Displays2go LTB8MLT3TH User manual

-4-
This product contains small items that could be a choking hazard if swallowed. Keep
these items away from young children
1.Make sure these instructions are read and completely understood before attempting
installation. If you are unsure of any part of this installation, contact a professional
installer for assistance.
2.The wall or mounting surface must be capable of supporting the combined weight of
the mount and the display; otherwise the structure must be reinforced
3.Safety gear and proper tools must be used. A minimum of two people are required
for this installation. Failure to use safety gear can result in property damage, serious
injury or death.
!
.
Warning
Thank you for choosing our product TV Size Range: 10 24
Max load capacity of each TV plate
8Kg/17.6lbs
Integrated Cable management
""
:
~
INSTALLATION GUIDE
Item No.:LTB8MLT3TH
CAUTION
Please read this guide before installation.
Ensure the correct installation. Keep away from high frequency or power equipment to
avoid disturbance.Choose desk to put this product.
We can not be responsible for any damage caused by wrong installation.
CABLE

-3-
-2-
Hardware Kit:
AB
.
Part 2-Attaching TV plate to screen
Center TV plate on back of the screen and align the twelve mounting holes.
Select screws(A,B). Attach TV plate to screen using selected screws
(A,B).
twelve
Tighten screws firmly. Do not overtighten
Part 2-Attaching TV plate to screen
F M5x10mm sunk bolt(5).ixed the wreath(4) on the tube by
Part 1-Fixed wreath
Part 1-Fixed wreath
45
NOTE:
AB,
First fixed the bottom support (8) on the tube and use (D) by 6X6mm
wrench (E) to make it tighten.Then slide the TV plate into the tube and fixed
it by knob (3).When fixed wreath and TV plate are installed, put on the tube
cover (1) and use (C) by 3X3mm wrench (E) to make it tighten.
Part 3-Install TV plate Bottom supportand fixed
Part 3-Install TV plate and fixed Bottom support
E(6X6mm)
1
C
E(3X3mm)
3
8
D
C
1E
2
D
8
6
7
3
45
Description
Bottom support
M5x10mm sunk bolt
ID
1
4
5
3
6
1
2
2
2
Qty
Tube Cover
TV plate
Knob
Fixed wreath
7
8
2
1
1
2Cable cover
Tube
2
M4×12mm bolt
M5×12mm bolt
M4×10mm bolt
C
A
B
1
12
12
D1M10×20mm bolt
E2
3X3,6X6mm Wrench
