Dimplex DFI2309 User manual

PRACTICAL USER’S GUIDE
FOR THE
DIMPLEX ELECTRIC FIREPLACE
Valued Customer,
We are pleased that you have chosen to purchase an electric fireplace
manufactured by Dimplex North America Ltd.
Over the years, valuable memories will occur around the warmth and comfort
of your hearth. Thank you for allowing our product to be the backdrop for
those special moments.
7205650100REV03

CONTENTS
PAGE 1 Important Instructions
PAGE 2 Installation
PAGE 3 Operation
PAGE 4 Maintenance
PAGE 6 Remote Control
PAGE 7 Warranty

QUICK REFERENCE GUIDE
FOR THE DIMPLEX ELECTRIC FIREPLACE
1. Prior to the first use of the fireplace verify the following:
• Are the circuit breakers for the fireplace on?
• Are the light bulbs in your fireplace loose? (to check, follow the
instructions for replacing the light bulbs under the maintenance
section of this manual)
2. The heater on your fireplace may emit a slight, harmless odor when
first used. This odor is a normal condition caused by the initial
heating of internal heater parts.
3. The information regarding the model of your fireplace can be found
on the rating plate located on the top or the back of the fireplace.
4. If you have any technical questions regarding the operation of your
fireplace, or require service for your fireplace contact Dimplex North
America customer service at 1-888-DIMPLEX (1-888-346-7539).

IMPORTANT INSTRUCTIONS
PLEASE RETAIN THIS USER’S GUIDE FOR FUTURE REFERENCE
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
1. Read all instructions before using this fireplace.
2. This fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. The
trim around the heater outlet becomes hot during heater operation. Keep combustible
materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m)
from the front of the unit.
3. Extreme caution is necessary when any heater is used by or near children or invalids and
whenever the fireplace is left operating and unattended.
4. Always unplug the fireplace when not in use.
5. Do not operate any fireplace with a damaged cord, plug, or if the heater has malfunctioned, the
fireplace has been dropped or damaged in any manner.
6. Do not use outdoors.
7. This fireplace is not intended for use in bathrooms, laundry areas and similar indoor locations.
8. Do not install the fireplace directly on carpet or a similar surface, which may restrict air
circulation beneath the unit.
9. Do not run the cord under carpeting. Do not cover cord with throw rugs, runners, or the like.
Arrange cord away from traffic area and where it will not be tripped over.
10. To disconnect the fireplace, turn the controls off, then remove the plug from the outlet.
11. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may
cause an electric shock or fire, or damage to the heater.
12. To prevent a possible fire, do not block air intake or exhaust in any manner.
13. All electrical heaters have hot and arching or sparking parts inside. Do not use in areas where
gasoline, paint, or flammable liquids are used or stored or where the unit will be exposed to
flammable vapors.
14. Do not modify this fireplace. Use it only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock or injury to persons.
15. To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than
the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper
outlet. Do not change the plug in any way.
Avoid the use of an extension cord. Extension cords may overheat and cause a risk of fire. If
you must use an extension cord, the cord must be No. 16 AWG minimum size and rated no less
than 1875 watts.
16. Do not burn wood or other materials in this fireplace.
17. Do not strike fireplace glass.
18. Always use a certified electrician should new circuits or outlets be required.
19. Always use properly grounded, fused and polarized outlets.
20. Disconnect all power supply before performing any cleaning, maintenance or relocation of the
fireplace.
21. When transporting or storing the fireplace and cord, keep in a dry place, free from excessive
vibration and store so as to avoid damage.
NOTE: Procedures and techniques that are considered important enough to emphasize.
CAUTION: Procedures and techniques, which, if not carefully followed, will result in damage
to the equipment.
WARNING: Procedures and techniques, which, if not carefully followed, will expose the user
to the risk of fire, serious injury, illness or death.
SAVE THESE INSTRUCTION 1

INSTALLATION
Existing Fireplace
(Applies only to DFI2309)
WARNING: The electric masonry insert must be installed in an opening with the
MINIMUM dimensions 24” (61cm) wide, 21.5” (54.6cm) high and 12” (30.5cm) deep.
NOTE: To prevent personal injury always use a licensed electrician to install new outlets or
circuits.
NOTE: To prevent personal injury always use a professional to cap the chimney flue or cut a
hole in the existing fireplace for wiring.
NOTE: If returning your fireplace to its original use (ex. wood burning), it should be inspected
by the local building department prior to use to reduce the risk of fire and personal injury.
1. Seal all drafts and vents with non-fibrous insulation materials to prevent chimney debris
from falling onto the fireplace insert. Do not install into an existing fireplace that is prone
to dampness.
2. Cap the top of the chimney flue and close damper (if applicable) to prevent rain from
entering.
3. Plan your electric power supply. A 15 amp, 120 volt circuit is required. A dedicated
circuit is preferred but not essential in all cases. A dedicated circuit will be required if
after installation, the circuit breaker or fuse trips. Additional appliances may exceed the
current rating of the circuit breaker or fuse.
4. Install an outlet into the existing fireplace. If an outlet is not installed into the existing
fireplace the power cord can also run along the front of the hearth to an outlet near the
fireplace.
5. Ensure the insert power is off. (SEE OPERATION PAGE 3). Plug the masonry insert
into the outlet and slide the unit into the existing fireplace.
6. Push the insert into the firebox and center within the opening. Adjust the four feet on
the bottom of the insert by turning counter clockwise to raise and clockwise to lower so
that is level with the existing fireplace hearth.
7. Install the trim kit onto the fireplace insert (if applicable) and push the trim and or insert
back until the trim is flat against the finished wall.
WARNING:
The fireplace insert can be used with existing fireplace and screens.
Due to the heat produced from the heater, existing fireplace screens must provide
adequate air flow in front of the unit. Do not use existing fireplace doors that close,
sealing off the fireplace insert from the room. If installed behind bi-fold doors, doors
must be open to allow heat to be exhausted.
2

OPERATION
Resetting the temperature cutoff switch
The heater is protected with a safety device to prevent overheating. Should the heater
overheat, an automatic cut out will turn the heater off and it will not come back on without
being reset. It can be reset by switching the ON/OFF SWITCH to OFF and waiting 5
minutes before switching the unit back on.
Caution
If you need to continuously reset the heater, unplug the unit and call your local dealer.
Main ON/OFF Flame ON/OFF switch
The ON/OFF switch supplies power to all unit functions. When this switch is in the ON
position the flame effect operates without heat.
Low heat switch
The LOW HEAT ON/OFF SWITCH supplies power to the heater fan and the heater
element. When the switch is in the ON position the heater operates on LOW.
High heat switch
The HIGH HEAT ON/OFF SWITCH supplies power to the heater fan and the heater
element, when the switch is in the ON position the heater operates on HIGH. The LOW
HEAT ON/OFF SWITCH must also be in the ON position for the high heat setting to
operate.
3
MAIN ON/OFF
HIGH HEAT
LOW HEAT

MAINTENANCE
Light Bulb Replacement
The light bulbs need to be replaced when you notice a dark section of the
flame. There are two bulbs under the log set which generate the flames and
embers.
Warning
Disconnect the power before attempting any maintenance or cleaning to
reduce the risk of fire, electric shock or damage to persons.
Warning
Ensure the power cord is not installed so that it is pinched or against a sharp
edge and ensure that the power cord is stored or secured to avoid tripping or
snagging to reduce the risk of fire, electric shock or injury to persons.
Construction and electrical outlet wiring must comply with local building codes
and other applicable regulations to reduce the risk of fire, electric shock and
injury to persons.
Do not attempt to wire your own new outlets or circuits. To reduce the risk of
fire, electric shock or injury to persons, always use a licensed electrician.
Cleaning
Glass
The glass is cleaned in the factory during the assembly operation. During
shipment, installation, handling, etc., the glass surface may collect dust
particles, these can be removed by buffing lightly with a clean dry cloth.
To remove fingerprints or other marks, the glass can be cleaned with a damp
cloth using a good quality household glass cleaner. The glass should be
completely dried with a lint free cloth or paper towel. Do not use abrasive
cleaners on glass surface or spray liquids directly onto any surface.
Surface
Use warm water only to clean painted surfaces. Do not use abrasive cleaners
on glass surface or spray liquids directly onto any surface.
Unit storage
Store the unit when not in use in a dry, dust free location with the power cord
properly secured.
4

Warning:
Allow at least 10 minutes for the light bulbs and heater to cool before
attempting any maintenance or cleaning.
Bulb Requirements
Quantity 2 clear chandelier or candelabra bulbs with an E-12 (small) socket
base, 60 watt rating. Example: GE 60BC or Philips 60CTC
Tools required:
Philips screwdriver
1. Remove the fireplace trim.
2. With a Philips screwdriver remove the two outer screws from the log
grate.
3. Slide the light assembly out of the insert by pulling the log grate
until the light assembly reaches the stop (approximately 2”)
4. Remove the log set by lifting straight up.
5. Examine the bulb(s) to determine which bulb(s) require replacement.
6. Unscrew the bulbs counter clockwise.
7. Insert new bulbs.
8. Replace the log set into the insert.
9. Slide the light assembly back into the insert.
10. Install the two outer screws into the log grate.
11. Reinstall the fireplace trim.
5

REMOTE CONTROL INSTRUCTIONS
(Not included with DFB4004/DFP5722ML/DFP5744CM)
1. Plug fireplace insert into the outlet located on the side of the receiver.
2. Plug receiver into the wall outlet.
3. Install a 9 volt battery into the transmitter.
Note
• Fireplace insert main switch must be in the ON position prior to using the
Remote Control.
• ON/OFF Remote Control works up to 50’ (15.4 m) away.
• ON/OFF Remote Control may be used to control most other electrical
devices including T.V.’s, stereos and lamps.
• For indoor use in dry areas only
• For use on electrical devices with 15 amp resistive load or 1/3 HP
inductive load
• 120 volt AC only
6
RECEIVER TRANSMITTER

ONE YEAR LIMITED WARRANTY
Products to which this limited warranty applies
This limited warranty applies to the following models of your newly purchased Dimplex electric
fireplace 6901470100, DFI2309 and to newly purchased Dimplex fireplace surrounds
(mantels) and trims. This limited warranty applies only to purchases made in any province of
Canada except for Yukon Territory, Nunavut, or Northwest Territories or in any of the 50
States of the USA (and the District of Columbia) except for Hawaii and Alaska. This limited
warranty applies to the original purchaser of the product only and is not transferable.
Products excluded from this limited warranty
Light bulbs are not covered by this limited warranty and are the sole responsibility of the
owner/purchaser. Products purchased in Yukon Territory, Nunavut, Northwest Territories,
Hawaii, or Alaska are not covered by this limited warranty. Products purchased in these
States, provinces, or territories are sold AS IS without warranty or condition of any kind
(including, without limitation, any implied warranties or conditions of merchantability or fitness
for a particular purpose) and the entire risk of as to the quality and performance of the
products is with the purchaser, and in the event of a defect the purchaser assumes the entire
cost of all necessary servicing or repair.
What this limited warranty covers and for how long
Products covered by this limited warranty have been tested and inspected prior to shipment
and, subject to the provisions of this warranty, Dimplex warrants such products to be free from
defects in material and workmanship for a period of 12 months from the date of the first
purchase of such product.
The limited 12 month warranty period also applies to any implied warranties that may exist
under applicable law. Some jurisdictions do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to the purchaser.
What this limited warranty does not cover
This limited warranty does not apply to products that have been repaired (except by Dimplex or
its authorized service representatives) or otherwise altered. This limited warranty does further
not apply to defects resulting from misuse, abuse, accident, neglect, incorrect installation,
improper maintenance or handling, or operation with an incorrect power source.
What you must do to get service under this limited warranty
Defects must be brought to the attention of Dimplex Technical Service by contacting Dimplex
at 1-888-DIMPLEX (1-888-346-7539), or 1367 Industrial Road, Cambridge Ontario, Canada
N1R 7G8. Please have proof of purchase, catalogue/model and serial numbers available
when calling. Limited warranty service requires a proof of purchase of the product.
What Dimplex will do in the event of a defect
In the event a product or part covered by this limited warranty is proven to be defective in
material or workmanship during the 12 month limited warranty period you have the following
rights: 7

 Dimplex will in its sole discretion either repair or replace such defective product or part
without charge. If Dimplex is unable to repair or replace such product or part, or if repair
or replacement is not commercially practicable or cannot be timely made, Dimplex may, in
lieu of repair or replacement, choose to refund the purchase price for such product or
part.
 Limited warranty service will be performed solely by dealers or service agents of
Dimplex authorized to provide limited warranty services.
 The purchaser is responsible for removal and transportation of such product or part
(and any repaired or replacement product or part) to and from the authorized dealer's or
service agent's place of business.
 This limited warranty does not entitle the purchaser to on-site or in-home services.
On-site or in-home services may be performed at the purchaser's specific request and
expense at Dimplex’s then-current rates for such services.
 Dimplex will not be responsible for, and the limited warranty services shall not include,
any expense incurred for installation or removal of the product or part (or any
replacement product or part) or any labour or transportation costs. Such costs shall be
the purchaser’s responsibility.
What Dimplex and its dealers and service agents are also not responsible for:
IN NO EVENT WILL DIMPLEX, OR ITS DIRECTORS, OFFICERS, OR AGENTS, BE LIABLE
TO THE PURCHASER OR ANY THIRD PARTY, WHETHER IN CONTRACT, IN TORT, OR
ON ANY OTHER BASIS, FOR ANY INDIRECT, SPECIAL, PUNITIVE, EXEMPLARY,
CONSEQUENTIAL, OR INCIDENTAL LOSS, COST, OR DAMAGE ARISING OUT OF OR IN
CONNECTION WITH THE SALE, MAINTENANCE, USE, OR INABILITY TO USE THE
PRODUCT, EVEN IF DIMPLEX OR ITS DIRECTORS, OFFICERS, OR AGENTS HAVE
BEEN ADVISED OF THE POSSIBILITY OF SUCH LOSSES, COSTS OR DAMAGES, OR IF
SUCH LOSSES, COSTS, OR DAMAGES ARE FORESEEABLE. IN NO EVENT WILL
DIMPLEX, OR ITS OFFICERS, DIRECTORS, OR AGENTS BE LIABLE FOR ANY DIRECT
LOSSES, COSTS, OR DAMAGES THAT EXCEED THE PURCHASE PRICE OF THE
PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO THE PURCHASER.
How State and Provincial law apply
This limited warranty gives you specific legal rights, and you may also have other rights
which vary from jurisdiction to jurisdiction. The provisions of the United Nations Convention
on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of
products covered by this limited warranty
1367 Industrial Road
Cambridge, Ontario
Canada, N1R 7G8
1-888-DIMPLEX
1-888-346-7539
Approved for use in the United States and Canada
8
