Dittmann KMT 285 User manual
Version 1, 2011-09
• 3 in 1, for pain, hot and cold
treatment on the knee
• Universal size, individually adjustable
with 2 large vlcro fasteners
• For all TENS devices with 2 mm
plug diameter
• With 4 cold/hot compresses
• Gel compresses individually removable
• 4 electrodes, can be wetted with water,
2 electrodes each can be addressed
with one channel of the TENS device
• Content:
1 knee ache cuff with
4 electrodes
4 cold/hot compresses, diameter
ca. 11 cm
• Incl. instruction manual
• 24 months warranty
INSTRUCTION MANUAL
Knee Ache Cuff KMT 285
KMT 285
1
GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:48
1.0
2.0
2.1
2.2
2.3
3.0
3.1
3.3
3.4
3.5
3.6
3.7
3.8
4.0
4.1
4.2
4.3
4.4
4.5
5.0
6.0
7.0
8.0
9.0
3
3
3
3
3
4
4
5
5
6
6
7
7
8
8
8
8
9
9
10
10
11
12
13
2
Warranty
Technical data, symbols
Hot treatment with the knee ache cuff
Cold treatment with the knee ache cuff
Putting on and using the knee ache cuff
Design of the knee ache cuff
Delivery scope/package contents
Disposal of the knee ache cuff
Cleaning and care of the knee ache cuff
Storage/maintenance of the knee ache cuff
Where may the knee ache cuff not be used?
Use of the knee ache cuff
Use by children and youths
For which application range is the knee ache cuff not suited?
For which application range is the knee ache cuff suited?
For which application range/environment is the knee ache cuff not suited?
For which application range/environment is the knee ache cuff suited?
General safety instructions
Safety instructions
Information on cold and hot treatment
Information on TENS use
What does TENS mean?
Basic information
What do the symbols mean?
No Subject Page
TABLE OF CONTENTS
GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:48
3
The knee ache cuff has 4 side compartments into which you can insert one of the four
cold/hot compresses each. The cold/hot compresses have a gel filling that stores heat or
cold very effectively. This ensures optimum cooling or heating of the body region around
the knee ache cuff.
2.3 Information on cold and hot treatment
A TENS device generates electric currents in the low frequency range for therapy. The
respective application program of the device controls the generated electric impulses,
their intensity, frequency and frequency range. The electric impulses are transferred to
the nervous system and the muscles by the adhesive skin electrodes. The current flows
from one electrode to the other, depending on the pulse type of the device. This method
influences the transmission of pain signals to the central nervous system in the applied
TENS therapy. The user no longer senses the pain or only to a limited extent. The
intensity of the electrodes in the knee ache cuff depends on the setting of the respective
device. If your TENS device has two channel outputs, two electrodes can be connected
per channel. When attached to the body, the pulses run horizontal to the respective
plane of the electrodes.
2.2 Information on TENS use
TENS: T= Transcutaneous (transmitted via the skin), E= Electric,
N= Nerve, S= Stimulation.
2.1 What does TENS mean?
2.0 Basic information
Warning/Danger: The device may not be used by persons with
pacemakers!
You must observe these instructions under all circumstances!
Warning/Danger: Danger of serious injury/damage in case of improper
handling!
Read and observe the instruction manual!
The symbols have the following meaning:
The safety symbols shown in this manual are instructions concerning the proper handling
of the knee ache cuff and your safety.
1.0 What do the symbols mean?
BASIC INFORMATION GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:48
3.1.1
3.1.2
3.1.3
3.1.4
3.1.5
3.1.6
3.1.7
3.1.8
3.1.9
3.2.0
3.2.1
3.2.2
3.2.3
3.2.4
3.2.5
4
Keep the instruction manual throughout the service life of the product.
If irregularities should occur during treatment, stop using the device
immediately.
If gel should leak from a compress and come into contact with your skin,
rinse the spot very thoroughly under running water.
Do not store the cold/hot compresses permanently in the refrigerator.
Do not place the cold/hot compresses for more than 4 hours in the
refrigerator.
Please note: not all types of inflammation can be treated with a cold therapy. If in
doubt, ask your physician.
Never use the enclosed cold/hot compresses for treatment without having the
knee ache cuff attached between the application site and the cold/hot compress if
you have previously heated or chilled the compress. This may lead to chilblains or
burns. Test the temperature on the back of your hand prior to use.
Do not place any heavy or sharp-edged objects onto the knee ache cuff
or the cold/hot compresses.
Prevent abuse and other use of the device that does not correspond to its
intended purpose. You may not use any other accessories of other devices.
Observe the operating instructions of the manufacturer of your TENS device when
connecting the knee ache cuff KMT 285 to this.
Keep this instruction manual for later questions and hand it over to third parties
when passing the knee ache cuff on. Also let third parties access these
instructions. The instruction manual is part of the knee ache cuff.
Do not use the knee ache cuff on points of your body with inexplicable pain,
swollen muscles or after grave muscle injuries without consulting your physician.
Treatment with the knee ache cuff does not replace medical diagnoses and
treatment.
If you have any doubts regarding the application of the knee ache cuff, consult
your physician before using it.
Do not use the knee ache cuff while driving a car and also do not perform any
other activities during application.
Prior to use, remove all metal objects like jewellery, belts, watches and other
utensils from your body so that these do not come into contact with the
knee ache cuff.
If you notice any skin changes, pain, swelling, indisposition or other irregularities
during the application of the knee ache cuff, stop it immediately and consult your
physician.
In case of a defect, you may not repair, use or modify the knee ache cuff yourself.
In case of wrong application, the stimulating current may lead to pain, injury and
burns.
3.1 General safety instructions
3.0 Safety instructions
SAFETY INSTRUCTIONS
GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:48
5
3.3.1
3.3.2
3.3.3
3.3.4
3.4.1
3.4.2
3.4.3
3.4.4
3.4.5
3.4.6
3.2.6
Do not use the knee ache cuff close to shortwave or microwave appliances (less
than 1.5 m) or a high-frequency HF surgical device to prevent skin irritation or
burns underneath the electrodes. Do not use the knee ache cuff and the
stimulator in the mountains at an altitude of above 3000 metres.
The knee ache cuff may interfere with other electric devices or be disturbed by
other electric devices. Therefore, do not use the knee ache cuff close to other
electric devices.
Do not use the knee ache cuff close to easily flammable substances and gasses or
close to explosives.
Do not use the knee ache cuff in bed and/or when sleeping.
Do not use the knee ache cuff when showering, swimming, going to the sauna,
bathing, or in any other environment with a high degree of humidity. Keep any
liquid away during application. Injuries or health damage may occur with excess
stimulation or in case of a short-circuit - mortal danger!
The knee ache cuff may not be used together with any other medical and electric
devices at the same time.
3.4 For which application range/environment is the knee ache cuff
not suited?
Use the knee ache cuff for hot treatments in case of:
tension, muscle aches.
Use the knee ache cuff for cold treatments in case of:
bruises, sprains, pulled muscles, swelling, inflammation, insect bites, contusions
and acute complaints like e.g.: haematoma.
The knee ache cuff is only intended for external application (via the skin) on
humans and the treatment of clearly diagnosed chronic pain.
Only use the knee ache cuff for the intended purpose for low-voltage application
max. electric pulses up to 120 Hz and max. 120 mA) on your knee.
3.3 For which application range/environment is the knee ache cuff
suited?
Avoid excessively high pressure during a hot or cold treatment to prevent bad
circulation and/or congestion. Adjust the pressure of the knee ache cuff in such a
way that the pressure sensation is pleasant. Excessively high pressure constricts
the blood vessels and nerves, which may lead to irreparable tissue damage and
loss of limbs.
SAFETY INSTRUCTIONS GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:48
6
3.6.1
3.6.2
3.6.3
3.6.4
3.6.5
3.6.6
3.6.7
3.5.1
Persons not able to fully feel hot or cold may not be subjected to a cold/hot
treatment with this knee ache cuff. Small children are more sensitive to heat and
cold! Fragile and handicapped
persons may not be able to voice complaints if the temperature is too hot or
too cold.
The following persons should not be subjected to a hot/cold treatment: children
below the age of 3, helpless persons, allergic persons, persons with a weak
immune system, persons with pain of unknown causes or diabetes, persons
suffering from circulation problems, persons with blood flow disorders on the
outer arteries and tissues,persons with severe cardiac disease. In case of
questions, consult your physician.
The cold/hot compresses as well as the knee ache cuff may not be applied to
open wounds, sensitive skin regions and fresh scars.
Do not use the knee ache cuff in case you might injure yourself due to sudden
startling.
In case of unspecific pain like e.g. unspecific headaches, treatment with the
knee ache cuff and a stimulator is ineffective.
In case of the following circumstances, you must consult your physician prior to
using the knee ache cuff: a. acute illnesses, b. tumours, c. in case of infectious
diseases, d. in case of fever, e. blood pressure problems, f. skin diseases, g. after
an accident, h. in case of nausea or dizziness, i. at the breakout of an illness, j. as
soon as irregularities result, k. in case of inexplicable pain, l. diabetes, m.
seizures, n. during menstruation, o. in case of no sensitivity to pain in the
respective body part, p. persons with metal in their body
In case of the following circumstances you may not use the knee ache cuff: a)
heart disease and arrhythmia (may lead to cardiac arrest), b. directly on lesions,
c. during pregnancy in the region of the uterus and during contractions, d. in the
range of the eyes, e. when wearing a pacemaker, f. on body parts with bad blood
circulation, g. on persons with psychological and emotional disorders, h. on
persons with diagnosed dementia (mental degeneration), i. on persons with low
IQ (intelligence quotient)
3.6 For which application range is the knee ache cuff not
suited?
TENS devices only treat symptoms. They cannot heal them. In case of questions
concerning your therapy, contact your physician.
3.5 For which application range is the knee ache cuff
suited?
SAFETY INSTRUCTIONS
GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:48
7
3.7.1
3.7.2
3.8.1
3.8.2
3.8.3
3.8.4
3.8.5
3.8.6
3.8.7
3.8.8
3.8.9
3.9.0
3.9.1
3.9.2
3.9.3 The perception of the intensity depends on your day to day condition and you can
adjust it with the intensity control of the of the stimulator to your personal needs.
If not prescribed differently by your physician, we recommend an average
treatment time of 30 min. up to three times a day.
Only place the knee ache cuff onto the intended parts of your knee.
The knee ache cuff may not be used on body parts with skin inflammation,
open and fresh wounds.
Do not pull on the cable if you want to disconnect the plug-type connector of the
knee ache cuff.
Each person reacts differently to electric nerve stimulation. If treatment is not
successful, you should consult your physician.
You can connect/disconnect the knee ache cuff to the TENS device with the plug-
and socket connector featuring the electricity cable.
To prevent damage to the cables, do not tug on the cables when removing the
plug-type connections from the knee ache cuff. To connect or remove the knee
ache cuff, only pull on the plugs or connect them there.
Only connect the cables and the knee ache cuff when the stimulation device
(TENS device) is turned off.
Prior to the treatment, thoroughly clean and dry the skin regions on which you
want to apply the knee ache cuff. The skin regions must be fat-free and clean.
Use of the knee ache cuff may result in skin irritation in some cases.
In case such skin irritations occur, e.g. redness, blistering or itching, do not use
the knee ache cuff anymore.
Do not use the knee ache cuff permanently on the same body part, as this may
also lead to skin irritations.
If you want to reposition the knee ache cuff during treatment, turn the
device/stimulator off first.
The knee ache cuff may only be connected to stimulators with a 2 mm plug. Make
sure that the device/stimulator is turned off when attaching or removing the knee
ache cuff.
3.8 Use of the knee ache cuff
Keep the knee ache cuff away from children and youths below the age of 18.
Children may not be treated with this knee ache cuff.
3.7 Use by children and youths
SAFETY INSTRUCTIONS GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:48
8
4.0.1
4.0.2
4.1.1
4.1.2
4.1.3
4.1.4
Carefully clean the surface of the with a damp cloth. The
device/stimulator may not be turned on during cleaning. Therefore remove the
batteries from the device/stimulator prior to cleaning it. Let the
dry thoroughly afterwards.
knee ache cuff
knee ache cuff
4.2.1
4.2.2
4.2.3
4.2.4
4.2.5
4.2.6
4.2.7
4.3.1 If the knee ache cuff is no longer usable, dispose of it in accordance with the
statutory regulations. For more information, contact your municipal administration
or a disposal company. Dispose of the knee ache cuff in line with the Waste
Electrical and Electronic Equipment EU guideline 2002/96/EU-WEEE.
4.3 Disposal of the knee ache cuff
Observe the washing instructions on the knee ache cuff.
Let the knee ache cuff dry thoroughly after each cleaning.
Also check the insides of the 4 side compartments (fig. F, page 9) to see that they
are properly dry.
Use a standard disinfectant for disinfection.
Let the knee ache cuff dry thoroughly afterwards.
The TENS device/stimulator may not be turned on during cleaning and
maintenance.
For reasons of hygiene, each user should use his/her own knee ache cuff.
The knee ache cuff may not be exposed to direct sunlight. Do not place the knee
ache cuff on hot surfaces.
4.2 Cleaning and care of the knee ache cuff
In case of commercial or business use of the knee ache cuff
KMT 285, a safety check has to be performed every 24 months in line with § 6
MPBetreibV. The safety check must be performed by a specialised medical
products company. For more information contact our service centre (see page 13)
The connection cables as well as the knee ache cuff may not be bent.
Clean the knee ache cuff after each application.
Do not disassemble or repair the knee ache cuff, as this may lead to technical
defects or physical accidents.
The knee ache cuff is maintenance-free.
4.1 Storage/maintenance of the knee ache cuff
Only place the knee ache cuff onto the intended part of your knee and observe
the placement instructions.
The knee ache cuff may not be used on body parts with skin inflammation,
open and fresh wounds.
4.0 Where may the knee ache cuff not be used?
STORAGE/CARE
GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:48
9
E. Top velcro
fastener
D. Bottom velcro
fastener
C. Connection sockets 2
F. 4 side compartments for
insertion of the cold/hot
compresses
B. Connection sockets 1
A. 4 round
electrodes
4.5 Design of the knee ache cuff
1 x Instruction manual
4 x cold/hot compresses
1 x Knee ache cuff
4.4 Scope of delivery/package content
SCOPE OF DELIVERY GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:49
10
Image. 1
Image 2
6.1
6.2
6.3
6.4
Place the gel compresses in a plastic bag and put them into the refrigerator or
freezer for at most 2 hours (max. - 18°C).
Check the temperature of the gel compresses with the back of your hand or
lower arm prior to use to make sure that they are not too cold.
Attention: Risk of chilblains.
Do not store the gel compresses permanently in the refrigerator or freezer.
Do not chill in the freezer! Risk of chilblains and irreparable tissue damage!
Take the knee ache cuff off your body once it has reached room temperature or
if the coldness of the cuff becomes uncomfortable.
6.0 Cold treatment with the knee ache cuff
Step 1:
For cold or hot treatment, you first have to heat or chill the cold/hot compresses (see
4.4 page 9) in line with the instructions on page 10 + 11. Then slide them completely
into the side compartments (fig. F, page 9). The gel compresses may not stick out.
Then perform steps 2 and 3 indicated above. After treatment, let the knee ache cuff
dry thoroughly.
Cold and hot treatment with the knee ache cuff
Step 5:
When you want to stop the treatment, you first have to turn off the stimulation
device. Afterwards you can detach the plug connections (B+C page 9) and take the
knee ache cuff off.
Step 4:
Now you can connect the TENS device with the connection sockets (B+C page 9).
Make sure that the stimulation device (TENS) is turned off when connecting
the device. Once the connection is established, you can start the TENS treatment.
When attached to the body, the pulses run horizontal to the respective plane of the
electrodes.
Step 3:
Wrap the two straps (see fig. D+E page 9) with the velcro
fasteners around the knee and fix it in the desired position on
the bandage (see fig. 2). The bandage and the 4 electrodes
(see fig. A page 9) must be flush to the knee and properly
fixed in place.
Step 2:
When applying the cuff, make sure that it is placed in
position A (fig. 1) in the centre of the thigh. The circular
opening B (fig. 1) must be placed centrally to
the kneecap.
Step 1:
For TENS application, you first have to wet the 4 round
electrodes (see fig. A page 9) with a bit of water. Best use a
damp cloth.
Application with a stimulation device (TENS)
5.0 Applying and using the knee ache cuff
APPLICATION
GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:52
11
COLD/HOT TREATMENT GB
7.0.1
7.0.2
7.0.3
7.0.4
7.1.1
7.2.1
7.1 Heating in a hot water bath
7.2 Heating in the microwave
Heat at low power (max. 180 Watt, thawing stage) for approx. 2 minutes.
Do not use a higher wattage. This may damage the gel compresses. If the
compresses do not have the desired heat yet, heat again in 15 seconds intervals.
Do not leave the gel compresses unattended while heating. If the gel compresses
start to bloat, turn off the microwave immediately. A damaged gel compress may
not be used again! Then place them carefully into the side compartments of the
using a cloth. Check the temperature with the back of your hand
or lower arm prior to use. If the gel compresses are too hot, leave them to cool
down to the desired temperature.
Attention: Risk of burns!
Take the compresses off your body once they have reached room temperature or
if the heat of the compresses becomes uncomfortable.
knee ache cuff
7.0 Hot treatment with the knee ache cuff
Never heat the gel compresses unattended! Check the temperature with the back
of your hand or lower arm prior to use to avoid skin burns.
Never place the gel compresses directly on the skin; always insert them into
the side compartments of the .
Excessively long heating may lead to damage to the gel compresses!
Prior to reheating, the gel compresses must have cooled down completely so they
do not become damaged. If the gel compresses are too hot, leave them to cool
down to the desired temperature.
knee ache cuff
Place the gel compresses in at most 60-80°C hot (not boiling) water for
approx. 1 to 2 minutes.
Attention: The water may not boil, otherwise the gel compresses may become
damaged. Carefully lift the gel compresses out of the water with e.g. a cooking
spoon or a pair of tongs. Then dry them off and place them carefully into the side
compartments of the . Check the temperature with the back of your
hand or lower arm prior to use. If the gel compresses are too hot, leave them to
cool down to the desired temperature. Attention: Risk of burns!
knee ache cuff
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:52
12
2011-09
V4711KMT285
5°C
50°C
10%
80%
Significance of the symbol on the product, the package or the instruction
manual: Electronic devices are valuable materials and do not belong into the
household waste after expiration of their service life! Help us to protect the
environment and valuable resources by returning this device to a disposal site
near you. In case you have any questions, contact the organization in charge
of waste disposal in your district. Dispose of the knee ache cuff in line with the
Waste Electrical and Electronic Equipment EU guideline
2002/96/EG-WEEE.
Knee Ache Cuff KMT 285
Diameter: 4 x approx. 65 mm
Up to 130 Volt at a load of 500 Ohm per channel
Up to max. 120 Hz (Hz = oscillations per second)
Up to max. 120 mA at 1000 Ohm load, DC (mA =
milliampere, Ohm = electric resistance)
5° to 40°C (Celsius)
30% - 80% (percent)
Storage and transport temperature
5°C to 50°C (Celsius)
Max. air humidity for storage and transport
10% - 80% (percent)
approx. 180 g without cold/warm gel compresses
Metals, polymers, polyester, nylon, silicon
The knee ache cuff is in conformity with EU guideline
93/42 EU for medical products.
Batch name:
Manufacturer: Handelshaus Dittmann GmbH
Kissinger Straße 68, D-97727 Fuchsstadt/Germany
Manufacturing date: 2011-09 (year-month)
Model/Type:
Electrode surface:
Max. pulse voltage (V):
Max. frequency (Hz):
Max. pulse strength (mA):
Ambient temperature:
Max. air humidity during
normal work:
Weight:
Material:
8.0 Technical data, symbols:
TECHNICAL DATA/SYMBOLS
GB
0
5
25
75
95
100
PJN056-11_(GA-GB)_KMT285_Knie_27.09.11
Dienstag, 27. September 2011 21:41:52
13
Handelshaus Dittmann GmbH
Kissinger Straße 68
D-97727 Fuchsstadt/Germany
Copyright © Handelshaus Dittmann GmbH, 2011
3905611-Technical Documentation by www.dittmann-consulting.com
Manufacturer:
With best regards
Handelshaus Dittmann GmbH
Service Center Department
Kissinger Straße 68
D-97727 Fuchsstadt/Germany
e-mail: hotline@servicecenter.tv
Telephone hotline: 0180-5012678 (0.14 €/min. from German landlines;
max. 0.42 € per minute from German mobile phones)
www.dittmann-gmbh.com
NOTICES: In case of a complaint concerning the knee ache cuff, please contact the
service center first!
If necessary, the service center will schedule the collection of your device.
The service center will not accept any FREIGHT FORWARD packages!
In the event of technical problems, and for questions in relation to warranty claims in
regard to this knee ache cuff, you can contact us as follows:
Once the warranty period has expired, you have the chance to
send the defect knee ache cuff for repair to the address stated below. Repairs after
expiration of the warranty period are subject to charges.
The following are excluded from the warranty:
- Damage caused by improper use
- Defects of which the customer was already aware at
the time of purchase
- Parts subject to wearing
- Damage caused by unauthorised intervention and
personal negligence of the customer
The legal warranty covers a period of 24 months from the date of purchase for material
and manufacturing faults of the product.
Please keep your receipt of payment as proof of your purchase of the knee ache cuff to
enable you to assert your warranty rights in the event of claims.
The knee ache cuff you have purchased was developed and produced with utmost care.
9.0 Warranty
WARRANTY GB
