Important Safety Advice
When using electrical appliances, basic precautions
should always be followed to reduce the risk of fire,
electrical shock and injury to persons, including the
following:
If the appliance is damaged, check with the supplier
before installation and operation.
Do not use outdoors.
Do not use in the immediate surroundings of a bath,
shower or swimming pool.
Do not locate the heater immediately below a fixed socket
outlet or connection box.
Do not cover the heater. Do not place material or garments
on the heater, or obstruct the air circulation around the heater,
for instance by curtains or furniture, as this could cause
overheating and a fire risk.
This appliance is not intended for use by children or other
persons without assistance or supervision if their physical,
sensory or mental capabilities prevent them from using it
safely. Children should be supervised to ensure that they do
not play with the appliance. Do not use this heater in series
with a thermal control, a program controller, a timer or any
other device that switches on the heat automatically, since a
fire risk exists when the heater is accidentally covered or
displaced.
Ensure that furniture, curtains or other combustible material
are positioned no closer than 1 metre from the heater.
In the event of a fault unplug the heater.
Unplug the heater when not required for long periods.
Although this heater complies with safety standards, we do
not recommend its use on deep pile carpets or on long hair
type of rugs.
The appliance must be positioned so that the plug is
accessible.
If the supply cord is damaged it must be replaced by the
manufacturer or service agent or a similarly qualified person
in order to avoid a hazard.
Keep the supply cord away from the front of the heater.
Warning: In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not be
supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on
and off by the utility.
General
Unpack the heater carefully and retain the packaging for possible
future use, in the event of moving or returning the fire to your supplier.
These models are designed to be free standing and are normally
positioned against a wall.
The fire incorporates a flame effect, which can be used with or without
heating, so that the comforting effect may be enjoyed at any time of
theyear. Using the flame effect on its own only requires little electricity.
A choice of 1kW or 2kW heat output is provided by the fan heater,
which is located at the bottom of the unit.
Before connecting the heater check that the supply voltage is the
same as that stated on the heater.
Please note: Used in an environment where background noise is
very low, it may be possible to hear a sound which is related to the
operation of the flame effect. This is normal and should not be a
cause for concern.
Electrical connection
WARNING – THIS APPLIANCE MUST BE EARTHED.
This heater must be used on an AC ~ supply only and the voltage
marked on the heater must correspond to the supply voltage.
Before switching on, please read the safety warnings and operating
instructions.
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Controls - see Fig. 2
The heater controls are located on the right hand side of the heater
- see Fig. 1. Three switches provide a choice of heat settings. A
switch is in the ON position when the side with the markings on (i.e.
I, I, or II) is pushed in.
Switch 1 (I) Controls the electricity supply to the heater and
flame effect. Note: This switch must be in the ON (I)
position for heater to operate with or without heat.
Switch 2 (I) Provides 1kW heat output
Switch 3 (II) Provides 2kW output with switch 2
Lamp Replacement - see Fig. 3, Fig. 4 and Fig. 5
The lamps are located behind the back panel. To gain access to the
lamps, the screws indicated in Fig. 3 which secure the back panel,
must be removed.
Remove and slide out panel as indicated on Fig. 4.
Remove the defective lamp by unscrewing it as shown in Fig. 5.
Replace with a 60W E14 SES Clear candle lamp. Take care not to
over-tighten the lamp.
Refit the back panel and secure with the screws.
Thermal Safety Cut-out
The built-in overheat cut-out switches off the appliance automatically
in the event of a fault. Switch off the appliance or disconnect the
mains plug from the socket. After a short cooling down phase, the
appliance is ready for use again. If the fault should occur again, see
your local dealer.
Maintenance
WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY MAINTENANCE.
Cleaning
WARNING – ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE CLEANING THE HEATER.
For general cleaning use a soft clean duster – never use abrasive
cleaners. The glass viewing screen should be cleaned carefully with
a soft cloth. DO NOT use proprietary glass cleaners.
To remove any accumulation of dust or fluff the soft brush attachment
of a vacuum cleaner should occasionally be used to clean the outlet
grille of the fan heater.
Recycling
Do not dispose of electrical appliances as unsorted
municipal waste. Use seperate collection facilities.
Contat your local government for information regarding
the collection systems available.
if electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the ground water, polluting the
food chain and damaging health and well being.
After Sales Service
Please see the separate Warranty leaflet for details of your Warranty
& After Sales Service including contact details.
Should you require after sales information or assistance with this
product, please contact Glen Dimplex Australia on 1300 556 816
(AUS) / 09 274 8265 (NZ) or visit our website at www.dimplex.com.au
(AUS) / www.dimplex.co.nz (NZ).
