Digitus DS-41300 User manual

HDMI Amplifier Splitter
１
HDMI Video Splitter
MANUAL
DS-41300
DS-42300
DS-43300

HDMI Amplifier Splitter
２
Table of Contents
1.0 Introduction..........................................................................3
2.0 Specifications.......................................................................4
3.0 Package Contents................................................................4
4.0 Panel Descriptions...............................................................5
5.0 Connection and Operation..................................................6

HDMI Amplifier Splitter
３
DIGITUSHDMI SPLITTER
Dear Customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
1.0 INTRODUCTION
The HDMI Amplifier Splitter are splitter with two, four or eight outputs. They
distribute a HDMI input signal into identical outputs simultaneously. Thereby they
have the ability of buffering and amplifying. Each output can achieve long distance
transmission of HDMI signal of more than 15 meters. But please note, this
depends also on the quality of the cable! The recommended max. length is 15
meter. When two or more products are cascaded, they can create a larger
distribution and longer length. The splitter support HDCP and the real HDMI High
Speed (1.3b). The video amplifier bandwidth can be up to 2.25 Gpbs/225MHz.
The HDMI Splitter offers solutions for HDTV retail and show site, HDTV, STB,
DVD and Projector factory, noise, space and security concerns, data center
control, information distribution, conference room presentation, school and
corporate training environments.
1.1 FEATURES
This HDMI Splitter has many features that enable it to perform in a superior
manner. Among those features you will find:
Easy to Use: Install in seconds, no need of setting.
Cascaded: Large distribution achieved by cascading the HDMI Amplifier
Splitter. (only for 2- and 4-port recommended)
Supports highest video resolution 1080p.
Supports 225MHz/2.25Gbps per channel (6.75Gbps all channel) bandwidth.
Supports 12bit per channel (36bit all channel) deep color.
Supports HDCP.
Supports uncompressed audio such as LPCM
Supports compressed audio such as DTS Digital, Dolby Digital（including
DTS-HD and Dolby True HD）
Support 3D all format, including [email protected]/24Hz,
[email protected]/60Hz/50Hz, bandwidth up to 225MHz.

HDMI Amplifier Splitter
４
2.0 SPECIFICATIONS (DS-41300 / DS-42300 / DS-43300)
Signal Inputs/Output
Input DDC Signal 5 volts p-p (TTL)
Maximum Single Link Range 1920X1080p
Output Video HDMI + HDCP1.0/1.1
Operating Frequency
Vertical Frequency Range 50/60Hz
Video Amplifier Bandwidth 2.25Gbps/225MHz
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Mechanical
Size(L-W-H) 155x70x23mm - DS-41300
155x70x25mm - DS-42300
260x115x27mm - DS-43300
Weight(Net) 260g / 285g / 740G
Warranty
Limited Warranty 2 Year Parts and Labor
Environmental
Operating Temperature 0℃to +70℃
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10℃to +80℃
Storage Humidity 5% to 90 % RH (no condensation)
Power Requirement
External Power Supply DC 5V/2A / 5V/3A / 5V4A
Power consumption (Max) 8W / 12W / 20W
Regulatory Approvals
Converter Unit FCC,CE,UL
Power Supply UL,CE,FCC
Accessories Adapter
AC Power Adapter 1
User Manual 1
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
1) Main unit
2) 5V DC Power Supply.
3) User’s Manual.

HDMI Amplifier Splitter
５
4.0 PANEL DESCRIPTIONS
DS-41300:
Input
Input 1Output1Output2
12 Power
DC/5V
DS-42300:
Output1Output2Output3
432
DC/5V
Input1
Input 1 Power
Output4
DS-43300:

HDMI Amplifier Splitter
６
5.0 CONNECTION AND OPERATION
1) Connect the HDMI input source and output devices into the HDMI Splitter.
(HDMI cables are optional)
*please refer to the connection diagram section.
2) Insert the DC side of 5v power supply into it and then connect the AC side of
the power supply into the wall outlet.
3) Turn on the power.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
