Dimplex TTRC90 User manual

1
X Y
TTRC90 505 165
TTRS120 505 165
TTRC130 505 230
TTRS175 505 230
TTRC150 760 230
3
2
(a)
(b) (c)
(d)
TTRC90
TTRS120
TTRC130
TTRS175
TTRC150
Watts
60
100
80
120
100
A
615
615
850
850
850
B
530
530
530
530
785
(mm)

Important Safety Advice
WARNING - THE SURFACE OF THIS RADIATOR CAN BE HOT.
In order to be effective the towel rail will get hot,
however momentary contact with any part of it should not cause injury.
DO NOT USE THIS APPLIANCE UNTIL THE WALL BRACKETS ARE
FITTED CORRECTLY.
FOLLOW these instruction carefully.
CAUTION - This appliance is not intended for use by chidren or other
persons without assistance or supervision if their physical, sensory or
mental capabilities prevent them from using it safely. Children should be
supervised to ensure that they do not play with the appliance.
Precautions should be taken to ensure that prolonged
contact with the towel rail cannot occur. Particular care should be taken
in conned areas where accidental prolonged contact with the rail could
be more likely to occur.
This appliance should only be used to dry fabrics washed in water using
commonly available detergents.
IMPORTANT - If the towel rail is to be installed in a place used by the
public, a warning notice should be placed adjacent to the rail advising
that the surface can be hot.
WARNING - This heater must not be located immediately above or below
a xed socket outlet or connection box.
If the mains lead is damaged, it must be replaced by the manufacture or its
service agents or a similary qualied person in order to avoid a hazard.
WARNING - In order to avoid a hazard for very young children, this
appliance should be installed so that the lowest heated rail is at least
600mm above the oor.
General
Your Dimplex electric towel rail has been designed to provide a year-round
service for airing towels and articles of clothing. It is not intended to provide a
sole heating service, but the larger models will take the chill off a normal size
bathroom or toilet.
Your rail will be in one of three sizes and will have either a chrome plated or stove-
enamel nish. The rail wattage has been carefully selected to ensure a suitable
surface temperature is maintained during normal operation conditions. The towel
rail has a sealed electrical element controlled by a pre-set thermostat which will
switch off the rail should it overheat for any reason.
All models are water proof to IPX5.
Use
Your Dimplex towel rail can quite safely be left on continuously if desired without
detrimental effect. When in use however no more than two layers of towelling or
similar fabric should be draped over each rail. It is not advisable to leave very damp
clothes or towels on the rail when it is not in use, as this may affect the nish.
The rail when in use, though hot to the touch, is not hot enough to scorch or burn
towels or clothes. However, soap and detergents remaining in articles after washing
can cause what appear to be scorch marks after being in contact with a hot rail.
Care should be taken therefore to thoroughly rinse out all articles before airing.
Electrical
WARNING – THIS APPLIANCE MUST BE EARTHED
In accordance with wiring regulations a suitable means for disconnection
must be incorporated in the xed wiring.
This heater must be used on an AC ~ supply only and the voltage marked on the
heater must correspond to the supply voltage.
Do not switch the appliance on until properly installed. Please read all the safety
warnings and operating instructions.
If tted in a room containing a bath or shower, to comply with the current I.E.E.
Regulations, a cable outlet will be necessary with the supply to the heater controlled
by a double-pole pull-cord switch having a contact separation of 3mm in each
pole. The body of the switch should be situated as to be normally inaccessible to
a person using a bath or shower.
Oil lled Electric Towel Rails - Model(s): TTRC90, TTRS120, TTRC130, TTRC150 & TTRS175
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Installation
The towel rail must be permanently tted to the wall.
The towel rail must be mounted so that the top rail is horizontal and at least 50mm
below any overhanging surface - see Fig. 1.
Wall mounting
The Wall mounting accessory pack (see Fig. 3) contains:
(a) 4 mounting straps
(b) 4 screws (M4 x 10)
(c) 4 wall mounting brackets
(d) 4 locator pins
Procedure for xing wall brackets
Step 1
Using Dim. X and Dim. Y as a guide for the wall bracket xing dimensions - see
Fig. 2, mark the hole positions for the four xing brackets and drill and plug the
wall to suit.
Note: Allow enough room above and below for the clearance stated. Screw the
four xing brackets securely to the wall - see Fig. 2.
Step 2
Place carefully around the upright bars the four mounting straps at the position
shown - see Fig. 2. (Note the straps must be positioned up tight to the cross bar as
indicated). Securely x them by screwing in place fully the M4 x 10mm screw. Ensure
the brackets are tted with the rear of the straps facing directly backwards.
Step 3
Place the towel rail straps into the wall mounted brackets, secure them with the
locater pins by inserting and giving a quarter turn - see Fig. 3. Check the four
brackets and towel rail are tting horizontally. If not go back to step 2. The straps
can be repositioned to ensure that the towel rail is horizontal when tted to your
wall. If the towel rail cross rails are not level, loosen both straps on either left or
right hand upright bar. Lower the two straps and raise up the towel rail until it is
horizontal, then secure as indicated in step 2 and 3.
Cleaning
The nish on your towel rail can be maintained by occasionally wiping over with
a damp cloth and lightly nishing with a soft dry cloth. This should only be carried
out when the rail is cold. Do not use abrasive cleaning powders as this could
damage the surface nish.
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it should not be disposed
of with household waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice in your country.
After Sales Service
If this product appears damaged when rst received or does not function
correctly contact us by e-mail [email protected] or ring 0844 879 35
87 and we will be able to help. For ROI please phone [phone].
Do Not Return the product in the rst instance as this may delay us providing you
with a satisfactory service.
ACCIDENTAL DAMAGE IS NOT COVERED UNDER THE WARRANTY.
Your product is guaranteed for two years from the date of purchase. Within this
period, we undertake to repair this product free of charge provided it has been
installed and operated in accordance with these instructions.
Should you require assistance with this product please go to www.dimplex.co.uk
and click on “Customer Support” or e-mail us at [email protected]
Alternatively ring our contact centre on 0844 879 35 87 (UK only). This is a Lo-call
no from a BT landline - other providers including mobile phones may charge you
more. For ROI please phone [phone].
To assist you, we will need the following information: model number & serial no
(these can be found on the product), nature of the fault & date of purchase. Please
retain your receipt as proof of purchase. Your rights under this guarantee are
additional to your statutory rights, which in turn are not affected by this guarantee.
Spares can be purchased on line, go to www.dimplex.co.uk/outlet_store
Please retain your receipt as proof of purchase.
08/12152/16 (UK) Issue 16
