DO HEATING Delta Manual

Fixing Instructions
Delta Radiator
Please unpack your delivery carefully and inspect the radiator
and contents – any damages or shortages must be notied to
your supplier within 3 days of delivery of your goods.

Specications
PLEASE NOTE: That in accordance with Part L1 2006 of the Building Regulations and BS7593:1992
code of practice for the treatment of hot water and central heating systems, we recommend
ushing the heating system before installation of new radiators and then adding the correct
quantity and type of inhibitor for use with the radiator and system to prevent corrosion. Damage
caused to systems not protected by a suitable inhibitor will not be covered by the manufacturer
warranty. It is the responsibility of the installer to ensure the correct use and suitability of the
xings provided. No liability for costs or damages arising from failure to do so can be accepted.
H
H
W
W
P/ V
P/ V P/ V
F/ R F/ R
P/ V
F/ R F/ R
VERTICAL
HORIZONTAL
Technical Information
Standard connections: ½”
F = Flow R = Return
P = Plug V = Vent
Pipe centres:
Vertical = radiator width + valves
Horizontal = radiator width - 50mm
Wall to front face = 60-70mm
Wall to pipe centre = 35-45mm
Technical Specications
Materials: Stainless Steel
Connections: ½” Flow and Return
Test pressure: 7 Bar
Testing authority: EN442
Max operation pressure: 4 Bar
Max working temperature: 95c
These can be cleaned using a soft
damp cloth with a non-abrasive
cleaning product.

Content list & Tools required
Contents list
Tools required
Review instructions carefully before installation.
Installation should be completed by a suitably qualied person.
Please dispose of packaging in a responsible manner.
Ref Icon Description Qty
A Decorative Cap 6
B Blind Plug 5
C Wall Mounting Screw 4
DWall Mounting Bracket 4
E Wall plug 4
F Setscrew 4
G Air Vent 1
H Diverter 1
Cross
Screwdriver
Spirit
Level
Steel Tape
Hammer
Step Ladder
(for high
products)
Allen Key
10mm
Masonry Bit
Electric Drill
& Cordless
Screwdriver
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationof yourradiatoras
desired,alignwith thegroundby using
aspiritlevel andmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyour radiatoronthe wall
and screw the mounting brackets all
thewayintothe wallwiththehelp of
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where the outletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheet byusi ng anAllenKey (M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews( F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsby usinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthe help
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall pl ug (x4)
Blind Plug (x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationof yourradiatoras
desired,alignwith thegroundby using
aspiritlevel andmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyour radiatoronthe wall
and screw the mounting brackets all
thewayintothe wallwiththehelp of
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where the outletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheet byusi ng anAllenKey (M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews( F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsby usinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthe help
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall pl ug (x4)
Blind Plug (x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationof yourradiatoras
desired,alignwith thegroundby using
aspiritlevel andmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyour radiatoronthe wall
and screw the mounting brackets all
thewayintothe wallwiththehelp of
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where the outletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheet byusi ng anAllenKey (M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews( F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsby usinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthe help
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall pl ug (x4)
Blind Plug (x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationof yourradiatoras
desired,alignwith thegroundby using
aspiritlevel andmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyour radiatoronthe wall
and screw the mounting brackets all
thewayintothe wallwiththehelp of
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where the outletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheet byusi ng anAllenKey (M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews( F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsby usinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthe help
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall pl ug (x4)
Blind Plug (x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationof yourradiatoras
desired,alignwith thegroundby using
aspiritlevel andmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyour radiatoronthe wall
and screw the mounting brackets all
thewayintothe wallwiththehelp of
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where the outletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheet byusi ng anAllenKey (M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews( F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsby usinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthe help
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall pl ug (x4)
Blind Plug (x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished pro ducts
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametricruler.
2- Setthelocationofyourradiatoras
desired,align withthe groundby using
aspiritlevelandmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screwcap holders (J).
2- Placeyour radiatoron thewall
and screw the mounting brackets all
thewayinto thewallwiththehelpof
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSS POINT
METRIC RULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where the outletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheet byusing an AllenKey (M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews (F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsby usinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) intothe spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytotheholeswiththe help
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall plug (x4)
Blind Plug(x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationof yourradiatoras
desired,alignwith thegroundby using
aspiritlevel andmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyour radiatoronthe wall
and screw the mounting brackets all
thewayintothe wallwiththehelp of
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where the outletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheet byusi ng anAllenKey (M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews( F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsby usinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthe help
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall pl ug (x4)
Blind Plug (x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationof yourradiatoras
desired,alignwith thegroundby using
aspiritlevel andmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyour radiatoronthe wall
and screw the mounting brackets all
thewayintothe wallwiththehelp of
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where the outletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheet byusi ng anAllenKey (M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews( F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsby usinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthe help
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall pl ug (x4)
Blind Plug (x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust theheight of your radiator by
using a metricruler.
2- Setthelocationofyourradiatoras
desired,alignwiththegroundbyusing
aspiritlevelandmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyourradiatoronthewall
and screw the mounting brackets all
thewayintothewallwiththehelpof
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where the outletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheetbyusing anAllenKey(M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews(F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyour radiator thentightenthe
setscrewsbyusinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) intothe spots
you have marked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holeswiththe help
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wallplug (x4)
Blind Plug(x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
A
D
B
E
G
C
F

User Manual
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY, AND RETAINED FOR FUTURE REFERENCE.
DO NOT CONNECT THE RADIATOR TO NETWORK BEFORE HAVING READ AND UNDERSTAND THE
FOLLOWING INSTRUCTIONS.
Radiator must be installed only by expert technicians and installation must be compliant with all applicable
rules, and national safety regulations and laws in force in the country where the product is installed.
CAUTION: Some parts of this product can become very hot and cause burns. Particular attention has to be
given where children and afflicted people are present.
During operation the radiator surface will get hot, however momentary contact with any part of it should not
cause any injury.
In case the radiator is used in a public place, a warning should be placed next to it advising the hot surface.
CARE AND MAINTENANCE
Radiators are designed to be used under below circumtances;
•Radiators are heavy items and should be securely fastened to the wall. In all cases, it is strongly
recommended that a suitably qualied professional carries out the installation. Specic care should be
taken into consideration, including the xing method used to secure the radiator to the wall, the type and the
condition of the wall itself, and any additional potential forces or weights, prior to nalising installation.
•The wall plugs supplied with your radiator may not be suitable for your wall type. The appropriate wall plugs
should be choosed by your installer.
• The product is reliable for maximum working pressure of 4 bar. DO NOT use the product above these
maximum pressure limits.
• Before installing the radiator, heating system should be properly ushed and lled in order to remove debris,
sludge and clean solid particles and chemical residues, which may cause corrosion and damage the system.
• When connecting pipes of various materials, their difference in electrode potential may cause galvanic
corrosion and serious damage of pipes, valves and other equipment in the system. To avoid galvanic
corrosion, it is highly recommended to use the same materials, or materials with similar electric potential,
throughout loop.
• When the air is trapped within the radiator, it may cause inefficient warming. Purge plug should be loosened
with a screwdriver to release the air. When the water starts to come out, the purge plug must be retightened.
CAUTION: To avoid overheating, do not cover the heating appliance.
CAUTION: Hot surface.

•Do not empty the water in your radiators throughout summer or during a renovation when they are not in
use for a long period. In this case turn of the inlet and outlet valves so that the water does not drain. If
radiators are left dry for a long time corrosion can occur.
•Ph of the water used in the systems shall be between 8,5 and 10,5.
• To clean the product, use a slightly wetted piece of cloth. DO NOT use harsh chemicals, cleaning solvents,
bleaches, strong detergents or especially those containing hydrochloric acid.
•Altough there is no direct contact, usage of cleaning solvents, chemicals (strong acids) or bleaches in the
same area with radiators may cause corrosion by the evaporation of these chemicals to air and condensation
back to radiator surface. This results in damaging the passive lm layer on stainless steel. Guarantee is not
valid for such cases.
•The water in the system should not contain substanc- es such as chlorine and halogen salts. Halogen salts
and chlorine can cause corrosion in your radiator.
•Many water conditioning materials contain chlorinated hydrocarbons. The use of chlorinated hydrocarbons
may harm to your radiator.
• Articially softened water shall not be used in the system.
• Water from a thermal source should not be used directly in the heating system as heat transfer uid.
• Radiators are designed to operate between 0 ° and 95 °. DO NOT use in open air environments.
•Radiators should be stored in dry, moisture-free, indoor and in chemical vapour free environments.
•Radiator and towel rack are for hanging and drying towel, do not use out of purpose. Do not hold onto,
get support or climb on it. Do not extend the usage area of the hanger with additional apparatus.
• Never wash the product with water. Clean only with a wetted piece of cloth.
• Do not remove or loosen the towel holder xing screws in products with towel holder.
GUARANTEE
•Guarantee conditions comply with the directive 1999/44/EC of the European Parliament and of the Council
of 25 May 1999 on certain aspects of the sale of consumer goods and associated guarantees.
• Guarantee conditions do not apply in below explained conditions:
- Non-compliance with the operating instructions given by the manufacturer in the ‘’care and maintenance’’
sections of this document during the use of the product,
- Modication or repair of the product by parties other than the manufacturer,
- Damaged caused intentionally, by negligence or by accident during transportation, installation or at any
stage of the product’s life cycle.
• Producer offers 5 years of guarantee for Carbon Steel radiators and 10 years of guarantee for Stainless Steel
radiators when they are installed in Closed Systems*.
• In Open Systems** while guarantee conditions do not apply to Carbon Steel radiators, Stainless Steel
radiators are under 5 years of producer guarantee.
•In Sanitary Hotwater Systems*** 2 years of producer guarantee is only valid for radiators which are produced
from 316 Grade (EN1.4401) Stainless Steel. Guarantee conditions apply neither to Carbon Steel nor to 304
Grade (EN1.4301) Stainless Steel radiators that are installed in Sanitary Hotwater System.
User Manual

* CLOSED HEATING SYSTEM: It is a system that water circulates in a closed loop water installation (including the
radiator and the towel heater) without exposure to the atmospheric effects.
** OPEN HEATING SYSTEM: It is a system that water circulates in the installation (including the radiator and the
towel heater) being exposed to atmospheric effects through open expansion tanks. Open expansion tanks are
used in order to balance the increasing pressure or to compensate the diminishing water in the heating system.
*** SANITARY HOT WATER SYSTEM: Domestic hot water is used for domestic purposes as well as heating the
radiators and towel warmers in an open circuit.
AFTER SALES SERVICES
If a manufacturing defect is observed within the warranty period, provided that it has been installed and
operated in accordance with these instructions, we undertake rst to repair the product. If the product can not
be repaired, we offer to exchange (we keep the right to modify, change, revise or cancel the products in our
range, so exchange is subjected to availability). If the product is no longer in our range, we offer a substitute
product.
If this product appears damaged when rst received or does not function correctly contact us by e-mail
[email protected]
To assist you, we will need the following information: model name & number (this can be found at the back of
the product) nature of the fault & date of purchase. Please retain your receipt as proof of purchase.
NOTES FOR DISPOSAL OF THIS PRODUCT VALID FOR THE EUROPEAN UNION
The crossed-out wheeled-bin symbol on your product reminds you that in the
European Union all electrical and electronic products and batteries must be
separately disposed at the end of their working life.
Do not dispose of these products as unsorted domestic waste. Return the products to
recycling to prevent possible harm to the environment or human health and to
promote the sustainable reuse of material resources. Recycling information is
available at the product retailer, local waste authorities or national organizations.
The producer is not liable for the misspellings and copying errors. The producer remains the right to make
changes in the product. This document can not be copied completely or partially without the written permission
of the producer.
For installation, please refer to the instruction manual which comes along with the product.
User Manual
23.10.2018 Rev:07
R.EYS.KK.00114
CAUTION: To avoid overheating,
do not cover the heating appliance.
USER MANUAL
for steel & stainless steel radiators
CAUTION: Hot surface.
• Radiators should be stored in dry, moisture-free,
indoor and in chemical vapour free environments.
• Radiator and towel rack are for hanging and drying
towel, do not use out of purpose. Do not hold onto,
get support or climb on it. Do not extend the usage
area of the hanger with additional apparatus.
• Never wash the product with water. Clean only with
a wetted piece of cloth.
• Do not remove or loosen the towel holder fixing
screws in products with towel holder.
effects through openexpansion tanks. Open expansion
tanks are used in order to balance the increasing
pressure or to compensate the diminishing water in
the heating system.
*** SANITARY HOT WATER SYSTEM: Domestic hot
water is used for domestic purposes as well as heating
the radiators and towel warmers in an open circuit.
AFTER SALES SERVICES
If a manufacturing defect is observed within the
warranty period, provided that it has been installed
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY,
AND RETAINED FOR FUTURE REFERENCE GUARANTEE
• Guarantee conditions comply with the directive
1999/44/EC of the European Parliament and of the
and operated in accordance with these instructions,
we undertake first to repair the product. If the
product can not be repaired, we offer to exchange
(we keep the right to modify, change, revise or cancel
the products in our range, so exchange is subjected
DO NOT CONNECT THE RADIATOR
TO NETWORK BEFORE HAVING READ
AND UNDERSTAND THE FOLLOWING
INSTRUCTIONS.
Radiator must be installed only by expert technicians
and installation must be compliant with all applicable
rules, and national safety regulations and laws in
force in the country where the product is installed.
CAUTION - Some parts of this product can become
very hot and cause burns. Particular attention has to be
given where children and afflicted people are present.
During operation the radiator surface will get hot,
however momentary contact with any part of it
should not cause any injury.
In case the radiator is used in a public place, a warning
should be placed next to it advising the hot surface.
CARE AND MAINTENANCE
Radiators are designed to be used under below
circumtances;
• Radiators are heavy items and should be securely
fastened to the wall. In all cases, it is strongly
recommended that a suitably qualified professional
carries out the installation. Specific care should be
taken into consideration, including the fixing method
used to secure the radiator to the wall, the type and
the condition of the wall itself, and any additional
potential forces or weights, prior to finalising installation.
• The wall plugs supplied with your radiator may not
be suitable for your wall type. The appropriate wall
plugs should be choosed by your installer.
• The product is reliable for maximum working
pressure of 4 bar. DO NOT use the product above
• When connecting pipes of various materials, their
difference in electrode potential may cause galvanic
corrosion and serious damage of pipes, valves and other
equipment in the system. To avoid galvanic corrosion, it
is highly recommended to use the same materials, or
materials with similar electric potential, throughout loop.
• When the air is trapped within the radiator, it may cause
inefficient warming. Purge plug should be loosened with
a screwdriver to release the air. When the water starts
to come out, the purge plug must be retightened.
• Do not empty the water in your radiators throughout
summer or during a renovation when they are not in
use for a long period. In this case turn of the inlet and
outlet valves so that the water does not drain. If
radiators are left dry for a long time corrosion can occur.
• Ph of the water used in the systems shall be
between 8,5 and 10,5.
• To clean the product, use a slightly wetted piece of
cloth. DO NOT use harsh chemicals, cleaning solvents,
bleaches, strong detergents or especially those
containing hydrochloric acid.
• Altough there is no direct contact, usage of cleaning
solvents, chemicals (strong acids) or bleaches in the same
area with radiators may cause corrosion by the evaporation
of these chemicals to air and condensation back to radiator
surface. This results in damaging the passive film layer on
stainless steel. Guarantee is not valid for such cases.
• The water in the system should not contain substanc-
es such as chlorine and halogen salts. Halogen salts
and chlorine can cause corrosion in your radiator.
• Many water conditioning materials contain chlorinated
hydrocarbons. The use of chlorinated hydrocarbons
may harm to your radiator.
• Artificially softened water shall not be used in the system.
Council of 25 May 1999 on certain aspects of the sale
of consumer goods and associated guarantees.
• Guarantee conditions do not apply in below
explained conditions:
- Non-compliance with the operating instructions given
by the manufacturer in the ‘’care and maintenance’’
sections of this document during the use of the product,
- Modification or repair of the product by parties
other than the manufacturer,
- Damaged caused intentionally, by negligence or by
accident during transportation, installation or at any
stage of the product’s life cycle.
• Producer offers5yearsofguaranteeforCarbonSteel
radiators and 10 years of guarantee for Stainless Steel
radiators when they are installed in Closed Systems*.
• In Open Systems** while guarantee conditions do
not apply to Carbon Steel radiators, Stainless Steel
radiators are under 5 years of producer guarantee.
• In Sanitary Hotwater Systems*** 2 years of producer
guarantee is only valid for radiators which are
produced from 316 Grade (EN1.4401) Stainless Steel.
Guarantee conditions apply neither to Carbon Steel
nor to 304 Grade (EN1.4301) Stainless Steel radiators
that are installed in Sanitary Hotwater System.
* CLOSED HEATING SYSTEM: It is a system that water
circulates in a closed loop water installation (including
the radiator and the towel heater) without exposure
to the atmosphericeffects.
** OPEN HEATING SYSTEM: It is a system that water
circulates in the installation (including the radiator
and the towel heater) being exposed to atmospheric
to availability). If the product is no longer in our range,
we offer a substitute product.
If this product appears damaged when first received
or does not function correctly contact us by e-mail
[e-mail]
To assist you, we will need the following information:
model name & number (this can be found at the back
of the product) nature of the fault & date of purchase.
Please retain your receipt as proof of purchase.
NOTES FOR DISPOSAL OF THIS PRODUCT VALID
FOR THE EUROPEAN UNION
The crossed-out wheeled-bin
symbol on your product reminds
you that in the European Union
all electrical and electronic
products and batteries must be
separately disposed at the end
of their working life.
Do not dispose of these
products as unsorted domestic
waste. Return the products to
recycling to prevent possible harm to the environment
or human health and to promote the sustainable
reuse of material resources. Recycling information is
available at the product retailer, local waste authorities
or national organizations.
The producer is not liable for the misspellings and
copying errors. The producer remains the right to
make changes in the product. This document can not
be copied completely or partially without the written
permission of the producer.
these maximum pressure limits.
• Before installing the radiator, heating system should
be properly flushed and filled in order to remove debris,
sludge and clean solid particles and chemical residues,
which may cause corrosion and damage the system.
• Water from a thermal source should not be used
directly in the heating system as heat transfer fluid.
• Radiators are designed to operate between 0 ° and
95 °. DO NOT use in open air environments.
For installation, please refer to the instruction manual which comes along with the product.
2
1

Installation Instructions
1. Adjust the height of your radiator by using
a metric ruler.
2. Set the location of your radiator as desired,
align with the ground by using a spirit level and
mark the position of the wall mounting brackets.
1. Place your radiator into the wall mounting
brackets (D).
2. Insert the setscrews (F) into the slots on the
mounting brackets (D), adjust the distance between
the wall and your radiator then tighten the
setscrews by using an Allen key (M3).
1. Insert the diverter into the tube where the outlet
valve is located then push until it reaches the metal
sheet inside the tube.
2. Screw the diverter onto the metal sheet by using
an Allen Key (M10).
1. Drill holes (Ø 10mm) into the spots you have marked.
2. Nail the wall plugs (E) in the holes by using a hammer.
3. Screw the wall mounting brackets all the way to the
holes with the help of a screwdriver.
A B
C D
IMPORTANT NOTE
• Place your radiator at least 12.5 cm above the oor.
•Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal uid to all treaded parts containing o-rings.
•Connect your radiator to the utilities after following all the installation steps in the manual.
•After connecting to the utilities, do not forget to discharge the trapped air inside the
radiator before commissioning.
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationofyourradiatoras
desired,alignwiththegroundbyusing
aspiritlevelandmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you havemarked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyourradiatoronthewall
and screw the mounting brackets all
thewayinto thewallwiththehelpof
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where theoutletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheetbyusing anAllen Key(M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews(F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsbyusinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you havemarked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthehelp
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall plug (x4)
Blind Plug(x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationofyourradiatoras
desired,alignwiththegroundbyusing
aspiritlevelandmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you havemarked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyourradiatoronthewall
and screw the mounting brackets all
thewayinto thewallwiththehelpof
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where theoutletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheetbyusing anAllen Key(M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews(F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsbyusinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you havemarked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthehelp
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall plug (x4)
Blind Plug(x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationofyourradiatoras
desired,alignwiththegroundbyusing
aspiritlevelandmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you havemarked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyourradiatoronthewall
and screw the mounting brackets all
thewayinto thewallwiththehelpof
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where theoutletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheetbyusing anAllen Key(M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews(F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsbyusinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you havemarked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthehelp
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall plug (x4)
Blind Plug(x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B
INSTALLATION GUIDE
E Installation information in this section
includes below products!
BIANCA,UNO,MALIBU
G CONTENT OF MOUNTING SET
J
INSTALLATION
1 2
1
2
1
3
2
4
1
Decorative Cap (x1) Blind Plug(x1) Wall Mounting
90°
C
Only for mirror finished products
I A B C
Screw (x12)
2
1
Wall Plug (x12) Air Vent (x1) Screw Cap
Holder (x12)
B
A
E G J
Screw cap (x12)
I
• Place your radiator at least 12.5 cm above the floor.
1- Adjust the height of your radiator by
using ametric ruler.
2- Setthelocationofyourradiatoras
desired,alignwiththegroundbyusing
aspiritlevelandmarkthepositionof
the wall mounting brackets.
1- Drill holes (Ø10 mm) into the spots
you havemarked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
1- Pass the wall mounting screws (C)
throughthe screw cap holders (J).
2- Placeyourradiatoronthewall
and screw the mounting brackets all
thewayinto thewallwiththehelpof
a screwdriver.
1- Attach the screw caps (I) to the
screw cap holders (J) on the wall
mounting brackets.
IMPORTANT NOTE
• Provide insulation by wrapping PTFE tape on the treads before installing the valves.
• Apply silicone seal fluid to all treaded parts containing o-rings.
• Connect your radiator to the utilities after following all the installation steps in the manual.
• After connecting to the utilities, do not forget to discharge the trapped air inside the radiator before commissioning.
05.10.2018 Rev:00
R.EYS.KK.00116
TOOLS REQUIRED FOR INSTALLATION
&
ELECTRIC DRILL &
DRILL BIT
SPIRIT LEVEL
SCREWDRIVER
CORDLESS
&
CROSSPOINT
METRICRULER HAMMER
(BIT PH2)
SCREWDRIVER
STEP LADDER ALLEN KEY
(FOR HIGH PRODUCTS)
H
G
1- Insert the diverter into the tube
where theoutletvalve is located
then push until it reaches the metal
sheet inside the tube.
2- Screw the diverter onto the metal
sheetbyusing anAllen Key(M10).
1- Place your radiator into the wall
mounting brackets (D).
2- Insertthe setscrews(F) into the
slots on the mounting brackets (D),
adjust the distance between the wall
andyourradiator thentightenthe
setscrewsbyusinganAllenkey
(M3).
3
1- Drill holes (Ø10 mm) into the spots
you havemarked.
2- Nail the wall plugs (E) in the holes
by using a hammer.
3- Screw the wall mounting brackets
allthe waytothe holes withthehelp
of a screwdriver.
1- Adjust the height of your radiator
by using a metric ruler.
2- Set the location of your radiator
as desired, align with the ground by
using a spirit level and mark the
position of the wall mounting
brackets.
Diverter (x1)
F
E
2
2
2
Wall Mounting
Screw (x4)
C
Setscrew (x4)
B
Wall plug (x4)
Blind Plug(x5)
Decorative Cap (x6)
Only for mirror finished products
A
Wall Mounting
Bracket (x4)
D
Air Vent (x1)
90°
1
CONTENT OF MOUNTING SET
1
4
3
2
1
2
2
1
1
INSTALLATION
Installation information in this section
includes below products!
ARES, NORTE, RAMSEY
G
E
D
F
C
A
B

Terms and Conditions
You must immediately remove all packaging, inspect the goods and notify us of any damage to the goods within
3 days of delivery. We shall have no obligation to replace or repair damaged goods in the event of failure by the
Buyer to comply with this provision. Radiators which are off an unacceptable standard or are damaged must not
be installed. If any items is installed it will be treated as being as accepted as received.
Damaged goods being returned will only be collected from your delivery address, unless otherwise agreed
in writing. Any other goods, which we accept back, are to be returned by you to our place of business at your
expense.
Items will be accepted as a return which have not been installed or damaged after delivery. We do not accept
liability for any damages sustained after delivery. Goods should be returned in their original packaging, provided
such packaging and goods are undamaged.
We may issue a credit note for goods which we accept as returned.
We may agree to provide you with replacement goods prior to collecting or receiving back the goods to be
returned (whether faulty, damaged or otherwise) but only on the condition that: the replacement goods are paid
for in full and we reserve the right to re-invoice you in the event that the returned goods are found to be in a
worse condition than when they were originally received by you or where such goods have not been received
back to us within 3 months of the replacement goods being received by yourselves. A re-stocking charge of
30% will be applied to all non-faulty stock items that wish to be returned. Special order and non-stock products
cannot be cancelled. Where cancellation or alteration of orders is accepted by us, you may be required to
pay a restocking charge, to cover administrative costs and collection costs (if applicable); such charges to be
determined by us. If the goods we deliver are faulty or damaged, we will meet the cost of the return, as long as
the fault is reported to us within 3 working days.
The goods will be deemed to have been accepted when they have been delivered and we may not accept claims
for any visible defects found after installation.
We accept no liability for any cost incurred relating to the cost of installation.
We shall not be liable for any plumber’s costs, decorator’s costs, transport costs, late penalties, or any other
costs, as a direct or indirect result of (i) any defect in the goods (including but not limited to any manufacturing
faults, such as leaks, that become apparent on or after installation) or (ii) late delivery of the goods.
GUARANTEES AND LIABILITIES – we are not the manufacturer of this product we will take all reasonable
endeavours to make over to you the benet of any warranty or guarantee given by the manufacturers. The item
must have been tted in accordance with British and or European standards as well as these tting instructions.
www.dqheating.com | [email protected] | 01842 810833
