Dimplex DCACM20 User manual

DCACM20
Air Circulator w/Manual
Controls
www.dimplex.com.au
INSTRUCTION MANUAL
PLEASE READ THE INSTRUCTION MANUAL CAREFULLY BEFORE USING THE UNIT.

www.dimplex.com.au
CONTENTS
WARNINGS AND PRECAUTIONS 1
STRUCTURE 3
OPERATION 4
CLEANING AND MAINTENANCE 6
TECHNICAL REFERENCE DATA 7
WARRANTY 7

1
Warnings
• Never place the unit near gas appliances, ames or
• ammable liquids.
• Never hit or shake the unit. Doing so may cause damage.
• Never cover or obstruct the air inlet or outlet.
• Doing so may cause overheating.
• Never spray water on or place the unit near water.
• Doing so may cause electric shock.
• Never connect other appliances to the same power outlet.
• Never connect or disconnect the power plug with wet hands.
• Doing so may cause electric shock.
• Never insert ngers or objects through the guards when the unit is
operating.
• Never use an extension cord.
• Always have a professional technician, manufacturer or service agent
replace a damaged power cord.
Precautions
• This appliance is for indoor use only.
• Do not use the unit near windows or where water collects. Rain and
water collection may lead to a risk of re or electric shock.
• Do not place the unit in a damp place or where humidity is high (such
as a bathroom).
• Do not leave the unit operating while unattended.
• Do not place the unit in direct sunlight to avoid surface discolouration.
WARNINGS & PRECAUTIONS

2
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of ex-
perience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure they do not play with the appli-
ance.
• Avoid electromagnetic interference. Keep the unit at least 1 metre away
from electric appliances such as televisions and radios.
• Avoid scratching and damaging the surface. Do not use chemical sol-
vents (i.e. Benzene, alcohol) to clean the surface.
• Place the unit on a stable surface when operating.
• Unplug the unit before cleaning, servicing or maintenance.
• Electrical connections must be in accordance with National or
• Local Codes.
• The rear of the unit must be at least 50cm away from the wall.
• If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
WARNINGS & PRECAUTIONS

3
1. Base
2. Dial
3. Setting panel
4. Brand badge
5. Front grille
6. Pivot point – oscillation
7. Rear housing
8. Fan body
9. Power cord
STRUCTURE

4
DISPLAY / CONTROL PANEL
OPERATION
OFF
When the dial is aligned to the ‘OFF’ marker, the unit will be/turn off. Turn the
dial left or right of this marker, and the unit will turn on.
LOW SPEED
Turn the dial one click right from the OFF position to operate in Low Speed.
LOW SPEED + OSCILLATION
When operating in low speed, turn the dial right once more to start
oscillation.
OFF
OFF Low speed
High speed
Low speed +
oscillation
High speed +
oscillation

5
OPERATION
HIGH Speed
Turn the dial one click left from the OFF position to operate in High Speed.
HIGH SPEED + OSCILLATION
When operating in high speed, turn the dial left once more to start
oscillation.
90° VERTICAL OSCILLATION
Tilt the fan head to achieve up to 90° angled oscillation. Ensure the fan is
OFF when adjusting the fan head position.
OPERATION
1. Remove the unit from its packaging
2. Plug the unit into a power outlet.
3. Turn the dial to either Low or High Speed to turn the unit on.
4. Turn the dial either far left or far right to being oscillation.
5. To switch the unit off at any time, turn the dial to the “Off” position.

6
CLEANING & MAINTENANCE
CLEANING
Over time, dust can accumulate on the rear grille cover and fan blades,
which can affect the fans performance. It is recommended to clean the fan
at least once a month.
1. Turn the unit OFF and disconnect the appliance from the power supply.
2. Remove any dust build up with a soft brush.
3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can
be used for any stubborn marks.
IMPORTANT
The control panel and other parts must not come into contact with water or
any other liquids.
• Do not dispose of electrical appliances as unsorted municipal waste.
• Use separate collection facilities.
• Contact your local government for information regarding the collection
systems available.
• If electrical appliances are disposed of in landlls or dumps, hazardous
substances can leak into the ground water, polluting the food chain and
damaging health and well-being.
MAINTENANCE
If the unit fails to operate efciently, is broken or other problems arise,
unplug and do not operate. Ask for advice by calling your local after sales
service agent or the Customer Care Centre on 1300 556 816 (AU) / 0800
666 2824 (NZ).

7
TECHNICAL & REFERENCE DATA
WARRANTY
The warranty period is 12 months from the date of purchase. For service
advice, please contact the Customer Care Centre on 1300 556 816 (AU) /
0800 666 2824 (NZ).
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
1340 Ferntree Gully Road, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
MODEL NO. DCACM20
Rated Power 45W
Voltage/Frequency 220-240V/50Hz
Net Weight 1.9kg
Dimensions Body (HxWxDmm) 320 x 225 x 215
Dimensions Packaging (HxWxDmm) 330 x 240 x 240
