DK SONIC DK-600FTS User manual

Shenzhen DeKang Electronic Cleaning Appliances Co.,Ltd
2F, Building 8, Yuanling Industrial Park, Shangwu Community, Shiyan Street, Bao'an District, Shenzhen
Tel.: [phone] Email: [e-mail]
Thank you for purchasing this ultrasonic cleaner. Please take some time to read these operating instructions before use
and keep them for future reference. Failure to follow these instructions may lead to serious artificial damages to the
product.
ULTRASONIC CLEANER
USER MANUAL

Shenzhen DeKang Electronic Cleaning Appliances Co.,Ltd
2F, Building 8, Yuanling Industrial Park, Shangwu Community, Shiyan Street, Bao'an District, Shenzhen
Tel.: [phone] Email: [e-mail]
ULTRASONIC PRINCIPLE
PREPARATION:
1. Carefully unpack the cleaner, remove all packing materials and check whether any
parts have become loose or damaged during transit.
Contents:
a: Main machine b: Sound proof lid c: Power lead
d: Outlet filter e: Mesh basket (Optional) f: Manual
2. Place the cleaner on a flat, clean surface and ensure that the cooling fan will get
adequate ventilation, and that all controls are set to off, and the drain tap is
closed.
3. Ensure that the power lead is securely plugged into the cleaner, and that no part of
the lead is likely to contact with moisture.
4. Carefully fill at least 1/2 of the tank with a solvent solution. Based on cleaning
requirements, we recommend to use a small amount of cleaning solution because
this will help increase the cleaning performance. Now the cleaner is ready for use.
Ultrasonic cleaning is based on the cavitation effect caused by
high frequency ultrasonic wave vibration signal in the fluid.
Microscopic bubbles are formed, and then implode violently
causing the cavitation which create an intense scrubbing action
on the surface of the item being cleaned. The bubbles are small
enough to penetrate microscopic crevices, cleaning them
thoroughly and consistently.
Ultrasonic cleaning is extremely effective at removing dirt and
grime which would normally require tedious manual cleaning by
hand. It has been used to clean a wide variety of instruments and
mechanical parts such as carburetors, returning them to almost
“like new” condition without damage to delicate parts.
Attention
While the machine is working normally, the syntony of the ultrasonic wave and tank gives
a well-proportioned sound with no shudder on the surface of the water but sprays
generated by the tiny bubbles. If there are discontinuous surges, please add or reduce a
little of washing solution in the tank to stop the surges, which is good for get a better
cleaning effect.

Shenzhen DeKang Electronic Cleaning Appliances Co.,Ltd
2F, Building 8, Yuanling Industrial Park, Shangwu Community, Shiyan Street, Bao'an District, Shenzhen
Tel.: [phone] Email: [e-mail]
SAFETY PRECAUTIONS
This device can not be used by individuals with limited physical knowledge, or the
mental disabled, or those lacking experiences or knowledge, such as children, unless
they are supervised by an individual who can take charge of their safety or have
received training in operating the device .
1) DO NOT operate the unit without fluid in the tank. Always ensure that the fluid is no
higher than the max mark and no lower than the minimum depth of 7cm.
2) DO NOT drop any item into the tank because it may damage the transducer. Always
place items gently into the tank and use the basket whenever possible.
3) The more items you place in the cleaning bath, the less cleaning efficient you can
get. Leaving enough spaces among items rather than overlapping them is
recommended.
4) Do keep the lid closed during use. This will prevent splashes and reduce evaporation
of the fluid.
5) Never immerse the machine or power cord in water or other liquid.
6) DO NOT touch the power plug with wet hands, especially when inserting or
removing the plug.
7) DO NOT touch the unit if the machine has fallen into water during operation.
Remove the power plug from the socket firstly.
8) DO NOT disassemble the machine if you are not professional.
9) UNPLUG the power source while filling or emptying the tank.
10) DO NOT spray water or liquid over the device and the control panel.
11) DO NOT operate the cleaner without proper grounding.
12) DO NOT place the device on a soft surface where the vents can be blocked.
13) Always turn the heater off after using as leaving it on can make the fluid evaporate
and damage the internal components.
14) Take care when adding or removing items from the cleaning tank as the splashed
fluid is likely to be hot and damage the internal components. Any splashed fluid
must be dried immediately.
15) In case of emergency or failure to follow the aforementioned items, disconnect the
main supply by turning off the switch on the back or removing the plug from the
main socket.
Keep it away from children !
Please read the following items very carefully as failure to
comply with them may invalidate your guarantee

Shenzhen DeKang Electronic Cleaning Appliances Co.,Ltd
2F, Building 8, Yuanling Industrial Park, Shangwu Community, Shiyan Street, Bao'an District, Shenzhen
Tel.: [phone] Email: [e-mail]
FEATURES
Die casting stainless steel tank
Industrial grade integrated circuit
0～99℃temperature range
1 sec~99 min 59 secs or always on
LCD screen and power adjustable
Power cut memory function
Dewaxing and degreasing function
Degas, pulse, power and turbo sweep working mode
Auto Stand-by, Sleep, and wake up by one key-press Mode
Digital controller of high-precision and a long service-life
APPLICATIONS
This list is almost endless. Provided any stuff is non porous and can normally be
immersed in water, they can be thoroughly cleaned. Here are some examples:
Jewelry especially gold, silver & platinum
Watchstraps
Coins and other collectibles
PCB Boards etc
Engine/Model parts
Toothbrushes & Dentures
Electrical components
Make-up cases
Diesel injection pumps
Printer heads and toner cartridges
Motorcycle radiators
Vehicle differentials
Milking parlor equipment
Golf clubs&grips&golf balls
Horse bits&stirrups &horse brasses
Tattoo needles
Surgical equipment
Motorcycle engine crank cases
Engine cylinder heads
Turbochargers
Bicycle derailleurs
Knives, bayonets and other militaria
Gun and gun components
Sundry laboratory use
Ultrasonic cleaning is not recommended to be used to clean the following gemstones:
Opal, Pearl, Emerald, Tanzanite, Malachite, Turquoise, Lapis and Coral.

Shenzhen DeKang Electronic Cleaning Appliances Co.,Ltd
2F, Building 8, Yuanling Industrial Park, Shangwu Community, Shiyan Street, Bao'an District, Shenzhen
Tel.: [phone] Email: [e-mail]
OPERATION
1. Fill the stainless steel tank with cleaning solution; Plug the power lead into
grounded outlet; Turns on the switch on the back of the ultrasonic cleaner and
press the rotary power knob; After power-on, the LCD screen displays the preset
temperature (25℃in default), actual environmental temperature, preset time (3
minutes in default), actual time, frequency and power ratio.
2. POWER (ON/OFF): The power knob can be used to turn on or off the machine
by pressing the knob once, and to adjust the value of ultrasonic power from “0%”
to “100%” by rotating the power knob. The power ratio can be displayed on the
right bottom of the LCD screen.
3. Cleaning modes: Common,Degas,Pulse,Turbo Sweep,Power Sweep.
Five cleaning modes can be chosen to clean different stuffs. Especially the power
under each cleaning modes can be adjusted by rotating the power knob.
4. Ultrasonic button: The ultrasonic cleaning can be started or paused by pressing
the “Ultrasonic” button once, and be stopped by keeping pressing the
“Ultrasonic” button for a few seconds. The indicator will be on when ultrasonic
cleaning works, while the indicator will be off and the machine will buzz when
ultrasonic cleaning is finished.
5. Time setting: Press the ultrasonic “+/- “ button once to add or decrease one
second cleaning time; keep pressing the ultrasonic “+/- “ button to make the time
setting to be added or decreased by seconds, and by minutes after the second
value has reached 59 seconds; press the ultrasonic “+” and “-” buttons
simultaneously to make the machine enter into the “always on” working mode.
6. Heating button: The heating function can be started or stopped by pressing the
“Heating” button once, while if the preset temperature is not 1~2℃higher than
the actual temperature, the heating function can not be started. Under working
mode, the heating function will start working automatically when the actual
temperature goes down to a value which is 1~2℃lower than the preset
temperature. In default, the heating function will stop automatically after the
ultrasonic cleaning is finished.
7. Temperature Setting: 1℃can be added or decreased by pressing the heating
“+/-” once, and the preset temperature can be added or decreased continuously
by keeping pressing the heating “+/-” button.
NOTE: Do not pour water out until it’s cooling, Hot water will hurt you and damage
the machine itself.

Shenzhen DeKang Electronic Cleaning Appliances Co.,Ltd
2F, Building 8, Yuanling Industrial Park, Shangwu Community, Shiyan Street, Bao'an District, Shenzhen
Tel.: [phone] Email: [e-mail]
DIFFERENT WAYS OF CLEANING
Gennral Cleaning—use only water to clean under the temperature of about 50℃;
Enhanced Cleaning—add few drops of standard cleaning solutions, liquid soap, or
detergent, or any other non-acidic cleaning agents.
Extensive Cleaning--removing tarnish, carbon & rust from non-plated metals, it is
recommended to use specific cleaning solution associated with ultrasonic cleaners.
The cleaning solution will deteriorate in effectiveness over time and use. It is important
to regularly change the fluid and carefully wash the inside of the cleaning tank in order
to preserve the effectiveness and longevity of the cleaner. Do not use corrosive or
abrasive cleaning tools to clean the tank which must be wiped down and dried before it
can be re-connected to the electrical supply.
NOTE: If the machine starts to spark, smoke, smell of burnt electrics or displays any
other fault the operator must immediately stop the machine, and isolate it from the
electrical supply and contact the supplier. It is dangerous to use it after that.
WARNING : Strong acid or alkaline cleaning solution will cause corrosion, rust and
even puncture of tank or machine body. To solve this problem, please dilute the solution
to mild PH or use a special tank made of a specific-graded stainless steel, like SUS304.

Shenzhen DeKang Electronic Cleaning Appliances Co.,Ltd
2F, Building 8, Yuanling Industrial Park, Shangwu Community, Shiyan Street, Bao'an District, Shenzhen
Tel.: [phone] Email: [e-mail]
Advantage
Ultrasonic is widely used throughout industries to remove difficult contaminants from
the parts during or after manufacturing process which might require a stage of
cleaning before the next process. In general, if an item can be cleaned with liquid, it
can be cleaned much faster and more thoroughly with an ultrasonic cleaner. Compared
with traditional solvent/scrubbing, our ultrasonic cleaners:
Are more effective at removing contaminants;
Are quicker to get a good cleaning effect;
Save labor time of employees (and subsequent labor cost);
can heat the cleaning solutions to a suitable cleaning temperature so as to
enhance the cleaning efficiency;
Have a digital controller of high-precision and a long service-life;
Are of high performance;
reduce chemicals in the cleaned stuffs;
Are environment friendly because of its recyclability.
For Better cleaning effect:
●Immerse the cleaned stuffs well into the water. (below the “MAX” mark)
●Add a small amount of cleaning solution is added.
●Make sure that there is enough space around each stuff in the tank. The more
stuffs you place in the tank, the less efficiency you can get. It is not advised to
overlap stuffs because the ultrasonic cleaning system can not work well with
layered stuffs.
●Use a basket. Do not put stuffs directly into the bottom of the tank because that
is harmful for the inner tank. So it is better to use a suitable basket. Especially a
metal basket only absorbs about 8% ultrasonic energy.
●Choose a suitable temperature: Generally, the higher the temperature is, the
better cleaning effect the ultrasonic cleaner can make. However, when
temperature exceed 70℃～80℃, cleaning effect will be affected. So the best
temperature we suggest is 40℃～60℃.

Shenzhen DeKang Electronic Cleaning Appliances Co.,Ltd
2F, Building 8, Yuanling Industrial Park, Shangwu Community, Shiyan Street, Bao'an District, Shenzhen
Tel.: [phone] Email: [e-mail]
SPECIFICATIONS
Model
Tank Size
(mm)
Overall Size
(mm)
Volume
(L)
Power
(W)
FREQ.
(KHz)
Heating
(W)
Time
(min:secs)
Temp.
(℃)
DK-600FTS
300x155x150
330×180×357
6.5
0~180
28/40/68
300
00:01-99:59
0-100
DK-1000FTS
300x240x150
330x270x357
10
0~240
300
00:01-99:59
0-100
DK-1500FTS
330x300x150
360x330x380
15
0~360
400
00:01-99:59
0-100
DK-2200FTS
500×300×150
550×330×357
22
0~480
500
00:01-99:59
0-100
DK-3000FTS
500×300×200
550×330×407
30
0~600
500
00:01-99:59
0-100
