DirectOut Technologies EXBOX.64 User manual

EXBOX.64
User‘s Manual
Version 2.0

page 2 of 40
EXBOX.64 Manual - Version 2.0
Copyright
All rights reserved. Permission to reprint or electronically reproduce
any document or graphic in whole or in part for any reason is
expressly prohibited, unless prior written consent is obtained from the
DirectOut GmbH.
All trademarks and registered trademarks belong to their respective
owners. It cannot be guaranteed that all product names, products,
trademarks, requisitions, regulations, guidelines, specifications and
norms are free from trade mark rights of third parties.
All entries in this document have been thoroughly checked; however
no guarantee for correctness can be given.
DirectOut GmbH cannot be held responsible for any misleading or
incorrect information provided throughout this manual.
DirectOut GmbH reserves the right to change specifications at any time
without notice.
DirectOut Technologies® is a registered trademark of the DirectOut
GmbH.
© DirectOut GmbH, 2017

page 3 of 40
EXBOX.64 Manual - Version 2.0
Table of contents
About This Manual 5
How to Use This Manual 5
Conventions 5
Chapter 1: Overview 6
Introduction 6
Feature Summary 7
Applications 8
How it works 8
CHAPTER 2: Legal issues & facts 10
Before Installing This Device 10
First Aid (in case of electric shock) 11
Defective Parts/Modules 12
Updates 12
Intended Operation 13
Conditions of Warranty 14
Conformity & Certificates 15
Contents 16
Contact 16
Accessory 18
Chapter 3: Installation 19
Installing the Device 19
CHAPTER 4: Operation 25
Introduction 25
Global Control 26
Connecting MADI 28

page 4 of 40
EXBOX.64 Manual - Version 2.0
USB 30
CHAPTER 5: Application Examples 31
Signal Conversion 31
Range Extension 31
CHAPTER 6: Troubleshooting and Maintenance 32
Troubleshooting 32
Maintenance 34
CHAPTER 7: Technical Data 36
Appendix A - Wiring Sketches 38
Hirose HR10 (DC PSU) 38
Index 39

page 5 of 40
EXBOX.64 Manual - Version 2.0
About This Manual
About This Manual
How to Use This Manual
This manual guides you through the installation and
operation of the device.
Use the Table of Contents at the beginning of the
manual or Index Directory at the end of the document
to locate help on a particular topic. You can access
more information and latest news by visiting on the
DirectOut website at www.directout.eu.
Conventions
The following symbols are used to draw your
attention to:
TIPS!
indicate useful hints and shortcuts.
NOTES!
are used for important points of clarification or cross
references.
WARNINGS!
alert you when an action should always be observed.

page 6 of 40 EXBOX.64 Manual - Version 2.0
Chapter 1: Overview
Chapter 1: Overview
Introduction
EXBOX.64is an active signal converter and re-clocker
for MADI signals.
Two MADI I/Os (1 x optical SC and 1 x coaxial BNC)
enable MADI signals to be converted from optical to
coaxial and vice versa.
The input signals, which are not required to be
in sync with each other, are cross patched to the
corresponding output. The output signal is re-clocked
at the output, thus refreshing the signal for cable
length extensions.

page 7 of 40
EXBOX.64 Manual - Version 2.0
Chapter 1: Overview
Feature Summary
MADI Ports* 2 x SC multi-mode connectors
or
1 x SC multi-mode connector
1 x coaxial BNC connectors
USB Port USB 2.0 port for firmware updates
MADI Formats 56/64 channel, 48k/96k Frame, S/MUX 2/4
Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
±12.5%
Power Supply external,
2 x Hirose connector (9 - 24 V)
* The device is available in two different versions
- see page 17.

page 8 of 40
EXBOX.64 Manual - Version 2.0
Chapter 1: Overview
Applications
EXBOX.64 can be used for conversion and refreshing
of MADI signals (AES10) and dialects of MADI.
Typical applications include:
• conversion of MADI signals (coaxial <> optical)
• refreshing the signal for cable length extension
(bridging the optical port)
How it works
The input signals are cross patched: i.e. input of
the coaxial port is output at the optical port and vice
versa.
The output signal is re-clocked and - at the coaxial
port - refreshed electrically. Both input signals are not
required to be in sync to each other.
The frame structure of the MADI signal is kept
unchanged- bittransparent signal flow. This means
that even proprietary adaptions of MADI (AES10) will
pass through the unit in their native state.
Both output ports don’t carry a signal unless a valid
input signal has been detected at the corresponding
input ports.

page 9 of 40
EXBOX.BLDS Manual - Version 1.2
Chapter 1: Overview
This page is left blank intentionally.

page 10 of 40
EXBOX.64 Manual - Version 2.0
CHAPTER 2: Legal issues & facts
CHAPTER 2: Legal issues & facts
Before Installing This Device
WARNING!
Please read and observe all of the following notes
before installing this product:
• Check the hardware device for transport
damage.
• Any devices showing signs of mechanical
damage or damage from the spillage of liquids
must not be connected to the mains supply,
or disconnected from the mains immediately by
pulling out the power lead.
• All devices must be grounded. The device is
grounded through its IEC power connections.
• All devices must be connected to the mains
using the three-cord power leads supplied with
the system. Only supply electrical interfaces
with the voltages and signals described in these
instructions.
• Do not use the device at extreme temperatures.
Proper operation can only be guaranteed
between temperatures of 5ºC and 45ºC
and a maximum relative humidity of 80%, non-
condensing.
• The cabinet of the device will heat up. Do not
place the device close to heating sources (e.g.
heaters). Observe the environmental conditions.

page 11 of 40
EXBOX.64 Manual - Version 2.0
CHAPTER 2: Legal issues & facts
First Aid (in case of electric shock)
WARNING!
• Do not touch the person or his/her clothing
before power is turned off, otherwise you risk
sustaining an electric shock yourself.
• Separate the person as quickly as possible from
the electric power source as follows:
- Switch off the equipment.
- Unplug or disconnect the mains cable.
• Move the person away from the power source
by using dry insulating material (such as wood or
plastic).
• If the person is unconscious:
- Check their pulse and reanimate if their
respiration is poor.
- Lay the body down and turn it to one side.
Call for a doctor immediately.
• Having sustained an electric shock, Always
consult a doctor.

page 12 of 40
EXBOX.64 Manual - Version 2.0
CHAPTER 2: Legal issues & facts
Defective Parts/Modules
WARNING!
This device contains no user-serviceable parts.
Therefore do not open the device.
In the event of a hardware defect, please send the
device to your DirectOut representative together with
a detailed description of the fault.
We would like to remind you to please check
carefully whether the failure is caused by erroneous
configuration, operation or connection before sending
parts for repair.
Updates
DirectOut products are continually in development,
and therefore the information in this manual may be
superseded by new releases. To access the latest
documentation, please visit the DirectOut website:
www.directout.eu.

page 13 of 40
EXBOX.64 Manual - Version 2.0
CHAPTER 2: Legal issues & facts
WARNING!
No compensation can be claimed for damages
caused by operation of this unit other than for the
intended use described above. Consecutive damages
are also excluded explicitly. The general terms and
conditions of business of DirectOut GmbH are
applied.
Intended Operation
The EXBOX.AES is designed for for conversion,
re-clocking and refreshing MADI signals (AES10).

page 14 of 40
EXBOX.64 Manual - Version 2.0
CHAPTER 2: Legal issues & facts
Conditions of Warranty
This unit has been designed and examined carefully
by the manufacturer and complies with actual norms
and directives.
Warranty is granted by DirectOut GmbH over the
period of two years for all components that are
essential for proper and intended operation of the
device. The date of purchase is applied for this period.
Consumable parts (e.g. battery) are excluded from
warranty claims.
WARNING!
All claims of warranty will expire once the device
has been opened or modified, or if instructions and
warnings were ignored.
For warranty claims please contact the dealer where
your device was acquired.

page 15 of 40
EXBOX.64 Manual - Version 2.0
CHAPTER 2: Legal issues & facts
Conformity & Certificates
CE
This device complies with the basic requests of
applicable EU guidelines. The appropriate procedure
for approval has been carried out.
RoHS
(Restriction of the use of certain Hazardous
Substances)
This device was constructed fulfilling the directive
on the restriction of the use of certain hazardous
substances in electrical and electronic equipment
2002/95/EC.
WEEE
(Directive on Waste Electrical and Electronic
Equipment)
Due to the directive 2002/96/EC for waste disposal
this device must be recycled.
For correct recycling please dispatch the device to:
DirectOut GmbH,
Leipziger Str. 32
09648 Mittweida
Germany
Only stamped parcels will be accepted!
WEEE-Reg.-No. DE 64879540

page 16 of 40
EXBOX.64 Manual - Version 2.0
CHAPTER 2: Legal issues & facts
Contact
DirectOut GmbH
Leipziger Str. 32, 09648 Mittweida, Germany
Phone: [phone]
Fax: [phone]
Mail: [email protected]
www.directout.eu
Contents
The contents of your EXBOX.64 package include:
• 1 x EXBOX.64
• 1 x external power supply unit (9- 24 V)
• 1 x Manual
To complete the delivery please download from the
product page on the
DirectOut website (www.directout.eu):
• USB Serial driver
• latest firmware

page 17 of 40EXBOX.64 Manual - Version 2.0
CHAPTER 2: Legal issues & facts
Single-Mode / Multi-Mode
The SC ports are multi-mode as default. It is possible
to equip the device with single-mode SC ports. The
housing of single-mode ports is colored blue.
Two different MADI I/O configurations are available:
1 x SC-Socket, 1 x BNC coaxial
2 x SC-Socket
multi-mode single-mode

page 18 of 40 EXBOX.64 Manual - Version 2.0
CHAPTER 2: Legal issues & facts
Accessory
BOX.MOUNT XL- for optimal rack mount of up to
three devices in a 19’’ frame (No: DOAPA0886):

page 19 of 40
EXBOX.64 Manual - Version 2.0
Chapter 3: Installation
WARNING
Avoid damage from condensation by waiting for the
device to adapt to the environmental temperature.
Proper operation can only be guaranteed between
temperatures of 5ºC and 45ºC and a maximum
relative humidity of 80%, non-condensing.
Ensure that the unit has sufficient air circulation for
cooling.
WARNING
The synthetics of the delivered pads might cause
stains on damageable surfaces. To avoid staining
of furniture surfaces it is recommended to place a
protective plate under the device.
Chapter 3: Installation
Installing the Device
1. Open the packaging and check that the
contents have been delivered complete and
undamaged.
2. Place the device on a non-slip horizontal
surface. The delivered pads may be affixed to
the bottom of the cabinet. Ensure a clean and
dry surface before affixing the pads.

page 20 of 40 EXBOX.64 Manual - Version 2.0
Chapter 3: Installation
Retain the protective cap if the optical port is unused.
This will protect against soiling which can lead to
malfunction.
3. Remove the protective cap from the optical
MADI port(s) before use.
SC/SC Version
BNC/SC Version
NOTE!
