DirectOut Technologies PRODIGY.MC Installation instructions

PRODIGY.MC
Hardware Guide
Version 1.0

page 2 of 64 Prodigy.MC Hardware Guide - Version 1.0
Copyright
All rights reserved. Permission to reprint or electronically reproduce any document or
graphic in whole or in part for any reason is expressly prohibited, unless prior written
consent is obtained from the DirectOut GmbH.
All trademarks and registered trademarks belong to their respective owners. It cannot
be guaranteed that all product names, products, trademarks, requisitions, regulations,
guidelines, specifications and norms are free from trade mark rights of third parties.
All entries in this document have been thoroughly checked; however no guarantee for
correctness can be given.
DirectOut GmbH cannot be held responsible for any misleading or incorrect
information provided throughout this manual.
DirectOut GmbH reserves the right to change specifications at any time without notice.
DirectOut Technologies® is a registered trademark of the DirectOut GmbH.
© DirectOut GmbH, 2019

page 3 of 64Prodigy.MC Hardware Guide - Version 1.0
Table of contents
About This Manual 5
How to Use This Manual............................................................................... 5
Conventions .................................................................................................. 5
CHAPTER 1: Overview 6
Introduction ................................................................................................... 6
Feature Summary.......................................................................................... 7
How it works................................................................................................. 8
Applications................................................................................................... 8
CHAPTER 2: Legal issues & facts 10
Before Installing This Device....................................................................... 10
Defective Parts/Modules ........................................................................... 10
First Aid (in case of electric shock).............................................................. 11
Updates ....................................................................................................... 12
Conditions of Warranty ............................................................................... 12
Intended Operation .................................................................................... 12
Conformity & Certificates ........................................................................... 13
Contact........................................................................................................ 13
Contents...................................................................................................... 14
Accessories................................................................................................. 15
CHAPTER 3: Installation 20
Installing the Device .................................................................................... 20
CHAPTER 4: Operation 24
Introduction ................................................................................................. 24
Global Control.............................................................................................. 25
Managing Device ........................................................................................ 26
Networking.................................................................................................. 27
Slots - Connecting Audio............................................................................. 29
Slots - Audio Network Modules .................................................................. 30
Slots - MADI Modules................................................................................. 34
Slots - Converter Modules .......................................................................... 36
Word clock .................................................................................................. 46
Clocking....................................................................................................... 47
USB ............................................................................................................. 48
GPIO............................................................................................................ 48
CHAPTER 5: Troubleshooting and Maintenance 50
Troubleshooting........................................................................................... 50
Maintenance................................................................................................ 51
CHAPTER 6: Technical Data 52
Index 56

page 4 of 64 Prodigy.MC Hardware Guide - Version 1.0
Appendix A - DSUB-25 Pin assignment 58
Appendix B - DSUB-9 Pin assignment 59
Appendix C - Firmware Update 60
Appendix D - Dimensions 61

page 5 of 64Prodigy.MC Hardware Guide - Version 1.0
About This Manual
About This Manual
How to Use This Manual
This manual guides you through the installation and operation of the device.
Use the Table of Contents at the beginning of the manual or Index Directory at the
end of the document to locate help on a particular topic. You can access more
information and latest news by visiting on the DirectOut website at
www.directout.eu.
Conventions
The following symbols are used to draw your attention to:
TIPS
indicate useful hints and shortcuts.
NOTES
are used for important points of clarification or cross references.
WARNINGS!
alert you when an action should always be observed.

page 6 of 64 Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 1: Overview
CHAPTER 1: Overview
Introduction
Welcome to PRODIGY.MC, DirectOut’s modular audio converter supporting
multiple formats, offering flexible I/O, networked audio, and extremely powerful
hardware and software.
PRODIGY.MC has been designed to address numerous applications in pro audio,
broadcast, installation and studio applications, using a single hardware frame.

page 7 of 64Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 1: Overview
Feature Summary
Audio Network
Modules *
1 slot (1 x SFP, 2 x RJ45 Socket) - configure to order:
- Dante (64 channels)
- RAVENNA (128 channels)
- SoundGrid (128 channels)
MADI Modules * 2 slots - :
- SFP (empty cage without module)
- SC-Socket multi/single-mode
- coaxial BNC, 75 Ω
Converter Modules* 8 slots - individually configurable - 8 channels each:
- Analog I/O - Line In / Out
- Mic I/O - Mic In / Line Out
- Digital I/O - AES3 In / Out
Headphones 1 x 6.3 mm jack
1 x 3.5 mm jack
Word Clock (I/O): 2 x coaxial BNC
(75 Ω termination switchable)
Supported Audio
Network Standards
(depending on module)
Dante / AES67
RAVENNA / AES67, ST 2110-30/31, ST 2022-7
(Seamless Protection Switching)
SoundGrid
MADI Formats 56/64 channel, 48k/96k Frame, S/MUX
Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz +/-12.5%
Management Port 1 x RJ45 Socket (Gigabit-Ethernet)
Device Control remote: via globcon or browser
local: via touch-display
GPIO 1 x DSUB-9 (2 x GPI, 2 x GPO, MOSFET switches)
USB Port USB 2.0 port for legacy control of ANDIAMO devices
Power Supply This device is equipped with two wide range power
supplies (84 V to 264 V AC / 47 Hz to 63 Hz / safety
class 1)
* see „Slots- Connecting Audio“ on page 29 for a comprehensive description
of the different modules available.

page 8 of 64 Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 1: Overview
How it works
All modules inserted into the mainframe offer a variety of inputs and outputs that
are managed by an internal routing matrix.
There are eight converter slots equipped with eight channels per module and
interface direction for conversion of up to 64 audio channels. Combined with the
audio network, two MADI options and the headphones outputs the maximum
channel capacity of the device increases to 320 inputs and 324 outputs.
Applications
PRODIGY.MC can be used for bidirectional conversion between analog and digital
signals, signal distribution, streaming audio, conversion between audio networks
and MADI environments, conversion of different MADI signals.
Typical applications include:
• stagebox for recording with 64 channels mic input, 64 returns
• stream generator
• stream monitoring (headphones)
• format conversion of a MADI signal (SFP <> SC <> BNC)
• signal distribution (routing matrix)
• ...
NETWORK
MADI 1
MADI 2
Slot 1
...
Slot 8
NETWORK MADI 1 MADI 2 Slot 1 ... Slot 8 Phones
GAIN
OUTPUT
INPUT
GAIN
ROUTING
MATRIX

page 9 of 64Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 1: Overview
This page is left blank intentionally.

page 10 of 64 Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
CHAPTER 2: Legal issues & facts
Before Installing This Device
WARNING!
Please read and observe all of the following notes before installing
this product:
• Check the hardware device for transport damage.
• Any devices showing signs of mechanical damage or damage from the
spillage of liquids must not be connected to the mains supply, or
disconnected from the mains immediately by pulling out the power lead.
• All devices must be grounded. The device is grounded through its
IEC power connections.
• All devices must be connected to the mains using the three-cord power
leads supplied with the system. Only supply electrical interfaces with the
voltages and signals described in these instructions.
• Do not use the device at extreme temperatures. Proper operation can
only be guaranteed between temperatures of 5ºC and 45ºC and a
maximum relative humidity of 80%, non-condensing.
• The cabinet of the device will heat up. Do not place the device close
to heating sources (e.g. heaters). Observe the environmental conditions.
Defective Parts/Modules
WARNING!
This device contains no user-serviceable parts. Therefore do not open the device.
In the event of a hardware defect, please send the device to your DirectOut
representative together with a detailed description of the fault.
We would like to remind you to please check carefully whether the failure is
caused by erroneous configuration, operation or connection before sending parts
for repair.

page 11 of 64Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
First Aid (in case of electric shock)
WARNING!
• Do not touch the person or his/her clothing before power is turned off,
otherwise you risk sustaining an electric shock yourself.
• Separate the person as quickly as possible from the electric power source
as follows:
- Switch off the equipment.
- Unplug or disconnect the mains cable.
• Move the person away from the power source by using dry insulating
material (such as wood or plastic).
• If the person is unconscious:
- Check their pulse and reanimate if their respiration is poor.
- Lay the body down and turn it to one side. Call for a doctor immediately.
• Having sustained an electric shock, always consult a doctor.

page 12 of 64 Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
Updates
DirectOut products are continually in development, and therefore the information
in this manual may be superseded by new releases. To access the latest
documentation, please visit the DirectOut website:
www.directout.eu.
WARNING!
No compensation can be claimed for damages caused by operation of this unit
other than for the intended use described above. Consecutive damages are also
excluded explicitly. The general terms and conditions of business of DirectOut
GmbH are applied.
Conditions of Warranty
This unit has been designed and examined carefully by the manufacturer and
complies with actual norms and directives.
Warranty is granted by DirectOut GmbH over the period of 36 months for all
components that are essential for proper and intended operation of the device. The
date of purchase is applied for this period.
Consumable parts (e.g. battery) are excluded from warranty claims.
WARNING!
All claims of warranty will expire once the device has been opened or modified, or
if instructions and warnings were ignored.
For warranty claims please contact the dealer where your device was acquired.
This guide refers to the following firmware version 1.1.
Intended Operation
PRODIGY.MC is designed for conversion / routing between analog, digital and
audio network signals. Digital audio refers to AES3 and AES10, audio network
refers to Dante, SoundGrid and RAVENNA (including AES67 and SMPTE
ST 2110-30/31).

page 13 of 64Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
Conformity & Certificates
CE
This device complies with the basic requests of applicable EU guidelines. The
appropriate procedure for approval has been carried out.
RoHS
(Restriction of the use of certain Hazardous Substances)
This device was constructed fulfilling the directive on the restriction of the use of
certain hazardous substances in electrical and electronic equipment 2002/95/EC.
WEEE
(Directive on Waste Electrical and Electronic Equipment)
Due to the directive 2002/96/EC for waste disposal this device must be recycled.
For correct recycling please dispatch the device to:
DirectOut GmbH,
Leipziger Str. 32
09648 Mittweida
Germany
Only stamped parcels will be accepted!
WEEE-Reg.-No. DE 64879540
Contact
DirectOut GmbH
Leipziger Str. 32, 09648 Mittweida, Germany
Phone: [phone]
Fax: [phone]
Mail: [email protected]
www.directout.eu

page 14 of 64 Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
Contents
The contents of your PRODIGY.MC package should include:
• 1 x PRODIGY.MC (19’’, 2 RU)
• 2 x power chord with self locking mechanism
• 1 x Hardware Guide
The device provides slots for audio network modules, MADI modules and
converter modules. The modules may be delivered separately and require
installation first to complete the delivery.

page 15 of 64Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
BREAKOUT
The BREAKOUT series is a range of adaptor boxes available in different variants to
extend the coverage of the ANDIAMO and PRODIDGY series. They are equipped
with XLR or BNC connectors on the front panel and DSUB-25 connectors on the
rear panel. Audio signals are carried passively between the front and rear panels.
The small form factor and angle brackets also allow for mounting the devices on
the back of an ANDIAMO unit.
BREAKOUT.AN8 - analog input / output, 8 channels
Article code: DOBOB0719
BREAKOUT.AN16I - analog input, 16 channels
Article code: DOBOB0720
BREAKOUT.AN16O - analog output, 16 channels
Article code: DOBOB0721
Accessories

page 16 of 64 Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
Patch Chords
Cabling from Cordial provides appropriate connection of the BREAKOUT with your
device to ensure proper transmission of the audio signals.
Name Description Article code
DSUB25.AN50 Analog patch cable for connection
with BREAKOUT.AN16I, AN16O, AN8,
transferring 8 audio channels, length 0.5 m
DOCAA0334
DSUB25.AN100 Analog patch cable for connection
with BREAKOUT.AN16I, AN16O, AN8,
transferring 8 audio channels, length 1.0 m
DOCAA0335
DSUB25.AES50 Digital patch cable for connection with
BREAKOUT.AES or AESid
transferring 8 audio channels, length 0.5 m
DOCAA0332
DSUB25.AES100 Digital patch cable for connection with
BREAKOUT.AES or AESid
transferring 8 audio channels, length 0.5 m
DOCAA0333
BREAKOUT.AES - digital input / output, 8 AES3 ports (16 channels)
Article Code: DOBOB0718
BREAKOUT.AESID - digital input / output, 16 AESid ports (32 channels)
Article Code: DOBOB0722

page 17 of 64Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
Two different optical SFP transceiver for MADI transmission are available from
DirectOut GmbH:
• Multimode SFP transceiver with LC connectors (No: DOICT0129)
• Singlemode SFP transceiver with LC connectors (No: DOICT0130)
Specification of the optical SFP modules:
SFP Multimode Singlemode
Wavelength TX 1310 nm 1310 nm
Wavelenght RX 1310 nm 1310 nm
Distance 2 km 10 km
Powerbudget (dB) 11 dB 12 dB
Protocols Fast Ethernet OC3/STM1 Gigabit Ethernet, Gigabit
Fibre Channel
Bandwidth from 100 Mbit/s 1.050 Gbit/s
Bandwidth 155 Mbit/s 1.250 Gbit/s
Laser FP FP
Receiver Type PIN PIN
Connector LC LC
Wavelength TX min 1260 nm 1260 nm
Wavelength TX max 1360 nm 1360 nm
Wavelength RX min 1260 nm 1260 nm
Wavelength RX max 1620 nm 1600 nm
Transmit min - 19.00 dBm - 9.00 dBm
Transmit max - 14.00 dBm - 3.00 dBm
Receive min - 30 dBm - 21.00 dBm
Receive max
(Receiver overload)
- 5.00 dBm - 3.00 dBm
Temperature (min) 0° Celsius 0° Celsius
Temperature (max) 70° Celsius 70° Celsius
Type of DDM/DOM internal internal
Extinction Ratio 8.20 dB 9 dB
SFP Transceiver - MADI

page 18 of 64 Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
Two different optical SFP transceiver for 1Gbit/s ethernet transmission are available
from DirectOut GmbH:
• SFP Copper Transceiver, RJ-45 (No: DOICT0132)
• SFP Optical Transceiver, optical LC Single Mode (No: DOICT0133)
Specification
SFP Copper - RJ45 Optical - LC single mode
Distance 100 m via CATe cable 2000 m
Wavelength - 1310 nm
Datarate 12 Mbit/s to 1.25 Gbit/s 2.67 GBit/s
SFP Transceiver - Network

page 19 of 64Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 2: Legal issues & facts
This page is left blank intentionally.

page 20 of 64 Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 3: Installation
Avoid damage from condensation by waiting for the device to adapt to the
environmental temperature. Proper operation can only be guaranteed between
temperatures of 5ºC and 45ºC and a maximum relative humidity of 80%, non-
condensing.
Ensure that the unit has sufficient air circulation for cooling.
CHAPTER 3: Installation
Installing the Device
1. Open the packaging and check that the contents have been delivered
complete and undamaged.
2. Fix the device in a 19’’ frame with four screws, or place it on a non-slip
horizontal surface.
WARNING!
Do not cover the fan outlets and the slots at the sides of the device!
Do not block the fans by putting objects through the protective grid!
3. For installation of separately delivered modules follow the instructions in the
manual enclosed with the packaging of the modules.
Audio Network Slot - see page 30
MADI Slots - see page 34
Converter Slots - see page 36
AIR AIR
1
2
3
1
2
3
