth File Transfer Access Authentication” window once your
phone connects to Bluetooth device and ready to send.
Click to grant or deny
Note: Your virus checker may not scan files received via Bluetooth. It is a good idea
to reserve a directory for incoming files and perform a virus check on this directory
before opening them.
Note: This is the only way of receiving files using the Windows XP Bluetooth stack.
If you make the PC permanently discoverable you will still need to initiate File
Receive from the Bluetooth icon.

16
Sending files from your PC
It’s very easy to send files to another Bluetooth device with the Bluetooth stack. Just
right click on the file you want to send, then select Send a File to Bluetooth Device.
You can select a file from your desktop or a file list in Windows Explorer.
Note: You cannot currently send from the File, Send menus in Word, Exchange or
other Office programs.
Windows will display a list of the devices that have been set up already (paired). Select the
device you want to send the file to, or Browse to find other devices. (Other devices must
be discoverable or set to Show to all). Then press Next.

17
Click Browse to choose the file and click Next while you’re ready to send out.
Show up file sending status window.

18
Once the transfer is complete, Windows will finish the Transfer Wizard and display
details of the transfer.
