For domestic household use only.
INSTRUCTION MANUAL
Heated Throw (Overblanket)
Model: DHDEHT

IMPORTANT
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY
AND RETAINED FOR FUTURE REFERENCE.
Note also the information presented on the appliance
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY
CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE
YOUR WARRANTY
Please read the operating instructions carefully before using your
electric for the rst time and keep them in a safe place.
• Before connecting and switching on the heated throw, ensure that the
voltage indicated on the rating label corresponds to the mains voltage
in your home.
• Do not plug into a powerboard, double adaptor or the like. The power
plug must be inserted directly into the wall power socket.
• Read the instructions carefully, in conjunction with the illustrations,
before using for the rst time.
• If the cord of this heated throw is damaged, unplug and discontinue use
of the product then contact the manufacturer.
• If the supply cord or controller is damaged, it must be completely
replaced by a special cord assembly available from the manufacturer or
its service agent.
• Check that your heated throw is not damaged before switching it on.
• Always unfold or unroll before switching on.
• Failure to observe these instructions will result in overheating. This will
activate the overheat safeguard system, thus leaving the heated throw
inoperative.
• Misuse of this heated throw will invalidate your warranty.
• When storing the heated throw, allow it to cool down before folding.
Fold neatly but not tightly (or rolled) without sharp bends in the heating
elements and store where no other heavy objects will be placed upon it.
• The heated throw should not be used on an adjustable bed or chair.
However, if the heated throw is used on an adjustable bed or chair,
check that the heated throw and cord do not become trapped or rucked
(creased or bunched up), for example, in hinges.
• The heated throw is not to be used by very young children (0-3 years).
Children under the age of three are not to use this appliance due to their
inability to react to overheating.
• The heated throw is not to be used by young children over the age of
three unless the controls have been pre-set by a parent or guardian, or
unless the child has been adequately instructed on how to operate the
controls safely.
2

• This heated throw is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
• This heated throw must not be used by persons insensitive to heat and
other very vulnerable persons who are unable to react to overheating.
• This heated throw is not intended for use by young children or inrm
persons without adequate supervision.
• Children should be supervised to ensure that they do not play with the
appliance.
• Heated throws are intended for human use only. Not for animals and
pets.
• Do not allow pets or animals to lie or chew on this product or on the
electrical cords etc.
• Prolonged application at the highest heat setting can result in skin burns.
• Do not use the heated throw rucked (creased) or folded.
• Keep the controller away from an open window.
• Keep the controller away from external heat sources. i.e. a heater, re
places etc.
• Do not use pins as these may damage the electric wiring.
• The exible supply cord and switch must, as far as practicable, be kept
outside of the heated throw. DO NOT COVER THE CONTROLLER.
• Do not switch the power on if the heated throw is wet or in a folded or
creased state.
• Switch o at the power outlet and remove the plug from the mains
when the heated throw is not in use.
• Do not leave heavy objects on the heated throw, e.g. folded blankets,
suitcases etc. when the heated throw is switched on as this will
trigger the overheat temperature device and render the heaed throw
PERMANENTLY inoperable. This may also invalidate the warranty.
• Do not dry-clean this heated throw. Cleaning liquid may have a damaging
eect on the insulation covering of the heating element. Follow washing
directions located on the heated throw rating label. (Foot end of the
blanket) and in this Instruction Manual.
• Do not use in bed. This heated throw is not to be used as an under or
over blanket while in bed.
• This heated throw is not to be used in bed or while asleep.
• For additional protection, it is strongly recommend that the use of a
residual current device (RCD) with a tripping current not exceeding
30mA be used on the circuit supplying this product. If you are unsure
if your home has this device, please contact your nearest Electrical
Contractor
3

• Always treat electrical appliances with the upmost care. Do not use this
product in any other fashion or for any other purpose other than stated
in these instructions.
• If any abnormality or defect in operation is observed, discontinue its use
immediately and consult the distributor regarding its examination and/
or repair.
• The heated throw should be examined frequently for signs of wear
or damage, either of the blanket, controller or exible cord. If wear is
visible or if any abnormality or defect in operation in the heated throw
is observed, discontinue use immediately and consult a qualied and
registered person for service.
• It is recommended that your heated throw is inspected by a qualied
and registered person after 3 years of use.
• This heated throw is for domestic use only. It is not intended for use in
hospitals or the like.
• Only use the controllers supplied with this blanket.
DO NOT use when
folded or creased
DO NOT pierce with
needles
Not to be used by
very young children
(0-3 years)
4

Exposed to the
weather outdoors
Near water If the power cable
wires are frayed or cut
Where small children
may be left unattended
If an extension
lead may become
overloaded
Where there is risk
of re or close to
a naked ame
Where the power
cable may be
damaged
On a slope or
uneven surface
Where it may be
damaged by
chemicals
If there is a risk
of water falling on
the unit
Where there is a risk
of interference by
foreign objects
This product is not
made for DIY repair
5

Model no. DHDEHT
Colour
Charcoal Grey
Power supply
220-240V~ 50/60Hz
Rated power 160W
Heat settings 6
Safety auto o 3 hours
Overheat protection Y
Cord length 2.4m
Detachable controls Y
Machine washable Y
Dimensions 1800 x 1300
Material Micro Fleece
Specication
• For greater precision, please always refer to the rating label placed on the product.
6

Connecting the Controller
Turn O Power and Remove the Plug from the Power Source
• To t the controller simply hold the socket on the heated throw with one hand and
push the controller plug all the way until it clicks in. There are grooves to guide.
• To remove the controller, hold the corner of the heated throw and pull the controller
plug directly out. Do not pull the controller cable.
• Do not fold, roll or kink the cable. Allow the cable to hang freely.
•
Ensure the cable is not pulled so tight that it bends hard at the heated throw
connector end.
Before First Use
Remove all packaging parts before initial operation.
When the heated throw is used for the rst time, it can smell of plastic, but this disappears
after a short time. Before using for the rst time, ensure that the temperature control
switch is in the OFF position. Use the appliance as a heated throw blanket only. This
appliance is only for warming human bodies.
The best results are expected when the blanket is placed onto a body before switching
it ON. Do not place the switch under a cover.
Pre-heating time takes about 10-30 minutes depending on ambient room temperature.
7

Heated Throw Placement
• Place the heated throw at ensuring that it does not overhang anywhere. Avoid
placing the heated throw where it can become folded or crumpled. The heated
throw may only be switched on when it is at and unfurled. It is recommended to
preheat it for 10 - 30 minutes.
• Once the heated throw has been placed correctly in position, connect the
controller supply plug to a suitable power outlet. Ensure the controller is set to
OFF. Switch the power ON. Select the desired heat setting on the controller. The
indicator lamp on the switch indicates that the blanket is ON.
• Only operate the heated throw with the supplied controller.
CAUTION: The electronic components inside the switch may lead to a slight
warming of the switch when the product is on. Therefore the switch must not be
covered or placed on top of the warming pad when it is in operation.
NOTE: Do not plug into a powerboard, double adaptor or the like. The power plug
must be inserted directly into the wall power socket.
IMPORTANT:DO NOT COVER THE CONTROLLERS AT ANY TIME.
Keep the controller away from external heat sources. i.e. heaters, replaces etc.
8

Using the Controller
IMPORTANT: Only use your heated throw with detachable controller Model CO3. Do
not use any other controller for this blanket.
Heat Settings:
0 = O
1-2 = Low, gentle heat (suitable for continuous use)
3-4 = Medium heat
5-6 = High heat (for preheating the bed only)
1. To select the required heat setting, simple slide the “Temperature Select Knob” up
or down to your desired setting.
2. The selected setting will be indicated with the number in blue on the display screen.
TURN OFF AND UNPLUG THE HEATED THROW WHEN NOT IN USE.
Keep the controller away from external heat sources. i.e. heater, replace etc.
Electrical Field Eect
When using the heated throw, some people may be susceptible to a tingling sensation
when alone or when touching someone else using the blanket.
This “Tingling” feeling is known as an “electric eld eect” and is occasionally known
to happen across all makes and brands of Blankets. It is caused by the current owing
through the element creating an Electromagnetic Field (EMF). Some people are more
susceptible to feeling this EMF tingling sensation than others. This is no cause for
concern and is in no way an electric shock.
9

Operation
Auto O
This controller is tted with a 3 hour count down auto OFF timer, which starts to
countdown from when your heat setting has been selected, and will switch o after
3 hours.
Note: Once a heat setting has been selected and the switch is powered ON, the
countdown timer will not be aected by adjusting the heat level.
The timer will only be reset to 3 hours by sliding the control knob to “0” or after
being powered OFF and then back ON.
When the controller has timed out, the element will turn o. Slide the control knob
to the “O” position to reset.
Preheat
At normal ambient temperature you should allow at least 10-30 minutes on heat
setting “5-6” to preheat.
You may use the heated throw sooner, while it's still warming up, however DO NOT
leave the blanket on setting "5-6" while on your body.
Note: A cold room that has not been used for some time may require a greater
length of time to pre-heat.
Overheat Protection
The heated throw is tted with numerous overheat safeguard systems. This oers
protection against overheating or damage to the elements by disengaging the
power to the elements before overheating hazards occur.
Should there ever be a problem with the heating element in the heated throw, it will
automatically close down the operation and the heated throw will turn o.
The controller must not be covered. The controller has built in protection, so that
if the controller overheats, or the heating element is damaged, it will automatically
close down the operation permanently.
If overheating occurs, the heated throw is permanently damaged and cannot be
used again. A replacement will be needed.
NOTE: Keep the controller away from external heat sources. i.e. heater, replace etc.
10

Cleaning & Care
This heated throw must be washed on the hand wash cycle only (MAX 40°C). Never
use hot water as the blanket may shrink and will void your warranty.
Before washing, rst disconnect the plug connection and remove the plug from the
heated throw. We recommend that the heated throw is washed separately. Ensure
the controllers do not get wet at any time.
Use a mild detergent with dosage according to the manufacturer’s instructions.
Please note that excessive washing will wear out the heated throw blanket. For this
reason, it should only be washed a maximum of 5 times throughout its entire life.
Only use the heated throw when it is completely dry.
IMPORTANT NEVER SWITCH ON THE HEATED THROW TO DRY IT!
Treatment For Localised Soiling
• The area aected should be sponged gently using a natural wool detergent or mild
soap akes dissolved in lukewarm water (40°C Max), followed by two consecutive
spongings using clean, soap-free lukewarm water.
• Lightly compress the treated area between two towels to absorb excess water.
• Do not wring or spin dry the heated throw.
• Refer to the section “Drying” for drying instructions.
• The connections to the blanket must be kept free of moisture
Hand Washing (Recommended)
• Place the heated throw in lukewarm (40°C Max) water (bathtub or large laundry
tub is ideal) mixed with either a natural wool detergent or with mild soap akes.
•
Soak the heated throw for approximately ve minutes, and then gently squeeze
the soapy water through.
• Rinse the heated throw thoroughly with clean lukewarm water until no more suds
are visible and allow water to drain o.
• Refer to the section “Drying” for drying instructions
• With normal use it is recommended that you hand wash your heated throw once
a year.
• Do not wring or spin dry the heated throw.
11

Cleaning & Care
Machine Washing
•
Place the heated throw in the washing machine with either a natural wool detergent
or with mild soap akes.
• Set your machine to the Hand wash/Delicate/Gentle cycle (without Spin dry) and
set the water temperature to warm (40°C Max). Do not wash with HOT water.
• When the cycle has nished, allow water to drain o.
• Refer to the section “Drying” for drying instructions
• Do not wring the heated throw. Do not spin dry.
Drying
• Spread the blanket out on a clean surface (e.g. a large table) to dry in a shady area.
• Your heated throw can also be dried on a clothes line provided the blanket is not
creased or folded.
• Ensure pegs are not used on the element areas of the heated throw if hanging on
the line.
•
Note: The heated throw must be thoroughly dried including controller sockets before
being re-tted to your bed.
• Do not wring the blanket. Do not spin dry.
Storage
When not in use, store the heated throw as follows. Allow it to cool down before folding.
Fold neatly (or rolled) but not tightly without sharp bends in the heating elements and
store where no other heavy objects will be placed upon it.
Store in a dry place where it cannot be damaged.
12

NOTE: There are no user serviceable parts in this blanket or controller/s.
If the unit fails to operate eciently, is broken or other problems arise, unplug and
do not operate. Ask for advice by calling your local after sales service agent or the
Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824 (NZ).
Maintenance
Recycling: Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities. Contact your
local government for information regarding the collection systems
available. If electrical appliances are disposed of in landlls or dumps,
hazardous substances can leak into the ground water, polluting the
food chain and damaging health and well-being.
Warranty
Please refer to the warranty card in the box for warranty information. For any
troubleshooting advice, please contact the relative Customer Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
1340 Ferntree Gully Road, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
13

Customer Care: 1300 556 816
[e-mail]
www.dimplex.com.au
Supplied by Glen Dimplex Australia
1340 Ferntree Gully Road, Scoresby, Victoria, 3179
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without
prior permission in writing of Glen Dimplex Australia.
14
