DISCOVER Lynk Lite User manual

1
805-0059 LYNK LITE
Victron (Mobile) Manual
805-0059 REV A
READ AND SAVETHESE INSTRUCTIONS

2
1. AUDIENCE, SAFETY, MESSAGES, AND WARNINGS ......................................3
1.1 Audience.................................................................3
1.2 Warning, Caution, Notice, and Note Messages..................................3
1.3 General Warnings .........................................................4
1.4 Safe Handling Procedures...................................................4
1.5 Personal Protective Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2. DOCUMENTATION...................................................................5
3. OVERVIEW .........................................................................5
3.1 System Overview..........................................................6
3.2 Compatibility .............................................................7
3.3 Minimum Battery System Capacity ...........................................8
4. INSTALLATION AND CONNECTING LYNK LITE TO THE VE.CAN NETWORK ................. 10
4.1 Networking Discover Lithium Batteries with LYNK LITE..........................10
4.2 Connecting LYNK LITE to the VE.CAN Network.................................11
5. ENABLING LYNK LITE TO COMMUNICATE WITH VICTRON DEVICES ...................... 12
5.1 Victron Open-Loop Configuration ...........................................13
5.2 Setting Victron as the LYNK LITE Communication Protocol .......................17
5.3 Victron Closed-Loop Configuration ..........................................18
5.4 Configurable Closed-Loop Settings ..........................................19

3
INTRODUCTION
This Application Note provides information about integrating LYNK and AEbus
network-enabled Discover Lithium Batteries using the LYNK LITE Communication
Gateway with Victron Mobile inverter-chargers.
1. AUDIENCE, SAFETY, MESSAGES, AND WARNINGS
1.1 Audience
Configuration, installation, service, and operating tasks should only be performed
by qualified personnel in consultation with local authorities having jurisdiction
and authorized dealers. Qualified personnel should have training, knowledge, and
experience in the:
• Installation of electrical equipment
• Application of applicable installation codes
• Analysis and reduction of the hazards involved in performing electrical work
• Installation and configuration of batteries
1.2 Warning, Caution, Notice, and Note Messages
Messages in this manual are formatted according to this structure.
WARNING
Important information regarding hazardous conditions that may result in personal
injury or death.
CAUTION
Important information regarding hazardous conditions that may result in personal
injury.
NOTICE
Important information regarding conditions that may damage the equipment but
not result in personal injury.
NOTE
Ad hoc information concerning important procedures and features not related to
personal injury or equipment damage.

4
1.3 General Warnings
WARNING
ELECTRIC SHOCK AND FIRE HAZARD
• This equipment must only be installed as specified.
• Do not disassemble or modify the battery.
• If the battery case has been damaged, do not touch exposed contents.
• There are no user-serviceable parts inside.
Failure to follow these instructions may result in death or serious injury.
WARNING
ELECTRIC SHOCK AND FIRE HAZARD
Do not lay tools or other metal parts on the battery or across the terminals.
Failure to follow these instructions may result in death or serious injury.
CAUTION
ELECTRIC SHOCK HAZARD
• Do not touch the energized surfaces of any electrical component in the battery
system.
• Before servicing the battery, follow all procedures to fully de-energize the battery
system.
• Follow the “Safe Handling Procedures” below when working with the battery.
Failure to follow these instructions may result in injury.
1.4 Safe Handling Procedures
Before using the battery and any power electronics, read all instructions and
cautionary markings on all components and appropriate sections of their manuals.
• Use personal protective equipment when working with batteries.
• Do not dispose of the battery in a fire.
• Promptly dispose of or recycle used batteries following local regulations.
• Do not disassemble, open, crush, bend, deform, puncture, or shred.
• Do not modify, re-manufacture, or attempt to insert foreign objects into the
battery, immerse or expose the battery to water or other liquids, fire, explosion,
or other hazards. If the user suspects damage to the battery module due to water,
heat, or other reason, take it to a service center for inspection.
• Only use the battery for the system for which it is specified.
• Do not lift or carry the battery while in operation.
• When lifting a heavy battery, follow the appropriate standards.
• Only lift, move, or mount following local regulations.
• Take care when handling battery terminals and cabling.

5
• Only use the battery with a charging system that meets specifications. Using a
battery or charger that does not meet specifications may present a risk of fire,
explosion, leakage, or other hazards.
• Do not short-circuit a battery or allow metallic conductive objects to contact
battery terminals.
• Replace the battery only with another one qualified for the system. Using an
unqualified battery may present a risk of fire, explosion, leakage, or other
hazards.
• Do not drop the device or battery. If the device or battery is dropped, especially
on a hard surface, and the user suspects damage, take it to a service center for
inspection.
1.5 Personal Protective Equipment
When handling or working near a battery:
• Use Personal Protective Equipment, including clothing, glasses, insulated gloves,
and boots.
• Do not wear rings, watches, bracelets, or necklaces.
2. DOCUMENTATION
This Application Note provides information about integrating LYNK network-
enabled Discover Lithium Batteries using the LYNK LITE Communication Gateway
with Victron Mobile inverter-chargers.
Before installation and configuration, consult the relevant product documentation,
including Manuals, Application Notes, and Installation and Configuration Guides.
Victron Energy Documentation
Visit https://www.victronenergy.com/ for the most recent version of published
documents.
Discover Battery Documentation
Visit https://discoverbattery.com for the most recent version of published
documents, including Discover Lithium battery user manuals and the LYNK LITE
Installation and Operation Manual (805-0035).
3. OVERVIEW
This manual provides general settings and is not a comprehensive guide to the
programming and configuration of a specific installation. An installation may
have unique conditions or use cases requiring value modification or adaptations.
Installers must be capable of reviewing and adapting to the specifics of an
installation and its specific use case and optimizing settings where needed.

6
The key steps required to install and configure the LYNK LITE Communication
Gateway with compatible Discover Lithium batteries and power conversion
equipment are as follows:
• Review and confirm equipment compatibility and correct sizing.
• Mount the LYNK LITE, and connect the Discover battery communication network
to either the LYNK Port or AEbus Port.
• Match and connect the LYNK LITE CAN out pins to the CAN pins of the power
conversion communication network.
• Terminate all networks correctly.
• Set up the open-loop configuration parameters on the power conversion
equipment.
• Set the LYNK LITE using LYNK ACCESS software to the correct protocol to enable
closed-loop communication between the Discover batteries and the power
conversion equipment.
• Set up the closed-loop configuration parameters on the power conversion
equipment.
• Set up user preferences and enable the use case using the power conversion
control system.
3.1 System Overview
The LYNK LITE Communication Gateway unlocks the full potential of a Discover
Lithium battery by enabling the internal Battery Management System (BMS)
to provide real-time data in a closed-loop configuration to other devices. This
configuration allows hybrid inverter-chargers and solar charge controller systems
to optimize control over the charging process. LYNK LITE also enables the remote
monitoring of Discover Lithium battery SOC and data logging of multiple sites using
the data monitoring services offered by inverter systems.
Discover Lithium batteries must be set up to work with power conversion and
monitoring devices in either an open-loop or closed-loop configuration.
In an open-loop configuration, charge and discharge settings are set up manually
through the controller for the power conversion device at the installation time.
In a closed-loop configuration, the BMS of the Discover Lithium battery sends the
battery status over a network data connection with the power conversion device.
Power conversion devices use the Discover Lithium battery BMS data to finetune
the output of their charger and deliver other functional controls based on battery
voltage, temperature, and percent State-of-Charge.
If communication is interrupted between the BMS and Victron inverter-charger, the
Victron inverter-charger uses the charge and discharge settings specified for an
open-loop configuration.

7
NETWORK
TERMINATOR
VE.CAN
M12 TO RJ45
CABLE
CONVERTER
VE.DIRECT
VE.BUS
LYNK PORT
LYNK PORT
CANUSB
CAN
Figure 1. Example LYNK LITE with Victron Energy devices
3.2 Compatibility
The LYNK LITE Communication Gateway is compatible with the following:
Discover Lithium Batteries
• LITHIUM PROFESSIONAL: DLP-GC2-12V, DLP-GC2-24V, DLP-GC2-48V
• AES LiFePO4: 12-48-6650, 14-48-3000, 14-24-2800
Victron Products
Control Panels:
• Cerbo GX
• Color Control GX
• Venus GX
Used in conjunction with:
• Quattro Inverter-Charger
• Multiplus Inverter-Charger
• SmartSolar MPPT

8
3.3 Minimum Battery System Capacity
Battery charge and discharge rates are managed automatically by the Discover
Lithium Battery and Victron Energy device. Using large solar arrays with battery
banks that are too small can exceed the operating limits of the battery to charge
and possibly lead to the BMS triggering over-current protection. Either curtail the
charging below the operational limit of installed batteries, or the battery capacity
must accept the maximum charge current of the system. Derive this value by
adding the charge capacities of all inverter-chargers and solar charge controllers in
the system. Additionally, battery peak capacity must support the surge requirements
demanded by the load attached to the inverter. Match all inverter peak power values
with the sum of all battery peak current values.
Inverter Peak Amps DC = (Inverter Surge W) / (Inverter Efficiency) / (48V: Low
Battery Cut-Off)
Discharge Continuous Amps DC = (Inverter ContinuousW) / (Inverter Efficiency) /
(48V: Low Battery Cut-Off)
48V 120 Vac
Models
Inverter
Peak
Amps
DC
Discharge
Continuous
Max Amps
DC
Charger
Continuous
Max Amps
DC
12-48-6650
Minimum
per
inverter
14-48-3000
Minimum
per
inverter
DLP-GC2-48V
Minimum
per
inverter
MultiPlus
48/2000/25-50 (1) 77 35 25 1 1 2
MultiPlus-II
48/3000/35-50 (2) 122 53 35 1 1 2
Quattro
48/3000/35-50/50
120V (3)
132 53 35 1 1 2
Quattro
48/5000/70-
100/100 120V
(4)
220 88 35 1 2 3
1 Calculated based on max 3500W at 120 VAC peak output,1600W at 120VAC continuous output, efficiency 95.0 %,
and 25A DC max charging, as published in Victron Multiplus 2kVA 120A Manual rev 05 - 01/2022.
2 Calculated based on max 5500W at 120 VAC peak output, 2400W at 120VAC continuous output, efficiency 94.0 %,
and 35A DC max charging, as published in Victron MultiPlus-II 12V/24V/48V 3kVA 120V Rev 02 09/2022.
3 Calculated based on max 2400W at 120 VAC peak output, 6000W at 120VAC continuous output, efficiency 95.0 %,
and 35A DC max charging, as published in Victron Quattro (with firmware xxxx400 or higher) 48/3000/35-50/50 120V
Version 14, 08-04-2020.
4 Calculated based on max 4000W at 120 VAC peak output, 10000W at 120VAC continuous output, efficiency 95.0 %,
and 70 A DC max charging, as published in Victron Quattro (with firmware xxxx400 or higher) 48/5000/70-100/100
120V Version 7, 08-05-2020.

9
Inverter Peak Amps DC = (Inverter Surge W) / (Inverter Efficiency) / (24V: Low
Battery Cut-Off)
Discharge Continuous Amps DC = (Inverter ContinuousW) / (Inverter Efficiency) /
(24V: Low Battery
Cut-Off)
24V 120 Vac
Models
Inverter
Peak
Amps DC
Discharge
Continuous
Max Amps
DC
Charger
Continuous
Max Amps DC
14-24-2800
Minimum
per inverter
DLP-GC2-24V
Minimum
per inverter
MultiPlus
24/2000/50-50 (1) 155 71 50 1 1
MultiPlus-II
24/3000/70-50 (2) 244 107 70 1 2
MultiPlus-II
2x120V
24/3000/70-50 (3)
244 107 70 1 2
Quattro
24/5000/120-
100/100 120V (4)
222 87 120 2 2
1 Calculated based on max 3500W at 120 VAC peak output,1600W at 120VAC continuous output, efficiency 94.0 %, and
50A DC max charging, as published in Victron Multiplus 2kVA 120V Manual Rev 05 - 01/2022.
2 Calculated based on max 5500W at 120 VAC peak output, 2400W at 120VAC continuous output, efficiency 94.0 %,
and 70 A DC max charging, as published in Victron MultiPlus-II 12V/24V/48V 3kVA 120V Rev 02 09/2022.
3 Calculated based on max 5500W at 120 VAC peak output, 2400W at 120VAC continuous output, efficiency 94.0 %,
and 70A DC max charging, as published in Victron MultiPlus-II 12V/24V 3kVA 2x120V Rev 06 08/2022.
4 Calculated based on max 4000W at 120 VAC peak output, 10000W at 120VAC continuous output, efficiency 94.0 %,
and 120A DC max charging, as published in Victron Quattro (with firmware xxxx400 or higher) 24/5000/120-100/100
120V Version 7, 08-05-2020.
Inverter Peak Amps DC = (Inverter Surge W) / (Inverter Efficiency) / (12V: Low
Battery Cut-Off)
Discharge Continuous Amps DC = (Inverter ContinuousW) / (Inverter Efficiency) /
(12V: Low Battery
Cut-Off)
12V 120 Vac Models
Inverter
Peak Amps
DC
Discharge
Continuous
Max Amps DC
Charger
Continuous
Max Amps DC
DLP-GC2-12V
Minimum per
inverter
MultiPlus 12/2000/80 (1) 314 144 80 2
MultiPlus 12/3000/120-
50 (2) 493 215 120 3
MultiPlus 12/3000/120-
50 2x 120 (3) 493 215 120 3
Quattro 12/5000/220-
100/100 120V (4) 887 355 200 5
1 Calculated based on max 3500W at 120 VAC peak output, 1600W at 120VAC continuous output, efficiency 93.0 %,
and 80A DC max charging, as published in Victron MultiPlus 2kVA 120V rev 05 - 01/2022.
2 Calculated based on max 5500W at 120 VAC peak output, 2400W at 120VAC continuous output, efficiency 93.0 %,
and 120A DC max charging, as published in Victron MultiPlus-II 12V/24V 3kVA 2x120V Rev 06 08/2022.
3 Calculated based on max 5500W at 120 VAC peak output, 2400W at 120VAC continuous output, efficiency 93.0 %,
and 120A DC max charging, as published in Victron MultiPlus-II 12V/24V/48V 3kVA 120V Rev 02 09/2022.
4 Calculated based on max 4000W at 120 VAC peak output, 10000W at 120VAC continuous output, efficiency 94.0 %,
and 200A DC max charging, as published in Victron Quattro (with firmware xxxx400 or higher) 12/5000/220-100/100
120V Version 7, 08-05-2020.

10
4. INSTALLATION AND CONNECTING LYNK LITE TO THE VE.CAN
NETWORK
4.1 Networking Discover Lithium Batteries with LYNK LITE
NOTICE
• Turn OFF all devices before connecting cables.
• Mixing the LYNK Network with other networks may result in equipment malfunction
and damage.
NOTICE
Unless specified by Discover Battery, do not connect power electronics directly to
the LYNK network or AEbus network.
Refer to the LYNK LITE Installation and Operation Manual (805-0035) for instructions
on network layouts, connections, and terminators of compatible Discover Lithium
battery models. Some key points are repeated here for convenience.
• Connect at least one battery to the LYNK Port on the LYNK LITE.
• A network of batteries will communicate as one battery.
• Connect no more than one network of batteries to the LYNK LITE.
• Proper system function requires network termination – some batteries and
devices may auto-terminate.
• LYNK LITE requires power from one of two possible sources (an AEbus/LYNK
Port-enabled Discover Lithium battery or a USB device).
• Discover Lithium batteries must be set to ON to supply power and communicate
with LYNK LITE.
Figure 2. AES LiFePO4 Mobile Industrial Battery
The LYNK LITE is internally terminated. AES batteries are not internally terminated.
When using LYNK LITE on an AESbus or LYNK network, install a terminator
opposite the LYNK LITE at the far end of the battery network.
