Dimplex DCWF50MB User manual

For domestic household use only.
INSTRUCTION MANUAL
HV Wall Fan
Model: DCWF50MB & DCWF75MB

IMPORTANT
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND
RETAINED FOR FUTURE REFERENCE.
Note also the information presented on the appliance
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/
OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY
Please read the operating instructions carefully before using your fan for
the first time and keep them in a safe place.
WARNING – This appliance must not be used in a bathroom.
WARNING – Do not use this appliance in the immediate surroundings of a
bath, a shower or a swimming pool.
• Never immerse the appliance in water or other liquids.
• Operate this unit only on a firm, flat surface.
• Do not place on soft, unstable or non-horizontal/angled surfaces.
• Never operate the appliance if a cable or connector has been damaged,
after appliance malfunction or if the appliance was dropped or is
otherwise damaged.
• If the mains lead is damaged it must only be replaced by the manufacturers
service agent or a similarly qualified person in order to avoid a hazard.
• Please ask a professional service agent to repair the product. Improper
repair may cause danger to users.
• Disconnect the appliance from mains power whenever it is not in use,
before relocating it, and before cleaning.
• Operate the appliance only at the voltage specified on the rating label.
• Only connect the unit to a properly installed and easily accessible socket
so that you can quickly disconnect the plug if necessary.
• Do not connect this product to the mains using an extension lead.
• This fan is only intended for INDOOR RESIDENTIAL applications. This fan
should not be used for commercial or industrial or leisure applications
or in small enclosed spaces.
• Never use the mains lead as a carrying strap or pulling lead.
• To avoid a fire or electrocution hazard, NEVER put the cord near heat
registers, radiator, stoves or heaters.
• DO NOT cover cord with carpeting, throw rugs, runners, or similar
coverings.
• DO NOT route cord under furniture or appliances. Take care to position
the cord away from traffic areas and where it will not be a tripping
hazard.
• DO NOT use the unit near windows or where water collects. Rain and
water collection may lead to a risk of fire or electric shock.
• Only operate this appliance with a minimum of 50cm clearance all
around i.e. away from walls, furniture and overhanging objects such as
curtains or a shelf.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with the
appliance.
• WARNING: To avoid danger of suffocation please remove all packaging
materials particularly plastic and EPS and keep these away from
vulnerable people, children and babies.
• NEVER drop or insert any object or fingers into any openings.
• Do not use the appliance in locations where paint, petrol or other
flammable liquids are used or stored.
• Do not use bug sprays or other flammable cleansers/vapour sprays on
or around the unit.
• Always switch off the unit and take the plug out of the socket:
• If you are not using the unit
• Before you clean or carry out maintenance on the unit
• If a fault occurs
• In the event of an electrical storm.
• Avoid electromagnetic interference. Keep the unit at least 1 metre away
from electrical appliances such as televisions & radios.
3
2

Exposed to the
weather outdoors
Near water If the power cable
wires are frayed or cut
Where small children
may be left unattended
If an extension
lead may become
overloaded
Where there is risk
of fire or close to
a naked flame
Where the power
cable may be
damaged
On a slope or
uneven surface
Where it may be
damaged by
chemicals
If there is a risk
of water falling on
the unit
Where there is a risk
of interference by
foreign objects
This product is not
made for DIY repair
Model no. DCWF50MB DCWF75MB
Colour
Matte Black
Power supply
220-240V~, 50-60Hz
Rated power 180W 285W
Speed settings
19
Modes - -
Timer 1/2/4/8hr
Tilt adjustable head Y
Horizontal oscillation Y
Noise level 73dB(A) 74dB(A)
Weight (net) 8.5kg 13kg
Dimensions (w x d x h) 580 x 380 x 730mm 815 x 380 x 915
Specification
• For greater precision, please always refer to the rating label placed on the product.
Included:
• Front & rear grilles
• Motor housing
• Fan blade
• Long bolt & washer
• Fixing bar
• Mounting bracket
• Remote control (batteries not included)
• Remote cradle (screws not included)
• 2 x fixing bar scews
• 4 x rear grille screws
• 1 x grub screw
• 1 x safety grill screw & bolt
Not included:
• 4 x M8 (35mm) masonry bolts and matching anchors.
• 4 x 8mm inner diameter washers.
• 2 x small remote cradle screws
• 1 x A23 12V battery
5
4

Parts Assembly
Mount to the wall
1. Determine the desired location of the wall fan (must be 1.8m from the floor) and
ensure the wall is structurely sound to cope with the load of the fan.
2. Hold the wall bracket (13) in position, and mark the screw holes with a pencil.
Ensure everything is marked horizontally and aligned before drilling.
3. Drill the holes where the pencil marks are to suit the 4 x fixing anchors (12).
4. Mount the wall bracket (13) on the wall with the 4 x fixing anchors (12)
Assemble the motor to the fixing bar
1. Attached the fan motor (8) to the fixing bar (11) by aligning the motor fixing hole
(9) with the fixing bar hole (10) and use the long bolt and washer supplied to
secure.
2. Place the bottom of the fixing bar (11) into the wall bracket (13) and use the
bracket fixing pole screws (14) to tighten and secure to the bracket.
Attach the rear grille
1. Align the rear grille (5) to motor shaft (6) on the fan motor (8) and ensure the
hole for the safety screw is at the bottom. The 4 screw holes on the front of the
fan motor (8) should line up. Firmly tighten all four rear grille screws (4).
Attach the fan blade
1. Once the rear grille (5) is attached to the fan motor (8), turn the motor shaft
(6) so the flat area is at the top. Slide the fan blade (3) all the way onto the
motor shaft (6) and firmly tighten the grub screw (2) by rotating in a clockwise
direction.
Attach the front grille
1. Once the fan blade is fixed, align the top locking clip on the front grille (1) so it
fixes to the that of the rear grille (5). Lock the side and bottom clips in place.
2. Secure the front & rear grille, by inserting and fixing the safety screw (15) and nut.
TIP: the logo should be horizontal.
Remote
Insert 1 x A23 12V batteries (not included) into the remote.
7. Control panel/
display
9. Motor fixing hole
12. Fixing
anchors
(not included)
11. Fixing bar
8. Fan motor
6. Motor shaft
5. Rear grille
4. Rear grille
screws
3. Fan blade
2. Grub screw
1. Front grille
15. Safety screw
10. Fixing bar hole & long
bolt & washer.
13 Wall bracket
14. Bracket &
fixing bar screws
Control/Display Panel
Remote
4. Rear grille
screws
7
6

Cleaning
Over time, dust can accumulate on the front & rear grille cover and fan blades, which
can affect the fans performance. It is recommended to clean the fan at least once a
month.
1. Turn the unit OFF and disconnect the appliance from the power supply.
2. Remove any dust build up with a soft brush.
3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can be used
for any stubborn marks.
Do not use abrasive sponges, scouring pads, or a stiff brush to clean the fan.
IMPORTANT
The control panel and other parts must not come into contact with water or any
other liquids.
Storage
If not using the unit for an extended period of time. After cleaning please:
• Turn the unit off, unplug and take care of the mains lead & plug.
• NB- Prolonged exposure to direct sunlight will discolour the enclosure.
The wall fan can be operated by the control panel, or the remote control.
1. Ensure the wall fan is plugged in and the power supplier is on.
2. Turn the fan ON by pressing the 'ON-OFF' button.
3. To adjust the speed, press the '+' or '-' button. The selected speed setting will
show on the display panel.
4. If oscillation is required, press the SWING button, to start & stop oscillation.
5. The MEMORY button memorise the previous speed setting when OFF.
6. There are 4 timer settings, however they can only be operated via the remote
control. Press the correspending timer button '1H', '2H', '4H' or '8H' to start the
desired time setting. The timer chosen, will display on the display panel. Note:
Only the 4 x settings can be selected, the time doesnt accummulate. The timer
can't be cancelled once activated, unless turned OFF manually.
7. Turn the fan OFF bypressing the 'ON-OFF' button.
Operation
9
8

If the unit fails to operate efficiently, is broken or other problems arise, unplug and
do not operate. Ask for advice by calling your local after sales service agent or the
Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824 (NZ).
Maintenance
Recycling: Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities. Contact your
local government for information regarding the collection systems
available. If electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the ground water, polluting the
food chain and damaging health and well-being.
Warranty
Please refer to the warranty card in the box for warranty information. For any
troubleshooting advice, please contact the relative Customer Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
11
10

Customer Care: 1300 556 816
[e-mail]
www.dimplex.com.au
Supplied by Glen Dimplex Australia
8 Lakeview Drive, Scoresby, Victoria, 3179
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without
prior permission in writing of Glen Dimplex Australia.
DCWF50MB & DCWF75MB REV1
