Dimplex DCAC20T User manual

For domestic household use only.
INSTRUCTION MANUAL
DC Air Circulator
Model: DCAC20T

CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE
INJURY AND/OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY
Please read the operating instructions carefully before using your air circulator for the
first time and keep them in a safe place.
WARNING – This appliance must not be used in a bathroom.
WARNING – Do not use this appliance in the immediate surroundings of a bath, a
shower or a swimming pool.
• If the supply cord is damaged it must only be replaced by the manufacturers service
agent or a similarly qualified person in order to avoid a hazard.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety.
• Children should be supervised to ensure they do not play with the appliance.
• Prior to cleaning or other maintenance, the appliance must be disconnected from
the supply mains.
• Never immerse the appliance in water or other liquids.
• Do not place on soft, unstable or non-horizontal/angled surfaces.
• Never operate the appliance if a cable or connector has been damaged, after
appliance malfunction or if the appliance was dropped or is otherwise damaged.
• If the mains lead is damaged it must only be replaced by the manufacturers service
agent or a similarly qualified person in order to avoid a hazard.
• Please ask a professional service agent to repair the product. Improper repair may
cause danger to users.
• Disconnect the appliance from mains power whenever it is not in use, before
relocating it, and before cleaning.
• Operate the appliance only at the voltage specified on the rating label.
• Only connect the unit to a properly installed and easily accessible socket so that
you can quickly disconnect the plug if necessary.
• Do not connect this product to the mains using an extension lead.
• This air circulator is only intended for INDOOR RESIDENTIAL applications. This air
circulator should not be used for commercial or industrial or leisure applications or
in small enclosed spaces.
• Never use the mains lead as a carrying strap or pulling lead.
• To avoid a fire or electrocution hazard, NEVER put the cord near heat registers,
radiator, stoves or heaters.
IMPORTANT
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND
RETAINED FOR FUTURE REFERENCE.
Note also the information presented on the appliance
2

• DO NOT cover cord with carpeting, throw rugs, runners, or similar coverings.
• DO NOT route cord under furniture or appliances. Take care to position the cord
away from traffic areas and where it will not be a tripping hazard.
• DO NOT use the unit near windows or where water collects. Rain and water collection
may lead to a risk of fire or electric shock.
• WARNING - To avoid danger of suffocation please remove all packaging materials
particularly plastic and EPS and keep these away from vulnerable people, children
and babies.
• NEVER drop or insert any object or fingers into any openings.
• Do not use the appliance in locations where paint, petrol or other flammable liquids
are used or stored.
• Do not use bug sprays or other flammable cleansers/vapour sprays on or around
the unit.
• Always switch off the unit and take the plug out of the socket:
• If you are not using the unit
• Before you clean or carry out maintenance on the unit
• If a fault occurs
• In the event of an electrical storm.
• Avoid electromagnetic interference. Keep the unit at least 1 metre away from
electrical appliances such as televisions & radios.
• Use this appliance on a horizontal and stable surface.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Children shall not plug in, regulate and clean the appliance or perform user
maintenance.
• DO NOT use this appliance with an extension lead or power board.
3

WARNING - KEEP BATTERIES OUT OF REACH OF CHILDREN
• Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical
burns and potential perforation of the oesophagus.
• If you suspect your child has swallowed or inserted a button battery immediately
call the 24-hour Poisons Information Centre on 13 11 26 (in Australia) or 0800 764
766 (in New Zealand) for fast, expert advice.
• Examine devices and make sure the battery compartment is correctly secured,
e.g. that the screw or other mechanical fastener is tightened. Do not use if the
compartment is not secure.
• Dispose of used button batteries immediately and safely. Flat batteries can still be
dangerous.
• Do not ingest battery, Chemical Burn Hazard.
• This product contains a coin/button cell battery. If the coin/button cell battery is
swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
• Keep new and used batteries away from children.
• If the battery compartment does not close securely, stop using the product and
keep it away from children. If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate medical attention.
• The batteries contain materials, which are hazardous to the environment; they must
be removed from the appliance before it is scrapped and they are disposed of safely.
4

Exposed to the
weather outdoors
Near water If the power cable
wires are frayed or cut
Where small children
may be left unattended
No extension leads or
power boards
Where there is risk
of fire or close to
a naked flame
Where the power
cable may be
damaged
On a slope or
uneven surface
Where it may be
damaged by
chemicals
If there is a risk
of water falling on
the unit
Where there is a risk
of interference by
foreign objects
This product is not
made for DIY repair
5

Model no. DCAC20T
Power supply 220-240V~, 50Hz
Rated power
26W
Speed settings
32
Timer 12 hours
Air speed 6.5m/s
Vertical oscillation 80
o
Horizontal oscillation 360
o
Noise level (MAX)
56dB(A)
Weight (net) 2.5kg
Dimensions (w x d x h) 255 x 237 x 374mm
Specification
• For greater precision, please always refer to the rating label placed on the product.
6

How It Works
In contrast to a traditional fan which brings only cooling benefits when directly facing
you; an air circulator works for any season, keeping the air in motion and making the
entire room more comfortable to be in.
Most fans simply lack the aerodynamics to keep the air in the room in motion. As
opposed to blowing air directly in contact with it, our Dimplex air circulators create a
3D oscillating draught in the form of an invisible jet stream.
This jet stream helps maintain a constant room temperature by ridding the room of
cold and warm spots. It also clears stuffy atmospheres by circulating stale air with fresh
air from an open window.
Air circulators are the safe, all-year-round temperature regulation solution you’ve been
looking for.
Where To Position
During Summer, pointing the air circulator towards a wall halfway between the floor and
the ceiling, as well as using the highest setting, will set up a high speed air circulation
pattern.
This will cool down the room in an efficient manner. Pointing towards your air conditioner
will help distribute the cool air faster, saving time and energy; essentially Turbo boosting
your A/C.
During Winter, the use of a heater alone produces warm air that rises naturally to the
ceiling.
By pointing the air circulator upwards, and utilising the lowest speed setting, the hot air
will circulate with the cooler air near the floor, resulting in a more even room temperature.
7

Parts
(1) Fan Head
(2) Front Grille
(3) Back Grille
(4) Speed Dial
(5) Front Cover
(6) Upper Base Cover
(7) Rotating Bracket
(8) Display Window
(9) Rear Shell
(10) Front Shell
(11) Bottom Cover
3
5
4
2
1
6
9
7
8
10
11
8

Control Panel & LED Display
Remote Control
On/Off
Wind Mode
Screen Off
Left/Right
Swing
Up/Down
Swing
Timer
On/Off
Decrease Fan Speed Increase Fan Speed
Left/Right Swing Up/Down Swing
Mode
Timer
Display On/Off
Fan
Timer
Vertical Swing
Sleep Wind
Horizontal Swing
Natural Wind
On/Off
LED Display
9

Operation
ON/OFF
After the power is turned on, the device will beep twice and enter standby state. In
standby state, all functions and displays will be off, and all buttons aside from the
On/Off button are invalid. In standby state, pressing the On/Off button once will
turn on the device. By default the power indicator light and the fan LED display
showing 10 levels of wind speed will turn on. All other functions remain off. To turn
the device off or back into standby state, press the On/Off button once more. If the
left/right function is turned on, the device will automatically return to centre point
before switching off.
SPEED DIAL
When the device is switched on, you can set the wind speed between 1-32 by
adjusting the speed dial. By rotating the dial to the right, the wind speed will
gradually increase. When the maximum wind speed is reached (32), a buzzer will
beep. If you keep rotating to the right after reaching max speed, the speed will no
longer increase and the buzzer will beep continuously. By turning the dial to the
left, the wind speed will gradually decrease. Once you reach the minimum wind
speed, the device will beep, and do so continuously. 5 Seconds after setting your
desired speed, the display will show the current wind speed. The default operation
of the speed dial is to change wind speed, however if you press the Timer button,
and enter the desired timer setting, the speed dial is also used to adjust the timer
setting.
TIMER SETTING
Press the Timer button to begin setting the timer on your device. When you press
this button, 'h' will light up on the LED display. Use the speed dial to choose the
timer setting between 0-12 hours. When adjusting the timer, rotating the dial to the
right will gradually increase the time length. When it reaches the maximum value (12
hours) the device will beep, and will do so continuously. Rotating the dial to the left
will gradually decrease the time length, and the device will beep, when you reach
the minimum timer setting. After entering the timer setting mode, the previous timer
setting will not yet be changed. The timer will only be reset when the timer value
is changed by the speed dial, and will take effect after pressing the timer button to
exit the function. After 5 seconds, the desired time setting will be displayed on the
LED screen. Once the timer is finished, the device will immediately enter standby
state. You can also use this function to schedule the device to turn on. Press the
Timer button when the device is in standby state, and follow the above process to
set a time to activate this function.
10

Operation
WIND MODE
By default, when the wind mode button is first pressed, the device will automatically
be on normal wind mode. Press the button again to switch modes. This will switch
the device wind modes in the following sequence: Normal - Natural - Sleep - Normal
etc. The corresponding indicator shows the function. The normal wind speed mode
has no indicator. When you switch the wind mode to natural, the LED display will
show a leaf. In natural wind mode, the 32 speeds are divided into three groups. 1-10
is low level natural wind speed, 11-20 is medium level and 21-32 is high level. The
display shows 10 levels under low level, 20 under medium and all 32 under high level.
In natural mode, the encoder switch can only select level 10, level 20 or level 32 wind
speed. When you switch the device to sleep mode, the LED display shows a moon.
In sleep mode, the encoder switch can only select level 10, level 20 or level 32.
VERTICAL SWING
Press the Up/Down Swing button to set off the vertical swing functionality. This
device will oscillate up to 80° vertically. When this function is switched on, the LED
display will show the vertical arrow symbol.
HORIZONTAL SWING
Press the Left/Right swing button to set of the horizontal swing functionality. This
device can oscillate up to 360° horizontally. You can select how much swing you
desire by pressing the button multiple times. You can choose between 30°, 90°, 180°
or the full 360°. 30° is the default setting. The LED display will show the desired
angle setting, as well as the side to side arrow icon.
SCREEN OFF
Press the Screen Off button to turn the display off whilst in operation. This will
ensure all indicator lights are switched off.
OTHER
Power Memory Function: By pressing the On/Off button in standby state, your
device will remember the state it was operating in before it was shut off, and
automatically return to these settings. Please note however, the timer function will
always need to be reset.
Display Brightness: After the device has been working for 1 minute, continuously,
the brightness of the display will be reduced to 1/3 of the normal brightness level to
reduce glare at night.
11

Over time, dust can accumulate on the grille covers, filter (if applicable) and fan
blades, which can affect the fans performance. It is recommended to clean the fan at
least once a month.
1. Turn the unit OFF and disconnect the appliance from the power supply.
2. Remove any dust build up with a soft brush.
3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can be used
for any stubborn marks.
IMPORTANT
The control panel and other parts must not come into contact with water or any
other liquids.
Storage
If not using the unit for an extended period of time. After cleaning please:
• Turn the unit off, unplug and take care of the mains lead & plug.
•
Cover the unit and store it upright in a location where it will not receive direct
sunlight. NB- Prolonged exposure to direct sunlight will discolour the outer casing.
Cleaning
12

If the unit fails to operate efficiently, is broken or other problems arise, unplug and
do not operate. Ask for advice by calling your local after sales service agent or the
Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824 (NZ).
Maintenance
Recycling: Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities. Contact your
local government for information regarding the collection systems
available. If electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the ground water, polluting the
food chain and damaging health and well-being.
Warranty
Please refer to the warranty card in the box for warranty information. For any
troubleshooting advice, please contact the relative Customer Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
13

14

15

Customer Care: 1300 556 816
[e-mail]
www.dimplex.com.au
Supplied by Glen Dimplex Australia
8 Lakeview Drive, Scoresby, Victoria, 3179
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without
prior permission in writing of Glen Dimplex Australia.
DCAC20T REV1
16
