DNR 20/TCAL2405 User manual

DNR Wheels Pte Ltd
USER MANUAL
DELUXE SELF-PROPEL COMMODE
DELUXE SELF-PROPEL COMMODE
WARNING
•DNR Wheels Pte Ltd shall not be held liable for any damages, injuries or accidents
arising from misusing, mishandling and negligence.
•DNR personnel shall demonstrate the basic handling of the commode.
•The safety features for operating the commode must be strictly observed.
•Any defects must be reported immediately to DNR Wheels Pte Ltd.
•When transporting the commode, brakes should be in an unlocked position. The
castors are designed for use in an indoor environment and on even surface.
•Castors may be damaged when moving the commode along any rough & uneven
surface.
SAFETY INSTRUCTION
•Commode should not be use if found damaged as it may injure the user or caregiver.
•Caregiver should be familiar with the functionality of the commode.
•Commode must not be overloaded (Maximum load capacity: 100kg).
•Ensure all the castors and wheels are locked and leg rest is drawn back before
transferring the user in/ out of the equipment.

DNR Wheels Pte Ltd
USER MANUAL
DELUXE SELF-PROPEL COMMODE
•If the user is on the commode, castors and wheels must be locked. An unlocked
commode poses a risk of falling to the user.
•While using the commode, footrest should be drawn out and user’s feet are to be well
rested on footrest.
•Bucket can be removed by sliding out from rear end of the commode seat.
•Users with limited physical strength should be supervised or assisted while using
commode.
•Do not leave user with poor stability unattended on the commode.
CLEANING
•Use a cloth to wipe the commode dry after use.
•Dry out in the sun if possible.
•Clean out debris from the castors regularly for easy manoeuvring.
Technical Specifications
Seat Width:
43cm (17”)
Overall Width:
61.5cm (24.2”)
Seat Depth:
43cm (17”)
Overall Depth:
102cm (40.2”) (without
footrests)
109cm (43”) (with footrests)
Armrest to Armrest
Width:
45cm (17.7”)
Overall
Height:
94cm (37”)
Seat to Armrest
Height:
19cm (7.5”)
Seat Cushion
Opening:
Front Opening: 8cm (3.1”)
(W)
Middle Opening: 18cm (7”)
(W)
Depth:36cm (14.2”)
Seat to Backrest
Height:
38.5cm (15.2”)
Front Castors:
12.7x3cm (5”x1.18”)
Floor to Seat Height:
52cm (20.5”)
Rear Wheels:
24”
Footrest to Seat
Height:
40 –50cm (15.7”-19.7”)
Material:
Aluminium Grade 6000
Width between Rear
Castors:
34cm (13.4”)
Max Weight
Capacity:
100kg
Floor to Bucket Holder:
42cm (16.5”)
Product
Weight:
20kg

DNR Wheels Pte Ltd
USER MANUAL
DELUXE SELF-PROPEL COMMODE
Flip up the armrest
Flip up the footplate
Adjust the height of the footplate
1. Pull out the pin.
2. Adjust the footplate to desired height.

DNR Wheels Pte Ltd
USER MANUAL
DELUXE SELF-PROPEL COMMODE
Detaching the footrest
Put on and release the brake
Lock and unlock the castor
Pull backward to release the brake
Push forward to put on the brake
Castor is locked
Castor is unlocked
