Digitus DC-52101 User manual

Cat5 RS232
EXTENDER
Remote
DC-52101
Local
DC-52101
USER MANUAL
Rev. 1-0
Package Contents-
DC-52101 Extender Local Unit
DC-52101 Extender Remote Unit
1 user manual
2 power adapter DC 9V/300mA
1 20cm Null Modem cable (DB-9 Male to Male)
Any thing missed, please contact with your vendor.
Features
Compatible with all RS-232 protocols.
Full-duplex data communication.
Sends RS-232 data at 230 kbps up to 1000M / 3300 ft.
Pure hardware solution - real time data transfer, no
software conflicts.
No external power required.
Transfer data or files between PCs, equipments.
One CAT-5 cable extension.
Specifications
Function DC-52101-L DC-52101-R
DC-52101 Connector DB-9 Female x1
RJ-45 Connector 1
Cable Distance (Max.) 1000M / 3300ft (UTP)
Communication mode Full-duplex data
Power Supply DC9V/300mA (Min.) spare
Housing Metal
Weight 65 g
Dimensions (LxWxH) mm 92x34x22
FRONT VIEW
1. DC-52101 (DB-9 Female Connector)
-1-
REAR VIEW
1. Power jack
2. CAT.5 (RJ-45 Connector)
Technical Specifications
Supported DC-52101 DCE Signals:
PIN1 N/A
PIN2 Transmit Data
PIN3 Received Data
PIN4 N/A
PIN5 Signal Ground
PIN6 N/A
PIN7 Clear To Send
PIN8 Request To Send
PIN9 N/A
Null modem with full handshaking:
Wiring Information & Coding:
Conductor
Identification RJ45 Pin Assignment Color Code for Conductor
Pair 1 5 White-Blue
4 Blue
Pair 2 1 White-Orange
2 Orange
Pair 3 3 White-Green
6 Green
Pair 4 7 White-Brown
8 Brown
-2-

Trouble shooting
Q: When DC-52101 does not work smoothly.
A1: Use power adapter of DC9V 300mA.
A2: Check the two Baud Rate setting of two ends, they
have to accord.
A3: Refer above sheet and check if it connect RJ45 pair
are correct.
© DIGITUS. All rights reserved.
Trademarks:
All the companies, brand names, and product names
referred to this manual are the trademarks or registered
trademarks belonging to their respective companies.
