DirectOut Technologies ANDIAMO 2.AD Installation instructions

DirectOut Technologies®
D.O.TEC®ANDIAMO 2.AD
Version 1.0
Hardware Guide

page 2 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
Copyright Note
© 2013 DirectOut GmbH
Copyright
All rights reserved. Permission to reprint or electronically reproduce any docu-
ment or graphic in whole or in part for any reason is expressly prohibited, un-
less prior written consent is obtained from the DirectOut GmbH.
All trademarks and registered trademarks belong to their respective owners. It can-
not be guaranteed that all product names, products, trademarks, requisitions, regulations,
guidelines, specifications and norms are free from trade mark rights of third parties.
All entries in this document have been thoroughly checked; how-
ever no guarantee for correctness can be given.
DirectOut GmbH cannot be held responsible for any misleading or in-
correct information provided throughout this manual.
DirectOut GmbH reserves the right to change specifications at any time without notice.
DirectOut Technologies® and D.O.TEC® are registered trademarks of the DirectOut GmbH.
© DirectOut GmbH, 2013

page 3 of 44D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
Table of Contents
© 2013 DirectOut GmbH
Table of contents
ABOUT THIS MANUAL 5
How to Use This Manual 5
Conventions 5
CHAPTER 1: OVERVIEW 6
Introduction 6
Feature Summary 6
Applications 7
CHAPTER 2: LEGAL ISSUES & FACTS 8
Before Installing This Device 8
Defective Parts/Modules 8
First Aid (in case of electric shock) 9
Updates 10
Intended Operation 10
Conditions of Warranty 10
Conformity & Certificates 11
Contact 11
Contents 12
Accessories 12
CHAPTER 3: INSTALLATION 14
Installing the Device 14
CHAPTER 4: OPERATION 18
Introduction 18
Global Control 18
Menu Control 19
Clocking 20
Clocking continued - MADI STATE 21
Sample Rates 22
Level Settings 23
Level Meters 24
Output Format 25
Bank Selection / Signal Routing 26
MADI / Word clock / USB 28
Analog Input 29
Delay Compensation 30
CHAPTER 5: MENU NAVIGATION 32
CHAPTER 6: TROUBLESHOOTING AND
MAINTENANCE 35
Troubleshooting 35
Maintenance 35
CHAPTER 7: TECHNICAL DATA 36

page 4 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
Table of Contents
© 2013 DirectOut GmbH
APPENDIX A: WIRING DSUB-25 39
DSUB-25 - analog (female) 39
APPENDIX B: CONFIGURATION EXAMPLES 40
INDEX 41

page 5 of 44D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
About This Manual
© 2013 DirectOut GmbH
Conventions
The following symbols are used to draw your attention to:
Tips – indicate useful tips and shortcuts.
Notes – are used for important points of clarification or cross refer-
ences.
Warning
Warnings – alert you when an action should always be observed.
Use the Table of Contents at the beginning of the manual or Index
Directory at the end of the document to locate help on a particular
topic.
You can access more information and latest news by visiting on the
DirectOut website at www.directout.eu.
About This Manual
How to Use This Manual
This manual guides you through the installation and operation of the
ANDIAMO 2.AD.

page 6 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 1: Overview
© 2013 DirectOut GmbH
CHAPTER 1: Overview
Introduction
Welcome to the ANDIAMO 2.AD, D.O.TEC’s s high quality AD con-
verter for MADI signals.
The ANDIAMO 2.AD provides two MADI inputs and outputs and 32
channels analog inputs. With one RU height, two redundant power
supplies and excellent sounding converters the device offers best
and safe audio quality at a minimal need of rackspace.
ANDIAMO 2.AD - SC / SC version (optical / optical)
ANDIAMO 2.AD - BNC /SC version (coaxial / optical)
Feature Summary
MADI Ports 2 x MADI input and output
2 x SC multi-mode connectors (SC/SC)
or
1 x SC multi-mode connectors &
1 x coaxial BNC connectors (BNC/SC)
MADI Formats 56/64 channel, 48k/96k Frame, S/MUX 2
Sample Rates 44.1, 48, 88.2, 96 kHz +/-12.5%
Clock Inputs 1 x Word clock coaxial BNC (75 Ω
termination switchable)
This input also accepts an
AES3 frame (AES11).

page 7 of 44D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 1: Overview
© 2013 DirectOut GmbH
Clock Output 1 x Word clock coaxial BNC
Line Inputs 4 x DSUB-25 (8 channels each)
USB Port USB 2.0 port for firmware
updates and remote control.
Routing Matrix Signal routing on a per channel
basis - 96 x 64 routing matrix.
Remote Control Software Remote control via USB,
Serial over MADI or MIDI over MADI
Power Supply This device is equipped with two wide
range power supplies (84 V to 264 V
AC / 47 Hz to 63 Hz / safety class 1).
Applications
ANDIAMO 2.AD can be used for conversion and recording of analog
signals.
Typical applications include:
• recording line signals
• conversion of a high number of channels from analog to digital
• redundant recording using both MADI I/Os
• format conversion of MADI signals
• ...
analog in - 4 x 8 channels
MADI In
MADI In
MADI Out
MADI Out

page 8 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 2: Legal issues & facts
© 2013 DirectOut GmbH
CHAPTER 2: Legal issues & facts
Before Installing This Device
Warning
Please read and observe ALL of the following notes before
installing this product:
• Check the hardware device for transport damage.
• Any devices showing signs of mechanical damage or damage
from the spillage of liquids MUST NOT be connected to the
mains supply, or disconnected from the mains immediately by
pulling out the power lead.
• All devices MUST be grounded. The device is grounded
through its IEC power connections.
• All devices MUST be connected to the mains using the three-
cord power leads supplied with the system. Only supply
electrical interfaces with the voltages and signals described in
these instructions.
• Do NOT use the device at extreme temperatures. Proper op-
eration can only be guaranteed between temperatures of 5º C
and 45º C and a maximum relative humidity of 80 %, non-
condensing.
• The cabinet of the device will heat up. DO NOT place the
device close to heating sources (e.g. heaters). Observe the
environmental conditions.
Defective Parts/Modules
Warning
This device contains no user-serviceable parts. Therefore do NOT
open the device.
In the event of a hardware defect, please send the device to your
D.O.TEC®representative together with a detailed description of the
fault.
We would like to remind you to please check carefully whether the fail-
ure is caused by erroneous configuration, operation or connection be-
fore sending parts for repair. See „CHAPTER 6: Troubleshooting and
Maintenance“ on page 35 for assistance with troubleshooting.

page 9 of 44D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 2: Legal issues & facts
© 2013 DirectOut GmbH
First Aid (in case of electric shock)
Warning
• DO NOT touch the person or his/her clothing before power
is turned off, otherwise you risk sustaining an electric shock
yourself.
• Separate the person as quickly as possible from the electric
power source as follows:
Switch off the equipment.
Unplug or disconnect the mains cable.
• Move the person away from the power source by using dry
insulating material (such as wood or plastic).
• If the person is unconscious:
Check their pulse and reanimate if their respiration is
poor.
Lay the body down and turn it to one side. Call for a doc-
tor immediately.
• Having sustained an electric shock, ALWAYS consult a doc-
tor.

page 10 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 2: Legal issues & facts
© 2013 DirectOut GmbH
Updates
D.O.TEC®products are continually in development, and therefore
the information in this manual may be superseded by new releases.
To access the latest documentation, please visit the DirectOut web-
site: www.directout.eu.
Warning
No compensation can be claimed for damages caused by operation
of this unit other than for the intended use described above. Con-
secutive damages are also excluded explicitly. The general terms
and conditions of business of DirectOut GmbH are applied.
Conditions of Warranty
This unit has been designed and examined carefully by the manu-
facturer and complies with actual norms and directives.
Warranty is granted by DirectOut GmbH over the period of two years
for all components that are essential for proper and intended opera-
tion of the device. The date of purchase is applied for this period.
Warning
All claims of warranty will expire once the device has been opened
or modified, or if instructions and warnings were ignored.
For warranty claims please contact the dealer where your device
was acquired.
This guide refers to fi rmware version 1.0.
Intended Operation
The ANDIAMO 2.AD is designed for conversion of audio signals
from analog to digital. In this context digital audio refers to a MADI
signal (AES10).

page 11 of 44D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 2: Legal issues & facts
© 2013 DirectOut GmbH
Conformity&Certificates
CE
This device complies with the basic requests of applicable EU guide-
lines. The appropriate procedure for approval has been carried out.
RoHS
(Restriction of the use of certain Hazardous Substances)
This device was constructed fulfilling the directive on the restriction
of the use of certain hazardous substances in electrical and elec-
tronic equipment 2002/95/EC.
WEEE
(Directive on Waste Electrical and Electronic Equipment)
Due to the directive 2002/96/EC for waste disposal this device must
be recycled.
For correct recycling please dispatch the device to:
IMM Elektronik GmbH,
Leipziger Strasse 32
09648 Mittweida
Germany
Only stamped parcels will be accepted!
WEEE-Reg.-No. DE 93924963
Contact
Sales:
DirectOut GmbH, Leipziger Strasse 32, 09648 Mittweida, Germany
Phone: [phone] // Fax: [phone]
www.directout.eu
Manufacturer:
IMM Elektronik GmbH, Leipziger Strasse 32, 09648 Mittweida,
Germany
Phone: [phone] // Fax: [phone]
www.imm-gruppe.de

page 12 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 2: Legal issues & facts
© 2013 DirectOut GmbH
Accessories
D.O.TEC®BREAKOUT series
The BREAKOUT series are adaptor boxes - available in different
variants - to widen the application range of the D.O.TEC®ANDI-
AMO series.
Each box is equipped with XLR connectors at the front panel (AESid
uses BNC connectors) and DSUB-25 connectors at the rear panel.
Audio signals are carried passively between front and rear panel.
Contents
The contents of your ANDIAMO 2.AD package should include:
• 1 x ANDIAMO 2.AD (19’’, 1 RU)
• 2 x power chord
• 2 x fixing unit for power plug
• 1 x Hardware Guide
To complete the delivery please download from the DirectOut
website:
• Software Guide ANDIAMO Remote
• D.O.TEC®USB Serial driver
• ‘ANDIAMO Remote’ application
Link: http://www.directout.eu/en/support/downloads/andiamo_2_ad.html
BREAKOUT.AN8 - analog input / output, 8 channels
BREAKOUT.AN16I - analog input, 16 channels
Three different models for analog signals are available:

page 13 of 44D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 2: Legal issues & facts
© 2013 DirectOut GmbH
BREAKOUT.AN16O - analog output, 16 channels

page 14 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 3: Installation
© 2013 DirectOut GmbH
Warning
Avoid damage from condensation by waiting for the device to adapt
to the environmental temperature. Proper operation can only be
guaranteed between temperatures of 5º C and 45º C and a maxi-
mum relative humidity of 80%, non-condensing.
Ensure that the unit has suffi cient air circulation for cooling.
Retain the protective cap if the optical port is unused. This will pro-
tect against soiling which can lead to malfunction.
CHAPTER 3: Installation
Installing the Device
1. Open the packaging and check that the contents have been
delivered complete and undamaged.
2. Fix the device in a 19’’ frame with four screws, or place it on
a non-slip horizontal surface.
4. Connect signal cable for the MADI signals.
3. Remove the protective cap from the optical MADI port(s)
before use.
ANDIAMO 2.AD - SC /SC version (optical / optical)
ANDIAMO 2.AD - BNC / SC version (coaxial / optical)

page 15 of 44D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 3: Installation
© 2013 DirectOut GmbH
Warning
This device MUST be connected to the mains using the three-cord
power leads supplied with the system. Only supply the voltages and
signals indicated (84 V – 264 V).
This device may operate with only one power supply. To provide
power supply redundancy, it is recommended to connect both PSU 1
and PSU 2 to independent power supplies with separate fuses.
5. Connect the signal cables1for the analog audio signals to
the DSUB-25 connectors (TASCAM pinout - see page 39).
1 signal cables are not included in delivery
7. Using the power cords provided connect both PSUs to a
matching power supply:
6. Optional: Connect an USB cable to the USB port for remote
control or fi rmware updates. This requires the D.O.TEC® USB
driver (Windows) being installed fi rst. The driver and the instal-
lation instructions are available at www.directout.eu.
Link: http://www.directout.eu/en/support/downloads/andiamo_2_ad.html

page 16 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 3: Installation
© 2013 DirectOut GmbH
To update the fi rmware an installed D.O.TEC® USB Serial driver (Win-
dows) and the D.O.TEC® Update Tool are necessary. The software
and the installation instructions are available at www.directout.eu.
Keep any packaging in order to protect the device should it need to
be dispatched for service.
Link: http://www.directout.eu/en/support/downloads/andiamo_2_ad.html
The fi rst seconds after switch-on the actual fi rmware is indicated by
the lower metering panel - e.g. fi rmware version 1.2.
8. Turn on the power switch and check the status of PSUs on
the front panel:
Use the D.O.TEC® Release Map to match your D.O.TEC® device
with the latest fi rmware or software release.
Link: http://www.directout.eu/upload/dokumente/dotec_release_map.pdf

page 17 of 44D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 3: Installation
© 2013 DirectOut GmbH
9. Installation of D.O.TEC® USB Serial driver
• download the D.O.TEC® USB Serial driver
• download the ‘Installation Guide for USB Control’
Link: http://www.directout.eu/en/support/downloads/andiamo_2_ad.html
• follow the installation instructions in the ‘Installation Guide for
USB Control’
10. Installation of ‘ANDIAMO Remote’
• download the ‘Software Guide ANDIAMO Remote‘
• download the ‘ANDIAMO Remote’ application
Link: http://www.directout.eu/en/support/downloads/andiamo_2_ad.html
• follow the installation instructions in the ‘Software Guide AN-
DIAMO REMOTE’
11. Start the ‘ANDIAMO Remote’ application
• Check selected COM port or MIDI I/O
• Click ‘CONNECT’

page 18 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 4: Operation
© 2013 DirectOut GmbH
Introduction
This chapter describes the basic operation of the device. Note that
throughout this manual, the abbreviation FS refers to sample rate or
sample frequency. So, when dealing with scaling factors, the follow-
ing sample rates can be written as:
• 44.1 kHz = 1 FS; 88.2 kHz = 2 FS
or
• 48 kHz = 1 FS; 96 kHz = 2 FS
The green LEDs (PSU 1 & PSU 2) indicate that a working power
supply is connected to the power supply unit. Note that an unlit LED
does not guarantee that the device is free of voltage. To ensure
that the device is completely disconnected from mains voltage, the
power chords must be disconnected.
CHAPTER 4: Operation
Global Control
The control on the right of the front panel indicates the power sup-
ply. Power switches are on the back panel:
Power 2 Switches
Enable / disable power supply.
PSU 1 & PSU 2 2 LEDs (green): indicate the status
of both power supply units
LED OFF = Power supply inactive
LED ON = Power supply active

page 19 of 44D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 4: Operation
© 2013 DirectOut GmbH
Blinking LEDs are also used to indicate an error (e.g. missing sync).
Concentrate on the section where one LED is blinking and the re-
maining LEDs are glowing weak.
Most settings can be adjusted either locally or via the remote ap-
plication (ANDIAMO Remote).
A few settings can be accessed via the remote application only:
• Confi guration of the system fan control
• Redundancy Mode (only devices with two MADI I/Os)
• Routing Matrix
• USB Embedder
• Display Dark (only ANDIAMO.MC)
The settings are stored inside the device.
Menu Control
All functions of the converter can be accessed using a simple menu.
Two push buttons are used for navigation and settings.
SELECT Button
Press longer than 2 seconds to
enter the menu. Press short for
navigation in menu mode.
SET Button
Only active in menu mode. Press short
to adjust a setting. Press longer than
2 seconds to toggle the Matrix Mode.
When the menu mode is active a LED will blink in one of the sec-
tions while the remaining LEDs of this section are glowing weak.
This indicates:
• a setting can be adjusted in this section
• the blinking LED(s) is the selected option in this section
After a short period of time the menu mode is exit automatically.
See also „CHAPTER 5: Menu Navigation“ on page 32.

page 20 of 44 D.O.TEC®ANDIAMO 2.AD Hardware Guide - Version 1.0
DirectOut Technologies
®
CHAPTER 4: Operation
© 2013 DirectOut GmbH
Clocking
The system clock can be set to one of three possible clock sources
in the menu (see „CHAPTER 5: Menu Navigation“ on page 32).
The LEDs on the front panel inform about selection and sync state1
of the selected source.
75Ω LED (yellow): indicates the termination
status of the word clock input
LED ON = Termination active
LED OFF = Termination inactive
WCK LED (green): indicates use of
word clock as clock source
LED ON = Clock source set to word clock
LED blinking = Clock source
set to word clock and no signal present
LED heartbeat = Signal locked
but not in sync
MADI LED (green): indicates use of MADI
input (1 or 2) as clock source
LED ON = Clock source set to MADI input
LED blinking = Clock source
set to MADI input and no signal present
LED heartbeat = Signal locked
but not in sync
INT LED (green): indicates use of internal
clock generator as clock source
LED ON = Clock source
set to internal clock generator
1 Lock = a valid signal is detected but its clock does not match with the system
reference
Sync = a valid signal is detected and matches with the system reference
